Svantek SV 104 User manual

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
1
SV 104
ACOUSTIC DOSIMETER
USER’S MANUAL
SVANTEK Sp. z o.o.
WARSAW, July 2013
I
II
In
nn
nstr stru
stru
stru
ument
menta
menta
menta
ationforScience
tionforSciencea
tionforSciencea
tionforSciencea
an nn
nd d
d
dI
I
I
In
n
n
nd
d
d
du
u
u
us ss stry try
try
try ISIsa-nvRue du Doyenné3 - 1180 BrusselsTel+32 (0) 2 343 30 81 Fax [phone] web : http:// www.isi-be.com mail : [email protected]

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
2
Notice: The SV104 dosimeter contains no user serviceable parts. Opening product case
invalidates the warranty.
Notice: When in normal use, always fit the SA 122 windshield provided. It is suggested that
the SA 122 windshield is removed whenever measurements are to be made in extremely clean
environments such as food preparation or pharmaceutical manufacturing in order not to accidentally lose the
windshield during the survey.
Notice: Battery power indicator - To improve accuracy of remaining battery life indicator, run
the dosimeter until it is fully discharged; then proceed with a full charge via the micro USB port.
The procedure is recommended before first use. Repeat this procedure every few months of use to maintain
more accurate current battery condition indication.
Notice: On account of continuous product improvement SVANTEK reserves the right
to make changes to product specifications without notice. To download the most up to date user's manual
please visit our web site at www.svantek.com.
This user’s manual presents the firmware revision named 1.02.01 (see the Unit Label review chapter 4.5
to check version details).
This user’s manual presents some aspects of SUPERVISOR software revision named 1.0.7
(see the software start-up splash screen).
The succeeding software revisions (marked with the higher numbers) can change the view of some displays
presented in the text of the manual.
WEEE Notice: Do not throw the device away with the unsorted municipal waste at the end
of its life. Instead, hand it in at an official collection point for recycling. By doing this you will help to preserve
the environment.
Trademarks
Microsoft and Windows are registered trademarks of Microsoft Corporation
Copyright ©2013, SVANTEK sp. z o.o.
All rights reserved. No part of this publication may be reproduced or distributed in any form,
or by any means, without prior written consent from SVANTEK, Warsaw, Poland
Thank you for buying and using this SVANTEK product!

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
3
CONTENTS
1INTRODUCTION 8
1.1 Sound pressure 9
1.2 Dosimetry 9
1.3 Standards 10
1.4 Applications 11
1.5 Measurement procedures 12
2KIT COMPONENTS 13
2.1 SV 104 dosimeter short form specification 13
2.2 Accessories included 14
2.3 Accessories available 14
2.4 Instrument Software (Firmware) options available 14
3GETTING STARTED 15
3.1 System description 15
3.2 Input output interfaces description 16
3.3 The windshield 17
3.4 The mounting clips 17
3.5 LED status indicator 18
3.6 Status bar icons 18
3.7 Manual control of the instrument 19
3.7.1 Primary key functions 20
3.7.2 Alternate key functions 21
3.7.3 Alternate combined keys function 22
3.8 Three instruments in one –ACOUSTIC PROFILE concept 23
3.9 The VIEW mode presentation concept 23
3.9.1 Running SPL view mode 23
3.9.2 Primary “ONE-RESULT” parameters view mode 24
3.9.3 RESULTS LIST view mode 24
3.9.4 OCTAVE analysis spectrum view mode 25
3.9.5 INSTRUMENT STATUS view mode 26
3.10ALARM screen review 26
4RUNNING AND OPERATING BASIC PROCEDURES 27
4.1 Charging 27
4.2 Before you turn the instrument on 28
4.3 Turning on/off 28
4.4 Battery check 30
4.5 Reviewing unit label 31
4.6 Measurement Setups - basic configuration 32
4.7 CALIBRATION 33

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
4
4.8 Voice comments recording 36
4.9 Before and after measurement run 37
4.10Starting and stopping measurement run 37
4.11Auto-run mode information 37
4.12Security lock 38
4.13Mounting and positioning the SV 104 38
4.14Reviewing measurements 39
4.15Resetting the dosimeter 39
5SUPERVISOR BASIC OPERATIONS 40
5.1 Installing and connecting to PC 40
5.2 Main software window 41
5.3 Instruments inventory panel 42
5.4 Advanced configuration setup 43
5.4.1 Working with configuration setup files 43
5.4.2 Profile settings tab 46
5.4.3 Measurement parameters settings tab 47
5.4.4 Time-history data logging settings tab 48
5.4.5 Display VIEW configuration tab 49
5.4.6 Octave analysis Spectrum configuration tab 50
5.4.7 General settings tab 50
5.4.7.1 Calibration settings panel 51
5.4.7.2 Statistical levels settings panel 51
5.4.7.3 Security settings panel 52
5.4.7.4 Auxiliary settings panel 53
5.4.8 Auto-Run settings (timer, pauses) tab 54
5.4.9 Recording options tab 56
5.4.9.1 Event and Wave recording configuration panel 56
5.5 Working with data files 57
5.5.1 Instrument files 57
5.5.2 Local files “Data Browser” 58
5.6 Working with sessions and reporting 59
5.6.1 Report panels 61
6SV104 MAINTENANCE 67
6.1 General recommendations for use 67
6.2 Cleaning 67
6.3 In situ calibration 67
6.4 Periodic testing 67
6.5 Changing the microphone and windshield 68
6.6 Firmware update 68
6.7 Storing the instrument 68
6.8 Transportation and carrying 69
6.9 Troubleshooting 69

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
5
7SVANTEK SERVICE 70

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
6
LIST OF FIGURES
FIGURE 2-1 SV 104 INSTRUMENT WITH THE MICROPHONE AND WINDSHIELD.................................................................................... 13
FIGURE 3-1 SV 104 AT A GLANCE............................................................................................................................................. 15
FIGURE 3-2 SV 104 SIDE VIEW –MICROPHONE AND MICRO USB CONNECTOR.................................................................................. 16
FIGURE 3-3 SV 104 BACK VIEW -CHARGING AND INFRARED PORT (RESERVED FOR FUTURE USE) ........................................................... 16
FIGURE 3-4 SA 122 WINDSHIELD ............................................................................................................................................. 17
FIGURE 3-5 SV 104 STANDARD MOUNTING CLIPS........................................................................................................................ 17
FIGURE 3-6 SV 104 DISPLAY ICONS DESCRIPTION ........................................................................................................................ 18
FIGURE 3-7 CONTROL KEYPAD ON THE FRONT PANEL –PRIMARY KEY FUNCTIONS ............................................................................... 20
FIGURE 3-8 CONTROL KEYPAD ON THE FRONT PANEL –ALTERNATE KEY FUNCTIONS ............................................................................ 21
FIGURE 3-9 CONTROL KEYPAD ON THE FRONT PANEL –ALTERNATE COMBINED KEYS FUNCTION ............................................................. 22
FIGURE 3-10 RUNNING SPL VIEW MODE SCREEN......................................................................................................................... 23
FIGURE 3-11 PRIMARY PARAMETERS VIEW MODE SCREEN ............................................................................................................. 24
FIGURE 3-12 RESULTS LIST VIEW MODE SCREENS ......................................................................................................................... 24
FIGURE 3-13 OCTAVE ANALYSIS SPECTRUM GRAPH LEQ VIEW MODE SCREENS .................................................................................. 25
FIGURE 3-14 OCTAVE ANALYSIS SPECTRUM GRAPH MAX VIEW MODE SCREENS ................................................................................. 25
FIGURE 3-15 INSTRUMENT STATUS VIEW MODE SCREENS.............................................................................................................. 26
FIGURE 3-16 ALARM VIEW SCREENS.......................................................................................................................................... 26
FIGURE 4-1 POWER-OFF WARNING SCREEN ................................................................................................................................ 29
FIGURE 4-2 INSTRUMENT STATUS -BATTERY STATE...................................................................................................................... 30
FIGURE 4-3 UNIT LABEL SCREENS.............................................................................................................................................. 31
FIGURE 4-4 LOAD SETUP MENU................................................................................................................................................ 32
FIGURE 4-5 LOAD SETUP CONFIRMATION ................................................................................................................................... 32
FIGURE 4-6 STATUS OF SETUP LOADING ..................................................................................................................................... 32
FIGURE 4-7 CALIBRATION MENU .............................................................................................................................................. 33
FIGURE 4-8 CALIBRATION -INITIAL DELAY SCREEN ........................................................................................................................ 34
FIGURE 4-9 CALIBRATION IN PROGRESS SCREEN........................................................................................................................... 34
FIGURE 4-10 CALIBRATION CONFIRMATION SCREEN ..................................................................................................................... 34
FIGURE 4-11 CALIBRATION -MICROPHONE NOT IN TOLERANCE SCREEN............................................................................................ 35
FIGURE 4-12 VOICE COMMENT LINKING SCREEN.......................................................................................................................... 36
FIGURE 4-13 VOICE COMMENT RECORDING COMMAND SCREEN ..................................................................................................... 36
FIGURE 4-14 VOICE COMMENT RECORDING IN PROGRESS SCREENS ................................................................................................. 36
FIGURE 4-15 VOICE COMMENT RECORD CONFIRMATION SCREEN .................................................................................................... 36
FIGURE 4-16 AUTO-RUN MODE –TIMER AND PROGRAMMABLE PAUSE SCREEN ................................................................................. 37
FIGURE 4-17 UNLOCKING THE UNIT SEQUENCE SCREENS ............................................................................................................... 38
FIGURE 4-18 SV 104 POSITIONING .......................................................................................................................................... 38
FIGURE 5-1 SUPERVISOR SPLASH SCREEN.................................................................................................................................... 40
FIGURE 5-2 SUPERVISOR MAIN WINDOW ................................................................................................................................... 41
FIGURE 5-3 INVENTORY PANEL AND ITS CAPABILITIES .................................................................................................................... 42
FIGURE 5-4 SETUP FILES MANAGER PANEL .................................................................................................................................. 43
FIGURE 5-5 EXPORTING THE CONFIGURATION SETUP FILE .............................................................................................................. 44
FIGURE 5-6 INSTRUMENT FILES PANEL AND CONTEXT COMMANDS................................................................................................... 45
FIGURE 5-7 DOSIMETER SETTINGS -PROFILE CONFIGURATION TAB .................................................................................................. 46
FIGURE 5-8 MEASUREMENT CONFIGURATION SETTTINGS TAB......................................................................................................... 47
FIGURE 5-9 TIME HISTORY (LOGGER)SETTINGS TAB..................................................................................................................... 48
FIGURE 5-10 DISPLAY VIEW CONFIGURATION TAB ...................................................................................................................... 49
FIGURE 5-11 SPECTRUM CONFIGURATION TAB ............................................................................................................................ 50
FIGURE 5-12 GENERAL SETTINGS TAB ........................................................................................................................................ 50
FIGURE 5-13 CALIBRATION SETTINGS PANEL ............................................................................................................................... 51
FIGURE 5-14 STATISTICAL LEVELS SETTINGS PANEL ....................................................................................................................... 51
FIGURE 5-15 KEYBOARD SECURITY SETTINGS PANEL...................................................................................................................... 52
FIGURE 5-16 AUXILIARY SETTINGS PANEL ................................................................................................................................... 53
FIGURE 5-17 AUTO-RUN CONFIGURATION TAB............................................................................................................................ 54
FIGURE 5-18 AUDIO EVENT AND WAVE RECORDING CONFIGURATION PANELS................................................................................... 56
FIGURE 5-19 SV 104 DOWNLOAD WINDOW .............................................................................................................................. 57
FIGURE 5-20 CHANGE INSTRUMENT WORKING DIRECTORY WINDOW ............................................................................................... 57

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
7
FIGURE 5-21 LOCAL FILES “DATA BROWSER”-WINDOW LAYOUT ................................................................................................... 58
FIGURE 5-22 SUPERVISOR MAIN SESSION WINDOW ............................................................................................................... 59
FIGURE 5-23 SESSION CONFIGURATION PANEL.......................................................................................................................... 60
FIGURE 5-24 MANAGING TEMPLATES WITH SUPERVISOR........................................................................................................... 61
FIGURE 5-25 SUPERVISOR REPORT OPTIONS........................................................................................................................... 61
FIGURE 5-26 HEARING PROTECTORS (HML) PANEL ..................................................................................................................... 62
FIGURE 5-27 INSTRUMENT CONFIGURATION PANEL...................................................................................................................... 62
FIGURE 5-28 LOGGER 1/1 OCTAVE PANEL ................................................................................................................................. 63
FIGURE 5-29 LOGGER 1/1 OCTAVE TSECT PANEL ....................................................................................................................... 63
FIGURE 5-30 LOGGER COMBINED PANEL .................................................................................................................................... 63
FIGURE 5-31 LOGGER RESULTS PANEL ....................................................................................................................................... 64
FIGURE 5-32 LOGGER STATISTICS PANEL .................................................................................................................................... 64
FIGURE 5-33 MARKED PERIODS TOTALS PANEL ........................................................................................................................... 65
FIGURE 5-34 NOISE EXPOSURE (ISO 9612) PANELS..................................................................................................................... 65
FIGURE 5-35 SESSION HEADER PANEL........................................................................................................................................ 66
FIGURE 5-36 CONFIGURABLE TEXT PANEL .................................................................................................................................. 66
FIGURE 5-37 POWERFULL “WHAT IF”PANEL .............................................................................................................................. 66
LIST OF TABLES
TABLE 1-1 EXAMPLE SOUND SOURCE LEVELS ................................................................................................................................. 9
TABLE 1-2 STANDARDIZATION ORGANIZATIONS’WEBSITES............................................................................................................. 10
TABLE 3-1 LED STATUS DESCRIPTION ........................................................................................................................................ 18

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
8
1INTRODUCTION
The SV 104 instrument is a revolutionary new approach to occupational health and safety noise
monitoring offering voice comments, audio events recording and vibration shock detection functions
which are new and useful concepts in an instrument of this size. It is a cable-free dosimeter and is typically
attached to the user’s shoulder, close to the ear using the mounting clips supplied.
This personal dosimeter has an incredibly robust 1/2" MEMS microphone (part number SV 27)
enabling easy and automatic calibration using most commonly available acoustic calibrators.
The class beating, high resolution, amazing colour OLED screen displays information in both text and
graphical form and offers excellent visibility in dark sites as well as in full daylight conditions. This makes
taking noise measurement a real pleasure.
Three independent acoustic profiles allow parallel measurements with separately defined filters
and RMS detector time constants. Each profile provides an extensive number of results (like Leq, Lmax,
Lmin, Lpeak, L, LE,…). All required weighting filters (A, C, Z) can be calculated in parallel.
For instance, it is trivial to set one profile to monitor noise parameters using the ACGIH (American
Conference of Governmental Industrial Hygienists) preset, second profile set to OSHA HC (Occupational
Safety and Health Administration - Hearing Conversation) preset and simultaneously monitor noise with the
OSHA PEL (Occupational Safety and Health Administration –Permissible Exposure Level) settings.
Using the computational power of its digital signal processor the SV 104 instrument can
simultaneously measure the dosimeter results and perform real time 1/1 Octave analysis including the
calculations of the statistical levels.
An inbuilt tri-axial accelerometer for vibration shock detection firmly places SV 104 as both the most
technically advanced and the most robust personal dosimeter out there.
Advanced time history logging for each profile provides safe and complete information about
measured signal in the internal large 8GB memory.
The instrument is powered from internal new generation Ni-MH rechargeable batteries offering circa
40 hours1of continuous operation. This new cell technology offers up to 1800 charge cycles in comparison
to standard maximum 500 cycles. Low battery self-discharge is about 3% per month in comparison to 40%
per month in standard NiMH technology. The powering and charging of the instrument from the USB
interface is provided which also enables easy data exchange connection between the SV 104 and a PC
without the requirement of a special docking station.
The instrument works with Svantek’s specialist health and safety software package - Supervisor,
and also with the full analysis package SVAN PC++.
Robust and lightweight design including innovative magnetic mounted windshield enhances
the exceptional features of this new generation instrument. Add to it the automatic calibration feature and
one can say: “Never before has a noise dosimeter been so accomplished yet so affordable, making your
measurements more accurate and reliable than ever before”.
To get started quickly with the SV 104, the first part of the manual describes basic noise dosimetry
information followed by a guide to setting up the dosimeter and running measurements.
1Display off. Octave analysis off;

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
9
1.1 Sound pressure
The human ear responds to audible sound pressure levels in the range from 20 μPa (hearing
threshold) to 20 Pa (pain threshold), resulting in the enormous scale 1:10,000,000. Since using such a large
arithmetic scale is not practical, a logarithmic scale in decibels (dB) was introduced which is also in
agreement with physiological and psychological hearing sensations. Therefore it is common that sound
pressure is measured in decibels. Below there is sample information about expected sound levels for
different sources.
Sound source
Sound level [dB]
Jet aircraft, 50 m away,
or gunshot at close range
140
Threshold of pain
130
Threshold of discomfort
120
Chainsaw, 1 m distance
110
Disco, 1 m from speaker
100
Vacuum cleaner, distance 1 m
70
Conversational speech, 1 m
60
Quiet library
40
Rustling leaves
10
Hearing threshold
0
Table 1-1 Example sound source levels
1.2 Dosimetry
Noise is definitely a serious hazard in many workplaces. In case exposure to noise from machinery
processes and equipment is not correctly eliminated or controlled, it may cause permanent hearing loss
in workers. The, so called, inner ear is very fragile part of our hearing sense, which with current knowledge
in medicine, cannot be truly repaired. Therefore it is of great importance to protect our senses from
excessive noise. Exposure to high levels of noise may also create physical and psychological stress, reduce
productivity and interfere with normal communications. This may lead to accidents and injuries by making it
difficult to hear moving equipment, other workers, and warning signals. Undoubtedly hearing loss has a very
significant impact on the quality of life for many workers and their families.
Therefore measuring noise exposure in the workplace is fundamental part of all good hearing
conservation and noise reduction programs. The aim of taking a measurement with a noise dosimeter is to
evaluate the average exposure of employees to noise during a normal shift. Wherever the worker goes the
noise dosimeter goes too so that it captures all of the harmful noise during the typical day.
The dosimeter may be worn for the complete shift if the work pattern is so variable that it is difficult to
predict exactly what will occur or it may be worn for a shorter but representative period and then the full day’s
dose extrapolated from that sample.

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
10
1.3 Standards
The effects of high sound exposure on hearing have been studied for many years. As far back in 1954
AIHA (American Industrial Hygiene Association) –Rosenwinkel & Stewart –described a “new device which
integrates sound energy over finite time periods.”In 1956 –von Witternand & von Gierke obtained a patent
for a noise exposure meter for “indicating the total time that noise exceeded a certain predetermined levels.”
Since then, measurements could be conducted over long periods of time and the instrument was worn by
personnel under normal work conditions.
Finally, organizations developed standards to regulate personal noise exposure. International
standards are specified by health and safety regulations such as the European Union Parliament and
Council Directive 2003/10/EC of February 6, 2003 on minimum health and safety requirements regarding the
exposure of workers to the risks arising from physical agents (noise) or International Electrotechnical
Commission IEC-61252 guidelines. The EU directive links to the ISO 9612-2009 Acoustics –Determination
of occupational noise exposure –Engineering method.
In the United States, the Occupational Safety and Health Administration (OSHA) 29 Code of Federal
Regulations (CFR) 1910 General Industry Regulations: Standard No. 1910.95 Occupational noise exposure,
the Mine Safety and Health Administration (MSHA), and the American Conference of Governmental
Industrial Hygienists (ACGIH) have created slightly different regulations and limitations on tolerable noise
exposure. Noise requirements are to ensure that the hazards associated with the exposure of workers to
noise are eliminated or properly controlled.
Organization
Website address
ISO
http://www.iso.org
IEC
http://www.iec.ch
OSHA
http://www.osha.gov
MSHA
http://www.msha.gov
NIOSH
http://www.cdc.gov/niosh
ACGIH
http://www.acgih.org
CCOHS
http://www.ccohs.ca
…
Table 1-2 Standardization organizations’ websites
Additionally, at present dosimeters should meet relevant accuracy and performance requirements
defined by:
- IEC 61252
- ANSI S1.25

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
11
1.4 Applications
The SV 104 noise dosimeter is extremely well suited to ISO, OSHA, ACGIH, MSHA, NIOSH,
workplace noise measurements in noise exposure assessments. The dosimeter comes with pre-defined
setups that suit different measurement requirements and offer versatile possibilities to be specifically
configured by the user for special requirements if needed:
- Measurement and control of the industrial noise
- work site assessments
- sites/plants/facilities survey monitoring systems
- hearing conservation compliance
- transportation noise studies
- personal noise verifications
- peak dosimeter for example in military applications
One of the most desirable SV104 feature is the unique data logging function that stores significant
number of noise parameters at regular intervals and superimposed random vibration shock or audio events
during a run.
Noise profiled results can be easily transferred to the Supervisor or SvanPC+ software packages.
The noisiest times can be immediately seen in the graphical report and actions directed to the appropriate
area. This makes checking for different regulatory bodies’ compliance and ensuring if hearing conservation
programs are needed definitely easier than ever before. The SV 104 answers all the important questions
such as WHEN? and HOW? did the noise exposure appear? The data logging measurements can be started
immediately or they can be pre-programmed in advance so that measurement run can begin and end
automatically at a preset start and end time without the need for any onsite supervision.
Additionally the SV 104 allows for custom voice note comments to be added before or after
the measurement run, and therefore this is the ideal instrument for the professional occupational hygienist to
use for all noise exposure studies.

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
12
1.5 Measurement procedures
Preferably, when taking measurements, the noise dosimeter should be attached to the employee at
the start of a shift and collected at the end of the whole shift. In case a shorter period is sampled then care
should be taken to ensure that the result is representative of the full shift exposure. Shorter sampled periods
require that the sampler has a deep and full understanding of the expected working tasks during the shift and
the duration cycles of those tasks.
Before performing any noise measurements, ensure that employees selected for evaluation are
operating equipment or performing tasks under normal (representative) conditions, and emphasise the
importance of continuing to work in their usual manner (wearing the dosimeter should not interfere with
normal duties). Explain the purpose and procedures of sampling to the employee who will be wearing the
dosimeter and the importance of not touching, tapping or interfering with the microphone. Instruct the
employee not to remove the dosimeter unless absolutely necessary.
The general procedure for taking measurements could be as follows:
1. Check that the indicated instrument battery life is at least twice the time required for the
measuring period
2. Check the instrument setup mode is appropriate and change if necessary
3. Check the calibration of the instrument and adjust the settings if required
4. Secure the instrument onto the shoulder of the employee selected for sampling. Refer to the
chapter with specific requirements regarding orientation of the microphone
5. Start the recording session manually if it is not programmed for an automatic timed start
6. At the end of the measurement period, stop the recording session, and remove the dosimeter
from the employee
7. Recheck the dosimeter’s calibration. If the instrument is not within the calibration limits then
the results are invalid (usually if a discrepancy is found between two successive checks of
more than ± 0.5dB in the reference level, then the results of the measurements taken between
the two checks should be considered invalid and the cause investigated and the measurement
repeated).
8. Follow your organisation’s specific procedure for personal noise exposure recordings analysis
9. Ensure the report is submitted to the appropriate person
10. Distribute copies of noise exposure recordings to test participants, explain the results and
ensure that their hearing protection adequately protects against the recorded noise exposure
levels.

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
13
2KIT COMPONENTS
2.1 SV 104 dosimeter short form specification
Acoustic Dosimeter conforming to international standards IEC 61252; ANSI S1.25;
Class 2 Microphone, MEMS type: SV27, 1/2" housing
OLED colour display with super brightness and contrast
Large 8GB memory
USB 2.0 high speed interface
Parallel Slow, Fast, Impulse detectors for the measurements with A, C, Zfilters
Frequency Range 30 Hz ÷ 8 kHz
Measurement range 55 dBA RMS ÷ 140.1 dBA Peak
Dynamic Range 80 dB
Exchange rates 2, 3, 4, 5, 6
Measurement results: Run Time, Lpeak, Lmax, Lmin, Lp, DOSE (%), D_8h, PrDOSE, Lav, Leq,
LAV, LE, SEL8, E, E_8h, LEPd, PSEL, Ltm3, Ltm5, Lstat, PTC, PTP, ULT, TWA, PrTWA, Lc-a
3independent user configurable acoustic measurement profiles
Easy in use predefined setups
Time-history data logging of Leq/Lav/Lmax/Lmin/Lpeak with variable 0.1 s to 1 hr logger step and
separate summary results intervals with statistical levels
1/1 Octave real time analysis - 9 filters with centre frequencies 31 Hz ÷ 8 kHz, Type 2 –IEC 1260;
presented as a bar graph with Leq and Lmax band levels plus overall A, C and Z broadband
weightings (as option called SF 104-OCT)
Audio events recording, triggered and continuous mode, 12/24 kHz sampling rate, wav format (as
option called SF 104-WAV)
Voice Comments records audio on demand, created before or after measurement, added to
measurement file
Vibration shock detector with user selectable variable threshold: 1g-15g
Automatic acoustic field calibration with one touch activation before and after measurement
Operational time > 40 hours (display off, octave analysis off)
Extremely compact, light weight and robust case with IP65 ingress protection
Figure 2-1 SV 104 instrument with the microphone and windshield

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
14
2.2 Accessories included
SV 27 - ½” MEMS microphone for SV 104 dosimeter
SA 122 - windshield
SC 156 - micro USB 2.0 cable
CD with instruction
Built-in rechargeable batteries (charger/ power supply wall adapter not included)
2.3 Accessories available
SV 27 –½” MEMS microphone for SV 104 dosimeter
SA 122_3 –Windscreens for SV 104 dosimeter 3 pcs per pack
SV 34 –Class 2 acoustic calibrator: 1000Hz/114dB
SC 156 –micro USB 2.0 cable
SA 54 –Charger/power supply for 1 x SV 104
SA 73 - Carrying case for 5 x SV 104 dosimeters and accessories (waterproof)
SA 156 –USB HUB for charging and data download from 5 x SV104 dosimeters
Supervisor Software for configuration, viewing and exporting data, USB drivers (MS Windows XP,
Vista, Windows 7) for 32 and 64 bit operating systems available as freeware
2.4 Instrument Software (Firmware) options available
SF 104 OCT 1/1 –real time 9 band 1/1 Octave analysis option
SF 104 WAV –Audio events recording option
Notice: The software options can be purchased in any time as only the introduction of a special
code is required for their activation.

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
15
3GETTING STARTED
3.1 System description
The following Figure 3-1 shows the SV 104 controls and ports:
Figure 3-1 SV 104 at a glance
Colour display
128 x 64 pixel resolution
LED status indicator
AMBER: stop mode
GREEN: measuring
RED: alarm

SV 27 microphone
with SA 122 windshield
Mounting
accessories
suspender clips
Keypad
Three control keys:
SCROLL
PROFILE
ENTER

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
16
3.2 Input output interfaces description
SV 104 instrument is equipped with a set of useful interfaces:
microphone connector (essential for measuring)
micro USB connector (charging, and data download)
charging connector (reserved for future use)
fast infrared port (reserved for future use)
Figure 3-2 SV 104 side view –microphone and micro USB connector
Figure 3-3 SV 104 back view - charging and infrared port (reserved for future use)
infrared
port
charging
connector
micro USB
connector
microphone
mounting head

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
17
3.3 The windshield
During use, it is strongly recommended that the SV104 is fitted with the supplied SA 122 windshield.
To calibrate the dosimeter it is necessary to remove the windshield to gain access to the microphone. It is
not necessary to remove the windshield to record the voice note comments.
The SV 104 uses an innovative windshield magnetic technique to fit tightly onto the microphone
housing. To remove the windshield just put more force holding the lower half of the foam and lift the
windshield off the microphone housing. Once the SV 104 has been calibrated, refit the windshield
by carefully placing it back over the microphone again.
Figure 3-4 SA 122 windshield
3.4 The mounting clips
Upon delivery, the SV 104 will be fitted with the standard mounting clips. Mounting clips can be easily
changed using just hand force.
Figure 3-5 SV 104 standard mounting clips

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
18
3.5 LED status indicator
There is a three-colour instrument LED status indicator on the SV 104, located to the right
of the microphone mounting head and above the display. Table 3-1 explains conditions under which
the specific LED colour appears.
LED status indication
Description
GREEN flashing
once per second
Indicates the dosimeter is running and has not exceeded
the alarm level.
AMBER flashing
once per over a dozen seconds
Indicates the dosimeter is stopped and has not exceeded
the dose alarm level.
RED single isolated flashes
with a duration of nominally one second
Indicates vibration shock threshold has been detected.
This will go off once the high vibration shock has ceased.
RED flashing quickly,
four times per second
Indicates the alarm conditions:
for instance: the dose has exceeded the alarm level.
Table 3-1 LED status description
3.6 Status bar icons
The upper part of the display is designed as basic status information provider. See the description
below.
Figure 3-6 SV 104 display icons description
current
ACOUSTIC
PROFILE
number
LOGGER
activation
indicator
UNDER-RANGE
indicator
MEASUREMENT RUN
flashing indicator
BATTERY
STATUS
indicator
incremental
flashing during
charging
CURRENT TIME
when in stopped mode or
MEASURMENT TIME
during measurement run.
OVERLOAD
indicator
EVENT or WAVE
recording
activation
indicator

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
19
3.7 Manual control of the instrument
Although the Instrument is small, its keypad is designed to be minimal, but still highly ergonomic
and easy to use providing effective operational capabilities. Thanks to that, the number of the control push-
buttons of the instrument is reduced to only three.
Generally the user can operate the instrument by:
- change the VIEW2mode with the <ENTER> key
- select the required ACOUSTIC PROFILE3with the <PROFILE> key
- and SCROLL thru the results with the <SCROLL> key
Notice: To save power consumption and extend battery life SV 104 will automatically switch off
the display after 30 seconds if no button on the keypad is pressed. The LED indicator will still inform the user
about the current state of operation and any possible alarm conditions. Press any key, to reactivate the
display.
2See chapter 3.9 about VIEW modes
3See chapter 3.8 about “3in1” functionality (3 independent acoustic profiles)

SV 104 USER'S MANUAL_DRAFT_______________________________________________
_
20
3.7.1 Primary key functions
On the front panel of the instrument the following control push-buttons are located. See below for
primary (short press) key functions description:
Figure 3-7 Control keypad on the front panel –primary key functions
<PROFILE> key
change presented
ACOUSTIC PROFILE,
1, 2, 3, 1, etc.
<SCROLL> key
scroll down thru
RESULTS
<ENTER> key
Change VIEW mode
(see chapter 3.9)
ACOUSTIC PROFILE
number and status bar
RESULTS
