SPECIFICATION SHEET
Symbol LS4278
Cordless freedom improves productivity and
protects profitability
Motorola’s cordless Symbol LS4278 provides
superior bar code scanning in a durable future-proof
device that delivers an outstanding total cost of
ownership. Workers can move within a 50 ft./15 m
radius to scan items — and the elimination of
hazardous cables creates a safer work environment.
From cashiers moving around the register to scan
large, heavy items and check for missed items to
healthcare workers double checking that the right
patient is receiving the right medication, integrated
Bluetooth wireless personal area networking
(WPAN) provides reliable and secure wireless
transmission of data between the scanner and
your host. Productivity is improved, revenues are
protected and potential liability due to injury from
lifting heavy objects is reduced.
Outstanding scanning performance
The Symbol LS4278 is designed to deliver exceptional
scanning performance. Users can scan objects at
any angle — the innovative multi-line rastering
scan pattern eliminates the need for exact aim and
positioning of the scanner. The laser line moves
vertically during scanning, allowing accurate capture
of even the smallest, stacked and poorly printed bar
codes on the first scan. And with superior motion
tolerance, users no longer need pause between
scans, further increasing productivity.
A new level of durability — and a lower TCO
The Symbol LS4278 scanner and cradle are
designed to withstand all day every day use,
from drops to spills, with features that deliver
maximum uptime and investment protection.
The scanner’s patented single board construction
eliminates the most common point of failure — the
interconnection between multiple boards. Even
if the scanner is accidentally dropped, a five-foot
(1.5m) drop specification ensures continuous reliable
operation. The scanner and cradle offer industrial
charging contacts that eliminate wear when
cradling the device, providing a reliable charging
connection through hundreds of thousands of
insertions — other common charging techniques
show wear between 5,000 to 10,000 insertions.
Drain points are designed into the cradle to protect
sensitive internal electronics from accidental liquid
spills. Built-in enterprise durability combines with
Motorola’s Enterprise Mobility Services to deliver a
low total cost of ownership. These comprehensive
services are available to assist in rapid deployment
as well as provide the ongoing support you need
to maintain peak performance — and achieve
maximum uptime and value.
For more information on the LS4278, visit
www.motorola.com/ls4278 or access our global
contact directory at www.motorola.com/enterprise/
contactus
Cordless handheld scanner
FEATURES
Bluetooth Class 2 v1.2
(Serial Port & HID Profiles
with authentication
and security)
Cordless scanning with
secure wireless transmission
of data
Multi-line rastering
scan pattern
Eliminates the need for
exact aim and positioning for
superior scanning accuracy
Remote scanner
management (RSM) ready
Discover, provision and
upgrade devices from a
central remote location;
dramatically reduces
management effort
and costs
Long life industrial
charging contacts
Reliable performance, rated
to 250,000+ insertions
Patented, single
circuit-board
Lowers TCO by eliminating a
major source of vulnerability

SPECIFICATION SHEET
SYMBOL LS4278
Cordless handheld scanner
Wide working range
Reads good and poor
quality bar codes at similar
ranges, reducing the need
for the user to move the
scanner back and forth
Superior motion tolerance
Eliminates the need to
pause between scans
Withstands 5 ft./1.5 m
drops to concrete
Protects against downtime
from breakage due to
everyday drops
Powered through
host cable
Eliminates need for a
power supply; simplifies
installation
Plug-and-play;
universal cable
Rapid deployment; single
cable connects to any
computing environment
Multi point-to-point
Use up to three
scanners with a single
cradle, reducing capital
expenditures and
maintenance costs
Batch mode operation
Increases application design
flexibility to better meet
your specific needs
Vertical or horizontal
mounting
Provides versatility to
accommodate your unique
environment
Symbol LS4278 Specifications
Physical Characteristics
Dimensions: Scanner: 7.3 in. H x 3.85 in. L x 2.7 in. W/
18.5 cm H x 9.7 cm L x 6.9 cm W
Cradle: 2.0 in. H x 8.35 in. L x 3.4 in./
5 cm H x 21.1 cm L x 8.6 cm W
Weight: Scanner: ~8.4 oz./238 g; Cradle: ~6.4 oz./183 g
Mounting Options: Cradle supports vertical or horizontal positions
Voltage & Current: Voltage Current (Charging / Non Charging)
(Cradle) 5 +/-10% VDC 620 mA / 70mA with external power
5 +/-10% VDC 450 mA / 70mA with host power
through cable
12 +/-10% VDC 270 mA / 50mA with external power
12 +/-10% VDC 230 mA / 50mA with host power
through cable
Color: Cash Register White (shown) or Twilight Black
Performance Characteristics
Light Source: 650 nm laser diode
Scan Element Frequency: 50Hz
Decode Rate: 200 decodes per second
Radio Range: Minimum 33 ft./10 m; typical warehouse environment
50 ft./15 m
Battery Specifications: 720 maH NiMH - (3) AAA
Number of scans per full charge: 32,000+ @ 1 scan/second
Charge time: Fully discharged battery: < 3 hours via
external power / ~4.5 hours via host power through
cable (Note: Typical daily scans are less than 4,000,
which fully charges within 1 hour)
Roll / Pitch / Yaw: +/- 35° / 60° / 60°
Nominal Working See chart below
Distance:
Print Contrast: 25% minimum reflectance
Multi-Line Aiming At 5 in./12.7 cm reading distance: ~ 0.5 in./1.3 cm
Coverage: At 10 in./25.4 cm reading distance: ~ 1 in./2.5 cm
Motion Tolerances: Horizontal velocity: 200 in./508 cm per second
Vertical velocity: 200 in./508 cm per second
Angular velocity: 200 in./508 cm per second
Decode Capability: UPC/EAN and with supplementals, Code 39, Code 39
Full ASCII, Tri-optic Code 39, GS1 DataBar (formerly
RSS) variants,, UCC/EAN 128, Code 128, Code 128 Full
ASCII, Code 93, Codabar (NW1), Interleaved 2 of 5,
Discrete 2 of 5 MSI, Codell, IATA, Bookland EAN,
Code 32
Interfaces Supported: LS4278 cradle features on-board multiple interface
with: RS-232C (Standard, Nixdorf, ICL and Fujitsu);
IBM 468x/469x; keyboard wedge; USB (Standard,
IBM SurePOS, Macintosh); laser/wand emulation. In
addition, Synapse adaptive connectivity allows for
connectivity to all of the above plus many non-standard
interfaces.
User Environment
Operating Temperature: 32° to 122° F/0° to 50° C
Storage Temperature: -40° to 158° F/-40° to 70° C
Humidity: 5% to 95% non-condensing
Drop Specifications: Withstands multiple 5 ft./1.5 m drops to concrete
# of Cradle Insertions: 250,000+ insertions
Ambient Light Immunity: Immune to normal artificial indoor and natural outdoor
(direct sunlight) lighting conditions
Regulatory
Electrical Safety: UL1950, CSA C22.2 No. 950, EN60950/IEC950
Laser Safety: CDRH Class II, IEC Class 2
EMI/RFI: FCC Part 15 Class B, ICES-003 Class B, European Union
EMC Directive, Australian SMA
Radio: Bluetooth, Class 2, Version 1.2, Serial Port & HID
Profiles 2.402 to 2.480 GHz Adaptive Frequency
Hopping (co-existence with 802.11 wireless networks)
Data rate: 720 kbps
Accessories
Brackets: Desktop/wall-mount bracket
Power Supplies: Power supplies are available for applications that do
not supply power over the host cable
Warranty
Subject to the terms of Motorola’s hardware warranty statement, the Symbol
LS4278 handheld scanner products are warranted against defects in workmanship
and materials for a period of three years from the date of shipment. The Liquid
Polymer Scan Element includes an unprecedented limited lifetime warranty.
For the complete Motorola hardware product warranty statement, go to:
http://www.motorola.com/warranty.
motorola.com
Part number SS-LS4278. Printed in USA 12/07. MOTOROLA and the Stylized M Logo and SYMBOL and the Stylized SYMBOL Logo are registered in the US Patent & Trademark
Office. All other product or service names are the property of their respective owners. ©2007 Motorola, Inc. All rights reserved. For system, product or services availability and
specific information within your country, please contact your local Motorola office or Business Partner. Specifications are subject to change without notice.
Paper Label English Metric
Code 39 - 5 mil 1.5” – 5.5” 3.81 – 13.97cm
100% UPC/EAN - 13 mil 0” – 19.0” 0 – 48.25cm
Code 39 - 10 mil 0” – 14.0” 0 – 35.56cm
Code 39 - 20 mil 0” – 29.0” 0 – 73.66cm
Depth of Field
Label Density LS4278
