Sutron P Line User manual

User Manual
P Line Touch Panel
Part Number: 80860.761
Version: 7
Date: 2014-03-12
Valid for: TP057ZTV
TP057GTV
TP070ZTW
TP070GTW
TP090ZTW
TP090GTW
TP105ZTS
TP105GTS
TP121ZTS
TP121GTS
TP121ZTM
TP121GTM
TP150ZTX
TP150GTX
TP154ZTM
TP154GTM

P Line Touch Panel
Version Date Modifications
1 2010-05-18 First Edition
2 2010-10-15 TP070ZTW, TP090ZTW, TP121ZTS added.
3 2011-09-13 TP057ZTV, TP121ZTM, TP151ZTX added.
4 2012-12-12 TP154ZTM, TP070GTW, TP090GTW, TP121GTM,
TP154ZTM added.
5 2013-05-15 RS232 / RS485 COM ports updated.
6 2013-08-08 TP057ZTV, TP121GTS, TP150GTX added.
7 2014-03-12 TP105ZTS, TP105GTS added.
This manual, including all illustrations contained herein, is copyright protected. Use of this manual by any third
party in departure from the copyright provision is forbidden. No part of this manual may be reproduced, trans-
lated or electronically or photographically archived or altered without the express written consent from Sütron
electronic GmbH. Violations shall be cause for damage liability.
Sütron electronic reserves the right to make any changes that contribute to technical improvement.

P Line Touch Panel Overall Table of Contents
3
Overall Table of Contents
1 Important Notes .......................................................................................................... 7
1.1 Symbols ....................................................................................................... 7
1.2 Safety Notes ................................................................................................ 7
1.3 Intended Use................................................................................................ 8
1.4 Target Group................................................................................................ 8
2 Installation and Commissioning .................................................................................. 9
2.1 Unpacking the Device .................................................................................. 9
2.2 Mounting the Device .................................................................................... 9
2.2.1 Front Panel Dimensions ....................................................................... 10
2.2.1.1 TP057ZTV / TP057GTV .............................................................................................. 10
2.2.1.2 TP070ZTW / TP070GTW ............................................................................................ 11
2.2.1.3 TP090ZTW / TP090GTW ............................................................................................ 12
2.2.1.4 TP105ZTS / TP105GTS .............................................................................................. 13
2.2.1.5 TP121ZTS / TP121GTS .............................................................................................. 14
2.2.1.6 TP121ZTM / TP121GTM ............................................................................................. 15
2.2.1.7 TP150ZTX / TP150GTX .............................................................................................. 16
2.2.1.8 TP154ZTM / TP154GTM ............................................................................................. 17
2.2.2 Mounting Cutout ................................................................................... 18
2.2.2.1 TP057ZTV / TP057GTV .............................................................................................. 18
2.2.2.2 TP070ZTW / TP070GTW ............................................................................................ 19
2.2.2.3 TP090ZTW / TP090GTW ............................................................................................ 20
2.2.2.4 TP105ZTS / TP105GTS .............................................................................................. 21
2.2.2.5 TP121ZTS / TP121GTS .............................................................................................. 22
2.2.2.6 TP121ZTM / TP121GTM ............................................................................................. 23
2.2.2.7 TP150ZTX / TP150GTX .............................................................................................. 24
2.2.2.8 TP154ZTM / TP154GTM ............................................................................................. 25
2.2.3 Side View, Mounting Depth .................................................................. 26
2.2.3.1 TP057ZTV / TP057GTV .............................................................................................. 26
2.2.3.2 TP070ZTW / TP070GTW ............................................................................................ 27
2.2.3.3 TP090ZTW / TP090GTW ............................................................................................ 28
2.2.3.4 TP105ZTS / TP105GTS .............................................................................................. 29
2.2.3.5 TP121ZTS / TP121GTS .............................................................................................. 30
2.2.3.6 TP121ZTM / TP121GTM ............................................................................................. 31
2.2.3.7 TP150ZTX / TP150GTX .............................................................................................. 32
2.2.3.8 TP154ZTM / TP154GTM ............................................................................................. 33
2.3 Connecting the Device............................................................................... 34
2.3.1 Supply Voltage...................................................................................... 34
2.3.2 Grounding ............................................................................................. 35
2.4 Switching On.............................................................................................. 36
2.4.1 Cockpit.................................................................................................. 36
2.4.1.1 Menu Structure ............................................................................................................37
2.4.1.2 Settings and Functions ................................................................................................ 37
2.4.1.2.1 Language Selection...............................................................................................37
2.4.1.2.2 Date and Time....................................................................................................... 38
2.4.1.2.3 Administration........................................................................................................38

Overall Table of Contents P Line Touch Panel
4
2.4.1.2.4 Network ................................................................................................................. 38
2.4.1.2.5 Password .............................................................................................................. 39
2.4.1.2.6 Display .................................................................................................................. 39
2.4.1.2.7 Write Filter............................................................................................................. 39
2.5 Identification ............................................................................................... 41
3 Control and Display Elements................................................................................... 43
3.1 Touch Screen............................................................................................. 43
3.2 Display ....................................................................................................... 43
4 Interfaces of the Device ............................................................................................ 45
4.1 Ethernet...................................................................................................... 46
4.1.1 Pin Assignment ..................................................................................... 46
4.1.2 Cable..................................................................................................... 46
4.1.3 Diagnosis .............................................................................................. 47
4.2 USB............................................................................................................ 47
4.2.1 Cable..................................................................................................... 47
4.3 Serial Interfaces ......................................................................................... 48
4.3.1 RS-422 / RS-485 (X14)......................................................................... 49
4.3.1.1 Pin Assignment............................................................................................................ 49
4.3.1.2 Termination.................................................................................................................. 50
4.3.1.3 Transmitter Control......................................................................................................51
4.3.1.4 Diagnosis..................................................................................................................... 51
4.3.2 RS232 (X15) ......................................................................................... 52
4.3.2.1 Pin Assignment............................................................................................................ 52
4.3.2.2 Diagnosis..................................................................................................................... 52
4.4 Field Bus Interfaces ................................................................................... 53
4.4.1 CAN (X12, X13) .................................................................................... 53
4.4.1.1 Pin Assignment............................................................................................................ 54
4.4.1.2 Cable ........................................................................................................................... 54
4.4.1.3 Termination.................................................................................................................. 55
4.4.1.4 Diagnosis..................................................................................................................... 55
4.5 Memory Card ............................................................................................. 56
4.5.1 Inserting the memory card .................................................................... 56
4.5.2 Ejecting the memory card ..................................................................... 56
4.6 Shielding D-SUB Connectors..................................................................... 57
5 Maintenance and Servicing....................................................................................... 59
5.1 Maintenance Interval.................................................................................. 59
5.2 Front Panel................................................................................................. 59
5.3 Fuse ........................................................................................................... 59
5.4 Battery........................................................................................................ 59
5.4.1 Changing the Battery ............................................................................ 60
5.4.2 Battery Disposal.................................................................................... 61

P Line Touch Panel Overall Table of Contents
5
6 Technical Data.......................................................................................................... 63
6.1 General ...................................................................................................... 63
6.2 TP057ZTV.................................................................................................. 65
6.3 TP057GTV ................................................................................................. 67
6.4 TP070ZTW................................................................................................. 69
6.5 TP070GTW ................................................................................................ 71
6.6 TP090ZTW................................................................................................. 73
6.7 TP090GTW ................................................................................................ 75
6.8 TP105ZTS.................................................................................................. 77
6.9 TP105GTS ................................................................................................. 79
6.10 TP121ZTS.................................................................................................. 81
6.11 TP121GTS ................................................................................................. 83
6.12 TP121ZTM ................................................................................................. 85
6.13 TP121GTM ................................................................................................ 87
6.14 TP150ZTX.................................................................................................. 89
6.15 TP150GTX ................................................................................................. 91
6.16 TP154ZTM ................................................................................................. 93
6.17 TP154GTM ................................................................................................ 95
7 Ordering Data ........................................................................................................... 97
A Index ......................................................................................................................... 99

Overall Table of Contents P Line Touch Panel
6

P Line Touch Panel Important Notes
7
1 Important Notes
1.1 Symbols
The symbols in this manual are used to draw your attention on notes and dangers.
1.2 Safety Notes
– Read this manual carefully before using the operating device. Keep this man-
ual in a place where it is always accessible to all users.
– Proper transportation, handling and storage, placement and installation of this
product are prerequisites for its subsequent flawless and safe operation.
– This user manual contains the most important information for the safe opera-
tion of the device.
– The user manual, in particular the safety notes, must be observed by all per-
sonnel working with the device.
– Observe the accident prevention rules and regulations that apply to the oper-
ating site.
– Installation and operation must only be carried out by qualified and trained
personnel.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible in-
jury or death.
DANGER
This indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING
This indicates a hazardous situation which, if not avoided, could result in death
or serious injury.
CAUTION
This indicates a hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE
This symbol together with the signal word NOTE and the accompanying text
alert the reader to a situation which may cause damage or malfunction to the
device, hardware/software, or surrounding property.
This symbol and the accompanying text provide the reader with additional infor-
mation or refer to detailed sources of information.

Important Notes P Line Touch Panel
8
1.3 Intended Use
– The device is designed for use in the industry.
– The device is state-of-the art and has been built to the latest standard safety
requirements. However, dangerous situations or damage to the machine itself
or other property can arise from the use of this device.
– The device fulfills the requirements of the EMC directives and harmonized Eu-
ropean standards. Any modifications to the system can influence the EMC be-
havior.
1.4 Target Group
The use of products described in this manual is oriented exclusively to:
– Qualified electricians or persons instructed by them, who are familiar with ap-
plicable standards and other regulations regarding electrical engineering and,
in particular, the relevant safety concepts.
– Qualified application programmers and software engineers, who are familiar
with the safety concepts of automation technology and applicable standards.
NOTICE: Radio Interference
This is a class A device. This device may cause radio interference in residential
areas. In this case, the user may be required to introduce appropriate counter-
measures, and to bear the cost of same.

P Line Touch Panel Installation and Commissioning
9
2 Installation and Commissioning
2.1 Unpacking the Device
Unpack all parts carefully and check the contents for any visible damage in transit.
Also check whether the shipment matches the specifications on your delivery
note.
If you notice damages in transit or discrepancies, please contact us immediately.
2.2 Mounting the Device
The device can be easily and quickly mounted from the rear of the device. A panel
thickness of 1 mm to 6 mm (0.039" to 0.236") is permitted for proper mounting.
1. Insert the device in the mounting cutout from the front.
Figure 2-1 Mounting the device using a mounting bracket
2. Insert the mounting brackets into the appropriate openings (figure 1) and pull
the brackets downwards until they lock in place (2).
3. Fasten the device into position using the threaded pins (3).
NOTICE: Damage
When installing the device, leave a gap of at least 30 mm (1.181") around the
device to ensure sufficient air circulation.
NOTICE: Damage
When the operating device is installed horizontally, please note that additional
sources of heat beneath the operating device may result in heat accumulation.
Make sure to allow sufficient heat dissipation!
Please observe the permissible temperature range specified in the technical
data of the user manual when operating the device.
NOTICE: Damage
In order to ensure the degree of protection specified in the technical data, al-
ways make sure that the seal lies flat against the mounting surface and the
threaded pins of the mounting brackets are tightened uniformly to a maximum
torque of 1 Nm.

Installation and Commissioning P Line Touch Panel
10
2.2.1 Front Panel Dimensions
2.2.1.1 TP057ZTV / TP057GTV
Figure 2-2 TP057ZTV / TP057GTV

P Line Touch Panel Installation and Commissioning
11
2.2.1.2 TP070ZTW / TP070GTW
Figure 2-3 TP070ZTW / TP070GTW

Installation and Commissioning P Line Touch Panel
12
2.2.1.3 TP090ZTW / TP090GTW
Figure 2-4 TP090ZTW / TP090GTW

P Line Touch Panel Installation and Commissioning
13
2.2.1.4 TP105ZTS / TP105GTS
Figure 2-5 TP105ZTS / TP105GTS

Installation and Commissioning P Line Touch Panel
14
2.2.1.5 TP121ZTS / TP121GTS
Figure 2-6 TP121ZTS / TP121GTS

P Line Touch Panel Installation and Commissioning
15
2.2.1.6 TP121ZTM / TP121GTM
Figure 2-7 TP121ZTM / TP121GTM

Installation and Commissioning P Line Touch Panel
16
2.2.1.7 TP150ZTX / TP150GTX
Figure 2-8 TP150ZTX / TP150GTX

P Line Touch Panel Installation and Commissioning
17
2.2.1.8 TP154ZTM / TP154GTM
Figure 2-9 TP154ZTM / TP154GTM

Installation and Commissioning P Line Touch Panel
18
2.2.2 Mounting Cutout
2.2.2.1 TP057ZTV / TP057GTV
Figure 2-10 TP057ZTV / TP057GTV
AMounting Cutout
BFront Panel

P Line Touch Panel Installation and Commissioning
19
2.2.2.2 TP070ZTW / TP070GTW
Figure 2-11 TP070ZTW / TP070GTW
AMounting Cutout
BFront Panel

Installation and Commissioning P Line Touch Panel
20
2.2.2.3 TP090ZTW / TP090GTW
Figure 2-12 TP090ZTW / TP090GTW
AMounting Cutout
BFront Panel
