Swann Eureka MULTI-CLEAN SC15810N User manual

MULTI-CLEAN
Model: SC15810N
MULTI-CLEAN PET
Model: SC15812N
Help line: 0333 220 6050 v1.0
CYLINDER VACUUM
SC15810_12_IM.indd 1 15/10/2018 12:14

2
When using an electrical appliance, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
WARNING
IMPORTANT SAFEGUARDS
!Follow caution information wherever you see this symbol.
This vacuum cleaner is intended for household use only and NOT for
commercial or industrial use.
• Only use the vacuum cleaner indoors on dry surfaces and keep the
area you’re cleaning well lit.
• Keep fingers, hair and loose clothing away from moving parts and
openings whilst using the vacuum cleaner.
• Use only Eureka | Swan recommended tools and accessories with
this vacuum cleaner.
• Don’t use the vacuum cleaner if it has been dropped, damaged or
left outdoors.
• Don’t run over the power cord or use the vacuum cleaner if the
power cord or plug is damaged.
• Don’t handle the plug or use the vacuum cleaner with wet hands.
• Don’t pull or carry the vacuum cleaner by the power cord.
• Don’t use the power cord as a handle, pull the power cord around
corners, sharp edges or close a door over the power cord.
• Don’t unplug vacuum cleaner by pulling on the power cord.
• Turn off all controls on the vacuum cleaner before disconnecting or
connecting the power cord.
• Always make sure the filters are in place before use.
• Always switch off the vacuum cleaner before disconnecting or
connecting the hose and accessories.
• Keep all openings clear and free from debris as this may affect the
air flow/suction.
• Always replace the fuse in the plug with a British 13 amp fuse.
SC15810_12_IM.indd 2 15/10/2018 12:14

3
IMPORTANT SAFEGUARDS
• Always protect the power cable from heated surfaces and open
flames.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the vacuum cleaner in
a safe way and understand the hazards involved. Children shall not
play with the vacuum cleaner. Cleaning and user maintenance shall
not be made by children without supervision.
• Don’t vacuum up any flammable or combustible materials (lighter
fluid, petrol, kerosene etc.) or use the vacuum cleaner in an area
with explosive vapours or liquid.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking
hot, burning items or use in an area where there may be harmful
fluids (chlorine, bleach, and ammonia drain cleaner).
• Don’t attempt to remove blockages with sharp objects as this may
cause damage to the vacuum cleaner.
• Don’t vacuum up hard or sharp objects such as glass, nails, screws
or coins etc.
• Don’t use the vacuum cleaner with incorrect voltage as this may
result in damage or injury to the user. The correct voltage is listed
on the rating label.
• Take extra care when positioning and using the vacuum cleaner on
the stairs.
• Use only CE marked 13 amp extension cords, non-approved
extension cords may overheat. Care should be taken to arrange
the extension cord as it can be a trip hazard.
• Store the vacuum cleaner in a cool, dry area. If filters have been
cleaned as per user guide instructions ensure they are thoroughly
dry before storing away.
Please keep instructions for future reference
SC15810_12_IM.indd 3 15/10/2018 12:14

4
Carefully unpack and inspect your new Eureka | Swan vacuum cleaner for shipping
damage.
Each unit is tested and thoroughly inspected before shipping. For instructions
regarding any shipping damage, call the Eureka | Swan Customer Service HELPLINE
at 0333 220 6050 immediately.
UNPACKING
! Make sure your vacuum cleaner is switched off and
unplugged when cleaning, removing or refitting parts.
SC15810_12_IM.indd 4 15/10/2018 12:14

5
WHAT’S IN THE BOX
Hose
Extension tube
Main brush
Main body
Push for
cord retract
Push for
power on/off
Pull to
extend cord
Remove the
dust tank
Push
Open the dust tank Remove the
filter cotton
Clean the
filter cotton
Remove
Crevice tool
Pet turbo tool
SC15812N model only Dusting brush
SC15810_12_IM.indd 5 15/10/2018 12:14

6
GET TO KNOW YOUR VACUUM
Hose
Extension tube
Main brush
Main body
Push for
cord retract
Push for
power on/off
Pull to
extend cord
Remove the
dust tank
Push
Open the dust tank Remove the
filter cotton
Clean the
filter cotton
Remove
1. Pull out the power
cord and connect to
mains supply. there
is a red mark on the
cord to indicate it is at
maximum extension
2. Push the power
button to switch the
vacuum cleaner on
or off
3. After unplugging,
press the cord
retract button. Take
care as cord is
retracting. Keep away
from fragile items or
pets!
Hose
Extension tube
Main brush
Main body
Push for
cord retract
Push for
power on/off
Pull to
extend cord
Remove the
dust tank
Push
Open the dust tank Remove the
filter cotton
Clean the
filter cotton
Remove
How to remove and empty
the dust tank
1. Gently lift the handle
of the dust tank
2. Push the release
button and carefully
empty the tank over
the bin. Keep it close
to the bin to prevent
overspill.
3. Clean the filter
cotton periodically
to maintain best
performance.
4. Open the dust tank at
the top. Remove and
wash the filter cotton.
5. Ensure it is
COMPLETELY dry
before refitting.
SC15810_12_IM.indd 6 15/10/2018 12:14

7
GET TO KNOW YOUR VACUUM
Hose
Extension tube
Main brush
Main body
Push for
cord retract
Push for
power on/off
Pull to
extend cord
Remove the
dust tank
Push
Open the dust tank Remove the
filter cotton
Clean the
filter cotton
Remove
Periodically remove and
clean the filter assembly.
PLEASE NOTE: it must be
COMPLETELY dry before
refitting.
Water inside the vacuum
could cause malfunction.
Remove the
dust tank
Push
Push
1
Dust tank maintenance
Open the dust tank: Gently lift the
dust tank open button, and then lift
up to open the dust tank cover.
Remove the filter cotton for
cleaning: Open the dust tank, remove
the filter cotton and clean it.
Clean the filter cottonSeparate
Filter disassembly and cleaning: Raise the filter and remove the filter cover,
put the filter and its bottom cover under the tap for washing.
Take out the filter Separate
1. The filter parts can be put back for use only after being cleaned and dried thoroughly.
2. All parts must be properly installed, otherwise it will cause product failure.
3. Water is not allowed to penetrate into the vacuum cleaner electrical components, or otherwise
may cause product failure.
Illustration of the main unit
Pull out the power cord to connect the power
supply:When you see the red mark on the power
cord, do not pull the power cord outward.
Press the ON/OFF button:Control the start
and stop of the vacuum cleaner.
Press the take up button: The power cord
is automatically rolled back into the machine.
1
2
3
Push
2
1
Push
3
Pull
Main Brush. Step down the pedal of main brush to extend or
retract the bristles. As a general rule: extended for hard floor,
retract for carpeted floors.
Pet Turbo Tool (SC15812N only) Connect to end of the hose
in place of the Main Brush to make short work of pet hairs etc.
TROUBLESHOOTING
• Empty dust tank and clean the filters.
• Remove anything that may be clogging the tubes or main brush
THE VACUUM MUST BE SWITCHED OFF WHEN REMOVING DEBRIS
Problem Solution
Motor will not start
Not enough
suction power
• Make sure cleaner is connected to mains supply
SC15810_12_IM.indd 7 15/10/2018 12:14

8
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You
are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information
about the recycling of electrical items. Please visit www.weeeireland.ie for access to information
about the recycling of electrical items purchased in Ireland. The WEEE directive, introduced in
August 2006, states that all electrical items must be recycled, rather than taken to landfill. Please arrange
to take this appliance to your local Civic Amenity site for recycling, once it has reached the end of its life.
DISPOSAL
TECHNICAL DATA
SC15810N
Performance
• Dust bin capacity: 2 Litres
• Energy class: A
• Dust pick-up on hard floor: A
• Dust pick-up on carpet: D
• Dust re-emission: A
• Motor power: 700 Watts
• Sound level: 79dBA
• Cleaning radius: 8 Metres
Accessories
• 1 x Main brush
• 1 x 1.5m hose
• 1 x 78cm telescopic metal tube
• 1 x Crevice tool and dusting brush
Weight & Dimensions
• Net weight: 4kg
• Product size (LxWxH): 36 x 25 x 31cm
• Power cord length: 5 Metres
SC15812N
Performance
• Dust bin capacity: 2 Litres
• Energy class: A
• Dust pick-up on hard floor: A
• Dust pick-up on carpet: D
• Dust re-emission: A
• Motor power: 700 Watts
• Sound level: 79dBA
• Cleaning radius: 8 Metres
•
Accessories
• 1 x Main brush
• 1 x Pet turbo tool
• 1 x 1.5m hose
• 1 x 78cm telescopic metal tube
• 1 x Crevice tool and dusting brush
Weight & Dimensions
• Net weight: 4kg
• Product size (LxWxH): 36 x 25 x 31cm
• Power cord length: 5 Metres
SC15810_12_IM.indd 8 15/10/2018 12:14

9
SPARES
Dust cyclone cover
Hose
Main brush
Outlet HEPA filter
Tube
Turbo pet head
SC15810N-01
SC15810N-02
SC15810N-03
SC15810N-04
SC15810N-05
SC15812N-01
www.eureka-swan.co.uk
Dusting tool SC15810N-07
Crevice tool SC15810N-06
SC15810_12_IM.indd 9 15/10/2018 12:14

10
This product is guaranteed for 2 years from the date of original purchase. If any defect arises due to faulty
materials of workmanship the faulty products must be returned to the place of purchase. Refunds or
replacement is at the discretion of the store.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• Swan Products Ltd has limited liability for incidental or consequential loss or damage.
• This guarantee is valid in the UK and Eire Only.
WARRANTY
