ENG
7
GC-W400
User Manual
X-INPUT MODE
Connect the steering wheel to your PC. D-input mode
is enabled by default. Press and hold the MODE button
for 3 seconds - the steering wheel will switch to X-input
mode. During mode switching, the red LED will blink
three times.
• Go to «control panel» menu, then click on «devices and
printers» icon, in the window that opens, select «LS-USB-
MX 1/2/3 Steering Wheel W/Vibration», shortcut, right-
click on «Game controllers settings» (see Fig. 8).
• Press «Properties» button in the window that opens
(see Fig. 9) you can check the operation of the axes and
keys. The «Parameters» tab allows you to calibrate the
steering wheel.
9. REMAPPING BUTTON
Source keys: 1,2,3,4,5,6,7,8
• Reassignable Keys: left petal (Y-), right petal (Y+),
brake pedal (Y-), gas pedal (Y+).
• Hold the 9 + 10 key at the same time for 3 seconds,
the green LED indicator will ash quickly.
• Press the reassignable key (for which you want to
change the value), the green LED will ash slowly.
• Press the programming key, the green LED will turn
o, programming is complete.
Setting the default key value
• Hold 9 + 10 keys at the same time for 3 seconds, the
green LED indicator will ash quickly.
• Press the reassignable key (right / left paddle, brake
or accelerator pedal), the green LED will ash slowly.
• Press the reassignable key again, the green LED will
turn o.
Reset all buttons to their default values
• Hold 9 + 10 keys at the same time for 3 seconds,
the green LED indicator will ash quickly.
• Hold the 10 key for 4 seconds, the green LED is o
and all programmed key functions are cleared.
The reassigned buttons retain their properties until the steering wheel is disconnected from
the PC. When you reconnect the steering wheel, the button values are set to default.
Fig. 8
Fig. 9
