Svive Halo S650 User manual

USER MANUAL
SVIVE S650 HALO CHASSIS

Model Svive Halo S650
Materials Chassis 0.6 mm SPCC, tempered
glass on le side panel
Motherboard suppo EATX(272*305), ATX, M-ATX, ITX
PSU type ATX PSU (Boom located)
TOP panel I/O pos USB3.1*1, USB3.0*2, HD Audio,
Light control
HDD bay 3.5” HDD*2, 2.5” SSD*2
Expansion Slots 7 slots, Suppo up to 360mm
(Max.) VGA card
CPU Cooler Height 170mm
Fan Cooler Front: 2*120mm or 2*140mm Fan
Top: 2*120mm or 2*140mm Fan
Rear: 1*120mm
Liquid cooling Front: 120/140/240/280 water
cooling radiator
Top: 120/140/240/280 water
cooling radiator
Rear: 1*120mm
Chassis size (L)390 x (W)210 x (H)445mm
Case size (L)438 x (W)210 x (H)468mm
CASE SPECIFICATION INTRODUCTION
Le side
Front To p Rear
Right side
1
2
3
4
6
7
9
10
11
12
13
14
15
16
17
5
8
1. Chassis main body
2. Le tempered glass side panel
3. Right side panel
4. Power supply box
5. Boom plate dust filter
6. Mute cover plate
7. SSD bracket
8. RGB control box
9. HDD bracket
10. VGA card bracket
11. VGA card installation position
12. Rear fan installation position
13. LED strips
14. Front fan installation position
15. Cable protective rubber
16. Side panel dust filter
17. Cable cleat
CHASSIS BREAKDOWN DRAWINGS

( )
screws
screws
( )
I/O PORTS INTRODUCTIONS SIDE PANEL INSTALLATION
1. Power Switch 2. RGB brightness 3. RGB color/mode 4. Audio in/out 5. USB Type-C™ 6. USB 3.0 7. USB 2.0
1. Unscrew the drop-proof screws (1), pull out the right side
panel toward to the arrowhead direction.
2. Unscrew the drop-proof screws (1), pull out the top of
the glas panel and li it from the frame. Handle the glas
panel gently to avoid any damage.
21 3 4 5 6 7

POWER SUPPLY INSTALLATION
1. Remove the right side panel and inse PSU.
2. Fix the screws.
MOTHERBOARD INSTALLATION
9 pre-installed motherboard spacers in factory
seing.
Align the motherboard according to the spacers and rear I/O
panel and mount it with the provided screws.
HDD INSTALLATION SSD INSTALLATION
Remove the front panel by pulling firmly in the boom of the
panel. A. Remove the screws,
remove the SSD bracket.
B. Mount the SSD to the
bracket.
C. Reaach the bracket into the
chassis near to top and le edge
of the M/B bracket.
D. Remember to secure the
brackets with the screws.
Fix the HDD into the HDD tool-less bracket according to
step 1/2 then inse the HDD bracket into the slots.

DUST FILTER DISASSEMBLY
FAN COOLER AND LIQUID COOLER INSTALLATION
Boom dust filter can be
disassembled by pulling it
gentlyfrom the front of the
case. Inse in same direction
for reassembly.
Fan suppo:
Front: 120mm x2 or140mm x2
Top: 120mm x2 or140mm x2
Rear: 120mm x1
Liquid cooling suppo:
Front: 120/140/240/280mm
Top: 120/140/240/280mm
Rear: 120mm x1
RGB CONTROLLER
Controller functions
The controller can be controlled by mainboard (MB mode) or by
the control switches on the front panel (Switch mode). When the
controller is connected to a ARGB header on a mainboard it is in
MB mode and is controlled by the computer. When the controller
is not connected to a mainboard it is in Switch mode and is then
controlled by the switches on the front panel.
How to control modes, colors and brightness in Switch mode;
- sho-press Mode Switch one time to change color modes
- sho-press Mode Switch two times to change color
- sho-press Brightness Switch one time to change brightness
Installation;
- make sure to shut down the system before you sta
- connect an available SATA power connector to
the SATA POWER input
- connect a cable from the ARGB input to an ARGB header
on the mainboard (if available)
- connect the cable from the control switches on the front panel
to the SW input
- connect the desired ARGB fans, components or strips
to the controller
- boot your system

Impoed by Svive, Østre Kullerød 4,
N-3241 Sandeord, Norway
www.svive.gg
