SureShade Power Bimini Installation instructions

1
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.26.22CCD-0004539
Table of Contents
Introduction ............................................ 2
Safety ................................................... 2
Parts List ................................................ 3
Installation .............................................. 3
Operation ............................................... 3
Storage ................................................ 3
Troubleshooting ........................................ 4
Maintenance ............................................ 4
Fabric Care ............................................ 4
Notes .................................................... 4
SureShade®
Power Bimini
Upgrades: High
Speed Mesh Top
Installation and
Owner’s Manual
(For Aftermarket Applications)
High Speed Mesh Kit PN 2021013518
Part # Description
129191 BIMINI COVER SPEED TOP WITH BOOT - BLACK

2
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.26.22
SureShade® Power
Bimini Upgrades: High
Speed Mesh Top
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004539
Introduction
SureShade has developed a high speed mesh bimini
exclusively for the power bimini installed on your pontoon
or deck boat that not only protects, but stays in place at
speeds up to 55 mph.
You can leisurely cruise with shade or ride the waves.
The 8-½’ x 10’—fully extended—Speed Top power shade
easily fits over the SureShade Power Bimini frame on your
deck or pontoon boat.
Our bimini is made with a nylon mesh that gives you the
protection you need from rain or the harsh UV rays of the
sun. Unlike traditional canvas bimini tops, the mesh doesn’t
hold the heat so you can remain comfortable.
Shade in an instant, add speed and you’re ready for a
perfect day on the water!
Additional information about this product can be obtained
from lci1.com/support or by using the LippertNOW app.
Replacement kits can be ordered from https://store.lci1.
com/ or by using the LippertNOW app.
The myLCI app is available for free on Apple App Store®
for iPhone®and iPad®and also on Google Play™for
Android™users.
App Store®and iPad®are registered trademarks of Apple
Inc.
Google Play™and Android™are trademarks of Google Inc.
Safety
Read and understand all instructions before installing or
operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables
can change the circumstances of the instructions, i.e., the
degree of difficulty, operation and ability of the individual
performing the instructions. This manual cannot begin to
plot out instructions for every possibility, but provides the
general instructions, as necessary, for effectively interfacing
with the device, product or system. Failure to correctly
follow the provided instructions may result in death, serious
personal injury, severe product and/or property damage,
including voiding of the LCI limited warranty.
THE “WARNING” SYMBOL ABOVE IS A SIGN THAT
A PROCEDURE HAS A SAFETY RISK INVOLVED
AND MAY CAUSE DEATH OR SERIOUS PERSONAL
INJURY AND/OR SEVERE PRODUCT OR PROPERTY
DAMAGE IF NOT PERFORMED SAFELY AND WITHIN
THE PARAMETERS SET FORTH IN THIS MANUAL.
FAILURE TO FOLLOW INSTRUCTIONS PROVIDED
IN THIS MANUAL MAY RESULT IN DEATH, SERIOUS
PERSONAL INJURY AND/OR SEVERE PRODUCT AND
PROPERTY DAMAGE, INCLUDING VOIDING OF THE
COMPONENT WARRANTY.
DO NOT FULLY OPEN THE BIMINI FRAME WITHOUT
THE CANVAS TOP INSTALLED. OPENING THE BIMINI
FRAME WITHOUT THE CANVAS TOP INSTALLED
WILL RESULT IN SEVERE PRODUCT DAMAGE. ONLY
FULLY OPEN THE BIMINI FRAME WITH THE CANVAS
TOP INSTALLED.
THE “CAUTION” SYMBOL ABOVE IS A SIGN THAT
A SAFETY RISK IS INVOLVED AND MAY CAUSE
PERSONAL INJURY AND/OR PRODUCT OR
PROPERTY DAMAGE IF NOT SAFELY ADHERED TO
AND WITHIN THE PARAMETERS SET FORTH
IN THIS MANUAL.
ALWAYS WEAR EYE PROTECTION WHEN
PERFORMING SERVICE, MAINTENANCE OR
INSTALLATION PROCEDURES.

3
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.26.22
SureShade® Power
Bimini Upgrades: High
Speed Mesh Top
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004539
LetterLetter PNPN DescriptionDescription QtyQty
A NA Bimini Cover Mesh Speed Top 1
B NA Bimini Cover Boot 1
Parts List
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
A
B
Installation
If replacing a traditional bimini canvas fabric top with
the Lippert high speed fine mesh top, follow the original
owner’s manual removal instructions for the canvas top.
Such instructions may include:
• Removal of any securing straps.
• Unsnapping canvas corner button snaps.
• Unzipping bimini frame canvas pockets.
Install the optional Lippert high speed mesh top as follows:
1. Retract—lower—the bimini frame almost all of the
way down.
2. Unzip the rear, middle and front mounting pockets of the
Lippert high speed mesh top.
3. Place the mesh top over the bimini frame.
NOTE: The rear of the mesh top has an access hole for
a stern light, the front of the mesh top has a zippered
storage pouch that is separate form the top’s front zippered
mounting pocket.
4. If a stern light is attached to the rear frame’s bow, slip
the mesh top’s access hole over the light, then spread the
top outward; aligning the rear zippered pouch over the
bimini’s rear bow frame.
5. Zip the rear mesh top pocket closed over the rear bimini
frame bow.
6. Pull the middle zippered pocket of the mesh top over the
middle frame bow, then zip it closed.
7. Pull the front zippered pocket of the mesh top over the
front frame bow, then zip it closed.
Operation
1. Turn on electrical power to the boat.
2. Remove any protective boot or restraints from the high
speed mesh top.
3. To operate the quick-connect (QC) bimini top, use one of
the following methods:
• Helm switch
• QC controller
NOTE: A helm switch and the QC controller are NOT
compatible. Only one type of control can be used.
NOTE: Do NOT fully open the QC bimini system without a
top installed or failure of the system will result.
Storage
When the high speed mesh top is not in use, properly store
the canopy as follows:
1. Lower the top to its fully retracted position.
2. Install the boot over the canopy.

4
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.26.22
SureShade® Power
Bimini Upgrades: High
Speed Mesh Top
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004539
Manual information may be distributed as a complete
document only, unless Lippert provides explicit consent
to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lippert.com. Manual information is
considered factual until made obsolete by a revised
version.
Please recycle all obsolete materials and contact
Lippert with concerns or questions.
Troubleshooting
What is happening? Why? What should be done?
Mesh top sags. Unzipped frame pocket. Zip all frame pockets closed.
Mesh top not fully opened. Fully open mesh top.
Maintenance
Fabric Care
Use clear water to consistently hose off the bimini top
fabric during the boating season.
If necessary, do a deeper clean of the bimini top fabric as
follows:
1. If necessary, remove the boot and place the bimini top
into its full open position.
2. If the top was stored wet, allow the bimini top and boot
to dry.
3. Remove any loose dirt and debris from the bimini top
and boot.
4. Hose down the bimini top and boot fabric.
5. Prepare a mixture of ¼ cup of mild dish soap and ve
gallons of warm water.
NOTE: Do NOT use harsh detergents.
6. Use a soft bristle brush to apply the soapy water
to the bimini top and boot fabric to remove stains and
embedded dirt.
7. Allow the solution time to soak completely into the fabric.
8. Hose o󰀨 the bimini top and boot fabric with fresh water.
Repeat if necessary.
9. Allow bimini top and boot to dry before closing the top
and installing the protective boot.
