Sylvac D70S Operator's manual

D70S/i/H Quick Startup
Installation
Remove the D70 from its packaging and connect the plug or mini-USB
at the back of the unit to a wall socket or to one of your computer’s USB
ports.
To start the D70, press the on/off button at the back of the unit (see
connectors).
On/off button
(hold for 2 s to
switch off)
Two ports for
Sylvac inductive
or capacitive
sensors (or
Heindehein sen-
sors on version H)
RS232 connector for PC
communication
Connector for pedal
Mini-USB connector
for power supply and
transferring the mea-
surement to a PC
Connectors
1
The D70 has four M5-thread holes, meaning that it can be affixed to a worktop, or the base
can be removed in order to place it anywhere.
Note: The four anti-slip pads need to be removed before the D70 can be affixed to a worktop.
Linearisation/Correction table
The D70 allows the linearity of the probes to be corrected by inputting a correction table contai-
ning up to 25 points. This allows a significant improvement in the performance of the connec-
ted probes.

Swiss manufacturer of precision measuring instruments since 1969
2
Restore factory settings
This function allows you to revert the D70 to default settings.
Caution:This function will reset all of the parameters and settings of your D70.Tolerances, benchmark settings
and sensor settings will be lost. (Linearisation is not lost on the D70S version however; it simply needs to be
reactivated.)
Mini-USB connector
This can supply power to the D70 and also allows for the
transmission of measurements to a computer.
Install the drivers located on the CD-ROM which accompa-
nies the D70. Then connect the unit to the computer. The
computer should recognise the new device and will display
the following message:
To do this, follow the procedure below:
1. Turn off the D70.
2. Switch on the D70.
3. When the start screen appears, tap the Sylvac logo.
4. A panel with five icons will appear.
5. Tap Linearity.
6. To activate the linearisation function, choose “En-
abled” = “Yes”.
7. You may then enter up to 25 correction points.
8. To do this, place yourself in a position corresponding to
one point: the non-corrected sensor value will be dis-
placed in the “Probe” box. Input the actual value in the
“Real position” box.
9. Press the “Home” icon to go back
To do this, follow points 1 to 4 above, then press “Initialisation” and confirm with YES or cancel
with NO. Then tap the “Home” icon to return to the measurement screen.
Your devices are ready to use
Device driver software installed
successfully.
681.124-110
