Supermicro Supero SC808T-980B User manual

SC808 Chassis Series
SUPER
USER’S MANUAL
1.0
SC808T-980V(B)

Chassis Manual
ii
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of
this manual, please see our web site at www.supermicro.com.
SUPERMICROCOMPUTER reserves the right to make changes to the product described in this
manual atany time and without notice. This product, including software,ifany, and documenta-
tion may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any
medium or machine without prior written consent.
IN NOEVENT WILL SUPERMICROCOMPUTER BE LIABLE FOR DIRECT, INDIRECT,SPECIAL,
INCIDENTAL,SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE
OR INABILITY TOUSE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR,THE VENDOR SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE,SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING
OR RECOVERING SUCH HARDWARE,SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California,USA. The State of California,County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all
claims will not exceed the price paid for the hardware product.
Manual Revision 1.0
Release Date: April 27, 2007
Unless you requestand receive written permission from SUPER MICROCOMPUTER, you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to hereinare trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2007 by SUPER MICROCOMPUTER INC.
All rights reserved.
Printed in the United States of America

iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SC808 1U chassis. Installa-
tion and maintenance should be performed by experienced technicians only.
Supermicro’s SC808 1U chassis features a unique and highly-optimized design
for dual-core Xeon platforms. The chassis is equipped with a 700W or 980Whigh
ef ciency power supply for superb power savings. High performance fans provide
ample optimized cooling for FB-DIMM memory modules and 4hot-swap drive bays
offers maximum storage capacity ina 1U form factor.
This document lists compatible parts available when this document was published.
Always refer to the our Web site for updates on supported parts and con gura-
tions.

Chassis Manual
iv
Notes

v
Preface
Manual Organization
Chapter 1: Introduction
The rstchapter provides a checklistof the maincomponents includedwith this
chassis and describes the mainfeatures of the SC808 chassis. This chapter also
includes contact information.
Chapter 2: System Safety
This chapter lists warnings,precautions,and systemsafety. You should thoroughly
familiarize yourself with this chapter for a generaloverviewof safety precautions
thatshould be followedbefore installing and servicing this chassis.
Chapter 3: Chassis Components
Refer here for details on this chassis modelincluding the fans,bays,airflow shields,
and other components.
Chapter 4: System Interface
Refer to this chapter for details on the systeminterface,which includes the functions
and information providedby the control panelon the chassis as well as other LEDs
locatedthroughout the system.
Chapter 5: Chassis Setup and Installation
Follow the procedures giveninthis chapter wheninstalling, removing, or
recon guring your chassis.
Chapter 6: Rack Installation
Refer to this chapter for detailedinformation on chassis rack installation. You should
follow the procedures giveninthis chapter wheninstalling, removing or recon guring
your chassis into a rack environment.

Chassis Manual
vi
Compatible Backplanes
This section lists compatible cables,power supply specications,and compatible
backplanes. Not all compatible backplanes are listed. Refer to our Website for the
latestcompatible backplane information.
Appendix A: Chassis Cables
Appendix C: Power Supply Specifications
Appendix C: SAS 808TQ Backplane Manual

vii
Preface
Table of Contents
Preface
About This Manual............................................................................................. iii
ManualOrganization ...........................................................................................v
Chapter 1: Introduction
1-1 Overview......................................................................................................... 1-1
1-2Shipping List.................................................................................................... 1-1
PartNumbers ............................................................................................. 1-1
1-3Contacting SuperMicro.................................................................................... 1-2
Chapter 2: System Safety
2-1 Overview......................................................................................................... 2-1
2-2Warnings and Precautions.............................................................................. 2-1
2-3Preparing for Setup......................................................................................... 2-1
2-4ElectricalSafety Precautions.......................................................................... 2-1
2-5GeneralSafety Precautions............................................................................ 2-2
2-6SystemSafety ................................................................................................. 2-3
Chapter 3: Chassis Components
3-1 Overview......................................................................................................... 3-1
3-2Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..................... 3-1
Chassis....................................................................................................... 3-1
Backplane................................................................................................... 3-1
Fans............................................................................................................ 3-1
Mounting Rails............................................................................................ 3-1
Power Supply ............................................................................................. 3-2
Air Shroud .................................................................................................. 3-2
3-3Where to getReplacement Components........................................................ 3-2
Chapter 4: System Interface
4-2Control PanelButtons..................................................................................... 4-2
4-3Control PanelLEDs........................................................................................ 4-2
4-4Drive Carrier LEDs.......................................................................................... 4-3
SAS/SATA Drives ....................................................................................... 4-3
SCSIDrives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...................... 4-4

Chassis Manual
viii
Chapter 5: Chassis Setup and Maintenance
5-1 Overview......................................................................................................... 5-1
5-2Installation Step1:Remove the Chassis Cover ............................................. 5-2
Toremove the chassis cover:.................................................................... 5-2
5-3Installation Step2: Install HardDrives ........................................................... 5-3
Toremove harddrive trays from the chassis............................................. 5-3
Toinstall a harddrive to the harddrive tray.............................................. 5-4
5-4Installation Step3: Installing the Motherboard............................................... 5-6
I/O Shield.................................................................................................... 5-6
Permanent and OptionalStandoffs................................................................. 5-6
Toinstall the motherboard:......................................................................... 5-7
Add-on Card/Expansion Slot Setup ................................................................ 5-8
Toinstall add-on cards:.............................................................................. 5-8
5-5Installation Step4: Installing the Air Shrouds............................................... 5-10
Air Shrouds................................................................................................... 5-10
Toinstall the air shroud:........................................................................... 5-10
5-6Installation Step5: Checking the Chassis the Air Flow.................................5-11
Tocheck the server's air flow:...................................................................5-11
Installation Complete......................................................................................5-11
5-7SystemFans................................................................................................. 5-12
Tochangea systemfan........................................................................... 5-12
5-8 Power Supply ............................................................................................... 5-14
Power Supply Replacement.......................................................................... 5-14
Tochange the power supply:................................................................... 5-15
Chapter 6: RackInstallation
6-1 Overview......................................................................................................... 6-1
6-2Unpacking the System.................................................................................... 6-1
6-3Preparing for Setup......................................................................................... 6-1
Choosing a Setup Location............................................................................. 6-1
Rack Precautions....................................................................................... 6-2
GeneralServer Precautions....................................................................... 6-2
Rack Mounting Considerations....................................................................... 6-2
Ambient Operating Temperature ................................................................ 6-2
ReducedAirflow ......................................................................................... 6-3
MechanicalLoading ................................................................................... 6-3
CircuitOverloading..................................................................................... 6-3
Reliable Ground ......................................................................................... 6-3
6-4Rack Mounting Instructions............................................................................. 6-4

ix
Preface
Identifying the Sections of the Rack Rails...................................................... 6-4
Installing the Inner RailExtension .................................................................. 6-5
Toinstall the inner rails:............................................................................. 6-5
Toinstall the outer rails to the rack:........................................................... 6-6
Toinstall the chassis into a rack:............................................................... 6-7
Appendices
Appendix A: Cables, Screws, and other Accessories
A-1 Overview.........................................................................................................A-1
A-2Cables Includedwith SC808TQChassis (SAS/SATA) ...................................A-1
A-4Compatible Cables..........................................................................................A-2
Alternate SAS/SATA Cables............................................................................A-2
Extending Power Cables.................................................................................A-3
Front Panelto the Motherboard......................................................................A-3
A-5Chassis Screws...............................................................................................A-4
Appendix B: SC808 Power Supply Specifications
AppendixC: SAS 808TQ BACKPLANE USER'S GUIDE

Chassis Manual
x
Notes

1-1
Chapter 1:Introduction
Chapter 1:
Introduction
1-1 Overview
Supermicro’s SC808 1U chassis features a unique and highly-optimizeddesign.
The chassis is equippedwith high ef ciency power supply. High performance fans
provide ample optimizedcooling for FB-DIMM memorymodules and 4hot-swap
drive bays offer maximum storage capacity ina 1U formfactor.
1-2 Shipping List
Part Numbers
Please visitthe following link for the latestshiping lists and partnumbers for your par-
ticular chassis modelhttp://www.supermicro.com/products/chassis/1U/?chs=808
1-1
SC808 Chassis
Model CPU HDD I/O Slots Power
Supply
SC808TQ-980B DP Dual-core
Xeon
4x SAS /
SATA 1xFF 980W

Chassis Manual
1-2
1-3 Contacting SuperMicro
Headquarters
Address:SuperMicroComputer,Inc.
980 Rock Ave.
SanJose,CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [e-mail] (GeneralInformation)
[e-mail] (TechnicalSupport)
WebSite:www.supermicro.com
Europe
Address:SuperMicroComputer B.V.
HetSterrenbeeld 28,5215ML
's-Hertogenbosch,The Netherlands
Tel: [phone]
Fax: [phone]
Email: [e-mail] (GeneralInformation)
[e-mail] (TechnicalSupport)
[e-mail] (Customer Support)
Asia-Pacific
Address:SuperMicro, Taiwan
4F,No. 232-1,Liancheng Rd.
Chung-Ho 235, Taipei County
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
WebSite:www.supermicro.com.tw
TechnicalSupport:
Email: [e-mail]
Tel: [phone],ext.132 or 139

2-1
Chapter 2: SystemSafety
Chapter 2:
System Safety
2-1 Overview
This chapter provides a quick setup checklistto getyour chassis up and running.
Following the steps inorder givenshould enable you to have your chassis setup and
operationalwithina minimalamount of time. This quick setup assumes thatyou
are anexperiencedtechnician, famailiar with common concepts and terminology.
2-2 Warnings and Precautions
You should inspect the boxthe chassis was shippedinand note ifitwas damaged
inany way. If the chassis itself shows damage,le a damage claimwith carrier
whodeliveredyour system.
Decide on a suitable location for the rack unitthatwill hold thatchassis. It should
be situatedina clean, dust-free area thatis well venilated. Avoidareas where heat,
electricalnoise and eletromagneticelds are generated.
You will alsoneeditplacednear atleastone groundedpower outlet. Whencon g-
ured, the SC808 chassis includes one power supply.
2-3 Preparingfor Setup
The SC808 Chassis includes a setof railassemblies,including mounting brackets
and mounting screws you will needto install the systems into the rack. Please read
this manualinits entirety before you beginthe installation procedure.
2-4 Electrical SafetyPrecautions
Basicelectricalsafety precautions should be followedto protect yourself from harm
and the SC808 from damage:
lBeaware of the locations of the power on/off switch on the chassis as well
as the room’s emergency power-off switch,disconnection switch or electri-

Chassis Manual
2-2
caloutlet. If anelectricalaccident occurs,you canthenquickly remove
power from the system.
lDo not workalone whenworking with high voltage components.
lPower should always be disconnectedfrom the systemwhenremoving or
installing mainsystemcomponents,such as the serverboard, memorymod-
ules and the DVD-ROM and floppy drives (not necessaryfor hot swappable
drives). Whendisconnecting power,you should rstpower down the
systemwith the operating systemand thenunplug the power cords from all
the power supply modules inthe system.
lWhenworking around exposedelectricalcircuits,another person whois fa-
miliar with the power-off controls should be nearby to switch off the power,
ifnecessary.
lUse only one hand whenworking with powered-on electricalequipment.
This is to avoidmaking a complete circuit, which will cause electricalshock.
Use extreme caution whenusing metaltools,which caneasily damage any
electricalcomponents or circuitboards theycome into contact with.
lDo not use mats designedto decrease electrostaticdischarge as protection
from electricalshock. Instead, use rubber mats thathave beenspecically
designedas electricalinsulators.
lThe power supply power cordmustinclude a grounding plug and mustbe
pluggedinto groundedelectricaloutlets.
lServerboardBattery: CAUTION - There is a danger of explosion ifthe
onboardbatteryis installedupside down, which will reverse its polarities
This batterymustbe replacedonly with the same or anequivalent type
recommendedby the manufacturer. Dispose of usedbatteries according to
the manufacturer’s instructions.
lDVD-ROM Laser:CAUTION - this server mayhave come equippedwith a
DVD-ROM drive. Toprevent direct exposure to the laser beamand hazard-
ous radiation exposure,do not openthe enclosure or use the unitinany
unconventionalway.
2-5 General SafetyPrecautions
lKeepthe area around the chassis cleanand free of clutter.

2-3
Chapter 2: SystemSafety
lPlace the chassis top cover and any systemcomponents thathave been
removedawayfrom the systemor on a table sothattheywon’taccidentally
be steppedon.
lWhile working on the system, do not wear loose clothing such as neckties
and unbuttonedshirtsleeves,which cancome into contact with electrical
circuits or be pulledinto a cooling fan.
lRemove any jewelryor metalobjects from your body, which are excellent
metalconductors thatcancreate shortcircuits and harmyou iftheycome
into contact with printedcircuitboards or areas where power is present.
lAfter accessing the inside of the system, close the systemback up and
secure itto the rack unitwith the retention screws after ensuring thatall
connections have beenmade.
2-6 System Safety
Electrostaticdischarge (ESD) is generatedby two objects with different electrical
charges coming into contact with each other. Anelectricaldischarge is createdto
neutralize this difference,which candamage electroniccomponents and printed
circuitboards. The following measures are generally suf cient to neutralize this
difference before contact is made to protect your equipment from ESD:
lDo not use mats designedto decrease electrostaticdischarge as protection
from electricalshock. Instead, use rubber mats thathave beenspecically
designedas electricalinsulators.
lUse a groundedwriststrapdesignedto prevent staticdischarge.
lKeepall components and printedcircuitboards (PCBs) intheir antistatic
bags untilready for use.
lTouch a groundedmetalobject before removing any boardfrom its anti-
staticbag.
lDo not letcomponents or PCBs come into contact with your clothing, which
mayretaina charge evenifyou are wearing a wriststrap.
lHandle a boardby its edges only;do not touch its components,peripheral
chips,memorymodules or contacts.
lWhenhandling chips or modules,avoidtouching their pins.

Chassis Manual
2-4
lPut the serverboardand peripherals back into their antistaticbags when
not inuse.
lFor grounding purposes,make sure your computer chassis provides excel-
lent conductivity betweenthe power supply, the case,the mounting fasten-
ers and the serverboard.

3-1
Chapter 3: Chassis Components
Chapter 3:
Chassis Components
3-1 Overview
This chapter describes the mostcommon components includedwith your chassis.
Some components listedmaynot be includedor compatible with your particular
chassis model. For more information, see the installation instructions detailedlater
inthis manual.
3-2 Components
Chassis
Chassis include four harddrive bays. Harddrives mustbe purchasedseparately.
For the latestshipping lists,visitour Website at: http://www.supermicro.com.
Backplane
Each SC808 chassis comes with a 1U backplane. For more information regarding
compatible backplanes,viewthe appendices found atthe end of this manual. In
addition, visitour Website for the latestinformation:http://www.supermicro.com.
Fans
The SC808 chassis accepts sixsystemfans . Systemfans for SC808 chassis are
poweredfrom the serverboard. These fans are 1U high and are poweredby 3-pin
connectors.
Mounting Rails
The SC808 canbe placedina rack for secure storage and use. Tosetup your
rack, follow the step-by-stepinstructions includedinthis manual.

Chassis Manual
3-2
Power Supply
Each SC808 chassis modelincludes a high-ef ciency power supply ratedat980
Watts. In the unlikely event your power supply fails,replacement is simple and
canbe done without tools.
Air Shroud
The SC808 chassis includes two mylar air shrouds thatfunnelair directly to where
itis needed.. Always use the air shroud includedwith your chassis.
3-3 Where to get Replacement Components
Though not frequently, you mayneedreplacement parts for your system. Toen-
sure the highestlevelof professionalservice and technicalsupport, we strongly
recommend purchasing exclusively from our SupermicroAuthorizedDistributors /
SystemIntegrators /Resellers. A listof SupermicroAuthorizedDistributors /Sys-
temIntegrators /Reseller canbe found at: http://www.supermicro.com. Click the
Where to Buy link.

4-1
Chapter 4: SystemInterface
Chapter 4:
System Interface
4-1 Overview
There are severalLEDs on the control paneland drive carriers to keepyoucon-
stantly informedof the overall status of the system. SC808 models include two
front panels thatcontrol two semi-independent systesm.
This chapter explains the meanings of all LEDindicators and the appropriate re-
sponse you mayneedto take.

Chassis Manual
4-2
4-2 Control Panel Buttons
There are two push-buttons locatedon the front of the chassis. These are (in
order from left to right) a resetbutton and a power on/off button.
l Reset:The resetbutton is usedto reboot the system.
l Power: The mainpower switch is usedto apply or remove power from
the power supply to the server system. Turning off systempower with this but-
ton removes the mainpower but keeps standbypower suppliedto the system.
Therefore,you mustunplug systembefore servicing.
4-3 Control Panel LEDs
The control panellocatedon the front of the SC808 chassis has ve LEDs. These
LEDs provide you with criticalinformation relatedto different parts of the system.
This section explains whateach LEDindicates whenilluminatedand any corrective
action you mayneedto take.
lOverheat/Fan Fail: Whenthis LEDflashes itindicates a fanfailure. When
continuously on (not flashing) itindicates anoverheatcondition, which maybe
causedby cables obstructing the airflow inthe systemor the ambient roomtem-
perature being too warm. Check the routing of the cables and make sure all fans
are present and operating normally. You shouldalsocheck to make sure thatthe
chassis covers are installed. Finally, verify thatthe heatsinks are installedproperly.
This LEDwill remainflashing or on as longas the temperature is too high or a fan
does not workcorrectly.
