Swann Retro SP21060 User manual

v1.0
Stand Mixer
Model: SP21060 (all colours)
Help line: 0333 220 6050
800 Watt
SP21060_IM.indd 1 18/11/2020 12:14

2
When using any electrical appliance, basic safety
precautions should always be followed including the
following:
• Always ensure that the voltage on the rating label
corresponds to the mains voltage in your home
• Incorrect operation and improper use can damage the
appliance and cause injury to the user.
• This appliance can be used by children aged from 8
years and above if they have been given supervision or
instruction concerning use of the appliance in a safe way
and if they understand the hazards involved.
• Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
Keep the appliance and its cord out of reach of children
aged less than 8 years.
• Check the power cord and plug regularly for any damage.
If the cord or the plug is damaged, it must be replaced by
the manufacturer or qualified person in order to avoid an
electrical hazard.
• Do not use the appliance if it has been dropped or
damaged in any way. In case of damage, take the unit in
for examination and/or repair by an authorised service
agent.
• Never immerse the unit in water or any other liquid for
cleaning purposes.
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
SP21060_IM.indd 2 18/11/2020 12:14

3
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
• Remove the plug from the socket by gripping the plug.
Do not pull on the cord to disconnect the appliance from
the mains. Always unplug the unit when not in use, before
cleaning or when adding or removing parts.
• The use of accessory attachments that are not
recommended or supplied by the manufacturer may
result in injuries, fire or electric shock.
• Do not let the cord hang over the edge of a table or
counter. Ensure that the cord is not in a position where it
can be pulled on inadvertently.
• Do not allow the cord to touch hot surfaces and do not
place on or near a hot gas or electric burner or in a
heated oven.
• Do not use the appliance on a gas or electric cooking top
or over or near an open flame.
• Use of an extension cord with this appliance is not
recommended. However, if it is necessary to use an
extension lead, ensure that the lead is suited to the power
consumption of the appliance to avoid overheating of
extension cord, appliance or plug point. Do not place the
extension cord in a position where it can be pulled on by
children or animals or tripped over.
• This appliance is not suitable for outdoor use. Do not use
the appliance for anything other than its intended use.
• Do not carry the appliance by the power cord.
• Do not leave the appliance unattended during use. Always
unplug the unit when not in use or before cleaning.
• Always operate the appliance on a smooth, even, stable
SP21060_IM.indd 3 18/11/2020 12:14

4
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
surface that can withstand the weight of the product. Do
not place the unit on a hot surface.
• Ensure that the unit is switched off after use.
• The manufacturer does not accept responsibility for any
damage or injury caused by improper or incorrect use, or
for repairs carried out by unauthorised personnel.
• In case of technical problems, switch off the product and
do not attempt to repair it yourself. Return the appliance to
an authorised service facility for examination, adjustment
or repair. Always insist on the use of original spare parts.
Failure to comply with the above mentions precautions
and instructions, could affect the safe operation of this
product.
• Your appliance must never be switched on through an
external timer or any kind of separate remote control
system
• This appliance is intended to be used in household and
similar applications such as: staff kitchen areas, in shops,
offices and other working environments; farm houses;
by clients in hotels, motels and other residential type
environments; bed and breakfast type environments.
• Do not touch moving parts with fingers or any utensil
during operation!
SP21060_IM.indd 4 18/11/2020 12:14

5
Description800W Mixer & Bowl
Model: SP21060 (all colours)
Input Voltage: 220-240V
Frequency: 50/60Hz
Power consumption: 800 Watts
Weight: 7kg. Bowl capacity: 4.0L
TECHNICAL DATA
PARTS OVERVIEW
1. Multifunction head
2. Splash guard
3. Stainless steel bowl (Max. capacity:
4L )
4. Release button for multifunction
head
5. Speed control switch
6. Mixer attachment
7. Dough hook attachment
8. Whisk attachment
SP21060_IM.indd 5 18/11/2020 12:14

6
HOW TO USE
BEFORE FIRST USE
Remove all packaging. Wash the bowl and accessories in warm, soapy water. Rinse
and dry thoroughly.
Cleaning the components is a good opportunity to familiarise yourself with
assembling the mixer, correctly, fitting the bowl/guard and fitting or removing the
mixer attachments.
TAKE CARE WHEN HANDLING THE BOWL, ESPECIALLY WHEN WET.
REPLACEMENTS ARE EXPENSIVE!
Turn the release Lever (4) clockwise and tilt the multi-function head (1)upward. To
fit the bowl, (3) place it over the base and turn clockwise to lock it into place. Mixing
attachments (6, 7, 8) are fitted and removed by placing them over the Control Shaft
(3). Push and turn clockwise to fit. Turn anti-clockwise and pull to remove.
NOTE: THE MOTOR WILL NOT RUN WHEN THE ARM IS IN THE UP POSITION
8 Whisk ATTACHMENT
Eggs - Maximum quantity 20 Eggs. Use this accessory for creams
with low consistency, sauces, mayonnaise, to beat cream, eggs,
liquids, egg whites, etc. Can be used at all speeds Be mindful that
some splashing can occur. Use the Splash Protection Lid (8) where
necessary. Typical use time: 3-5 minutes.
6 Mixer ATTACHMENT
Soft yeast dough - Maximum quantity 2000 g
Use this accessory for semi-hard doughs, sauces, medium-consist-
ency creams, chocolate based doughs, whipped pastry doughs, etc.
Use speed 1-5. Typical use time 60 seconds or less.
7 DOUGH HOOK ATTACHMENT
Maximum quantity 1000 g. Use this accessory for flour-based
doughs, such as breads and pizza’s dough etc, short pastry, cookies’
dough, etc. Use speeds 1-3 for up to 4 minutes
Select the desired attachment depending on the mixing task to be
performed:
SP21060_IM.indd 6 18/11/2020 12:14

7
HOW TO USE
PLEASE FOLLOW THE MIXING TIMES AND INGREDIENT WEIGHTS FOR EACH
ATTACHMENT ABOVE. IGNORING THEM COULD DAMAGE THE MOTOR AND
INVALIDATE THE WARRANTY
• If the motor stops or struggles to start immediately turn the mixer off and
inspect the dough. It is probably too heavy
• Do not use the appliance for more than 7-8 consecutive minutes
TIPS
For a good result it’s necessary to respect some basic rules. Here are some tips
which can be applied to most of the recipes you’re going to prepare.
• Always use clean accessories; when beating egg whites, even a small grease
residue could prevent a good result.
• When using eggs, make sure they’re very fresh and at ambient temperature.
• Slice/dice/soften ingredients like butter or margarine to ease their process-
ing.
• Add the ingredients to the dough delicately, in order to not unduly interrupt the
performed processing.
• Start processing at speed “1” to amalgamate the ingredients, to avoid liquid
splashes, then gradually increase speed according to the type of processing
being done
• Do not exceed the maximum advised capacities or running times.
ALWAYS USE THE SPLASH GUARD, ESPECIALLY WHEN
MIXING HOT INGREDIENTS
SP21060_IM.indd 7 18/11/2020 12:14

8
• Disconnect from mains power supply before cleaning.
• Do not submerge the appliance in water. This may lead to electric shock
or fire.
• Do not use a wire brush or other abrasive utensils for cleaning.
• Do not use aggressive or abrasive cleaning agents.
• Motor housing: Clean the housing only with a damp cloth and a squirt of
washing-up liquid.
• The attachments areNOT suitable for dishwasher. Heat
and aggressive cleaning agents may warp or discolour the
attachments.
• Parts which have come into contact with food can be rinsed out with
water
• Leave the parts to dry properly before re-assembling the appliance.
TAKE EXTRA CARE WHEN HANDLING THE BOWL,
ESPECIALLY WHEN WET
CLEANING
SP21060_IM.indd 8 18/11/2020 12:14

9
WARRANTY
This product is guaranteed for 2 years from the date of original purchase. If
any defect arises due to faulty materials of workmanship the faulty products
must be returned to the place of purchase. Refunds or replacement is at the
discretion of the store.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions
contained in this instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• Swan Products Ltd has limited liability for incidental or consequential loss
or damage.
• This guarantee is valid in the UK and Eire Only.
The wires in the mains lead are coloured in accordance with the following
code:
BLUE NEUTRAL
BROWN LIVE
As the colours of the wire in the mains lead of this appliance may not
correspond with the colour markings identifying the terminals on your plug,
proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which
is marked with the letter N or coloured black. The wire which is coloured
BROWN must be connected to the terminal which is marked with the letter
L or coloured red.
WARNING: THIS APPLIANCE IS DOUBLE INSULATED. DO NOT CONNECT
ANY WIRE TO THE EARTH TERMINAL
BS PLUG
SP21060_IM.indd 9 18/11/2020 12:14

10
DISPOSAL OF UNIT
Appliances bearing the symbol shown here may not be disposed of
in domestic rubbish. You are required to dispose of old electrical
and electronic appliances like this separately. Please visit www.
recycle-more.co.uk or www.recyclenow.co.uk for access to information
about the recycling of electrical items. Please visit www.weeeireland.ie
for access to information about the recycling of electrical items purchased
in Ireland. The WEEE directive, introduced in August 2006, states that all
electrical items must be recycled, rather than taken to landfill. Please arrange
to take this appliance to your local Civic Amenity site for recycling, once it has
reached the end of its life.
PARTS/ACCESSORY ORDERING
When ordering spare parts/accessories, use the references below:
SP21060N-02: Splash Guard
SP21060N-03 Bowl
SP21060N-06Mixer attachment
SP33010N-08 Whisk attachment
SP21060N-07 Dough Hook attchment
SP21060_IM.indd 10 18/11/2020 12:14

11
NOTES
SP21060_IM.indd 11 18/11/2020 12:14

www.swan-brand.co.uk
Copyright © Swan Products Ltd.
PO Box 3117, Stoke-on-Trent ST4 9GD
