Preface
Preface
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SC113M chassis. Installation
and maintenance should be performed by experienced technicians only.
Supermicro’s SC113M 1U chassis packages outstanding high-end performance
into an astonishingly short 20” deep chassis, featuring advanced air-ow/thermal
design for space-limited applications. With its short depth, it efciently packages
eight hot-swappable 2.5” SAS/SATA hard drive bays into a compact 1U form fac-
tor. This chassis features our advanced 330W (Gold Level), 400W, 560W or 563W
(Gold Level) high-efciency power supply.
This document lists compatible parts and congurations available when this docu-
ment was published. Always refer to our Web site for updates on supported parts
and congurations at http://www.supermicro.com.

SC113M Chassis Manual
iv
Manual Organization
Chapter 1: Introduction
The introduction provides a checklist of the main components included with this
chassis and describes the main features of the SC113M chassis. This chapter also
includes contact information.
Chapter 2: System Safety
This chapter lists warnings, precautions, and system safety. You should thoroughly
familiarize yourself with this chapter for a general overview of safety precautions
that should be followed before installing and servicing this chassis.
Chapter 3: Chassis Components
Refer here for details on this chassis model, including the fans, bays, airow shields,
and other components.
Chapter 4: System Interface
This chapter provides details on the system interface, which includes the functions
and information provided by the control panel on the chassis, as well as other LEDs
located throughout the system.
Chapter 5: Chassis Setup and Maintenance
Refer to this chapter for detailed information on this chassis. Follow the procedures
given in this chapter when installing, removing, or reconguring your chassis.
Chapter 6: Rack Installation
Refer to this chapter for detailed information on chassis rack installation. You should
follow the procedures given in this chapter when installing, removing or reconguring
your chassis into a rack environment.

v
Preface
Appendix A: Chassis Cables
This section references cables, which are compatible with your SC113M system. Re-
fer to our Web site for additional information on cabling at www.supermicro.com.
Appendix B: Power Supply
This chapter lists supported power supply information for the SC113M system. Refer
to our Web site for additional details at www.supermicro.com.
Appendix C: SAS-113TQ
Refer to this chapter for supported backplane information. Refer to the Supermicro
Web site at www.supermicro.com for the most up-to-date information.

SC113M Chassis Manual
vi
Table of Contents
Chapter 1 Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Shipping List.................................................................................................... 1-1
1-3 Contacting Supermicro.................................................................................... 1-2
1-4 Returning Merchandise for Service................................................................. 1-3
Chapter 2 System Safety
2-1 Overview ......................................................................................................... 2-1
2-2 Warnings and Precautions .............................................................................. 2-1
2-3 Preparing for Setup......................................................................................... 2-1
2-4 Electrical Safety Precautions .......................................................................... 2-2
2-5 General Safety Precautions ............................................................................ 2-3
2-6 System Safety ................................................................................................. 2-3
Chapter 3 Chassis Components
3-1 Overview ......................................................................................................... 3-1
3-2 Components .................................................................................................... 3-1
Chassis............................................................................................................ 3-1
Backplane........................................................................................................ 3-1
Fans ................................................................................................................ 3-1
Power Supply .................................................................................................. 3-2
Air Shroud ....................................................................................................... 3-2
3-3 Where to get Replacement Components........................................................ 3-2
Chapter 4 System Interface
4-1 Overview ......................................................................................................... 4-1
4-2 Control Panel Buttons ..................................................................................... 4-2
4-3 Control Panel LEDs ........................................................................................ 4-2
4-4 Drive Carrier LEDs.......................................................................................... 4-4
Chapter 5 Chassis Setup and Maintenance
5-1 Overview ......................................................................................................... 5-1
5-2 Installation ....................................................................................................... 5-1
5-3 Removing the Chassis Cover ......................................................................... 5-2
5-4 Installing Hard Drives...................................................................................... 5-3
5-5 Installing the DVD-ROM Drive ........................................................................ 5-5
5-6 Installing the Motherboard .............................................................................. 5-6
Permanent and Optional Standoffs................................................................. 5-7
5-7 Installing the Air Shroud.................................................................................. 5-8

vii
Preface
5-8 Checking the Airow ....................................................................................... 5-9
Installation Complete....................................................................................... 5-9
5-9 System Fans ................................................................................................. 5-10
5-10 Power Supply ............................................................................................... 5-12
5-11 Removing the Backplane .............................................................................. 5-14
5-12 Installing the Backplane ................................................................................ 5-15
Chapter 6 Rack Installation
6-1 Overview ......................................................................................................... 6-1
6-2 Unpacking the System .................................................................................... 6-1
6-3 Preparing for Setup......................................................................................... 6-1
Choosing a Setup Location............................................................................. 6-1
Rack Precautions ............................................................................................ 6-2
General Server Precautions............................................................................ 6-2
Rack Mounting Considerations ....................................................................... 6-3
Ambient Operating Temperature ................................................................ 6-3
Reduced Airow ......................................................................................... 6-3
Mechanical Loading ................................................................................... 6-3
Circuit Overloading..................................................................................... 6-3
Reliable Ground ......................................................................................... 6-3
Identifying the Sections of the Rack Rails...................................................... 6-4
Locking Tabs ................................................................................................... 6-4
Outer Rack Rails............................................................................................. 6-6
Appendix A SC113M Chassis Cables
Appendix B SC113M Power Supply Specications
Appendix C SAS-113TQ Backplane

SC113M Chassis Manual
viii
Notes

Model CPU HDD I/O Slots Power
Supply
SC113MTQ-563CB DP/UP 8x 2.5" hot-swap
SAS/SATA 1x FH 560W (Gold Level)
SC113MTQ-560CB DP/UP 8x 2.5" hot-swap
SAS/SATA 1x FH 560W
SC113MTQ-R400CB DP/UP 8x 2.5" hot-swap
SAS/SATA 1x FH 400W (Redundant)
SC113MTQ-330CB DP/UP 8x 2.5" hot-swap
SAS/SATA 1x FH 330W (Gold Level)
Chapter 1
Introduction
1-1 Overview
Supermicro’s SC113M 1U chassis featues eight hot-swappable 2.5” SAS/SATA
hard drive bays. Only enterprise level hard drives are recommended for use in
Supermicro chassis. The SC113M chassis includes one 330W (Gold Level), or a
560W (Gold Level) high-efciency power supply. The SC113MTQ-R400CB model
chassis has dual redundant 400W power supplies. One slim DVD-ROM drive is
included on the SC113MTQ-560CB model, and is optional on the other models.
1-2 Shipping List
Please visit the following link for the latest shipping lists and part numbers for your par-
ticular chassis model. http://www.supermicro.com/products/chassis/1U/?chs=113M
Chapter 1: Introduction
1-1

SC113M Chassis Manual
1-2
1-3 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacic
Address: Super Micro Computer, Inc.
4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei County
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone]

1-3
Chapter 1: Introduction
1-4 Returning Merchandise for Service
A receipt or copy of your invoice marked with the date of purchase is required be-
fore any warranty service will be rendered. You can obtain service by calling your
vendor for a Returned Merchandise Authorization (RMA) number. When returning to
the manufacturer, the RMA number should be prominently displayed on the outside
of the shipping carton, and mailed prepaid or hand-carried. Shipping and handling
charges will be applied for all orders that must be mailed when service is complete.
For faster service, RMA authorizations may be requested online (http://www.
supermicro.com/support/rma/).
Whenever possible, repack the chassis in the original Supermicro carton, using the
original packaging material. If these are no longer available, be sure to pack the
chassis securely, using packaging material to surround the chassis so that it does
not shift within the carton and become damaged during shipping.
This warranty only covers normal consumer use and does not cover damages in-
curred in shipping or from failure due to the alteration, misuse, abuse or improper
maintenance of products.
During the warranty period, contact your distributor rst for any product problems.

SC113M Chassis Manual
1-4
Notes

2-1
Chapter 2: System Safety
Chapter 2
System Safety
2-1 Overview
This chapter provides a quick setup checklist to get your chassis up and running.
Following the steps in the order provided should enable you to have your chassis up
and operational within a minimal amount of time. This quick setup assumes that you
are an experienced technician, familiar with common concepts and terminology.
2-2 Warnings and Precautions
You should inspect the box the chassis was shipped in and note if it was damaged
in any way. If the chassis itself shows damage, le a damage claim with carrier
who delivered your system.
Decide on a suitable location for the rack unit that will hold that chassis. It should
be situated in a clean, dust-free area that is well ventilated. Avoid areas where heat,
electrical noise and electromagnetic elds are generated.
You will also need it placed near at least one grounded power outlet. When cong-
ured, the SC113M chassis includes both a primary and a redundant power supply
which will require two grounded outlets.
2-3 Preparing for Setup
The SC113M chassis includes a set of rail assemblies, including mounting brackets
and mounting screws you will need to install the systems into the rack. Please read
this manual in its entirety before beginning the installation procedure.

SC113M Chassis Manual
2-2
2-4 Electrical Safety Precautions
Basic electrical safety precautions should be followed to protect yourself from harm
and the SC113M from damage:
•Be aware of the locations of the power on/off switch on the chassis as well
as the room’s emergency power-off switch, disconnection switch or electrical
outlet. If an electrical accident occurs, you can then quickly remove power from
the system.
•Do not work alone when working with high voltage components.
•Power should always be disconnected from the system when removing or in-
stalling main system components, such as the serverboard, memory modules
and the DVD-ROM and oppy drives (not necessary for hot-swappable drives).
When disconnecting power, you should rst power down the system with the
operating system and then unplug the power cords from all the power supply
modules in the system.
•When working around exposed electrical circuits, another person who is fa-
miliar with the power-off controls should be nearby to switch off the power, if
necessary.
•Use only one hand when working with powered-on electrical equipment. This
is to avoid making a complete circuit, which will cause electrical shock. Use
extreme caution when using metal tools, which can easily damage any electrical
components or circuit boards they come into contact with.
•Do not use mats designed to decrease electrostatic discharge as protection from
electrical shock. Instead, use rubber mats that have been specically designed
as electrical insulators.
•The power supply power cord must include a grounding plug and must be
plugged into grounded electrical outlets.
•Serverboard battery: CAUTION - There is a danger of explosion if the onboard
battery is installed upside down, which will reverse its polarities This battery
must be replaced only with the same or an equivalent type recommended by
the manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.

2-3
Chapter 2: System Safety
•Please handle used batteries carefully. Do not damage the battery in any way;
a damaged battery may release hazardous materials into the environment. Do
not discard a used battery in the garbage or a public landll. Please comply
with the regulations set up by your local hazardous waste management agency
to dispose of your used battery properly.
•DVD-ROM laser: CAUTION - This server may have come equipped with a
DVD-ROM drive. To prevent direct exposure to the laser beam and hazardous
radiation exposure, do not open the enclosure or use the unit in any uncon-
ventional way.
2-5 General Safety Precautions
•Keep the area around the chassis clean and free of clutter.
•Place the chassis top cover and any system components that have been re-
moved away from the system or on a table so that they won’t accidentally be
stepped on.
•While working on the system, do not wear loose clothing such as neckties and
unbuttoned shirt sleeves, which can come into contact with electrical circuits or
be pulled into a cooling fan.
•Remove any jewelry or metal objects from your body, which are excellent metal
conductors that can create short circuits and harm you if they come into contact
with printed circuit boards or areas where power is present.
•After accessing the inside of the system, close the system back up and secure
it to the rack unit with the retention screws after ensuring that all connections
have been made.
2-6 System Safety
Electrostatic discharge (ESD) is generated by two objects with different electrical
charges coming into contact with each other. An electrical discharge is created to
neutralize this difference, which can damage electronic components and printed
circuit boards. The following measures are generally sufcient to neutralize this
difference before contact is made to protect your equipment from ESD:
•Do not use mats designed to decrease electrostatic discharge as protection from
electrical shock. Instead, use rubber mats that have been specically designed
as electrical insulators.

SC113M Chassis Manual
2-4
•Use a grounded wrist strap designed to prevent static discharge.
•Keep all components and printed circuit boards (PCBs) in their antistatic bags
until ready for use.
•Touch a grounded metal object before removing any board from its antistatic
bag.
•Do not let components or PCBs come into contact with your clothing, which may
retain a charge even if you are wearing a wrist strap.
•Handle a board by its edges only; do not touch its components, peripheral chips,
memory modules or contacts.
•When handling chips or modules, avoid touching their pins.
•Put the serverboard and peripherals back into their antistatic bags when not
in use.
•For grounding purposes, make sure your computer chassis provides excellent
conductivity between the power supply, the case, the mounting fasteners and
the serverboard.

3-1
Chapter 3 Chassis Components
Chapter 3
Chassis Components
3-1 Overview
This chapter describes the most common components included with your chassis.
Some components listed may not be included or compatible with your particular
chassis model. For more information, see the installation instructions detailed later
in this manual.
3-2 Components
Chassis
The chassis includes eight 2.5" hard drive bays, and on the SC113MTQ-560CB , one
slim DVD-ROM drive. (On all other chassis models, the DVD-ROM is an optional
item). For the latest shipping lists, visit our Web site at: http://www.supermicro.com.
This chassis accepts a 1U backplane, four fans (with an optional fth fan) and one
or two power supplies. SC113M models come in black.
Backplane
Each SC113M chassis comes with a 1U SAS/SATA backplane. For more informa-
tion regarding compatible backplanes, view the appendices found at the end of
this manual. In addition, visit our Web site for the latest information: http://www.
supermicro.com.
Fans
The SC113M chassis accepts four system fans and provides space for two addi-
tional fans if required. System fans for the SC113M chassis are powered from the
serverboard. These fans are 1U high and are powered by 4-pin connectors.
Mounting Rails
The SC113M can be placed in a rack for secure storage and use. To set up your
rack, follow the step-by-step instructions included in this manual.

SC113M Chassis Manual
3-2
Power Supply
Each SC113M chassis model includes a high-efciency power supply rated at 330,
400 or 560 Watts. In the unlikely event your power supply fails, replacement is simple
and can be done without tools. The SC113MTQ-R400CB includes dual redundant
power supplied which may be replaced without powering-down the server.
Air Shroud
Air shrouds are shields, usually plastic, that channel air directly to where it is needed.
Always use the air shroud included with your chassis.
3-3 Where to get Replacement Components
Although not frequently, you may need replacement parts for your system. To
ensure the highest level of professional service and technical support, we strongly
recommend purchasing exclusively from our Supermicro Authorized Distributors/
System Integrators/Resellers. A list of Supermicro Authorized Distributors/System
Integrators/Reseller can be found at: http://www.supermicro.com. Click the Where
to Buy link.

4-1
Chapter 4: System Interface
Chapter 4
System Interface
4-1 Overview
There are several LEDs on the control panel as well as others on the drive carriers
to keep you constantly informed of the overall status of the system as well as the
activity and health of specic components. Most SC113M models have three push-
buttons on the control panel: a UID button, a reset button and an on/off switch. This
chapter covers these buttons, and explains the meanings of all LED indicators and
the appropriate responses you may need to take.
Figure 4-1: Chassis User Interface

SC113M Chassis Manual
4-2
•Power: The main power switch is used to apply or remove power from the
power supply to the server system. Turning off system power with this button
removes the main power but keeps standby power supplied to the system.
Therefore, you must unplug system before servicing.
4-3 Control Panel LEDs
The control panel located on the front of the SC113M chassis has ve LEDs.
These LEDs provide you with critical information related to different parts of the
system. This section explains what each LED indicates when illuminated and any
corrective action you may need to take.
•Reset: The reset button is used to reboot the system.
4-2 Control Panel Buttons
There are three push-buttons located on the front of the chassis. These are (in
order from left to right) a UID button, a reset button and a power on/off button.
•UID: Depressing the UID (unit identier) button illuminates an LED on both the
front and rear of the chassis for easy system location in large stack con gura-
tions. The LED will remain on until the button is pushed a second time. Another
UID button on the rear of the chassis serves the same function. This button
has an LED built into it, which will illuminate when either the front or rear UID
button is pushed.
