Surefire Sonic Defenders Ultra EP7-SPR User manual

SONIC DEFENDERS® ULTRA
Filtered, Foam-Tipped Earplugs with 28 dB NRR
HEARING PROTECTION
ALL-DAY PROTECTION & COMFORT. EVERYDAY APPLICATIONS.
EP7

LOUD NOISE SPEECH-LEVEL SOUND
enters ear canal; foam-tipped
stem provides all-day comfort
DANGEROUS NOISE
is reduced to safer levels
NOISE-REDUCING FILTER
lowers dangerous sound levels
while allowing ambient sound
and conversation to be heard
SureFire®EP7 Sonic Defenders®Ultra
feature replaceable memory-foam Comply™ Canal Tips for
a high level of comfort and hearing protection. They protect
your hearing from dangerous noise levels—including
sudden impulse noise like gunshots—without interfering
with your ability to hear safe ambient sounds. So you enjoy
effective hearing protection while maintaining situational
awareness and the ability to hear important conversations
or commands.
EP7 SONIC DEFENDERS ULTRA FEATURES
∞Two levels of protection with lter caps in or out—the louder
the noise, the more the protection
∞Patented EarLock®rings provide unparalleled retention
∞Replaceable memory-foam Comply™ Canal Tips provide
comfort & secure seal
∞Hypoallergenic soft-polymer construction provides all-day
comfort & durability
∞Can be used as an earpiece for compatible radio
communication systems
NOISE-REDUCING FILTERS
Filtered Sonic Defenders use established, non-electronic technology
to reduce dangerous noise while allowing the hearing of safe-level
conversations, commands, and ambient sounds.
1 Loud, potentially harmful sound waves enter the filter.
2
Sound waves above 85dB hit the ridges inside the filter.
3
These sound waves reflect off the ridges of the
narrowing walls and cancel themselves out.
4
Dangerous sound levels are reduced, and safe levels
pass through.
5
The louder the sound, the more noise gets canceled.
www.surefire.com/earproproducts
PATENTED EARLOCK®RETENTION RINGS
SureFire Sonic Defenders feature our innovative EarLock outer rings,
which lock the earplugs in place with seven unique grab points. A low-
profile design allows for easy wearing under a hat, helmet, mask, headset,
or supplemental muffs—even while using the phone.
All SureFire earplugs and earpieces feature
seven unique grab points.
HELIX LOCK
(Under Ridge)
TOP OF CYMBA
CONCHA LOCK
(Under Ridge)
ANTI-TRAGUS LOCK
(Under Ridge)
BACK RIDGE
OF CONCHA
BOWL LOCK
TOP CRUS OF
HELIX LOCK
BOTTOM CRUS
OF HELIX LOCK
TRAGUS LOCK
(Under Ridge)
1 5
6
7
2
3
4
HEARING PROTECTION
SAFE SOUNDHARMFUL NOISE
FILTER CAP
can be inserted to block ambient
sound & conversation

PROTECTS AGAINST TWO TYPES OF NOISE...
132 dB Overall Average PIL
150 dB Overall Average PIL
168 dB Overall Average PIL
24.5
29.3
32.1
Average Peak Impulse Level dB Reduction
132 dB Overall Average PIL
150 dB Overall Average PIL
168 dB Overall Average PIL
41.8
45.3
44.9
Average Peak Impulse Level dB Reduction
132 dB Overall Average PIL
150 dB Overall Average PIL
168 dB Overall Average PIL
24.5
29.3
32.1
Average Peak Impulse Level dB Reduction
132 dB Overall Average PIL
150 dB Overall Average PIL
168 dB Overall Average PIL
41.8
45.3
44.9
Average Peak Impulse Level dB Reduction
IMPULSE NOISE DATA
NOISE REDUCTION RATING (NRR)
www.surefire.com/earproproducts
14
NRR
Test Frequencies (Hz)
Mean Attenuation (dB)
Standard Deviation (dB)
125
9.5
4.2
250
10.6
3.1
500
18.7
3.5
1000
26.9
3.6
2000
34.6
4.1
3150
34.3
2.6
4000
30.8
4.4
8000
41.1
2.9
6300
36.1
4.3
EP7 Sonic Defenders Ultra - FILTER CAPS OUT
28
NRR
Test Frequencies (Hz)
Mean Attenuation (dB)
Standard Deviation (dB)
125
31.3
3.7
250
29.8
2.9
500
35.9
3.6
1000
36.3
3.6
2000
38.1
2.8
3150
40.1
4.2
4000
34.8
3.5
8000
41.3
4.4
6300
38.5
4.8
EP7 Sonic Defenders Ultra - FILTER CAPS IN
PROVIDES TWO LEVELS OF HEARING PROTECTION...
Filter caps out for hearing
of ambient sounds & conversation
1. CONSTANT NOISE
(example: loud roar of an engine)
2. IMPULSE NOISE
(example: gunshot or explosion)
HEARING PROTECTION
WARNING: Improper fit of this device will
reduce its effectiveness in attenuating noise.
Consult instructions for proper fit. Failure to
follow instructions could result in hearing loss
and/or injury. EP7 Sonic Defenders Ultra fit
most people; however, no hearing protection
fits everyone. If proper fit cannot be achieved
following instructions, discontinue use. Do
not use in environments with extreme air/
water pressure or where abrupt pressure
changes occur. For swimming use we
recommend polymer flange-stemmed Sonic
Defenders®models.
14
NRR
Test Frequencies (Hz)
Mean Attenuation (dB)
Standard Deviation (dB)
125
9.5
4.2
250
10.6
3.1
500
18.7
3.5
1000
26.9
3.6
2000
34.6
4.1
3150
34.3
2.6
4000
30.8
4.4
8000
41.1
2.9
6300
36.1
4.3
EP7 Sonic Defenders Ultra - FILTER CAPS OUT
28
NRR
Test Frequencies (Hz)
Mean Attenuation (dB)
Standard Deviation (dB)
125
31.3
3.7
250
29.8
2.9
500
35.9
3.6
1000
36.3
3.6
2000
38.1
2.8
3150
40.1
4.2
4000
34.8
3.5
8000
41.3
4.4
6300
38.5
4.8
EP7 Sonic Defenders Ultra - FILTER CAPS IN
EP7 Sonic Defenders®Ultra
28
(when used as directed)
EP7 Sonic Defenders®Ultra
14
(when used as directed)
ANSI S12.42-2010
ANSI S12.42-2010
NOISE REDUCTION (dB)
IMPULSE NOISE LEVEL (dB)
EP7 Impulse Noise Reduction—Filter Caps Out
NOISE REDUCTION (dB)
IMPULSE NOISE LEVEL (dB)
EP7 Impulse Noise Reduction—Filter Caps In
132 150 168
50
45
40
35
30
25
20
15
10
5
0
45
40
35
30
25
20
15
10
5
0
132 150 168
Filter caps in for additional
protection and blocking ambient
sounds & conversations

ORDERING INFORMATION
EP7 Sonic Defenders®Ultra are available in clamshell retail packaging, featuring a
single pair of earplugs in a plastic carry case, and bulk packaging, featuring 25 pairs
of poly-bagged earplugs in plastic carrying cases.
CLEANING & PRODUCT LIFE
EP7 Sonic Defenders Ultra typically last up to 6+ months,
depending on usage and care. Clean earpieces with mild
soap and water and allow to air dry. Clean foam tips by
wiping with a clean cloth and rinsing with water, then air
dry. Replace earplugs when they become stiff and
hardened. For optimal performance, foam tips should be
replaced every 2–4 weeks or when soiled, with
replacement tips available from SureFire.
RADIO SYSTEM EARPIECE USE
With its noise-reducing lter removed** , an EP7 earplug
can be used as a comfortable, high-performance earpiece
with many popular radio communication systems.
**EP7s provide a reduced level of hearing protection with
noise-reducing lters removed.
To install & test:
1. Roll Comply™Canal Tip of color-coded (red filter for
right) EP7 into a thin, round cylinder, being careful not
to unscrew tip from stem.
2. Starting with the EarLock®retention ring of the right
earplug oriented slightly backward, rotate the earplug
forward while inserting the foam tip deep into the right
ear canal. Fit the retention ring to the natural contour
of concha bowl surrounding the ear canal to lock
the earplug in place. Hold in place 15-30 seconds while
foam tip fully expands in ear canal.
3. Check earplug’s seal by placing your fingertip over the
outer hole of filter and removing. Detection of a slight
suction indicates a proper seal.
4. Repeat process with other earpiece for left ear.
5. Test by clapping, with filter caps out. If no noticeable
decrease in volume, reinsert and retest.
6. To block lower-level noise* in quiet environments,
insert attached filter cap into filter’s hole and push in
until snug.
* Inserting filter cap negates noise-reducing filter’s ability to let
ambient sounds & conversations pass safely through.
SIZING, FITTING & TESTING
SUREFIRE NO-HASSLE PROMISE
We’ll do what it takes to keep your SureFire gear running smoothly.
SureFire warrants that if you—our customer—purchase one of our products, and we determine that it is defective
in material and/or workmanship, we will repair or replace it for free or refund your money—no hassle! SureFire
Hearing Protection products are warranted for 90 days from the date of purchase. Our warranty does not cover
consumables, or normal wear-and-tear, or damage resulting from abuse, alterations, unauthorized repairs, or use
contrary to SureFire’s user manuals. For complete warranty information, visit www.surere.com/warranty.
Package Contents
Clamshell with one pair of SMALL clear earplugs
Clamshell with one pair of MEDIUM clear earplugs
Clamshell with one pair of LARGE clear earplugs
Dispenser box of 25 pairs of SMALL clear earplugs
Dispenser box of 25 pairs of MEDIUM clear earplugs
Dispenser box of 25 pairs of LARGE clear earplugs
Clamshell with one pair of SMALL black earplugs
Clamshell with one pair of MEDIUM black earplugs
Clamshell with one pair of LARGE black earplugs
Dispenser box of 25 pairs of SMALL black earplugs
Dispenser box of 25 pairs of MEDIUM black earplugs
Dispenser box of 25 pairs of LARGE black earplugs
Clamshell with one pair of SMALL orange earplugs
Clamshell with one pair of MEDIUM orange earplugs
Clamshell with one pair of LARGE orange earplugs
Dispenser box of 25 pairs of SMALL orange earplugs
Dispenser box of 25 pairs of MEDIUM orange earplugs
Dispenser box of 25 pairs of LARGE orange earplugs
Catalog Number
CLEAR MODELS
EP7-SPR
EP7-MPR
EP7-LPR
EP7-SPR-BULK
EP7-MPR-BULK
EP7-LPR-BULK
BLACK MODELS
EP7-BK-SPR
EP7-BK-MPR
EP7-BK-LPR
EP7-BK-SPR-BULK
EP7-BK-MPR-BULK
EP7-BK-LPR-BULK
ORANGE MODELS
EP7-OR-SPR
EP7-OR-MPR
EP7-OR-LPR
EP7-OR-SPR-BULK
EP7-OR-MPR-BULK
EP7-OR-LPR-BULK
UPC
084871319386
084871319393
084871319409
084871319478
084871319485
084871319492
084871319416
084871319423
084871319409
084871319508
084871319515
084871319522
084871319447
084871319454
084871319461
084871319539
084871319546
084871319553
www.surefire.com/earproproducts
Rev
18300 MT. BALDY CIRCLE // FOUNTAIN VALLEY, CA 92708, U.S.A
WWW.SUREFIRE.COM/HEARINGPROTECTION // 800.828.8809
1” = Medium
Less than 1” = Small
Greater than 1” = Large
EP7 SIZING
Medium EP7s t most people. Sizing is based
on the ear’s concha bowl:
EP7 COLORS & SIZES
Colors: Black, orange, clear
Sizes: Small, medium, large
Accessories: Included 26” retention lanyard
HEARING PROTECTION
© 2013 SureFire, LLC. All rights reserved.
Prices, availability, specifications, and promotional offers are
subject to change or cancellation at any time without notice.
TO ORDER OR LOCATE A DEALER:
www.surere.com/tactical-equipment/hearing protection
www.surere.com/dealer-locator
800–828–8809 or 714–545–9444 (U.S.A.)
00–800–7843–7843 (UK & Germany)
NSN
6515-01-622-1984
6515-01-622-2001
6515-01-622-2007
6515-01-622-2019
6515-01-622-2539
6515-01-622-2558
