Introduction
This is the Supra TRAC-Lock BT Installation
Instructions. Read these instructions and the lockset
installation instructions before installing TRAC-Lock BT.
If you do not mount the TRAC-Lock BT accurately, it
will not function properly. Supra will not be responsible
for replacing the TRAC-Lock BT if it is damaged or
destroyed upon removal.
Installation supplies provided
• Installation instructions
• Drill template
• Electronics enclosure with lid
• Mounting plate (interior)
• Exterior TRAC-Lock BT plate
• Three 9-volt batteries
• Twosetsoffour#8atheadscrews(Two
different screw lengths for the mounting plate)
• Last battery change sticker
• Oneelectriedlockset(nolockcore)
• Four #8 × 5/16 in. (8mm) pan head screws and
lock washers (for electronics enclosure)
• Six#4×1/2in.(13mm)atheadscrews
• Plastic weather cover assembly
CAUTION: The electronics in this package are
electrostatic sensitive devices. Before you install
the unit, discharge or use a grounding belt.
Installation tools required
• Drill
• Drill bits
• File
• Phillips screwdriver
• Level or punch
• Pen or pencil
P/N10103023P1RevB•January2012
© 2011 UTC Fire & Security. All rights reserved.
TRAC-Lock BT
Installation Instructions
Hardware not provided
When a lockset is provided with the TRAC-Lock BT,
the lockset will not include a lock core. If you install the
TRAC-Lock BT into a door that has a noncylindrical lock
(for example, a mortise lock), you will need additional
hardware. Consult a locksmith for the parts you need for
the conversion.
Figure 1. Standard TRAC-Lock BT installation
Installation notes
The TRAC-Lock BT is designed to be installed above,
below, or to the side of the lockset (Figure 1). We
recommend 6 in. (15 cm) above the lockset, or as far
above the lockset as needed to be out of the way of door
hardware. To meet ADA requirements, the lockset must
be no higher than 48 in. (120 cm) from the ground to
center of the device.
If you install the TRAC-Lock BT in a wood door, align it
horizontally with the lockset and latch (Figure 2). When
drilling, drill the latch set hole through the backset hole
and into the door. You will use this hole to thread the
wiring from the lockset to the TRAC-Lock BT. Align the
TRAC-Lock drill template (PN: 43336) so that the 5/8
in. (16 mm) wire feed hole intersects with the horizontal
hole. Use this channel to feed the wire from the lockset
to the TRAC-Lock BT. When you install the lockset, allow
room for expansion in hot weather.

Installation
To install the TRAC-Lock BT:
1. Remove the lid from the electronics enclosure and
unplug the four-prong connector.
2. Using the drill template, mark the four mounting
holes and the one center wire feed hole on the
exterior side of the door. Drill the four mounting
holes 9/16 in. (14 mm) and the center wire feed hole
5/8 in. (16 mm) through the door.
Note: If you are drilling a metal door, be sure to
letheroughedgesofthedrillholesorusea
countersink drill.
3. Install the new lockset using the instructions
provided by the manufacturer. Thread the two-wire
plug from the lockset, through the door and through
the interior 5/8 in. (16 mm) wire feed hole.
4. Feed the four-wire plug from the exterior TRAC-Lock
BT plate through the 5/8 in. (16 mm) hole drilled in
the door and secure the interior mounting plate to
the exterior TRAC-Lock BT plate (Figure 3).
Note: The white ferrite snap bead is not required
for TRAC-Lock. Installer may discard. Also,
Common Wire from Bezel is not required.
Installer may remove or leave in bezel.
5. Insert and tighten screws through interior plate. For
1-1/4 to 1-1/2 in. (32 to 38 mm) doors, use 3/4 in.
(19 mm) screws. For 1-1/2 to 2 in. (32 to 51 mm),
use 1-1/4 in. (38 mm) screws.
Note: If the screw does not fully secure the plates
to the door when tightened, use a shorter screw.
Do not overtighten the long screw.
6. Thread the four-wire plug from the exterior TRAC-
Lock BT plate, and the two-wire plug from the
lockset through the wire feed hole in the electronics
enclosure. You will attach the wires after securing
the enclosure.
7. Use the four #8 × 5/16 in. (8 mm) pan head screws
and lock washers to attach the electronics enclosure
to the interior mounting plate. Insert and tighten the
screws and lock washers securely.
8. Attach the two-wire plug to the two prong connector.
Attach the four-wire plug to the four-wire connector.
9. Insert and connect the three 9-volt batteries to the
battery terminal connectors. Secure the batteries in
the battery holder compartment and make sure the
wires point toward you as you secure them in place.
(Battery connectors should point toward the circuit
board).
10. Perform an Install function with a valid TRACcess
eKEY. Refer to the TRACcess eKEY user
instructions for step by step operation.
11. Test the lock operation using the TRACcess eKEY.
Refer to the TRACcess eKEY user instructions for
stepbystepoperation.Testthelockrstwiththe
door open and then with the door shut to ensure the
lock strike catches the door frame.
12. Once you have tested the lock, place the lid on
the back of the electronics enclosure and position
the logo directly over the battery pack. Insert the
Figure 3. TRAC-Lock BT assembly
Figure 2. TRAC-Lock BT wood door installation
Electronics
Enclosure
Exterior
TRAC-Lock
BT Plate
Interior
Mounting
Plate
Electronics
Enclosure Lid
Lockset
2-wire plug
4-wire plug

providedsix#4×1/2in.(13mm)atheadscrews
into the predrilled holes. Hand-tighten the upper
right corner screw and continue hand-tightening
the remaining screws in a clockwise order. Do not
overtighten the screws, as doing so may damage the
electronics enclosure and prevent the lid from being
securely fastened.
13. Install the plastic weather cover.
14. Record the TRAC-Lock BT serial number and
installation location.
Battery removal/disposal
This product contains three 9-volt batteries. To remove
the batteries:
1. Remove the lid from the electronics enclosure.
2. Pull the batteries out of the slots.
For proper recycling, dispose of all batteries as required
by local ordinances or regulations.
Supra:800-547-0252•www.suprasystems.com
FCC
The device, Assy, Bezel, WTI, part number
10102917G1, complies with part 15 of the FCC rules.
Operation is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
Changesormodicationsnotexpresslyapprovedbythe
party responsible for compliance could void the user’s
authority to operate the equipment.
2002/96/EC (WEEE directive). Products marked with
this symbol cannot be disposed of as unsorted municipal
waste in the European Union. For proper recycling,
return this product to your local supplier upon the
purchase of equivalent new equipment, or dispose of it
at designated collection points.
