SYSFORM S-500 User manual

S-500
Electric Corner Cutter
OPERATING MANUAL
Electric Corner Cutter
OPERATING MANUAL

Safety
Please use thismachine carefully, do not put your hand beneath
the blade to avoid hurt and contingency.Pleasenote the followings
when you use this machine:
Place:The machine is approximate21Kg.please fixthe machine in aflat
and sturdyandwell-ventilated place.
Electric supply: Please connectthe electric supplycorrectlyas per the
instruction on thebackofthe machine. Theelectric supplyshould be
stable AC230V or AC115V, 50/60Hz, and 65W. No matter the voltage is
too lowor high, bothwill make themachine work incorrectly.
Grounding: For safetyconcern, please use the socket with earth wire.
Overload: Please do not connect toomanyelectric appliances ina
samesocket becauseoverload maycause fire.
Clean: Beforeyou clean this machine,please switch-offthe power and
pull the plugout of thesocket.
1

1. Unpack and check
After you open the box, pleasecheck the machine and
attached parts, if youfind anydamage or something lost,
please contact us immediately.
a. Machine1 set
b. Manual 1 pc
c. Hexagon wrench 3 pc(3,4,5mm)
d. Philips screwdriver1 pc
e. Stacker 1 pc
f.Calibrationgauge3 pc
g.Foot pedal 1 pc
h. Power cord 1pc
²Note
nIt is suggested to readthis manual carefullybefore you
use thismachine,which willimproveyourskillto useit
to get an excellent result.
nPlease savethe packing carton and theplastic bag for
transferring next time.
2

1. Names and Functions
A
B
C
D
E
AClamp
BScrewfor adjustingclamp
CSide lay
DLower die
EInchingbutton
F. Foot pedal
G. Power switch
H. Waste box
I. Upper blade
3
I
H
G
E
F

2. Operation Instructions
lPlace themachineonttop
of a sturdy working bench
lMake sure the waste box
is in position
lLoosen the screw at right
side of the working table.
lDirectly plug in the
expanding table and
tighten thescrew a bit.
4

lPlug foot pedal and
power cord into the
socket
lPress down the inching
button to let the upper
blade slowly go down
intermittently to touch
the lower blade, check
if the bladeis
lLoosen the screw to
adjust position of the
clamp.
lClamp pressure =3-6 kg.
5
if the bladeis
ready to work.

lUse left and right edges
of the stacker to knock
the stack of sheets in
parallel till sheets are
neat.
lUse the stacker by left
hand to push the stack
of sheets to close right
and left side lays.(keep
finger out of the clamp)
lPress down the foot
pedal by right hand for
cutting down.(press
down the foot pedal one
time to finish one cycle)
6

3. Changing blade
lSwitch the machine off
lRemove the clamp
lRemove the left and right
side lays
lLoosen the two lower
die fixing screws.
lTake away the lower die
7

lLoosen the four fixing
plate screws.
lReplace a new upper
blade backinto the
original position and
make sure screws fasten
tightly.
lSwitch the machine on
then press theinching
button to have the
upper bladecutdown to
the lowest point.
lPut thelower die into
the working desk, and
setting two screws.
8

lAs shown in the photo, left hand
push
to press the upper blade slightly
then fasten
screws.
lAfter replacing the blade,
theside lays
recalibrated
4. Calibration for side lay
lSwitch the machine on
then press theinching
button to have the upper
blade cutdown to the
lowest point.
lPlace thecalibration
gauge onto the working
table. Push it to let its angle pr
ess the upper blade with
no gap
9
push
es the lower die
then fasten
two
theside lays
must be
ess the upper blade with

l
Push theleft and right side lays to close the left and
right edges of the calibration gauge thenfasten their
fixing screws.
5. Sharpening bladeand die
lSharpen the upper blade
and thelower die, grind
the planeshown at the
arrowed place and
remove 0.1mm per time.
lOne sharpeningprocess
can sustain for over 10000 cuts.
6. Lubrication
l
Refuel lubricant every 30 days for using frequently, for
not often use every 90 days.
10
Push theleft and right side lays to close the left and
right edges of the calibration gauge thenfasten their
Refuel lubricant every 30 days for using frequently, for

lSwitch the machine off,
unplug the power cord.
lRemove the cover,
lubricate sliding motion
mechanism.
lAdjust sliding gap every
90 days for using
frequently, for not often
use every 180 days.
lLoosen the two screws of lower die
,
screws of left slid
ing bar then letthe sliding bar clamp
the upper bladecarrier
slightly then fasten their screws
l
Attention, the blade must be recalibrated after
adjustment.
11
,
loosen thetwo
ing bar then letthe sliding bar clamp
slightly then fasten their screws
.
Attention, the blade must be recalibrated after

7. warning
nThe machineshall not be operated by two operators at
the same time.
nThe machineshall be well-connected and well
maintained. If you want to maintain machine, please
disconnect themachine from power.
12
