Sweet Fountains SF PRO Series User manual

Chocolate Fountain
User Guide
This manual covers the use of the following
commercial fountain models:
SF-PRO-31 | SF-PRO-43 | SF-PRO-50

SF-PRO-31; SF-PRO-34C; SF-PRO-38; SF-PRO-44C; SF-PRO-50
SOME IMPORTANT NOTES ABOUT YOUR NEW SF PRO
SERIES CHOCOLATE FOUNTAIN - PLEASE KEEP FOR
FUTURE REFERENCE
NOT FOLLOWING THESE TIPS WILL VOID WARRANTY
• *BEARINGS SHOULD BE CHANGED EVERY 500 HOURS OR IF THEY
CAN’T TURN BY HAND WITH BOWL REMOVED FROM BASE*
• DO NOT WASH BOWL IN DISHWASHER (can force water into bearings)
• DO NOT TURN ON WITH HARDENED CHOCOLATE IN UNIT EVER
• DO NOT EVER LIFT FOUNTAIN BY BOWL (pickup by base)
• DO NOT REMOVE BOWL WHILE MOTOR IS RUNNING
• DO NOT REMOVE BOWL WHEN HOT (heat expands the metal)
• DO NOT RUN WITH TOO THICK OF CHOCOLATE
• CLEAN FOUNTAIN THOROUGHLY AFTER EVERY USE
• TEMPERATURE MUST BE WITHIN 10 DEGREES OF SET TEMP OR FOUNTAIN
WON’T TURN ON (Let warm up 10 minutes before use)
• WE STRONGLY RECOMMEND USING SF SIGNATURE FOUNTAIN
CHOCOLATE FOR REDUCTION IN MAINTENANCE AND EASE OF USE

WARRANTY INFORMATION
Subject to the limitations below, SF Sales Inc. warrants your purchase to be free from defects in materials and
workmanship under normal use by the original user for the life of the equipment. This warranty is non-transferable
and is subject to the terms below. To qualify for the warranty, you must have proof of purchase. Please note,
warranty coverage is separate from our 14-day shipping and return policy.
Shipping
Customer is responsible for ALL shipping charges on warranty repairs and is responsible for insuring and properly
packaging item for shipment to SF Sales. Any shipping damages are customer’s responsibility. We will pack item to
Fed Ex standards for shipment to customer. We will contact you for return shipping charges which must be paid
prior to return of product.
Exclusions
-Motor and related components have a TWO YEAR warranty
-Fountains that have not had proper bearing service - Read “BEARING SERVICE” section
-Wear and Tear components (including bearings, bushings, fuses, drive shaft, etc.) - Read “BEARING
SERVICE” section
-Fountains with seized bearings - Read “BEARING SERVICE” section
-Shipping related damage (must be filed as a shipping claim within 14 days of purchase)
-Discontinued items where parts are not available
-Items that have been damage discounted by any amount for any reason at time of sale including demos
and floor models
-Any items that have been physically altered in any way by anyone except SF Sales Inc., unless written
permission has been granted by SF Sales, Inc.
-Products used outside the United States with or without a voltage converter
Bearing Service
The bearings in your removable bowl are a vital part of your fountain and require frequent checking and servicing
(think of oil changes in a car). The main issue with a lack of bearing service is that chocolate can leak into the motor
causing other damage. Find below information regarding bearings:
-Fountains must have authorized bearing service every 800 hours or one year (whichever comes first) or
warranty is void. This service is not covered under your warranty. This is a separate charge.
-The removable bowl should only be hand washed and never submerged. Do not put in a dishwasher.
-Every time you use your fountain, the auger should be able to turn by hand. This indicates properly
functioning bearings.
- Any machine that is returned to us with seized bearings will not be covered under warranty.
-If your bearings are beginning to tighten up, please contact us to schedule a bearing replacement. This is
a separate charge.
Documentation/How to Receive Coverage
To receive warranty coverage, customer must first call to receive an RMAwarranty form. Customer must return item
with copy of receipt, RMA form and item properly packaged. Please allow 1-2 weeks for check in and evaluation of
your product. Repairs can vary in time. We will contact you for return shipping charges which must be paid prior to
return of product.
Limits of Liability
SF Sales, Inc. responsibility under this or any other warranty, implied or express, is limited to the repair replacement
or refund of the product purchase, as set forth above. These remedies are the sole and exclusive remedies for any
breach of warranty. You, the purchaser, agree and acknowledge that SF Sales, Inc. has no liability and shall not be
responsible for any damage you may incur from the non-receipt of your product due to delays in delivery, product
failure, the design or construction of the product or any other cause. Whether liability is asserted in tort, contract or
other wise. SF Sales, Inc. is not responsible for damages of any kind resulting from breach of warranty.

IMPORTANT SAFEGUARDS
When using our Chocolate Fountain, safety precautions should always be followed including the following:
1. READ ALL INSTRUCTIONS BEFORE USING THIS FOUNTAIN.
2. When the fountain basin is removed, the top of the fountain base can be extremely hot. Avoid any contact with
the top of the fountain base if it is exposed as the heating element is located directly beneath.
3. Avoid all other surfaces that have become hot during use.
4. To protect against electrical shock and damage to the fountain, do not put the fountain base in water or other
liquids. Never allow liquid to enter the fountain base through the bottom grate, vent holes, or other openings.
5. When basin is removed, take extra caution to keep liquid or other objects from entering into the exposed opening
at the top of the fountain base.
6. Avoid contact with moving parts, such as the auger in the cylinder or the spindle in the center of the basin.
7. Close supervision is necessary when the fountain is used near children.
8. Do not operate the fountain if you observe damage to the electrical cord or plug or if the base of the fountain has
been dropped of damaged in any manner. The fountain must be returned to SF Sales Inc. or a designated repair
facility for examination and repair as specified in the “Warranty” section of this manual.
9. Always unplug the fountain from the electrical outlet when it is not in use, especially before putting on or taking off
parts, and before cleaning.
10. Do not allow the electrical cord to come into contact with hot surfaces. An extension cord 14 guage or stronger
may be used if necessary. Care should be taken to position the electrical cord so that it does not create a hazard by
hanging over a table or counter edge in such a way where it might be tripped on or pulled by those around the
fountain.
11. Never place any object, especially your fingers, inside the central cylinder while the fountain is in use. Doing so
may cause severe injury to persons or damage to the fountain it self.
12. The use of accessory attachments, other than those made available specifically for use with this fountain, is not
recommended by the manufacturer, and may cause injury, and will void your warranty.
13. Extreme caution must be used when moving a fountain or fountain components containing hot liquid. Always
move the fountain by lifting the base. If you lift by the bowl it might come off of the base.
14. Use of the fountain outdoors is not recommended unless used with a Wind Guard.
15. Do not use this fountain for other than its intended use.
16. The Fountain must be on a level surface to operate properly.
17. Observe and follow customary sanitation guidelines when using this machine.

FOUNTAIN ASSEMBLY INSTRUCTIONS
1B. SF-PRO-43/50 Tier and Shaft Assembly - 7-9 pieces total (Depending on model)
1.) Bottom Shaft (9.75” H) -Twist and locks into basin
2.) Bottom Tier (11.5” D) - Sets on top of Large Base Shaft
3.) Bottom-Mid Shaft (8.5” H) - Sets on top of Large Base Tier
4.) Bottom-Mid Tier (9.75” D) - Sets on top of 8.5” Shaft Extender
5.) Top-Mid Shaft (7.75” H) - Sets on top of 9.75” Middle Tier
6.) Top-Mid Tier (7.75” D) - Sets on top of 7.75” Shaft Extender
7.) Top Shaft (5.75” H) - Sets on top of 7.75” Middle Tier (SF-PRO-50 Model Only)
8.) Top Tier (6.25” D) - Sets on top of 5.75” Top Shaft Extender (SF-PRO-50 Model Only)
9.) Crown (5.5” D) - Sets on top of 6.25” Top Tier
2. Auger Assembly - Depending on model 2-3 connecting pieces total - Reverse Thread
3. Removable Bowl - Sits on top of the base and holds the center column and screw.
***HAND WASH ONLY. DO NOT LIFT BY FOUNTAIN BOWL***
4. Motor Housing - This is the bottom of the fountain. Has all the electrical components, including the motor unit.
a.) ***Only to be opened by a qualified person***
b.) The vent holes allow hot air produced by the motor and heating elements to escape, cooling the
electrical components.
c.) Vent holes should not be covered during use.
5. Control Panel - The control panel switches the chocolate heater on and off to maintain the
temperature at a pre-set level and switches the motor on and off as required. There is a two digit LED
display to indicate the temperature in Celcius, and also two individual LED indicators which light when
the heater and motor respectively are ON. The membrane switch panel has a pair of push button switches
for UP and DOWN control of the temperature, and a third push button commands the ON/OFF state of the motor.
NOTE: Fountain must reach within 10 degrees of set temperature before operation to prevent damage.
6. Fuse - The machine has 3 fuses. 1st fuse is in the power cord. 2nd fuse in the power socket on the
drum and the 3rd fuse is on the PCB board inside the drum. Only qualified electrician should replace the
fuse in the PCB board.
7. Adjustable Feet - Screw into the bottom of the base. These may be tightened or loosened to raise or
lower a particular side of the fountain for leveling.
FOUNTAIN COMPONENTS
T
T
Fountain Specifications
otal
Fountain Height
Chocolate Capacity
otal
Fountain Weight
SF-PRO-31 SF-PRO-43 SF-PRO-50
31 inches 43 inches 50 inches
11 lbs 28 lbs 33 lbs
36 lbs 59 lbs 63 lbs
1A. SF-PRO-31 Tier and Shaft Assembly - 8 pieces total
1.) Bottom Shaft (6.5” H) -Twist and locks into basin
2.) Bottom Tier (7.75” D) - Sets on top of Large Base Shaft
3.) Bottom-Mid Shaft (4.5” H) - Sets on top of Large Base Tier
4.) Bottom-Mid Tier (6.5” D) - Sets on top of 8.5” Shaft Extender
5.) Top-Mid Shaft (4.5” H) - Sets on top of 6.5” Middle Tier
6.) Top-Mid Tier (5.5” D) - Sets on top of 4.5” Shaft Extender
7.) Top Shaft (2” H) - Sets on top of 5.5” Middle Tier
9.) Crown (4.5” D) - Sets on top of 2” Top Shaft
Parts are labeled respectively with 1 being the bottom and highest number being the top.

1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8 1.9
2
3
5
4
7

»
»»
Step 1
Remove fountain components from their cases and place
fountain base on a sturdy, level surface. Make sure the base
is level so that the chocolate will flow properly.
Step 2
Place the bowl on top of the motor housing at an angle and
push down and turn clockwise 45 degrees to lock the bowl
with the motor housing. To check the fountain is level, place
a leveler on the bowl rim at various locations. If leveling is
needed, raise or lower a particular side of the fountain by
adjusting the feet.
Step 3
Assemble the auger by threading the two or three pieces
together until it is secure. Please note that this is a reverse
thread.
Step 4
Twist, lock and secure the Long Base Shaft into the center
of the bowl.
Step 5
Place the Large Base Tier on top of the Large Base Shaft
and turn until it sits properly.
Step 6
Repeat Step 4 and 5 to build the Shaft assembly starting
with the larger pieces and ending with the smaller pieces.
Work your way up from 1 to the heightest number.
Step 7
Place the crown on top making sure that the auger pin sits in
the middle of the crown ring.
NOTE: Fountain must preheat to to within 10 degrees of set
temperature before the motor will turn on.
FOUNTAIN ASSEMBLY SF-PRO-31, 43 and 50

FOUNTAIN OPERATING INSTRUCTIONS
Step 1
Preheat the fountain by turning on switch on the power socket. Set the heat level to 70 degrees by pressing
the + key. Allow fountain to preheat for at least 10 minutes, to a minimum of 60 degrees celsius. The fountain
will not turn on until temperature hits within 10 degress of set temperature.
Step 2
SF Signature Chocolate can either be pre-melted in bags or melted directly in the fountain. To pre-melt
follow the instructions on the microwaveable safe bags. To melt in fountain, add 3-4 lbs of chocolate at a time,
stirring occasionally until completely melted.
To add chocolate to the fountain during use, either pre-melt the chocolate or sprinkle 1 bag of chips at a time
directly in to the basin. Allow chips to melt before adding more.
Important note: Do not overfill the fountain; see fountain capacities below.
IMPORTANT NOTE:
CHOCOLATE PREPARATION
We strongly encourage you to use SF Signature Chocolate Fondue, available in Dark, Milk, and White varieties.
Using the wrong chocolate can damage your fountain. SF Signature Chocolate Fondue is specially formulated to
melt down to the correct viscosity to flow perfectly through the fountain every time. Our unique fondue choco-
late is exquisite in taste and aroma and your guests and clients are sure to be delighted. You can order SF
Signature Chocolate Fondue at www.sweetfountains.com.
Before using the chocolate fondue, store it in a cool, dry place. Do not freeze or refrigerate as moisture could affect
the chocolate’s consistency.
You may melt the chocolate directly in the fountain basin, in a double boiler, or in microwave according to the
instructions on the bags. WHEN MICROWAVING CHOCOLATE, ALWAYS USE HALF-POWER TO PRE-
VENT SCORCHING.
Melting the chocolate directly in the fountain basin takes approximately 60 minutes. Add chocolate 2 lbs at a
time to expedite the melting process. Stir chocolate occasionally, scraping it from the basin with a spatula as
you go, this will prevent scorching. Milk and White chocolate are more susceptible to burning so be sure to
stir more frequently (2-3 minutes) and use appropriate temperature settings.
SF Signature Chocolate Fondue is designed to perform without oil in most chocolate fountains. Due to condi-
tions such as humidity, temperature, and the RPM of the fountain motor, up to 3-4 tablespoons of vegetable
or canola oil per 1.75 lbs. may be needed to thin the chocolate. Only do this if needed. May vary by product.)
Fountain Capacities
Model Min. Amt (Lbs) Max. Amt (Lbs)
SF-PRO-31 7 lbs 11 lbs
SF-PRO-43 12 lbs 28 lbs
SF-PRO-50 14 lbs 33 lbs
Video at: sweetfountains.com/videos.html

Temperature Settings
Chocolate Type Melting (Operating (
Dark 80 70
Milk 80 70
White 70 60
Step 3
Once the chocolate is completely melted, lower the heat by pressing key to the operating temperature
and turn the motor switch ( ) to “ON”.
Step 2 (cont.)
MELTING CHOCOLATE IN FOUNTAIN BASIN
CAUTION: The heat setting should never be higher than 70 degrees when melting White Chocolate.
Overheating White or Milk chocolate causes it to thicken or become clumpy and it will not flow properly.
To help correct this problem see “TROUBLESHOOTING” item #2.
Farenheit to Celcius Conversion Chart
Farenheit
Celcius 010 20 30 40 50 60 70 80 90 100
32 50 68 86 104 122 140 158
176
194 212
Temperature may slightly vary due to conditions and ambient temperature.
Temperature Settings - Melting
Chocolate Type Heat
Setting Operating
Setting Approx. Melting Time
SF-PRO-31 SF-PRO-43/50
Dark 80°C 60 mins 75 mins
Milk 80°C 60 mins 75 mins
White 70°C 60 mins 75 mins
70°C
70°C
60°C

1) SETTING THE TEMPERATURE
When either the or push buttons is pressed the system enters the temperature setting mode and
the display shows the existing unchanged set point temperature. The two display decimal points flash on
alternately to confirm that the temperature setting mode is enabled. Further pressing of the push-buttons
cause the temperature to be increased or decreased respectively by 1°C at a time, but if either push-button
is held for longer than two seconds, the temperature is raised or lowered continuously at a rate of 3°C per
second for as long as the push-button is held. If the temperature reaches 99, further use for the push-button
cannot alter the temperature further nor if the temperature reaches 0°C the push-button will not have any
effect (note that setting a temperature below room temperature is irrelevant as the system has a heater
only).
If neither push-button is operated for longer than three seconds, the system automatically comes out of the
temperature setting mode and the flashing decimal points turn off. At the same time the final set temperature
value (TSET) is stored in memory; this value will be retrieved and subsequently used when the fountain is
next switched on.
2) TEMPERATURE CONTROL
When the fountain is switched on, the heater is always in the ON state initially, and the Heater LED is illumi-
nated. When the temperature has risen to T > TSET, the heater and its indicator LED are switched OFF.
When the temperature then falls to T < (TSET-1), the heater and indicator are switched ON again. Thus the
hysteresis band is 2°C. If the temperature sensor fails, or is unplugged from the control board, the heater
and the motor are both switched OFF, and the display shows “SF” (Sensor Fault).
3) MOTOR CONTROL
When the fountain is switched on, the motor is always in the OFF state initially, and the motor LED is off. The
motor is subsequently runs when the push-button is pressed, and the motor LED is illuminated. Subse-
quent operation of the push-button toggles the motor and indicator between the ON and OFF states.
However, if the motor is commanded to be ON and the chocolate bowl temperature is less than 10°C from
set temp, then the motor is inhibited and does not start. In this event, the display shows “LT”(Low tempera-
ture) for two seconds before it reverts to the normal temperature indication. This is to minimize possible
motor damage, as there is risk of the Auger being locked due to solid chocolate.
The motor also has a built-in thermal switch which opens if its temperature exceeds a safe limit. This switch
connects back to the controller to override normal motor operation. Whenever the thermal switch is open, the
motor drive is set to OFF, and the display shows “OL” (Over-Load) until the motor has cooled sufficiently to
reset the thermal switch. The motor can then be re-started manually by using the push-button.
Important information about the Control Panel
The control system switches the chocolate heater on and off such as to maintain the temperature at a
pre-set level, and switches the motor on and off as required.
There is a two digit LED display to indicate the temperature in degrees Centigrade, and also two individual
LED indicators which light when the heater and motor respectively are on. A membrane switch panel has a
pair of push-button switches for UP ( ) and DOWN ( ) control of the temperature, and a third push-
button commands the ON/OFF state of the motor.
CONTROL PANEL INSTRUCTIONS
Recommeded setting is 70°C for most chocolate.
See previous page. Do not run above 80°C.
