Supermicro SC826E1-R800LP User manual

SC826 Chassis Series
SC826TQ-R800UB
SC826E1-R800UB SC826E2-R800UB
SC826TQ-R800LP SC826TQ-R800RC2
(OEM)
SC826E2-R800LP SC826E2-R800RC2
(OEM)
SC826E1-R800LP SC826E1-R800RC2
(OEM)
USER’S MANUAL
1.0c
SUPER
®

SC826 Chassis Manual
ii
Manual Revision 1.0c
Release Date: May 5, 2008
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software, if any,
and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or
reduced to any medium or machine without prior written consent.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for
all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2008 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

iii
Preface
Preface
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SC826 chassis. Installation
and maintenance should be performed by experienced technicians only.
Supermicro’s SC826 chassis features a unique design, which is highly optimized for
data storage applications. It is equipped with an 800W (redundant) high-efficiency
power supply for superb power savings. High-performance fans provide ample
cooling for the chassis.
This document lists compatible parts and configurations available when this docu-
ment was published. Always refer to our Web site for updates on supported parts
and configurations.

SC826 Chassis Manual
iv
Manual Organization
Chapter 1: Introduction
The introduction provides a checklist of the main components included with this
chassis and describes the main features of the SC826 chassis. This chapter also
includes contact information.
Chapter 2: System Safety
This chapter lists warnings, precautions, and system safety. You should thoroughly
familiarize yourself with this chapter for a general overview of safety precautions
that should be followed before installing and servicing this chassis.
Chapter 3: Chassis Components
Refer here for details on this chassis model including the fans, bays, airflow shields,
and other components.
Chapter 4: System Interface
Refer to this chapter for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
Chapter 5: Chassis Setup and Maintenance
Refer to this chapter for detailed information on this chassis. You should follow the
procedures given in this chapter when installing, removing, or reconfiguring your
chassis.
Chapter 6: Rack Installation
Refer to this chapter for detailed information on chassis rack installation. You should
follow the procedures given in this chapter when installing, removing or reconfiguring
your chassis into a rack environment.

v
Preface
Appendix A:
This section references cables, which are compatible with your SC826 system. Re-
fer to our Web site for additional information on cabling at www.supermicro.com.
Appendix B:
This chapter lists supported power supply information for your SC826 system. Refer
to our Web site for additional details at www.supermicro.com.
Appendix C:
This section provides detailed information on the BPN-SAS-826TQ backplane. Ad-
ditional information can by found on our Web site at www.supermicro.com
Appendix D:
This section provides detailed information on the BPN-SAS-826EL series back-
planes. Additional information can by found on our Web site at www.supermicro.
com

SC826 Chassis Manual
vi
Table of Contents
Chapter 1 Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Shipping List .................................................................................................... 1-1
1-3 Contacting Supermicro .................................................................................... 1-2
1-4 Returning Merchandise for Service ................................................................ 1-3
Chapter 2 System Safety
2-1 Overview ......................................................................................................... 2-1
2-2 Warnings and Precautions .............................................................................. 2-1
2-3 Preparing for Setup ......................................................................................... 2-1
2-4 Electrical Safety Precautions .......................................................................... 2-2
2-5 General Safety Precautions ............................................................................ 2-3
2-6 System Safety ................................................................................................. 2-3
Chapter 3 System Interface
3-1 Overview ......................................................................................................... 3-1
3-2 Control Panel Buttons ..................................................................................... 3-2
3-3 Control Panel LEDs ........................................................................................ 3-2
3-4 Drive Carrier LEDs .......................................................................................... 3-4
Chapter 4 Chassis Setup and Maintenance
4-1 Overview ......................................................................................................... 4-1
4-2 Installation Steps ............................................................................................. 4-1
4-3 Removing the Chassis Cover ......................................................................... 4-2
4-4 Installing Hard Drives ...................................................................................... 4-3
4-5 Installing the Motherboard .............................................................................. 4-6
Riser Card Bracket (OEM ONLY) ................................................................... 4-6
I/O Shield ........................................................................................................ 4-7
Permanent and Optional Standoffs ................................................................. 4-8
Installing the Motherboard .............................................................................. 4-9
Add-on Card Setup (SC826 RC chassis - OEM Only) ................................. 4-10
Add-on Card Setup (SC826 LP Chassis) ..................................................... 4-12
4-6 Installing the Air Shroud ................................................................................ 4-13
4-7 Checking the Air Flow ................................................................................... 4-14
Installation Complete ..................................................................................... 4-15
4-8 System Fans ................................................................................................. 4-16
4-9 Power Supply ............................................................................................... 4-18
4-10 Optional Front Bezel ..................................................................................... 4-20

vii
Preface
Chapter 5 Rack Installation
5-1 Overview ......................................................................................................... 5-1
5-2 Unpacking the System .................................................................................... 5-1
5-3 Preparing for Setup ......................................................................................... 5-1
Choosing a Setup Location ............................................................................. 5-1
Rack Precautions ............................................................................................ 5-2
General Server Precautions ............................................................................ 5-2
Rack Mounting Considerations ....................................................................... 5-3
Ambient Operating Temperature ................................................................ 5-3
Reduced Airflow ......................................................................................... 5-3
Mechanical Loading ................................................................................... 5-3
Circuit Overloading ..................................................................................... 5-3
Reliable Ground ......................................................................................... 5-3
Identifying the Sections of the Rack Rails ...................................................... 5-4
Locking Tabs ................................................................................................... 5-4
Outer Rack Rails ............................................................................................. 5-6
Appendix A SC826 Chassis Cables
Appendix B SC826 Power Supply Specifications
Appendix C BPN-SAS 826TQ Backplane Specifications
Appendix D BPN-SAS-826EL Backplane Specifications

Chapter 1
Introduction
Chapter 1: Introduction
1-1
Model CPU HDD I/O Slots Power
Supply
SC826TQ-R800UB DP Dual-core
Xeon
12x SAS / SATA
w/SES2 4 FF + 3 LP
800W
Redun-
dant
SC826E2-R800UB DP Dual-core
Xeon
12x SAS / SATA
w/SES2 4 FF + 3 LP
800W
Redun-
dant
SC826E1-R800UB DP Dual-core
Xeon
12x SAS / SATA
w/SES2 4 FF + 3 LP
800W
Redun-
dant
SC826TQ-R800LP DP Dual-core
Xeon
12x SAS / SATA
w/SES2 7x LP
800W
Redun-
dant
SC826E2-R800LP DP Dual-core
Xeon
12x SAS / SATA
w/SES2 7x LP
800W
Redun-
dant
SC826E1-R800LP DP Dual-core
Xeon
12x SAS / SATA
w/SES2 7x LP
800W
Redun-
dant
SC826TQ-R800RC2 DP Dual-core
Xeon
12x SAS / SATA
w/SES2 3 FF + 3 LP
800W
Redun-
dant
SC826E2-R800RC2 DP Dual-core
Xeon
12x SAS / SATA
w/SES2 3 FF + 3 LP 560W
SC826E1-R800RC2 DP Dual-core
Xeon
12x SAS / SATA
w/SES2 3 FF + 3 LP
800W
Redun-
dant
1-1 Overview
Supermicro’s SC826 2U chassis features a unique and highly-optimized design.
The chassis is equipped with high efficiency power supply.
1-2 Shipping List
Please visit the following link for the latest shipping lists and part numbers for
your particular chassis model http://www.supermicro.com/products/chassis/1U/
?chs=826

SC826 Chassis Manual
1-2
1-3 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address: Super Micro Computer, Inc.
4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei County
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone]

1-3
Chapter 1: Introduction
1-4 Returning Merchandise for Service
A receipt or copy of your invoice marked with the date of purchase is required be-
fore any warranty service will be rendered. You can obtain service by calling your
vendor for a Returned Merchandise Authorization (RMA) number. When returning
to the manufacturer, the RMA number should be prominently displayed on the
outside of the shipping carton, and mailed prepaid or hand-carried. Shipping and
handling charges will be applied for all orders that must be mailed when service
is complete.
For faster service, RMA authorizations may be requested online (http://www.
supermicro.com/support/rma/).
Whenever possible, repack the chassis in the original Supermicro carton, using the
original packaging material. If these are no longer available, be sure to pack the
chassis securely, using packaging material to surround the chassis so that it does
not shift within the carton and become damaged during shipping.
This warranty only covers normal consumer use and does not cover damages in-
curred in shipping or from failure due to the alteration, misuse, abuse or improper
maintenance of products.
During the warranty period, contact your distributor first for any product problems.

2-1
Chapter 2: System Safety
Chapter 2
System Safety
2-1 Overview
This chapter provides a quick setup checklist to get your chassis up and running.
Following the steps in order given should enable you to have your chassis setup and
operational within a minimal amount of time. This quick set up assumes that you are
an experienced technician, familiar with common concepts and terminology.
2-2 Warnings and Precautions
You should inspect the box the chassis was shipped in and note if it was damaged
in any way. If the chassis itself shows damage, file a damage claim with carrier
who delivered your system.
Decide on a suitable location for the rack unit that will hold that chassis. It should
be situated in a clean, dust-free area that is well ventilated. Avoid areas where heat,
electrical noise and electromagnetic fields are generated.
You will also need it placed near at least one grounded power outlet. When con-
figured, the SC826 chassis includes one power supply. "R" models (i.e. SC826S-
R700V Chassis) include a redundant power supply and require two grounded
outlets.
2-3 Preparing for Setup
The SC826 Chassis includes a set of rail assemblies, including mounting brackets
and mounting screws you will need to install the systems into the rack. Please read
this manual in its entirety before you begin the installation procedure.

SC826 Chassis Manual
2-2
2-4 Electrical Safety Precautions
Basic electrical safety precautions should be followed to protect yourself from harm
and the SC826 from damage:
Be aware of the locations of the power on/off switch on the chassis as well
as the room’s emergency power-off switch, disconnection switch or electrical
outlet. If an electrical accident occurs, you can then quickly remove power from
the system.
Do not work alone when working with high voltage components.
Power should always be disconnected from the system when removing or in-
stalling main system components, such as the serverboard, memory modules
and the DVD-ROM and floppy drives (not necessary for hot swappable drives).
When disconnecting power, you should first power down the system with the
operating system and then unplug the power cords from all the power supply
modules in the system.
When working around exposed electrical circuits, another person who is fa-
miliar with the power-off controls should be nearby to switch off the power, if
necessary.
Use only one hand when working with powered-on electrical equipment. This
is to avoid making a complete circuit, which will cause electrical shock. Use
extreme caution when using metal tools, which can easily damage any electrical
components or circuit boards they come into contact with.
Do not use mats designed to decrease electrostatic discharge as protection from
electrical shock. Instead, use rubber mats that have been specifically designed
as electrical insulators.
The power supply power cord must include a grounding plug and must be
plugged into grounded electrical outlets.
Serverboard Battery: CAUTION - There is a danger of explosion if the onboard
battery is installed upside down, which will reverse its polarities This battery
must be replaced only with the same or an equivalent type recommended by
the manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
•
•
•
•
•
•
•
•

2-3
Chapter 2: System Safety
DVD-ROM Laser: CAUTION - this server may have come equipped with a
DVD-ROM drive. To prevent direct exposure to the laser beam and hazardous
radiation exposure, do not open the enclosure or use the unit in any uncon-
ventional way.
2-5 General Safety Precautions
Keep the area around the chassis clean and free of clutter.
Place the chassis top cover and any system components that have been re-
moved away from the system or on a table so that they won’t accidentally be
stepped on.
While working on the system, do not wear loose clothing such as neckties and
unbuttoned shirt sleeves, which can come into contact with electrical circuits or
be pulled into a cooling fan.
Remove any jewelry or metal objects from your body, which are excellent metal
conductors that can create short circuits and harm you if they come into contact
with printed circuit boards or areas where power is present.
After accessing the inside of the system, close the system back up and secure
it to the rack unit with the retention screws after ensuring that all connections
have been made.
2-6 System Safety
Electrostatic discharge (ESD) is generated by two objects with different electrical
charges coming into contact with each other. An electrical discharge is created to
neutralize this difference, which can damage electronic components and printed
circuit boards. The following measures are generally sufficient to neutralize this
difference before contact is made to protect your equipment from ESD:
Do not use mats designed to decrease electrostatic discharge as protection from
electrical shock. Instead, use rubber mats that have been specifically designed
as electrical insulators.
Use a grounded wrist strap designed to prevent static discharge.
Keep all components and printed circuit boards (PCBs) in their antistatic bags
until ready for use.
•
•
•
•
•
•
•
•
•

SC826 Chassis Manual
2-4
Touch a grounded metal object before removing any board from its antistatic
bag.
Do not let components or PCBs come into contact with your clothing, which may
retain a charge even if you are wearing a wrist strap.
Handle a board by its edges only; do not touch its components, peripheral chips,
memory modules or contacts.
When handling chips or modules, avoid touching their pins.
Put the serverboard and peripherals back into their antistatic bags when not
in use.
For grounding purposes, make sure your computer chassis provides excellent
conductivity between the power supply, the case, the mounting fasteners and
the serverboard.
•
•
•
•
•
•

3-1
Chapter 3: System Interface
Chapter 3
System Interface
3-1 Overview
There are several LEDs on the control panel as well as others on the drive carriers
to keep you constantly informed of the overall status of the system as well as the
activity and health of specific components. Most SC826 models are two buttons
on the control panel: a reset button and an on/off switch. This chapter explains
the meanings of all LED indicators and the appropriate response you may need
to take.
Figure 3-1: Chassis User Interface

SC826 Chassis Manual
3-2
Power Failure: When this LED flashes, it indicates a power failure in the power
supply.
•
Overheat/Fan Fail: When this LED flashes it indicates a fan failure. When
continuously on (not flashing) it indicates an overheat condition, which may be
caused by cables obstructing the airflow in the system or the ambient room
temperature being too warm. Check the routing of the cables and make sure
all fans are present and operating normally. You should also check to make
•
3-3 Control Panel LEDs
The control panel located on the front of the SC826 chassis has five LEDs. These
LEDs provide you with critical information related to different parts of the system.
This section explains what each LED indicates when illuminated and any corrective
action you may need to take.
Power: The main power switch is used to apply or remove power from the
power supply to the server system. Turning off system power with this button
removes the main power but keeps standby power supplied to the system.
Therefore, you must unplug system before servicing.
•
Reset: The reset button is used to reboot the system.•
3-2 Control Panel Buttons
There are two push-buttons located on the front of the chassis. These are (in order
from left to right) a reset button and a power on/off button.
!

3-3
Chapter 3: System Interface
Power: Indicates power is being supplied to the system's power supply units.
This LED should normally be illuminated when the system is operating.
•
HDD: Indicates IDE channel activity. SAS/SATA drive and/or DVD-ROM drive
activity when flashing.
•
NIC1: Indicates network activity on GLAN1 when flashing.•
NIC2: Indicates network activity on GLAN2 when flashing.•
sure that the chassis covers are installed. Finally, verify that the heatsinks are

SC826 Chassis Manual
3-4
3-4 Drive Carrier LEDs
Your chassis uses SAS or SATA, but not both at the same time.
SAS/SATA Drives
Each SAS/SATA drive carrier has two LEDs.
Green: Each Serial ATA drive carrier has a green LED. When illuminated, this
green LED (on the front of the SATA drive carrier) indicates drive activity. A
connection to the SATA backplane enables this LED to blink on and off when
that particular drive is being accessed.
Red: The red LED indicates a SAS/SATA drive failure. If one of the SAS/SATA
drives fail, you should be notified by your system management software.
•
•

4-1
Chapter 4: Chassis Setup and Maintenance
Chapter 4
Chassis Setup and Maintenance
4-1 Overview
This chapter covers the steps required to install components and perform main-
tenance on the chassis. The only tool you will need to install components and
perform maintenance is a Phillips screwdriver, and under certain circumstances,
a hex wrench. Print this page to use as a reference while setting up your chassis.
4-2 Installation Steps
Removing the Chassis Cover 4-2
Installing Hard Drives 4-3
Installing the Motherboard 4-6
Installing the Air Shroud 4-13
Completing the Installation 4-15
Review the warnings and precautions listed in the manual be-
fore setting up or servicing this chassis. These include infor-
mation in Chapter 2: System Safety and the warning/precau-
tions listed in the setup instructions.
!

SC826 Chassis Manual
4-2
4-3 Removing the Chassis Cover
Removing the Chassis Cover the chassis cover:
Press the release tabs to remove the cover from the locked position. Press
both tabs at the same time.
Once the top cover is released from the locked position, slide the cover
toward the rear of the chassis.
Lift the cover off the chassis.
1.
2.
3.
Warning: Except for short periods of time, do NOT operate the
server without the cover in place. The chassis cover must be in
place to allow proper airflow and prevent overheating.
Figure 4-1: Removing the Chassis Cover
Release Tab
Remove this screw
!
1
2
1
3
