SwissOne BBM 605 User manual
Tip: Some features require extra
memory, to expand your phone’s storage
capacity, install a micro SD card.
3. Micro-SD card (optional)
Lightly press the card
holder and push it
carefully toward the
corner of the
compartment. The
card holder can now be ipped up
vertically. Place the memory card in the
black plastic bracket. Make sure that
the memory card contacts are facing
down and that the card is placed in
accordance with the marked area (see
gure). Do not scratch or bend the card
contacts. Push the metal holder back
down, press it at and slide it until it
snaps into place.
1. Charging
contacts
2. Micro USB
port
For battery charger
3. + and - keys Adjust ring volume
and
loudspeaker volume
4. LEDs Blue = battery full
Blinking blue = Dur-
ing calls, Notication
of missed calls and
received SMS
5. LEDs Red = Battery charg-
ing
6. Headset
socket
For 3.5 mm standard
headset
7. Torch key
8. Charging
cradle
9. Receiver/
loudspeaker
Make phone calls
holding the cell phone
to the ear
10. Display
11. Left soft key
Right soft key
Main menu
Phone book
12. Call key Dial and answer calls;
open the call log
13. Arrow keys In idle state to
open the quick access
list
to open Proles.
Scroll up and down in
menus and lists
14. Handsfree
key
Switch to handsfree
during a call
15. Alarm clock
shortcut
16. Numerical
keys
In idle state: input of
phone number;
long keystroke on 1:
calling the voice mail
box (the phone num-
ber must be stored)
17.
*key In idle state: to enter:
“*”/ “+” / “P”/“W“;
Input: special charac-
ters
18.
#key In idle state: long
keystroke to toggle
between ring tone on/
off;
Input: toggle input
modes
19. SMS shortcut
20. End key End a call, return to
idle mode; switch the
phone on/off
21. SOS key
Install the SIM card and the battery
The SIM card holder is located inside the
battery compartment.
CAUTION
Only use batteries, charger and
accessories that have been approved for
use with this particular model. Connecting
other accessories may be dangerous and
may invalidate the phone’s type approval
and guarantee.
1. Remove the battery cover
slide your ngernail into the small
notch on the bottom
side of the phone
and pull the cover
upward. If the battery
is installed, slide
your ngernail in the
notch next to the battery to lift it up.
2. Insert the SIM card (required)
push it carefully in
under the metal
bracket on the lower
side. Make sure the
contacts of the SIM
card point
downwards and the cut-off corner ts
exactly in the recessed shaping of the
holder. The contacts of the SIM card
must not be scratched or bent. Try not
to touch the contacts with your ngers.
BBM 605
© IVS GmbH 2015 • All rights reserved
QSG_Swisstone BBM_605_en_A3(A7)_v1.0
English
Version 1.0 0359
Specications
Network: GSM 900/1800 MHz
Dimensions: 92 mm x 44 mm x 16 mm
Weight: 76 g
Battery: 3.7V/800 mAh Li-ion
battery
Operating ambient
temperature:
Min: 0°C (32°F)
Max: 40°C (104°F)
Charging ambient
temperature:
Min: 0°C (32°F)
Max: 40°C (104°F)
Storage
temperature:
Min: -20°C (-4°F)
Max: 60°C (140°F)
Changes and errors excepted.
EN
1
2
3
4
5
6
9
10
11
12
13
14
15
16
17 18
19
20
21
7
8
IMPORTANT!
Use only compatible memory cards
with this device. Compatible card type:
microSD, microSDHC.
Incompatible cards may damage the
card itself, the device and corrupt any
data stored on the card. Depending on
the market some phones may have a
pre-installed memory card.
4. Insert the battery (required)
by pushing it into the
battery compartment
ensuring that the
three contacts on
the front touch the
three spring contacts on the bottom in
the battery compartment.
5. Replace the cover and push it upward
using gentle pressure with the thumb
until it snaps securely into place again.
When the battery performance is low, the
empty battery symbol ashes to indicate
the battery state and an alarm signal will
sound. To recharge the battery, connect the
mains adapter to the micro USB connector
on the bottom side of the phone.
Alternatively, you can place the telephone
into the charging cradle connected to the
main adapter via the USB cable.
During charging, the red charging LED
is on and the charge status icon moves
(visible in the upper right corner of the
display).
A complete charging process of the
rechargeable battery takes approximately 3
hours. When the battery is fully charged the
animation of the charge status icon stops.
Power on the phone
Press and hold the red key on the
phone to turn it on and off.
If the SIM card is valid but protected with a
PIN code (Personal Identication Number),
Enter PIN
is displayed.
Enter the SIM PIN code and press
OK
( upper left corner of keypad). Delete
with
Delete
( upper right corner of
keypad).
Make a call
1. Enter the phone number with the area
code. You can delete digits with
Delete
.
2. Press to dial. Press
Cancel
to
cancel dialling.
3. Press to end the call.
Tip: For international calls, always enter
a +symbol before the country code to be
able to use the phonebook optimally in
any country.
Press the *key twice to enter the inter-
national area code +.
Answer a call
1. Press or
Answer
to accept the call
or press reject to reject the call (busy
signal).
Alternatively, you can press to
reject the call directly.
2. Press to end the call.
Create phonebook entry
1. Press
Menu
â
Phonebook
â
OK
.
2. Select
Add new contact
â
Add
.
3. Select whether you want to save the
contact on the SIM card or in the phone.
4. Enter a name for the contact.
5. Press .
6. Enter the phone number including the
area code.
7. Press .
8. You can select a different ring tone for
the contact by using the keys *and #.
Note!
Storage needs to be set to
Phone
.
9. Then press
Options
â
Save
â
Select
.
Set language
The default language of the phone menu,
messages and so on is determined by the
SIM card used (Automatic). You can always
switch between the languages supported
by the phone.
1. Press
Menu
â
Settings
â
OK
.
2. Select
Phone settings
â
OK
.
3. Select
Language
â
OK
.
4. Select language â
OK
.
Set time and date
1. Press
Menu
â
Settings
â
OK
.
2. Select
Phone settings
â
OK
.
3. Select
Time and date
â
OK
.
4. Select
Set time/date
â
OK
.
5. Enter the time (HH:MM) â.
6. Enter the date (DD/MM/YYYY) â
OK
.
Tip: For international calls, always enter
a +symbol before the country code to be
able to use the phonebook optimally in
any country.
Press the *key twice to enter the inter-
national area code +.
Volume control
You can adjust the volume during a call
using the side keys
+
/
–
. The volume level is
shown on the display.
Enter text
Select character
• Press a numerical key repeatedly
until the desired character is shown.
• Wait a few seconds (until the blue
background of the character has
disappeared) before entering the
next character.
Special characters/smileys
• Press *to view a list of special
characters.
• Select the desired character with or
*and # (to move left or right) and
press
OK
to enter.
Move the cursor within text
• Use the keys
/
, to move the
cursor within the text.
Upper case, lower case and numerals
• Press #to choose between upper
case, lower case and numerals. The
symbol at the top left in the display
indicates the input mode.
Instructions
Tip: Some features require extra
memory, to expand your phone’s storage
capacity, install a micro SD card.
3. Micro-SD card (optional)
Lightly press the card
holder and push it
carefully toward the
corner of the
compartment. The
card holder can now be ipped up
vertically. Place the memory card in the
black plastic bracket. Make sure that
the memory card contacts are facing
down and that the card is placed in
accordance with the marked area (see
gure). Do not scratch or bend the card
contacts. Push the metal holder back
down, press it at and slide it until it
snaps into place.
1. Charging
contacts
2. Micro USB
port
For battery charger
3. + and - keys Adjust ring volume
and
loudspeaker volume
4. LEDs Blue = battery full
Blinking blue = Dur-
ing calls, Notication
of missed calls and
received SMS
5. LEDs Red = Battery charg-
ing
6. Headset
socket
For 3.5 mm standard
headset
7. Torch key
8. Charging
cradle
9. Receiver/
loudspeaker
Make phone calls
holding the cell phone
to the ear
10. Display
11. Left soft key
Right soft key
Main menu
Phone book
12. Call key Dial and answer calls;
open the call log
13. Arrow keys In idle state to
open the quick access
list
to open Proles.
Scroll up and down in
menus and lists
14. Handsfree
key
Switch to handsfree
during a call
15. Alarm clock
shortcut
16. Numerical
keys
In idle state: input of
phone number;
long keystroke on 1:
calling the voice mail
box (the phone num-
ber must be stored)
17.
*key In idle state: to enter:
“*”/ “+” / “P”/“W“;
Input: special charac-
ters
18.
#key In idle state: long
keystroke to toggle
between ring tone on/
off;
Input: toggle input
modes
19. SMS shortcut
20. End key End a call, return to
idle mode; switch the
phone on/off
21. SOS key
Install the SIM card and the battery
The SIM card holder is located inside the
battery compartment.
CAUTION
Only use batteries, charger and
accessories that have been approved for
use with this particular model. Connecting
other accessories may be dangerous and
may invalidate the phone’s type approval
and guarantee.
1. Remove the battery cover
slide your ngernail into the small
notch on the bottom
side of the phone
and pull the cover
upward. If the battery
is installed, slide
your ngernail in the
notch next to the battery to lift it up.
2. Insert the SIM card (required)
push it carefully in
under the metal
bracket on the lower
side. Make sure the
contacts of the SIM
card point
downwards and the cut-off corner ts
exactly in the recessed shaping of the
holder. The contacts of the SIM card
must not be scratched or bent. Try not
to touch the contacts with your ngers.
BBM 605
© IVS GmbH 2015 • All rights reserved
QSG_Swisstone BBM_605_en_A3(A7)_v1.0
English
Version 1.0 0359
Specications
Network: GSM 900/1800 MHz
Dimensions: 92 mm x 44 mm x 16 mm
Weight: 76 g
Battery: 3.7V/800 mAh Li-ion
battery
Operating ambient
temperature:
Min: 0°C (32°F)
Max: 40°C (104°F)
Charging ambient
temperature:
Min: 0°C (32°F)
Max: 40°C (104°F)
Storage
temperature:
Min: -20°C (-4°F)
Max: 60°C (140°F)
Changes and errors excepted.
EN
1
2
3
4
5
6
9
10
11
12
13
14
15
16
17 18
19
20
21
7
8
IMPORTANT!
Use only compatible memory cards
with this device. Compatible card type:
microSD, microSDHC.
Incompatible cards may damage the
card itself, the device and corrupt any
data stored on the card. Depending on
the market some phones may have a
pre-installed memory card.
4. Insert the battery (required)
by pushing it into the
battery compartment
ensuring that the
three contacts on
the front touch the
three spring contacts on the bottom in
the battery compartment.
5. Replace the cover and push it upward
using gentle pressure with the thumb
until it snaps securely into place again.
When the battery performance is low, the
empty battery symbol ashes to indicate
the battery state and an alarm signal will
sound. To recharge the battery, connect the
mains adapter to the micro USB connector
on the bottom side of the phone.
Alternatively, you can place the telephone
into the charging cradle connected to the
main adapter via the USB cable.
During charging, the red charging LED
is on and the charge status icon moves
(visible in the upper right corner of the
display).
A complete charging process of the
rechargeable battery takes approximately 3
hours. When the battery is fully charged the
animation of the charge status icon stops.
Power on the phone
Press and hold the red key on the
phone to turn it on and off.
If the SIM card is valid but protected with a
PIN code (Personal Identication Number),
Enter PIN
is displayed.
Enter the SIM PIN code and press
OK
( upper left corner of keypad). Delete
with
Delete
( upper right corner of
keypad).
Make a call
1. Enter the phone number with the area
code. You can delete digits with
Delete
.
2. Press to dial. Press
Cancel
to
cancel dialling.
3. Press to end the call.
Tip: For international calls, always enter
a +symbol before the country code to be
able to use the phonebook optimally in
any country.
Press the *key twice to enter the inter-
national area code +.
Answer a call
1. Press or
Answer
to accept the call
or press reject to reject the call (busy
signal).
Alternatively, you can press to
reject the call directly.
2. Press to end the call.
Create phonebook entry
1. Press
Menu
â
Phonebook
â
OK
.
2. Select
Add new contact
â
Add
.
3. Select whether you want to save the
contact on the SIM card or in the phone.
4. Enter a name for the contact.
5. Press .
6. Enter the phone number including the
area code.
7. Press .
8. You can select a different ring tone for
the contact by using the keys *and #.
Note!
Storage needs to be set to
Phone
.
9. Then press
Options
â
Save
â
Select
.
Set language
The default language of the phone menu,
messages and so on is determined by the
SIM card used (Automatic). You can always
switch between the languages supported
by the phone.
1. Press
Menu
â
Settings
â
OK
.
2. Select
Phone settings
â
OK
.
3. Select
Language
â
OK
.
4. Select language â
OK
.
Set time and date
1. Press
Menu
â
Settings
â
OK
.
2. Select
Phone settings
â
OK
.
3. Select
Time and date
â
OK
.
4. Select
Set time/date
â
OK
.
5. Enter the time (HH:MM) â.
6. Enter the date (DD/MM/YYYY) â
OK
.
Tip: For international calls, always enter
a +symbol before the country code to be
able to use the phonebook optimally in
any country.
Press the *key twice to enter the inter-
national area code +.
Volume control
You can adjust the volume during a call
using the side keys
+
/
–
. The volume level is
shown on the display.
Enter text
Select character
• Press a numerical key repeatedly
until the desired character is shown.
• Wait a few seconds (until the blue
background of the character has
disappeared) before entering the
next character.
Special characters/smileys
• Press *to view a list of special
characters.
• Select the desired character with or
*and # (to move left or right) and
press
OK
to enter.
Move the cursor within text
• Use the keys
/
, to move the
cursor within the text.
Upper case, lower case and numerals
• Press #to choose between upper
case, lower case and numerals. The
symbol at the top left in the display
indicates the input mode.
Instructions
Tip: Some features require extra
memory, to expand your phone’s storage
capacity, install a micro SD card.
3. Micro-SD card (optional)
Lightly press the card
holder and push it
carefully toward the
corner of the
compartment. The
card holder can now be ipped up
vertically. Place the memory card in the
black plastic bracket. Make sure that
the memory card contacts are facing
down and that the card is placed in
accordance with the marked area (see
gure). Do not scratch or bend the card
contacts. Push the metal holder back
down, press it at and slide it until it
snaps into place.
1. Charging
contacts
2. Micro USB
port
For battery charger
3. + and - keys Adjust ring volume
and
loudspeaker volume
4. LEDs Blue = battery full
Blinking blue = Dur-
ing calls, Notication
of missed calls and
received SMS
5. LEDs Red = Battery charg-
ing
6. Headset
socket
For 3.5 mm standard
headset
7. Torch key
8. Charging
cradle
9. Receiver/
loudspeaker
Make phone calls
holding the cell phone
to the ear
10. Display
11. Left soft key
Right soft key
Main menu
Phone book
12. Call key Dial and answer calls;
open the call log
13. Arrow keys In idle state to
open the quick access
list
to open Proles.
Scroll up and down in
menus and lists
14. Handsfree
key
Switch to handsfree
during a call
15. Alarm clock
shortcut
16. Numerical
keys
In idle state: input of
phone number;
long keystroke on 1:
calling the voice mail
box (the phone num-
ber must be stored)
17.
*key In idle state: to enter:
“*”/ “+” / “P”/“W“;
Input: special charac-
ters
18.
#key In idle state: long
keystroke to toggle
between ring tone on/
off;
Input: toggle input
modes
19. SMS shortcut
20. End key End a call, return to
idle mode; switch the
phone on/off
21. SOS key
Install the SIM card and the battery
The SIM card holder is located inside the
battery compartment.
CAUTION
Only use batteries, charger and
accessories that have been approved for
use with this particular model. Connecting
other accessories may be dangerous and
may invalidate the phone’s type approval
and guarantee.
1. Remove the battery cover
slide your ngernail into the small
notch on the bottom
side of the phone
and pull the cover
upward. If the battery
is installed, slide
your ngernail in the
notch next to the battery to lift it up.
2. Insert the SIM card (required)
push it carefully in
under the metal
bracket on the lower
side. Make sure the
contacts of the SIM
card point
downwards and the cut-off corner ts
exactly in the recessed shaping of the
holder. The contacts of the SIM card
must not be scratched or bent. Try not
to touch the contacts with your ngers.
BBM 605
© IVS GmbH 2015 • All rights reserved
QSG_Swisstone BBM_605_en_A3(A7)_v1.0
English
Version 1.0 0359
Specications
Network: GSM 900/1800 MHz
Dimensions: 92 mm x 44 mm x 16 mm
Weight: 76 g
Battery: 3.7V/800 mAh Li-ion
battery
Operating ambient
temperature:
Min: 0°C (32°F)
Max: 40°C (104°F)
Charging ambient
temperature:
Min: 0°C (32°F)
Max: 40°C (104°F)
Storage
temperature:
Min: -20°C (-4°F)
Max: 60°C (140°F)
Changes and errors excepted.
EN
1
2
3
4
5
6
9
10
11
12
13
14
15
16
17 18
19
20
21
7
8
IMPORTANT!
Use only compatible memory cards
with this device. Compatible card type:
microSD, microSDHC.
Incompatible cards may damage the
card itself, the device and corrupt any
data stored on the card. Depending on
the market some phones may have a
pre-installed memory card.
4. Insert the battery (required)
by pushing it into the
battery compartment
ensuring that the
three contacts on
the front touch the
three spring contacts on the bottom in
the battery compartment.
5. Replace the cover and push it upward
using gentle pressure with the thumb
until it snaps securely into place again.
When the battery performance is low, the
empty battery symbol ashes to indicate
the battery state and an alarm signal will
sound. To recharge the battery, connect the
mains adapter to the micro USB connector
on the bottom side of the phone.
Alternatively, you can place the telephone
into the charging cradle connected to the
main adapter via the USB cable.
During charging, the red charging LED
is on and the charge status icon moves
(visible in the upper right corner of the
display).
A complete charging process of the
rechargeable battery takes approximately 3
hours. When the battery is fully charged the
animation of the charge status icon stops.
Power on the phone
Press and hold the red key on the
phone to turn it on and off.
If the SIM card is valid but protected with a
PIN code (Personal Identication Number),
Enter PIN
is displayed.
Enter the SIM PIN code and press
OK
( upper left corner of keypad). Delete
with
Delete
( upper right corner of
keypad).
Make a call
1. Enter the phone number with the area
code. You can delete digits with
Delete
.
2. Press to dial. Press
Cancel
to
cancel dialling.
3. Press to end the call.
Tip: For international calls, always enter
a +symbol before the country code to be
able to use the phonebook optimally in
any country.
Press the *key twice to enter the inter-
national area code +.
Answer a call
1. Press or
Answer
to accept the call
or press reject to reject the call (busy
signal).
Alternatively, you can press to
reject the call directly.
2. Press to end the call.
Create phonebook entry
1. Press
Menu
â
Phonebook
â
OK
.
2. Select
Add new contact
â
Add
.
3. Select whether you want to save the
contact on the SIM card or in the phone.
4. Enter a name for the contact.
5. Press .
6. Enter the phone number including the
area code.
7. Press .
8. You can select a different ring tone for
the contact by using the keys *and #.
Note!
Storage needs to be set to
Phone
.
9. Then press
Options
â
Save
â
Select
.
Set language
The default language of the phone menu,
messages and so on is determined by the
SIM card used (Automatic). You can always
switch between the languages supported
by the phone.
1. Press
Menu
â
Settings
â
OK
.
2. Select
Phone settings
â
OK
.
3. Select
Language
â
OK
.
4. Select language â
OK
.
Set time and date
1. Press
Menu
â
Settings
â
OK
.
2. Select
Phone settings
â
OK
.
3. Select
Time and date
â
OK
.
4. Select
Set time/date
â
OK
.
5. Enter the time (HH:MM) â.
6. Enter the date (DD/MM/YYYY) â
OK
.
Tip: For international calls, always enter
a +symbol before the country code to be
able to use the phonebook optimally in
any country.
Press the *key twice to enter the inter-
national area code +.
Volume control
You can adjust the volume during a call
using the side keys
+
/
–
. The volume level is
shown on the display.
Enter text
Select character
• Press a numerical key repeatedly
until the desired character is shown.
• Wait a few seconds (until the blue
background of the character has
disappeared) before entering the
next character.
Special characters/smileys
• Press *to view a list of special
characters.
• Select the desired character with or
*and # (to move left or right) and
press
OK
to enter.
Move the cursor within text
• Use the keys
/
, to move the
cursor within the text.
Upper case, lower case and numerals
• Press #to choose between upper
case, lower case and numerals. The
symbol at the top left in the display
indicates the input mode.
Instructions
Tip: Some features require extra
memory, to expand your phone’s storage
capacity, install a micro SD card.
3. Micro-SD card (optional)
Lightly press the card
holder and push it
carefully toward the
corner of the
compartment. The
card holder can now be ipped up
vertically. Place the memory card in the
black plastic bracket. Make sure that
the memory card contacts are facing
down and that the card is placed in
accordance with the marked area (see
gure). Do not scratch or bend the card
contacts. Push the metal holder back
down, press it at and slide it until it
snaps into place.
1. Charging
contacts
2. Micro USB
port
For battery charger
3. + and - keys Adjust ring volume
and
loudspeaker volume
4. LEDs Blue = battery full
Blinking blue = Dur-
ing calls, Notication
of missed calls and
received SMS
5. LEDs Red = Battery charg-
ing
6. Headset
socket
For 3.5 mm standard
headset
7. Torch key
8. Charging
cradle
9. Receiver/
loudspeaker
Make phone calls
holding the cell phone
to the ear
10. Display
11. Left soft key
Right soft key
Main menu
Phone book
12. Call key Dial and answer calls;
open the call log
13. Arrow keys In idle state to
open the quick access
list
to open Proles.
Scroll up and down in
menus and lists
14. Handsfree
key
Switch to handsfree
during a call
15. Alarm clock
shortcut
16. Numerical
keys
In idle state: input of
phone number;
long keystroke on 1:
calling the voice mail
box (the phone num-
ber must be stored)
17.
*key In idle state: to enter:
“*”/ “+” / “P”/“W“;
Input: special charac-
ters
18.
#key In idle state: long
keystroke to toggle
between ring tone on/
off;
Input: toggle input
modes
19. SMS shortcut
20. End key End a call, return to
idle mode; switch the
phone on/off
21. SOS key
Install the SIM card and the battery
The SIM card holder is located inside the
battery compartment.
CAUTION
Only use batteries, charger and
accessories that have been approved for
use with this particular model. Connecting
other accessories may be dangerous and
may invalidate the phone’s type approval
and guarantee.
1. Remove the battery cover
slide your ngernail into the small
notch on the bottom
side of the phone
and pull the cover
upward. If the battery
is installed, slide
your ngernail in the
notch next to the battery to lift it up.
2. Insert the SIM card (required)
push it carefully in
under the metal
bracket on the lower
side. Make sure the
contacts of the SIM
card point
downwards and the cut-off corner ts
exactly in the recessed shaping of the
holder. The contacts of the SIM card
must not be scratched or bent. Try not
to touch the contacts with your ngers.
BBM 605
© IVS GmbH 2015 • All rights reserved
QSG_Swisstone BBM_605_en_A3(A7)_v1.0
English
Version 1.0 0359
Specications
Network: GSM 900/1800 MHz
Dimensions: 92 mm x 44 mm x 16 mm
Weight: 76 g
Battery: 3.7V/800 mAh Li-ion
battery
Operating ambient
temperature:
Min: 0°C (32°F)
Max: 40°C (104°F)
Charging ambient
temperature:
Min: 0°C (32°F)
Max: 40°C (104°F)
Storage
temperature:
Min: -20°C (-4°F)
Max: 60°C (140°F)
Changes and errors excepted.
EN
1
2
3
4
5
6
9
10
11
12
13
14
15
16
17 18
19
20
21
7
8
IMPORTANT!
Use only compatible memory cards
with this device. Compatible card type:
microSD, microSDHC.
Incompatible cards may damage the
card itself, the device and corrupt any
data stored on the card. Depending on
the market some phones may have a
pre-installed memory card.
4. Insert the battery (required)
by pushing it into the
battery compartment
ensuring that the
three contacts on
the front touch the
three spring contacts on the bottom in
the battery compartment.
5. Replace the cover and push it upward
using gentle pressure with the thumb
until it snaps securely into place again.
When the battery performance is low, the
empty battery symbol ashes to indicate
the battery state and an alarm signal will
sound. To recharge the battery, connect the
mains adapter to the micro USB connector
on the bottom side of the phone.
Alternatively, you can place the telephone
into the charging cradle connected to the
main adapter via the USB cable.
During charging, the red charging LED
is on and the charge status icon moves
(visible in the upper right corner of the
display).
A complete charging process of the
rechargeable battery takes approximately 3
hours. When the battery is fully charged the
animation of the charge status icon stops.
Power on the phone
Press and hold the red key on the
phone to turn it on and off.
If the SIM card is valid but protected with a
PIN code (Personal Identication Number),
Enter PIN
is displayed.
Enter the SIM PIN code and press
OK
( upper left corner of keypad). Delete
with
Delete
( upper right corner of
keypad).
Make a call
1. Enter the phone number with the area
code. You can delete digits with
Delete
.
2. Press to dial. Press
Cancel
to
cancel dialling.
3. Press to end the call.
Tip: For international calls, always enter
a +symbol before the country code to be
able to use the phonebook optimally in
any country.
Press the *key twice to enter the inter-
national area code +.
Answer a call
1. Press or
Answer
to accept the call
or press reject to reject the call (busy
signal).
Alternatively, you can press to
reject the call directly.
2. Press to end the call.
Create phonebook entry
1. Press
Menu
â
Phonebook
â
OK
.
2. Select
Add new contact
â
Add
.
3. Select whether you want to save the
contact on the SIM card or in the phone.
4. Enter a name for the contact.
5. Press .
6. Enter the phone number including the
area code.
7. Press .
8. You can select a different ring tone for
the contact by using the keys *and #.
Note!
Storage needs to be set to
Phone
.
9. Then press
Options
â
Save
â
Select
.
Set language
The default language of the phone menu,
messages and so on is determined by the
SIM card used (Automatic). You can always
switch between the languages supported
by the phone.
1. Press
Menu
â
Settings
â
OK
.
2. Select
Phone settings
â
OK
.
3. Select
Language
â
OK
.
4. Select language â
OK
.
Set time and date
1. Press
Menu
â
Settings
â
OK
.
2. Select
Phone settings
â
OK
.
3. Select
Time and date
â
OK
.
4. Select
Set time/date
â
OK
.
5. Enter the time (HH:MM) â.
6. Enter the date (DD/MM/YYYY) â
OK
.
Tip: For international calls, always enter
a +symbol before the country code to be
able to use the phonebook optimally in
any country.
Press the *key twice to enter the inter-
national area code +.
Volume control
You can adjust the volume during a call
using the side keys
+
/
–
. The volume level is
shown on the display.
Enter text
Select character
• Press a numerical key repeatedly
until the desired character is shown.
• Wait a few seconds (until the blue
background of the character has
disappeared) before entering the
next character.
Special characters/smileys
• Press *to view a list of special
characters.
• Select the desired character with or
*and # (to move left or right) and
press
OK
to enter.
Move the cursor within text
• Use the keys
/
, to move the
cursor within the text.
Upper case, lower case and numerals
• Press #to choose between upper
case, lower case and numerals. The
symbol at the top left in the display
indicates the input mode.
Instructions
SOS call setting
Activate the emergency call function.
1. Press
Menu
â
SOS Setting
â
OK
.
2. Select
Emergency alert
â
OK
.
3. Select
On
or
Off
â
OK
.
Important
If you deactivate the emergency call
function the emergency call key on the
back of the telephone will not work!
SOS Alarm Tone
Alarm sound on or off.
1. Press
Menu
, select
SOS Setting
and
press
OK
.
2. Select
SOS Alarm Tone
â
OK
.
3. Select
On
or
Off
â
OK
.
Emergency call contacts
The phone numbers to be called when
pressing the emergency call key. A
maximum of 5 numbers can be saved.
1. Press
Menu
â
SOS Setting
â
OK
.
2. Select
Emergency numbers
â
OK
.
3. Add at maximum 5 desired phone
numbers
Note!
Always inform your contacts when
adding them.
4. Press
Save
.
5. Conrm the question
Save?
with
Yes
.
SOS-SMS
SMS transmission on or off.
1. Press
Menu
â
SOS Setting
â
OK
.
2. Select
SOS SMS
â
OK
.
3. Select
On
or
Off
â
OK
.
FM radio
To listen to the radio, you should connect
a compatible headset which acts as an
antenna.
1. Press
Menu
â
Multimedia
â
OK
.
Alternavely press key from idle
mode.
2. Select
FM Radio
â
OK
.
3. Set the Volume with the side keys
+
/
-
.
4. Select a Frequency using keys *and
#.
5. Mute and unmute the radio with
PAUSE
.
6. Press
Options
â
•
Channel list
- list of the saved
channels.
•
Manual input
– to select a frequency
manually via ne tuning.
•
Auto. search
– radio station scan
and saving of the stations found.
Settings
•
Background playback
– If you select
On
the radio will still be on after
exiting the menu. To deactivate it,
stop the background playback in the
menu FM radio.
•
Loudspeaker
– Choose whether
the loudspeaker shall be on or the
playback shall take place via the
headset only when a headset is
connected.
Safety instructions
WARNING
The unit and the accessories can contain small parts. Keep
all of the equipment out of the reach of small children.
The mains adapter is the disconnect device between the
product and mains power. The mains socket outlet must be
close to the equipment and easily accessible.
Network services and costs
Your device is approved for use on the
GSM 900/1800 MHz networks. To use the
device, you need a subscription with a service
provider.
Using network services may result in trafc
costs. Some product features require support
from the network, and you may need to
subscribe to them.
Operating environment
Follow the rules and laws that apply wherever
you are, and always turn off the unit whenever
its use is prohibited or can cause interference
or hazards. Only use the unit in its normal user
position.
This unit complies with guidelines for radiation
when it is used either in a normal position
against your ear, or when it is at least 1.5 cm
from your body. If the unit is carried close to
your body in a case, belt holder or other holder,
these holders should not contain any metal, and
the product should be placed at the distance
from your body specied above. Make sure that
the distance instructions above are followed until
the transfer is complete.
Parts of the unit are magnetic. The unit can attract
metal objects. Do not keep credit cards or other
magnetic media near the unit. There is a risk that
information stored on them can be erased.
Medical units
The use of equipment that transmits radio signals,
for example, mobile phones, can interfere with
insufciently protected medical equipment. Consult
a doctor or the manufacturer of the equipment to
determine if it has adequate protection against
external radio signals, or if you have any questions.
If notices have been put up at health care facilities
instructing you to turn off the unit while you are there,
you should comply. Hospitals and other health care
facilities sometimes use equipment that can be
sensitive to external radio signals
Implanted medical devices
To avoid potential interference, manufactur-
ers of implanted medical devices recommend
a minimum separation of 15 cm between a
wireless device and the medical device. Persons
who have such devices should:
• Always keep the wireless device more than 15 cm
from the medical device.
• Not carry the wireless device in a breast pocket.
• Hold the wireless device to the ear opposite the
medical device.
If you have any reason to suspect that interference
is taking place, turn the phone off immediately. If
you have any questions about using your wireless
device with an implanted medical device, consult
your health care provider.
Areas with explosion risk
Always turn off the unit when you are in an
area where there is a risk of explosion. Follow
all signs and instructions. There is a risk of
explosion in places that include areas where
you are normally requested to turn off your
car engine. In these areas, sparks can cause
explosion or re which can lead to personal
injury or even death.
Turn off the unit at lling stations, and any
other place that has fuel pumps and auto repair
facilities.
Follow the restrictions that apply to the use
of radio equipment near places where fuel is
stored and sold, chemical factories and places
where blasting is in progress. Areas with risk for
explosion are often
– but not always – clearly marked. This also
applies to below decks on ships; the transport
or storage of chemicals; vehicles that use liquid
fuel (such as propane or butane); areas where
the air contains chemicals or particles, such as
grain, dust or metal powder.
Li-ion battery
This product contains a Li-ion battery. There
is a risk of re and burns if the battery pack is
handled improperly.
WARNING
Danger of explosion if battery is incorrectly replaced. To
reduce risk of re or burns, do not disassemble, crush,
puncture, short external contacts, expose to temperature
above 60° C (140° F), or dispose of in re or water.
Recycle or dispose of used batteries according to the local
regulations or reference guide supplied with your product.
Protect your hearing
WARNING
Excessive exposure to loud sounds can cause
hearing damage.
Exposure to loud sounds while driving may
distract your attention and cause an accident.
Listen to a headset at a moderate level, and do not hold the
device near your ear when the loudspeaker is in use.
Emergency calls
Important!
Mobile phones use radio signals, the mobile phone network,
the terrestrial network and user-programmed functions. This
means that connection cannot be guaranteed in all circum-
stances. Therefore, never rely only on a mobile phone for
very important calls such as medical emergencies.
Vehicles
Radio signals can affect electronic systems
in motor vehicles (for example, electronic fuel
injection, ABS brakes, automatic cruise control,
air bag systems) that have been incorrectly
installed or are inadequately protected. Contact
the manufacturer or its representative for more
information about your vehicle or any additional
equipment.
Do not keep or transport ammable liquids,
gases or explosives together with the unit or its
accessories.
For vehicles equipped with air bags: Remember
that air bags ll with air with considerable force.
Do not place objects, including xed or portable
radio equipment in the area above the airbag or
the area where it might expand.
Serious injuries may be caused if the mobile
phone equipment is incorrectly installed and the
airbag lls with air.
It is prohibited to use the unit in ight. Turn
off the unit before you board a plane. Using
wireless telecom units inside a plane can pose
risks to air safety and interfere with telecommu-
nications. It may also be illegal.
Care and maintenance
Your unit is a technically advanced product
and should be treated with the greatest care.
Negligence may void the warranty.
• Protect the unit from moisture. Rain/snowfall,
moisture and all types of liquid can contain
substances that corrode the electronic circuits. If
the unit gets wet, you should remove the battery
and allow the unit to dry completely before you
replace it.
• Do not use or keep the unit in dusty, dirty envi-
ronments. The unit’s moving parts and electronic
components can be damaged.
• Do not keep the unit in warm places. High tem-
peratures can reduce the lifespan for electronic
equipment, damage batteries and distort or melt
certain plastics.
• Do not keep the unit in cold places. When the
unit warms up to normal temperature, condensa-
tion can form on the inside which can damage
the electronic circuits.
• Do not try to open the unit in any other way than
that which is indicated here.
• Do not drop the unit. Do not knock or shake
it either. If it is treated roughly the circuits and
precision mechanics can be broken.
• Do not use strong chemicals to clean the unit.
The advice above applies to the unit, battery,
mains adapter and other accessories. If the
phone is not working as it should, please contact
the place of purchase for service. Don’t forget
the receipt or a copy of the invoice.
Warranty
In case you need support during setup or usage of
your mobile phone you will nd the relevant contact
details on the following website: www.swisstone.de
If you detect a defect resulting from manufac-
turing and/or material faults within 24 months
from purchase, please contact your dealer.
The warranty does not apply for improper
treatment or failure to comply with information
contained in this user guide, for interference on
device executed by dealer or user (e. g. instal-
lations, software downloads,…) and for total
loss. Furthermore it does not apply to ingress of
liquids, use of force, non-maintenance, improper
operation or other circumstances caused by the
user. It also does not apply to failure caused by a
thunderstorm or any other voltage uctuations.
The manufacturer reserves the right in this case
to charge the customer for replacement or repair.
For wear parts such as batteries, keyboard or
casing a restricted warranty period of 6 months
is valid. Manuals and possibly supplied software
are excluded from this warranty. Further or other
claims arising from the manufacturer’s warranty
are excluded. Thus, there is no liability claim for
business interruption, loss of prots, loss of data,
additionally installed software by user or other
information. The receipt with purchase date forms
the warranty proof.
Specic Absorption Rate (SAR)
This device meets applicable international safety
requirements for exposure to radio waves. The
highest SAR value under the ICNIRP guidelines
for use of the device at the ear is 0,668 W/kg
measured over 10 g tissue.
The maximum limit according to ICNIRP is 2.0
W/kg measured over 10 g tissue.
Declaration of Conformity
We hereby declare that Swisstone BBM 605 is
conform to the essential requirements and other
relevant regulations contained in the
Directives 1999/5/EC (R&TTE) and 2011/65/EC
(RoHS).
A copy of the Declaration of Conformity is
available at www.swisstone.de
SOS call setting
Activate the emergency call function.
1. Press
Menu
â
SOS Setting
â
OK
.
2. Select
Emergency alert
â
OK
.
3. Select
On
or
Off
â
OK
.
Important
If you deactivate the emergency call
function the emergency call key on the
back of the telephone will not work!
SOS Alarm Tone
Alarm sound on or off.
1. Press
Menu
, select
SOS Setting
and
press
OK
.
2. Select
SOS Alarm Tone
â
OK
.
3. Select
On
or
Off
â
OK
.
Emergency call contacts
The phone numbers to be called when
pressing the emergency call key. A
maximum of 5 numbers can be saved.
1. Press
Menu
â
SOS Setting
â
OK
.
2. Select
Emergency numbers
â
OK
.
3. Add at maximum 5 desired phone
numbers
Note!
Always inform your contacts when
adding them.
4. Press
Save
.
5. Conrm the question
Save?
with
Yes
.
SOS-SMS
SMS transmission on or off.
1. Press
Menu
â
SOS Setting
â
OK
.
2. Select
SOS SMS
â
OK
.
3. Select
On
or
Off
â
OK
.
FM radio
To listen to the radio, you should connect
a compatible headset which acts as an
antenna.
1. Press
Menu
â
Multimedia
â
OK
.
Alternavely press key from idle
mode.
2. Select
FM Radio
â
OK
.
3. Set the Volume with the side keys
+
/
-
.
4. Select a Frequency using keys *and
#.
5. Mute and unmute the radio with
PAUSE
.
6. Press
Options
â
•
Channel list
- list of the saved
channels.
•
Manual input
– to select a frequency
manually via ne tuning.
•
Auto. search
– radio station scan
and saving of the stations found.
Settings
•
Background playback
– If you select
On
the radio will still be on after
exiting the menu. To deactivate it,
stop the background playback in the
menu FM radio.
•
Loudspeaker
– Choose whether
the loudspeaker shall be on or the
playback shall take place via the
headset only when a headset is
connected.
Safety instructions
WARNING
The unit and the accessories can contain small parts. Keep
all of the equipment out of the reach of small children.
The mains adapter is the disconnect device between the
product and mains power. The mains socket outlet must be
close to the equipment and easily accessible.
Network services and costs
Your device is approved for use on the
GSM 900/1800 MHz networks. To use the
device, you need a subscription with a service
provider.
Using network services may result in trafc
costs. Some product features require support
from the network, and you may need to
subscribe to them.
Operating environment
Follow the rules and laws that apply wherever
you are, and always turn off the unit whenever
its use is prohibited or can cause interference
or hazards. Only use the unit in its normal user
position.
This unit complies with guidelines for radiation
when it is used either in a normal position
against your ear, or when it is at least 1.5 cm
from your body. If the unit is carried close to
your body in a case, belt holder or other holder,
these holders should not contain any metal, and
the product should be placed at the distance
from your body specied above. Make sure that
the distance instructions above are followed until
the transfer is complete.
Parts of the unit are magnetic. The unit can attract
metal objects. Do not keep credit cards or other
magnetic media near the unit. There is a risk that
information stored on them can be erased.
Medical units
The use of equipment that transmits radio signals,
for example, mobile phones, can interfere with
insufciently protected medical equipment. Consult
a doctor or the manufacturer of the equipment to
determine if it has adequate protection against
external radio signals, or if you have any questions.
If notices have been put up at health care facilities
instructing you to turn off the unit while you are there,
you should comply. Hospitals and other health care
facilities sometimes use equipment that can be
sensitive to external radio signals
Implanted medical devices
To avoid potential interference, manufactur-
ers of implanted medical devices recommend
a minimum separation of 15 cm between a
wireless device and the medical device. Persons
who have such devices should:
• Always keep the wireless device more than 15 cm
from the medical device.
• Not carry the wireless device in a breast pocket.
• Hold the wireless device to the ear opposite the
medical device.
If you have any reason to suspect that interference
is taking place, turn the phone off immediately. If
you have any questions about using your wireless
device with an implanted medical device, consult
your health care provider.
Areas with explosion risk
Always turn off the unit when you are in an
area where there is a risk of explosion. Follow
all signs and instructions. There is a risk of
explosion in places that include areas where
you are normally requested to turn off your
car engine. In these areas, sparks can cause
explosion or re which can lead to personal
injury or even death.
Turn off the unit at lling stations, and any
other place that has fuel pumps and auto repair
facilities.
Follow the restrictions that apply to the use
of radio equipment near places where fuel is
stored and sold, chemical factories and places
where blasting is in progress. Areas with risk for
explosion are often
– but not always – clearly marked. This also
applies to below decks on ships; the transport
or storage of chemicals; vehicles that use liquid
fuel (such as propane or butane); areas where
the air contains chemicals or particles, such as
grain, dust or metal powder.
Li-ion battery
This product contains a Li-ion battery. There
is a risk of re and burns if the battery pack is
handled improperly.
WARNING
Danger of explosion if battery is incorrectly replaced. To
reduce risk of re or burns, do not disassemble, crush,
puncture, short external contacts, expose to temperature
above 60° C (140° F), or dispose of in re or water.
Recycle or dispose of used batteries according to the local
regulations or reference guide supplied with your product.
Protect your hearing
WARNING
Excessive exposure to loud sounds can cause
hearing damage.
Exposure to loud sounds while driving may
distract your attention and cause an accident.
Listen to a headset at a moderate level, and do not hold the
device near your ear when the loudspeaker is in use.
Emergency calls
Important!
Mobile phones use radio signals, the mobile phone network,
the terrestrial network and user-programmed functions. This
means that connection cannot be guaranteed in all circum-
stances. Therefore, never rely only on a mobile phone for
very important calls such as medical emergencies.
Vehicles
Radio signals can affect electronic systems
in motor vehicles (for example, electronic fuel
injection, ABS brakes, automatic cruise control,
air bag systems) that have been incorrectly
installed or are inadequately protected. Contact
the manufacturer or its representative for more
information about your vehicle or any additional
equipment.
Do not keep or transport ammable liquids,
gases or explosives together with the unit or its
accessories.
For vehicles equipped with air bags: Remember
that air bags ll with air with considerable force.
Do not place objects, including xed or portable
radio equipment in the area above the airbag or
the area where it might expand.
Serious injuries may be caused if the mobile
phone equipment is incorrectly installed and the
airbag lls with air.
It is prohibited to use the unit in ight. Turn
off the unit before you board a plane. Using
wireless telecom units inside a plane can pose
risks to air safety and interfere with telecommu-
nications. It may also be illegal.
Care and maintenance
Your unit is a technically advanced product
and should be treated with the greatest care.
Negligence may void the warranty.
• Protect the unit from moisture. Rain/snowfall,
moisture and all types of liquid can contain
substances that corrode the electronic circuits. If
the unit gets wet, you should remove the battery
and allow the unit to dry completely before you
replace it.
• Do not use or keep the unit in dusty, dirty envi-
ronments. The unit’s moving parts and electronic
components can be damaged.
• Do not keep the unit in warm places. High tem-
peratures can reduce the lifespan for electronic
equipment, damage batteries and distort or melt
certain plastics.
• Do not keep the unit in cold places. When the
unit warms up to normal temperature, condensa-
tion can form on the inside which can damage
the electronic circuits.
• Do not try to open the unit in any other way than
that which is indicated here.
• Do not drop the unit. Do not knock or shake
it either. If it is treated roughly the circuits and
precision mechanics can be broken.
• Do not use strong chemicals to clean the unit.
The advice above applies to the unit, battery,
mains adapter and other accessories. If the
phone is not working as it should, please contact
the place of purchase for service. Don’t forget
the receipt or a copy of the invoice.
Warranty
In case you need support during setup or usage of
your mobile phone you will nd the relevant contact
details on the following website: www.swisstone.de
If you detect a defect resulting from manufac-
turing and/or material faults within 24 months
from purchase, please contact your dealer.
The warranty does not apply for improper
treatment or failure to comply with information
contained in this user guide, for interference on
device executed by dealer or user (e. g. instal-
lations, software downloads,…) and for total
loss. Furthermore it does not apply to ingress of
liquids, use of force, non-maintenance, improper
operation or other circumstances caused by the
user. It also does not apply to failure caused by a
thunderstorm or any other voltage uctuations.
The manufacturer reserves the right in this case
to charge the customer for replacement or repair.
For wear parts such as batteries, keyboard or
casing a restricted warranty period of 6 months
is valid. Manuals and possibly supplied software
are excluded from this warranty. Further or other
claims arising from the manufacturer’s warranty
are excluded. Thus, there is no liability claim for
business interruption, loss of prots, loss of data,
additionally installed software by user or other
information. The receipt with purchase date forms
the warranty proof.
Specic Absorption Rate (SAR)
This device meets applicable international safety
requirements for exposure to radio waves. The
highest SAR value under the ICNIRP guidelines
for use of the device at the ear is 0,668 W/kg
measured over 10 g tissue.
The maximum limit according to ICNIRP is 2.0
W/kg measured over 10 g tissue.
Declaration of Conformity
We hereby declare that Swisstone BBM 605 is
conform to the essential requirements and other
relevant regulations contained in the
Directives 1999/5/EC (R&TTE) and 2011/65/EC
(RoHS).
A copy of the Declaration of Conformity is
available at www.swisstone.de
SOS call setting
Activate the emergency call function.
1. Press
Menu
â
SOS Setting
â
OK
.
2. Select
Emergency alert
â
OK
.
3. Select
On
or
Off
â
OK
.
Important
If you deactivate the emergency call
function the emergency call key on the
back of the telephone will not work!
SOS Alarm Tone
Alarm sound on or off.
1. Press
Menu
, select
SOS Setting
and
press
OK
.
2. Select
SOS Alarm Tone
â
OK
.
3. Select
On
or
Off
â
OK
.
Emergency call contacts
The phone numbers to be called when
pressing the emergency call key. A
maximum of 5 numbers can be saved.
1. Press
Menu
â
SOS Setting
â
OK
.
2. Select
Emergency numbers
â
OK
.
3. Add at maximum 5 desired phone
numbers
Note!
Always inform your contacts when
adding them.
4. Press
Save
.
5. Conrm the question
Save?
with
Yes
.
SOS-SMS
SMS transmission on or off.
1. Press
Menu
â
SOS Setting
â
OK
.
2. Select
SOS SMS
â
OK
.
3. Select
On
or
Off
â
OK
.
FM radio
To listen to the radio, you should connect
a compatible headset which acts as an
antenna.
1. Press
Menu
â
Multimedia
â
OK
.
Alternavely press key from idle
mode.
2. Select
FM Radio
â
OK
.
3. Set the Volume with the side keys
+
/
-
.
4. Select a Frequency using keys *and
#.
5. Mute and unmute the radio with
PAUSE
.
6. Press
Options
â
•
Channel list
- list of the saved
channels.
•
Manual input
– to select a frequency
manually via ne tuning.
•
Auto. search
– radio station scan
and saving of the stations found.
Settings
•
Background playback
– If you select
On
the radio will still be on after
exiting the menu. To deactivate it,
stop the background playback in the
menu FM radio.
•
Loudspeaker
– Choose whether
the loudspeaker shall be on or the
playback shall take place via the
headset only when a headset is
connected.
Safety instructions
WARNING
The unit and the accessories can contain small parts. Keep
all of the equipment out of the reach of small children.
The mains adapter is the disconnect device between the
product and mains power. The mains socket outlet must be
close to the equipment and easily accessible.
Network services and costs
Your device is approved for use on the
GSM 900/1800 MHz networks. To use the
device, you need a subscription with a service
provider.
Using network services may result in trafc
costs. Some product features require support
from the network, and you may need to
subscribe to them.
Operating environment
Follow the rules and laws that apply wherever
you are, and always turn off the unit whenever
its use is prohibited or can cause interference
or hazards. Only use the unit in its normal user
position.
This unit complies with guidelines for radiation
when it is used either in a normal position
against your ear, or when it is at least 1.5 cm
from your body. If the unit is carried close to
your body in a case, belt holder or other holder,
these holders should not contain any metal, and
the product should be placed at the distance
from your body specied above. Make sure that
the distance instructions above are followed until
the transfer is complete.
Parts of the unit are magnetic. The unit can attract
metal objects. Do not keep credit cards or other
magnetic media near the unit. There is a risk that
information stored on them can be erased.
Medical units
The use of equipment that transmits radio signals,
for example, mobile phones, can interfere with
insufciently protected medical equipment. Consult
a doctor or the manufacturer of the equipment to
determine if it has adequate protection against
external radio signals, or if you have any questions.
If notices have been put up at health care facilities
instructing you to turn off the unit while you are there,
you should comply. Hospitals and other health care
facilities sometimes use equipment that can be
sensitive to external radio signals
Implanted medical devices
To avoid potential interference, manufactur-
ers of implanted medical devices recommend
a minimum separation of 15 cm between a
wireless device and the medical device. Persons
who have such devices should:
• Always keep the wireless device more than 15 cm
from the medical device.
• Not carry the wireless device in a breast pocket.
• Hold the wireless device to the ear opposite the
medical device.
If you have any reason to suspect that interference
is taking place, turn the phone off immediately. If
you have any questions about using your wireless
device with an implanted medical device, consult
your health care provider.
Areas with explosion risk
Always turn off the unit when you are in an
area where there is a risk of explosion. Follow
all signs and instructions. There is a risk of
explosion in places that include areas where
you are normally requested to turn off your
car engine. In these areas, sparks can cause
explosion or re which can lead to personal
injury or even death.
Turn off the unit at lling stations, and any
other place that has fuel pumps and auto repair
facilities.
Follow the restrictions that apply to the use
of radio equipment near places where fuel is
stored and sold, chemical factories and places
where blasting is in progress. Areas with risk for
explosion are often
– but not always – clearly marked. This also
applies to below decks on ships; the transport
or storage of chemicals; vehicles that use liquid
fuel (such as propane or butane); areas where
the air contains chemicals or particles, such as
grain, dust or metal powder.
Li-ion battery
This product contains a Li-ion battery. There
is a risk of re and burns if the battery pack is
handled improperly.
WARNING
Danger of explosion if battery is incorrectly replaced. To
reduce risk of re or burns, do not disassemble, crush,
puncture, short external contacts, expose to temperature
above 60° C (140° F), or dispose of in re or water.
Recycle or dispose of used batteries according to the local
regulations or reference guide supplied with your product.
Protect your hearing
WARNING
Excessive exposure to loud sounds can cause
hearing damage.
Exposure to loud sounds while driving may
distract your attention and cause an accident.
Listen to a headset at a moderate level, and do not hold the
device near your ear when the loudspeaker is in use.
Emergency calls
Important!
Mobile phones use radio signals, the mobile phone network,
the terrestrial network and user-programmed functions. This
means that connection cannot be guaranteed in all circum-
stances. Therefore, never rely only on a mobile phone for
very important calls such as medical emergencies.
Vehicles
Radio signals can affect electronic systems
in motor vehicles (for example, electronic fuel
injection, ABS brakes, automatic cruise control,
air bag systems) that have been incorrectly
installed or are inadequately protected. Contact
the manufacturer or its representative for more
information about your vehicle or any additional
equipment.
Do not keep or transport ammable liquids,
gases or explosives together with the unit or its
accessories.
For vehicles equipped with air bags: Remember
that air bags ll with air with considerable force.
Do not place objects, including xed or portable
radio equipment in the area above the airbag or
the area where it might expand.
Serious injuries may be caused if the mobile
phone equipment is incorrectly installed and the
airbag lls with air.
It is prohibited to use the unit in ight. Turn
off the unit before you board a plane. Using
wireless telecom units inside a plane can pose
risks to air safety and interfere with telecommu-
nications. It may also be illegal.
Care and maintenance
Your unit is a technically advanced product
and should be treated with the greatest care.
Negligence may void the warranty.
• Protect the unit from moisture. Rain/snowfall,
moisture and all types of liquid can contain
substances that corrode the electronic circuits. If
the unit gets wet, you should remove the battery
and allow the unit to dry completely before you
replace it.
• Do not use or keep the unit in dusty, dirty envi-
ronments. The unit’s moving parts and electronic
components can be damaged.
• Do not keep the unit in warm places. High tem-
peratures can reduce the lifespan for electronic
equipment, damage batteries and distort or melt
certain plastics.
• Do not keep the unit in cold places. When the
unit warms up to normal temperature, condensa-
tion can form on the inside which can damage
the electronic circuits.
• Do not try to open the unit in any other way than
that which is indicated here.
• Do not drop the unit. Do not knock or shake
it either. If it is treated roughly the circuits and
precision mechanics can be broken.
• Do not use strong chemicals to clean the unit.
The advice above applies to the unit, battery,
mains adapter and other accessories. If the
phone is not working as it should, please contact
the place of purchase for service. Don’t forget
the receipt or a copy of the invoice.
Warranty
In case you need support during setup or usage of
your mobile phone you will nd the relevant contact
details on the following website: www.swisstone.de
If you detect a defect resulting from manufac-
turing and/or material faults within 24 months
from purchase, please contact your dealer.
The warranty does not apply for improper
treatment or failure to comply with information
contained in this user guide, for interference on
device executed by dealer or user (e. g. instal-
lations, software downloads,…) and for total
loss. Furthermore it does not apply to ingress of
liquids, use of force, non-maintenance, improper
operation or other circumstances caused by the
user. It also does not apply to failure caused by a
thunderstorm or any other voltage uctuations.
The manufacturer reserves the right in this case
to charge the customer for replacement or repair.
For wear parts such as batteries, keyboard or
casing a restricted warranty period of 6 months
is valid. Manuals and possibly supplied software
are excluded from this warranty. Further or other
claims arising from the manufacturer’s warranty
are excluded. Thus, there is no liability claim for
business interruption, loss of prots, loss of data,
additionally installed software by user or other
information. The receipt with purchase date forms
the warranty proof.
Specic Absorption Rate (SAR)
This device meets applicable international safety
requirements for exposure to radio waves. The
highest SAR value under the ICNIRP guidelines
for use of the device at the ear is 0,668 W/kg
measured over 10 g tissue.
The maximum limit according to ICNIRP is 2.0
W/kg measured over 10 g tissue.
Declaration of Conformity
We hereby declare that Swisstone BBM 605 is
conform to the essential requirements and other
relevant regulations contained in the
Directives 1999/5/EC (R&TTE) and 2011/65/EC
(RoHS).
A copy of the Declaration of Conformity is
available at www.swisstone.de
SOS call setting
Activate the emergency call function.
1. Press
Menu
â
SOS Setting
â
OK
.
2. Select
Emergency alert
â
OK
.
3. Select
On
or
Off
â
OK
.
Important
If you deactivate the emergency call
function the emergency call key on the
back of the telephone will not work!
SOS Alarm Tone
Alarm sound on or off.
1. Press
Menu
, select
SOS Setting
and
press
OK
.
2. Select
SOS Alarm Tone
â
OK
.
3. Select
On
or
Off
â
OK
.
Emergency call contacts
The phone numbers to be called when
pressing the emergency call key. A
maximum of 5 numbers can be saved.
1. Press
Menu
â
SOS Setting
â
OK
.
2. Select
Emergency numbers
â
OK
.
3. Add at maximum 5 desired phone
numbers
Note!
Always inform your contacts when
adding them.
4. Press
Save
.
5. Conrm the question
Save?
with
Yes
.
SOS-SMS
SMS transmission on or off.
1. Press
Menu
â
SOS Setting
â
OK
.
2. Select
SOS SMS
â
OK
.
3. Select
On
or
Off
â
OK
.
FM radio
To listen to the radio, you should connect
a compatible headset which acts as an
antenna.
1. Press
Menu
â
Multimedia
â
OK
.
Alternavely press key from idle
mode.
2. Select
FM Radio
â
OK
.
3. Set the Volume with the side keys
+
/
-
.
4. Select a Frequency using keys *and
#.
5. Mute and unmute the radio with
PAUSE
.
6. Press
Options
â
•
Channel list
- list of the saved
channels.
•
Manual input
– to select a frequency
manually via ne tuning.
•
Auto. search
– radio station scan
and saving of the stations found.
Settings
•
Background playback
– If you select
On
the radio will still be on after
exiting the menu. To deactivate it,
stop the background playback in the
menu FM radio.
•
Loudspeaker
– Choose whether
the loudspeaker shall be on or the
playback shall take place via the
headset only when a headset is
connected.
Safety instructions
WARNING
The unit and the accessories can contain small parts. Keep
all of the equipment out of the reach of small children.
The mains adapter is the disconnect device between the
product and mains power. The mains socket outlet must be
close to the equipment and easily accessible.
Network services and costs
Your device is approved for use on the
GSM 900/1800 MHz networks. To use the
device, you need a subscription with a service
provider.
Using network services may result in trafc
costs. Some product features require support
from the network, and you may need to
subscribe to them.
Operating environment
Follow the rules and laws that apply wherever
you are, and always turn off the unit whenever
its use is prohibited or can cause interference
or hazards. Only use the unit in its normal user
position.
This unit complies with guidelines for radiation
when it is used either in a normal position
against your ear, or when it is at least 1.5 cm
from your body. If the unit is carried close to
your body in a case, belt holder or other holder,
these holders should not contain any metal, and
the product should be placed at the distance
from your body specied above. Make sure that
the distance instructions above are followed until
the transfer is complete.
Parts of the unit are magnetic. The unit can attract
metal objects. Do not keep credit cards or other
magnetic media near the unit. There is a risk that
information stored on them can be erased.
Medical units
The use of equipment that transmits radio signals,
for example, mobile phones, can interfere with
insufciently protected medical equipment. Consult
a doctor or the manufacturer of the equipment to
determine if it has adequate protection against
external radio signals, or if you have any questions.
If notices have been put up at health care facilities
instructing you to turn off the unit while you are there,
you should comply. Hospitals and other health care
facilities sometimes use equipment that can be
sensitive to external radio signals
Implanted medical devices
To avoid potential interference, manufactur-
ers of implanted medical devices recommend
a minimum separation of 15 cm between a
wireless device and the medical device. Persons
who have such devices should:
• Always keep the wireless device more than 15 cm
from the medical device.
• Not carry the wireless device in a breast pocket.
• Hold the wireless device to the ear opposite the
medical device.
If you have any reason to suspect that interference
is taking place, turn the phone off immediately. If
you have any questions about using your wireless
device with an implanted medical device, consult
your health care provider.
Areas with explosion risk
Always turn off the unit when you are in an
area where there is a risk of explosion. Follow
all signs and instructions. There is a risk of
explosion in places that include areas where
you are normally requested to turn off your
car engine. In these areas, sparks can cause
explosion or re which can lead to personal
injury or even death.
Turn off the unit at lling stations, and any
other place that has fuel pumps and auto repair
facilities.
Follow the restrictions that apply to the use
of radio equipment near places where fuel is
stored and sold, chemical factories and places
where blasting is in progress. Areas with risk for
explosion are often
– but not always – clearly marked. This also
applies to below decks on ships; the transport
or storage of chemicals; vehicles that use liquid
fuel (such as propane or butane); areas where
the air contains chemicals or particles, such as
grain, dust or metal powder.
Li-ion battery
This product contains a Li-ion battery. There
is a risk of re and burns if the battery pack is
handled improperly.
WARNING
Danger of explosion if battery is incorrectly replaced. To
reduce risk of re or burns, do not disassemble, crush,
puncture, short external contacts, expose to temperature
above 60° C (140° F), or dispose of in re or water.
Recycle or dispose of used batteries according to the local
regulations or reference guide supplied with your product.
Protect your hearing
WARNING
Excessive exposure to loud sounds can cause
hearing damage.
Exposure to loud sounds while driving may
distract your attention and cause an accident.
Listen to a headset at a moderate level, and do not hold the
device near your ear when the loudspeaker is in use.
Emergency calls
Important!
Mobile phones use radio signals, the mobile phone network,
the terrestrial network and user-programmed functions. This
means that connection cannot be guaranteed in all circum-
stances. Therefore, never rely only on a mobile phone for
very important calls such as medical emergencies.
Vehicles
Radio signals can affect electronic systems
in motor vehicles (for example, electronic fuel
injection, ABS brakes, automatic cruise control,
air bag systems) that have been incorrectly
installed or are inadequately protected. Contact
the manufacturer or its representative for more
information about your vehicle or any additional
equipment.
Do not keep or transport ammable liquids,
gases or explosives together with the unit or its
accessories.
For vehicles equipped with air bags: Remember
that air bags ll with air with considerable force.
Do not place objects, including xed or portable
radio equipment in the area above the airbag or
the area where it might expand.
Serious injuries may be caused if the mobile
phone equipment is incorrectly installed and the
airbag lls with air.
It is prohibited to use the unit in ight. Turn
off the unit before you board a plane. Using
wireless telecom units inside a plane can pose
risks to air safety and interfere with telecommu-
nications. It may also be illegal.
Care and maintenance
Your unit is a technically advanced product
and should be treated with the greatest care.
Negligence may void the warranty.
• Protect the unit from moisture. Rain/snowfall,
moisture and all types of liquid can contain
substances that corrode the electronic circuits. If
the unit gets wet, you should remove the battery
and allow the unit to dry completely before you
replace it.
• Do not use or keep the unit in dusty, dirty envi-
ronments. The unit’s moving parts and electronic
components can be damaged.
• Do not keep the unit in warm places. High tem-
peratures can reduce the lifespan for electronic
equipment, damage batteries and distort or melt
certain plastics.
• Do not keep the unit in cold places. When the
unit warms up to normal temperature, condensa-
tion can form on the inside which can damage
the electronic circuits.
• Do not try to open the unit in any other way than
that which is indicated here.
• Do not drop the unit. Do not knock or shake
it either. If it is treated roughly the circuits and
precision mechanics can be broken.
• Do not use strong chemicals to clean the unit.
The advice above applies to the unit, battery,
mains adapter and other accessories. If the
phone is not working as it should, please contact
the place of purchase for service. Don’t forget
the receipt or a copy of the invoice.
Warranty
In case you need support during setup or usage of
your mobile phone you will nd the relevant contact
details on the following website: www.swisstone.de
If you detect a defect resulting from manufac-
turing and/or material faults within 24 months
from purchase, please contact your dealer.
The warranty does not apply for improper
treatment or failure to comply with information
contained in this user guide, for interference on
device executed by dealer or user (e. g. instal-
lations, software downloads,…) and for total
loss. Furthermore it does not apply to ingress of
liquids, use of force, non-maintenance, improper
operation or other circumstances caused by the
user. It also does not apply to failure caused by a
thunderstorm or any other voltage uctuations.
The manufacturer reserves the right in this case
to charge the customer for replacement or repair.
For wear parts such as batteries, keyboard or
casing a restricted warranty period of 6 months
is valid. Manuals and possibly supplied software
are excluded from this warranty. Further or other
claims arising from the manufacturer’s warranty
are excluded. Thus, there is no liability claim for
business interruption, loss of prots, loss of data,
additionally installed software by user or other
information. The receipt with purchase date forms
the warranty proof.
Specic Absorption Rate (SAR)
This device meets applicable international safety
requirements for exposure to radio waves. The
highest SAR value under the ICNIRP guidelines
for use of the device at the ear is 0,668 W/kg
measured over 10 g tissue.
The maximum limit according to ICNIRP is 2.0
W/kg measured over 10 g tissue.
Declaration of Conformity
We hereby declare that Swisstone BBM 605 is
conform to the essential requirements and other
relevant regulations contained in the
Directives 1999/5/EC (R&TTE) and 2011/65/EC
(RoHS).
A copy of the Declaration of Conformity is
available at www.swisstone.de
Table of contents
