INTRODUCTION
1.
This product was carefully designed and manufactured for optimal performance, economy, and ease of use. It is important for any operator of
this product to go over all information contained in this manual, to follow these step-by-step instructions, and to have the manual on hand for
reference when needed.
This manual contains important safety information: Read this information carefully and be on the lookout
for any possible accidents. Keep all labeling on the equipment and replace labeling if necessary.
This equipment enables you to clear land of quick-growing vegetation, small shrubs, and grass; it can also be used to shred the leftovers of crops
such as corn, wheat, barley, sorghum, etc.
SAFETY INFORMATION
2.
In this section, we will discuss the most important points for ensuring your safety and the safety of others.
2.1 PROTECTIVE EQUIPMENT
It is essential to use the following protective equipment while operating the rotary cutter:
- Protective gloves
- Safety glasses
- Closed footwear
- Ear plugs or ear muffs
- Overalls
- Mask
4.
6.
5.
7.
8.
4.2.1 Rotary cutter hitch
4.2.2 How to cut the PTO shaft to the correct length
4.3 Working position and cutting level
4.4 Starting your equipment
4.5 Off-centering the rotary cutter (optional)
5. Maintenance................................................................ 6
5.1 Maintenance Guide
6. Common problems and troubleshooting..................6
7. Replacement parts...................................................... 7, 8
8. Storage......................................................................... 8
9. Warranty....................................................................... 9
1.
2.
3.
1. Introduction……………........................................... 1
2. Safety information………........................................ 1, 2
2.1 Protective equipment
2.2 Safety measures
3. General information…………................................. 2, 3
3.1 Nameplate
3.2 Main components
3.3 Technical information
3.4 Assembly
4. Operation………….................................................. 4, 5
4.1 Before starting your equipment
4.2 Tractor hitch
2.2 SECURITY MEASURES.
Read this instruction manual carefully before using your equipment.
Serious accidents can occur if the equipment is used incorrectly or if it is used by an untrained person.
Do not change or modify this product; doing so can jeopardize your equipment and can compromise your safety as well as the safety of
others. You assume the risk for any changes or modifications performed, and these alterations will make the warranty invalid.
Do not allow children, the elderly, people with special abilities, or animals near the equipment while it is in use, being maintained, or even
when it is in storage.
Always keep the equipment in perfect running condition.
When transporting your equipment, make sure it is properly connected to the tractor that is towing it.
If you must transport the rotary cutter on federal or state roads, follow all traffic laws.
Keep hands, feet, and loose clothing away from moving parts.
Make sure your equipment is on flat and firm ground when you disconnect it.
The operator must not be impaired by—or under the influence of —alcohol, drugs, or medications.
Prevent accidents that can be caused by poor understanding or by not following the security measures established in this manual.
