Supermicro BPN-SAS3-815TQ User manual

BPN-SAS3-815TQ BAckPlANe
USeR'S GUIDe
1.0
+5V
GNDGND+12V
2
IC
+5V +12V +5V +12V
#1
#2
#3 #0
ACT IN
ACT0 ACT1
JTAG UPGRADE JP29:9071 RST JP18:BUZZER RESET
ACT2 ACT3
SIDEBAND
M9
M15
JP10
D3
JP18
J8
J7
J6 J5
JP29
JP44
R144
MH2
M46
J9 J10 JP26
JP47
JP46
JP42
JP33
JP34
JP40 JP51
REV 1.00
SAS815TQ
S
UPER
R
JP50

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software, if any,
and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or
reduced to any medium or machine without prior written consent.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Manual Revision 1.0
Release Date: July 14, 2015 mk
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2015 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

iii
Contents
Contents
Contacting Supermicro.......................................................................................iv
Returning Merchandise for Service.....................................................................v
Chapter 1 Guidelines
1-1 ESD Safety Guidelines ................................................................................... 1-1
1-2 General Safety Guidelines .............................................................................. 1-1
1-3 Version Information ......................................................................................... 1-2
Chapter 2 Connectors, Jumpers and LEDs
2-1 Rear Connector Locations .............................................................................. 2-1
2-2 RearConnectorDenitions............................................................................. 2-2
2-3 RearJumpersandPinDenitions .................................................................. 2-4
Explanation of Jumpers .................................................................................. 2-4
I2C and SGPIO Modes and Jumper Settings ................................................. 2-5
2-4 Rear LED Indicators ...................................................................................... 2-6
2-5 Front Connectors and LED Indicators ............................................................ 2-7

BPN-SAS3-815TQ Backplane Manual
iv
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Web Site: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Email: [email protected]
Web Site: www.supermicro.com.tw

v
Contents
Returning Merchandise for Service
A receipt or copy of your invoice marked with the date of purchase is required before
any warranty service will be rendered. You can obtain service by calling your vendor
for a Returned Merchandise Authorization (RMA) number. When returning to the
manufacturer, the RMA number should be prominently displayed on the outside of
the shipping carton, and mailed prepaid or hand-carried. Shipping and handling
charges will be applied for all orders that must be mailed when service is complete.
For faster service, RMA authorizations may be requested online (http://www.
supermicro.com/support/rma/).
Whenever possible, repack the backplane in the original Supermicro box, using the
original packaging materials. If these are no longer available, be sure to pack the
backplane in an anti-static bag and inside the box. Make sure that there is enough
packaging material surrounding the backplane so that it does not become damaged
during shipping.
This warranty only covers normal consumer use and does not cover damages
incurred in shipping or from failure due to the alteration, misuse, abuse or improper
maintenance of products.
Duringthewarrantyperiod,contactyourdistributorrstforanyproductproblems.

BPN-SAS3-815TQ Backplane Manual
vi
Notes

1-1
Chapter 1 Guidelines
Chapter 1
Guidelines
This chapter offers guidelines for personal and equipment safety, and notes about
the BPN-SAS3-815TQ version documented in this manual.
1-1 ESD Safety Guidelines
Electrostatic Discharge (ESD) can damage electronic components. To prevent
damage to your system, it is important to handle it very carefully. The following
measuresaregenerallysufcienttoprotectyourequipmentfromESD.
• Use a grounded wrist strap designed to prevent static discharge.
• Touch a grounded metal object before removing a component from the antistatic
bag.
• Handle the backplane by its edges only; do not touch its components, peripheral
chips, memory modules or gold contacts.
• When handling chips or modules, avoid touching their pins.
• Put the card and peripherals back into their antistatic bags when not in use.
1-2 General Safety Guidelines
• Always disconnect power cables before installing or removing any components
from the computer, including the backplane.
• Disconnect the power cable before installing or removing any cables from the
backplane.
• Make sure that the backplane is securely and properly installed on the
motherboard to prevent damage to the system due to power shortage.

BPN-SAS3-815TQ Backplane Manual
1-2
1-3 Version Information
The BPN-SAS3-815TQ backplane has been designed to utilize the most up-to-date
technology available, providing your system with reliable, high-quality performance.
This manual reflects BPN-SAS3-815TQ, Revision 1.00, the most current
release available at the time of publication. Refer to the Supermicro Web site
at www.supermicro.com for the latest updates, compatible parts and supported
congurations.

2-1
Chapter 2 Connectors, Jumpers and LEDs
+5V
GNDGND+12V
2
IC
+5V +12V +5V +12V
#1
#2
#3 #0
ACT IN
ACT0 ACT1
JTAG UPGRADE JP29:9071 RST JP18:BUZZER RESET
ACT2 ACT3
SIDEBAND
M9
M15
JP10
D3
JP18
J8
J7
J6 J5
JP29
JP44
R144
MH2
M46
J9 J10 JP26
JP47
JP46
JP42
JP33
JP34
JP40 JP51
REV 1.00
SAS815TQ
S
UPER
R
JP50
+5V
GNDGND+12V
2
IC
+5V +12V +5V +12V
#1
#2
#3 #0
ACT IN
ACT0 ACT1
JTAG UPGRADE JP29:9071 RST JP18:BUZZER RESET
ACT2 ACT3
SIDEBAND
M9
M15
JP10
D3
JP18
J8
J7
J6 J5
JP29
JP44
R144
MH2
M46
J9 J10 JP26
JP47
JP46
JP42
JP33
JP34
JP40 JP51
REV 1.00
SAS815TQ
S
UPER
R
JP50
Chapter 2
Connectors, Jumpers and LEDs
This manual covers BPN-SAS3-815TQ enabling SAS3 drives with 12Gbps speeds.
2-1 Rear Connector Locations
The following connectors are on the side of the backplane that faces the rear of the
chassis. They are marked by silkscreen labels.
1. Main Power: JP10 (4 pin)
2. Peripheral power: J9 and J10
(4 pin)
3. JTAG JP47 (10 pin)
4. Upgrade: JP46 (6 pin)
5. MG9071 Chip
6. Sideband JP51 (10 pin)
7. I2C Connector JP44 (4 pin)
8. ACT_IN JP26 (10 pin)
9. SAS Port #0 J5
10. SAS Port #1 J6
11. SAS Port #2 J7
12. SAS Port #3 J8
1
3
1
4
1
1
1
5
1
6
1
8
1
7
1
2
1
9
1
11 1 10
Figure 2-1. Rear Connectors
1
2
12

BPN-SAS3-815TQ Backplane Manual
2-2
2-2 RearConnectorDenitions
3, 4. JTAG Connector and Upgrade Connector
The JTAG connector, designated JP47, and the upgrade connector, designated
JP46, are for diagnostic purposes. These connectors should be used by a
certiedandexperiencedtechnician.
5. MG9071 Chip
The MG9071 is an enclosure management chip that supports the SES-2
controller and SES-2 protocols.
Main Power
(JP10)
Pin#Denition
1+12V
2 and 3 Ground
4 +5V
1. Backplane Main Power Connectors
The 4-pin connectors, designated JP10
provide power to the backplane.
2. Peripheral Drive 4-Pin Connectors
The 4-pin connectors, designated J9
and J10, provide power to DVD or other
peripheral drives.
Peripheral Drive Power
(J9 and J10)
Pin#Denition
1 +5V
2 and 3 Ground
4 +12V
6. Sideband Headers
The sideband header is designated JP51.
For SES-2 to work properly, you must
connect an 8-pin sideband cable.
Sideband Header
(JP51)
Pin#Denition Pin#Denition
2 Backplane
Addressing
(SB5)
1 Controller
ID (SB6)
4 Reset (SB4) 3 GND (SB2)
6 GND (SB3) 5 SDA (SB1)
8 Backplane
ID (SB7)
7 SCL (SB0)
10 No Connec-
tion
9 No Connec-
tion

2-3
Chapter 2 Connectors, Jumpers and LEDs
7. I2C Connectors
The I2C Connectors, designated JP44, are
used to monitor HDD activity and status.
I2C Connector
(JP44)
Pin#Denition
1 Data
2 Ground
3 Clock
4 No Connection
SAS Activity LED Header
(JP26)
Pin#Denition Pin#Denition
1ACT IN#0 6ACT IN#4
2ACT IN#1 7ACT IN#5
3ACT IN#2 8ACT IN#6
4ACT IN#3 9ACT IN#7
5Ground 10 Empty
8. Activity LED Header
The Activity LED header, designated JP26,
is used to indicate the activity status of
each SAS drive. To enable, connect using
a 10-pin LED cable.
9-12. SAS Ports
The SAS ports are used to connect cables to SAS3 drives, enabling 12Gbps
speeds. The four ports are designated #0 - #4. Each port is also compatible
with SATA drives.

BPN-SAS3-815TQ Backplane Manual
2-4
2-3 RearJumpersandPinDenitions
Explanation of Jumpers
To modify the operation of the backplane,
jumpers can be used to choose between
optional settings. Jumpers create shorts
between two pins to change the function
of the connector. Pin 1 is identied with
a square solder pad on the printed circuit
board. Note: On two pin jumpers, "Closed"
means the jumper is on and "Open" means
the jumper is off the pins.
Connector
Pins
Jumper
Setting
3 2 1
3 2 1
Figure 2-2. Rear Jumpers
JP29
+5V
GNDGND+12V
2
IC
+5V +12V +5V +12V
#1
#2
#3 #0
ACT IN
ACT0 ACT1
JTAG UPGRADE JP29:9071 RST JP18:BUZZER RESET
ACT2 ACT3
SIDEBAND
M9
M15
JP10
D3
JP18
J8
J7
J6 J5
JP29
JP44
R144
MH2
M46
J9 J10 JP26
JP47
JP46
JP42
JP33
JP34
JP40 JP51
REV 1.00
SAS815TQ
S
UPER
R
JP50
JP18
+5V
GNDGND+12V
2
IC
+5V +12V +5V +12V
#1
#2
#3 #0
ACT IN
ACT0 ACT1
JTAG UPGRADE JP29:9071 RST JP18:BUZZER RESET
ACT2 ACT3
SIDEBAND
M9
M15
JP10
D3
JP18
J8
J7
J6 J5
JP29
JP44
R144
MH2
M46
J9 J10 JP26
JP47
JP46
JP42
JP33
JP34
JP40 JP51
REV 1.00
SAS815TQ
SUPER
R
JP50
JP33
JP34
JP40
General Jumpers
Jumper Settings Description
JP18 Open: Enabled
Closed: Disabled
Buzzer Reset
JP29 Open: Default
Closed: Reset
MG 9071 Chip Reset
JP42
JP50

2-5
Chapter 2 Connectors, Jumpers and LEDs
I2C and SGPIO Modes and Jumper Settings
This backplane can utilize I2C or SGPIO. SGPIO is the default mode and can be
used without making changes to your jumpers. Use the following settings for I2C
mode.
I2C Jumpers
Jumper Setting Description
JP33 2-3 Controller ID
JP34 1-2:ID#0 Backplane ID
JP40 Open I2C Reset SD OUT
JP42 2-3 Backplane ID SDIN
JP50 Closed I2C Reset
SGPIO Jumpers (Default)
Jumper Setting Description
JP33 1-2 Controller ID
JP34 1-2:ID#0 Backplane ID
JP40 Closed I2C Reset SD OUT
JP42 1-2 Backplane ID SDIN
JP50 Open I2C Reset

BPN-SAS3-815TQ Backplane Manual
2-6
2-4 Rear LED Indicators
Figure 2-3. Rear LEDs
+5V
GNDGND+12V
2
IC
+5V +12V +5V +12V
#1
#2
#3 #0
ACT IN
ACT0 ACT1
JTAG UPGRADE JP29:9071 RST JP18:BUZZER RESET
ACT2 ACT3
SIDEBAND
M9
M15
JP10
D3
JP18
J8
J7
J6 J5
JP29
JP44
R144
MH2
M46
J9 J10 JP26
JP47
JP46
JP42
JP33
JP34
JP40 JP51
REV 1.00
SAS815TQ
S
UPER
R
JP50
+5V
GNDGND+12V
2
IC
+5V +12V +5V +12V
#1
#2
#3 #0
ACT IN
ACT0 ACT1
JTAG UPGRADE JP29:9071 RST JP18:BUZZER RESET
ACT2 ACT3
SIDEBAND
M9
M15
JP10
D3
JP18
J8
J7
J6 J5
JP29
JP44
R144
MH2
M46
J9 J10 JP26
JP47
JP46
JP42
JP33
JP34
JP40 JP51
REV 1.00
SAS815TQ
SUPER
R
JP50
Overheat
or Drive
Failure LED
Rear LEDs
LED State Specication
D3 On Overheat or Drive Failure

2-7
Chapter 2 Connectors, Jumpers and LEDs
SAS
#3
SAS
#2
SAS
#1#0
SAS
M9
M15
D5
D6
D7
D8
D12
D13
D14
J1 J2 J3 J4
R82
MH2
M46
D15
Figure 2-4. Front Connectors
2-5 Front Connectors and LED Indicators
The front of the backplane has four sockets to connect disk drives, along with
LEDs indicators.
D12
D5
SAS #0
D13
D6
SAS #1 SAS #2 SAS #3
D14
D7 D15 D8
Front SAS/SATA Connectors and LED Indicators
Drive Number Label
HDD Activity LED
(blue)
Failure LED
(red)
SAS #0 J1 D12 D5
SAS #1 J2 D13 D6
SAS #2 J3 D14 D7
SAS #3 J4 D15 D8

BPN-SAS3-815TQ Backplane Manual
2-8
Disclaimer (cont.)
The products sold by Supermicro are not intended for and will not be used in life support systems,
medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency
communication devices or other critical systems whose failure to perform be reasonably expected
toresultinsignicantinjuryorlossoflifeorcatastrophicpropertydamage.Accordingly,Supermicro
disclaims any and all liability, and should buyer use or sell such products for use in such ultra-
hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully
indemnify, defend and hold Supermicro harmless for and against any and all claims, demands,
actions, litigation, and proceedings of any kind arising out of or related to such ultra-hazardous
use or sale.
