syslogic CPC/MITX7i A Series Operator's manual

u s e r d o c u m e n t a t i o n
CPC/MITX7ixY-Azzz
Document Ordercode: DOC/MITX7ixY
Revision
Date
Author
Modification
0.1
02.02.18
D. Lagler
Preliminary
1.0
25.05.18
D. Lagler
Initial version
1.1
30.05.18
D. Lagler
Technical Data added

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 2/29
Contents
1Introduction 6
1.1 General Remarks 6
1.2 Contents of this Documentation 6
1.3 Additional Products and Documents 6
1.3.1 Hardware Products 6
1.3.2 Documents 6
1.4 Items delivered 7
1.5 Installation 7
1.6 Safety Recommendations and Warnings 7
1.6.1 General warnings 7
1.6.2 EMC 8
1.6.3 Electro Static Discharge 8
1.6.4 Battery 8
1.6.5 Hot surface 8
1.7 Life Cycle Information 8
1.7.1 Transportation and Storage 8
1.7.2 Assembly and Installation 8
1.7.3 Operation 9
1.7.4 Maintenance and Repair 9
1.7.5 Disposal 9
2Product Description 10
2.1 Features 10
2.2 Product Variants 12
3Hardware Description 13
3.1 Overview 13
3.2 Peripheral Devices 13
3.2.1 DisplayPort Interface 13
3.2.2 High Definition Audio 13
3.2.3 SATA Interface (internal) 14
3.2.4 SATA Power (internal) 14
3.2.5 M.2 Slot (internal) 15
3.2.6 Micro SD Card (internal) 16
3.2.7 Serial Ports 16
3.2.8 USB Interface Front 17
3.2.9 USB Interface internal 18
3.2.10 Ethernet LAN Interface 18
3.2.11 Power supply 19
3.2.12 Power button 19

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 3/29
4Technical Data 20
4.1 General Electrical Data 20
4.2 EMI / EMC Specification 21
4.3 Mechanical Data 22
5Programming Information 23
5.1 Peripheral Devices 23
5.1.1 SATA-Interface 23
5.1.2 Serial Ports 23
5.1.3 Ethernet Interface 23
5.1.4 USB Interface 23
6Installation and cabling 24
6.1 Introduction 24
6.2 Powering the COMPACTc7 System 24
6.3 Cabling the interfaces 24
6.4 Grounding 25
6.5 Cabling of communication links 26
7Service 27
7.1 Replaceable Parts 27
8Firmware 28
8.1 Software Structure 28
8.1.1 BIOS (Basic Input/Output System) 28
8.1.2 OS (Operating System) 28
8.1.3 Application Programs 28
8.2 Firmware Functions 28
8.3 Application Programming Interface (API) 28
9Manufacturer Information 29
9.1 Contact 29
9.2 Warranty 29

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 4/29
List of Tables
Tab. 1 Product Variants ...................................................................................................................................12
Tab. 2 MIC-IN Pinout Description ..................................................................................................................13
Tab. 3 Line-OUT Pinout Description.............................................................................................................. 13
Tab. 4 X12: 15-pin standard SATA power connector .................................................................................14
Tab. 5 X10: M.2 type 3042/2242 interface................................................................................................... 15
Tab. 6 Connector X60 Pinout Description ....................................................................................................16
Tab. 7 Serial Ports COM1/2 on DSUB-9 male X1, X2 .................................................................................16
Tab. 8 USB1/2 Interface Connector (Dual Type A).....................................................................................17
Tab. 9 USB3/4 Interface Connector (Dual Type A).....................................................................................17
Tab. 10 USB7/8 on interface connector X16.................................................................................................. 18
Tab. 11 USB9/10 on interface connector X15................................................................................................18
Tab. 12 Power supply connector......................................................................................................................19

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 5/29
List of Figures
Fig. 1 Block diagram miniITX-Board (all functions)................................................................................... 11
Fig. 2 Additional grounding of the cable shields at the entry point of a cabinet.................................25
Fig. 3 Non-isolated communication link with common chassis potential.............................................26
Fig. 4 Isolated communication link ..............................................................................................................26
Fig. 5 Drawing COMPACTc7 system...........................................................................................................22

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 6/29
1Introduction
1.1 General Remarks
The content and presentation of this document has been carefully checked. No responsibility is accepted
for any errors or omissions in the documentation.
Note that the documentation for the products is constantly revised and improved. The right to change this
documentation at any time without notice is therefore reserved.
Syslogic is grateful for any help referring to errors or for suggestions for improvements.
The following registered trademarks are used:
IBM-PC, PC/AT, PS/2 trademarks of IBM Corporation
I2C trademark of Philips Corporation
CFast trademark of CompactFlash Association
PCIe trademark of PCI-SIG
1.2 Contents of this Documentation
This document addresses to system integrators, programmers and instructed installation and
maintenance personal working with the industrial PC system. It provides all information needed to
configure, setup and program the CPC/MITX7ixY-Azzz systems. For complete information the
documentation of the mounted communications and I/O boards must be consulted as well. In the
following paragraphs all descriptions referenced to COMPACTc7 apply to all, the CPC/MITX7ixY-Azzz
products, if not declared otherwise.
1.3 Additional Products and Documents
1.3.1 Hardware Products
The following hardware products are useful together with the COMPACTc7 system:
Mini PCI Express Cards
1.3.2 Documents
The following additional documents are useful for correct installation and operation of the COMPACTc7
system:
The following documents are useful for additional information about MiniPCIe:
–PCIe Base Specification Version 1.1
–PCIe Mini Card Electromechanical Specification Version 1.2
The MiniPCIe Specification may be downloaded from the Internet (see address below).
–PCI-SIG Consortium
www.pcisig.com/specifications/pciexpress/base
The following documents are useful for additional information about IEEE 996.1:
–IEEE 996: IEEE standard document ‘Personal Computer Bus Standard’
–IEEE 996.1: IEEE standard document ‘Compact Embedded -PC Modules’
–ISBN 0-929392-15-9: ‘ISA & EISA, Theory and Operation’ by Edward Sol ari
(Annabooks, San Diego)
The IEEE standard documents may be ordered directly from the IEEE or any standards document
distributor (see addresses below).

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 7/29
–IEEE Standards Department
www.ieee.org
–Global Engineering Documents
www.global.ihs.com
1.4 Items delivered
The COMPACTc7 comes without external cabling and power supply. These additional items must be
ordered separately and installed according to the respective user documentations.
1.5 Installation
The installation of the COMPACTc7 system is described in chapter 6 of this documentation.
Important Note
Before applying power to the COMPACTc7 system, all installed boards must be correctly
configured and mounted.
1.6 Safety Recommendations and Warnings
The products are intended for measurement, control and communications applications in industrial
environments. The products must be assembled and installed by specially trained people. The strict
observation of the assembly and installation guidelines is mandatory.
The use of the products in systems in which life or health of persons is directly dependent (e.g. life support
systems, patient monitoring systems, etc.) is not allowed.
The use of the products in potentially explosive atmospheres requires additional external protection
circuitry which is not provided with the products.
In case of uncertainty or of believed errors in the documentation please immediately contact the
manufacturer (address see chapter 9). Do not use or install the products if you are in doubt. In any case
of misuse of the products, the user is solely liable for the consequences.
1.6.1 General warnings
Important note
Ensure that the power supply is disconnected from the device before working
on the device (connecting interfaces, replacing flash cards, batteries, opening
the enclosure, etc.).
Important note
The output voltage of the external power supply shall be SELV and shall be
limited power source according to clause 2.5 EN 60950-1.
Please read the safety instructions of the power supply before
installing/connecting the device.

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 8/29
1.6.2 EMC
Important note
This is a Class A product and not intended to be used in domestic environment.
The product may cause electromagnetic interference. Appropriate measures
must be taken.
1.6.3 Electro Static Discharge
Electronic boards are sensitive to Electro-Static Discharge (ESD). Please ensure
that the product is handled with care and only in an ESD protected environment.
Otherwise a proper operation is not guaranteed.
1.6.4 Battery
Maintenance of battery
Empty batteries may leak.
Check battery status flag and replace the battery to avoid loss of date (RTC) and
damage to the product.
Changing batteries
Danger of explosion if the battery is not correctly replaced. Replace only with
the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Never short the battery.
1.6.5 Hot surface
Attention! Hot surfaces
Make sure the device is not hot before mounting or changing the installation.
The device may be hot and may cause burns.
1.7 Life Cycle Information
1.7.1 Transportation and Storage
During transportation and storage the products must be in their original packing. The original packing
contains antistatic and shock-absorbing material. It is recommended, to keep the original packing in case
of return of the product to the factory for repair. Note that the packing is recyclable.
1.7.2 Assembly and Installation
Observe the EMI-precautions against static discharge. Carefully read the assembly and installation
documentation (see chapter 6) before unpacking the products. Make sure that you have all the necessary
items ready (including all the small parts). Follow the assembly guidelines in chapter 6 strictly.

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 9/29
The installation procedures must be strictly observed. Note that deviations from the installation guidelines
may result in degraded operational reliability or in unfavorable EM-radiation or EM-susceptibility.
1.7.3 Operation
The operating environment must guarantee the environmental parameters (temperature, power supply,
etc.) specified in the technical specification section of the product manuals.
The main functionality of the COMPACTc7 system is defined by the application programs running on the
processor board. The application programs are not part of the delivery by Syslogic but are defined,
developed and tested by the customer or a system-integrator for each specific application. Refer to the
respective documentation for more information.
1.7.4 Maintenance and Repair
The IPC system features error- and malfunction-detection circuitry. Diagnostic information gathered is
transferred to the applications software where it can be used. In the rare case of a module hardware-
failure or malfunction, the complete system should be exchanged. The faulty system must be returned to
the factory for repair. Please use whenever possible the original packing for return of the product (EMI
and mechanical protection).
1.7.5 Disposal
At the end of the lifespan the COMPACTc7 products must be properly disposed. COMPACTc7 products
contain a multitude of elements and must be disposed like computer parts. Some of the COMPACTc7
products contain batteries which should be properly disposed.

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 10/29
2Product Description
2.1 Features
The COMPACTc7 system is a x86 based industrial PC designed for use with the IPC line of communications
and I/O boards. Its many different variants allow to build up various industrial controls based on the
standard PC/AT architecture.
The COMPACTc7 offers the following main features:
-mITX-Board
-High performance 7th Generation Intel® CoreTM Mobile SoC U-Processors.
-up to 2.8 GHz processor clock
-High Definition Audio Interface (Realtek ALC 888S)
-Improved Graphics Performance with Intel HD Graphics HD620
-Multi-Stage watchdog
-supervised battery backup for Real Time Clock
-2x SO DIMM Socket (dual channel DDR4 up to 2133 MT/s; max. 2x 16GB)
-External connectors
-Audio IN, Line OUT
-Two GBit Ethernet LAN interfaces
-Four USB 3.0 ports
-Two serial RS232 ports (COM1/2)
-Two independent DisplayPort++ ports supporting up to 4096 x2160@60 Hz
-Internal connectors
-1x M.2 interface (already used for hard drive memory)
-1x PCIe x4 slot (gen. 3)
-1x mPCIe slot
-2x SATA interfaces (6Gbps)
-4x USB 2.0
-1x microSIM card slot
-1x microSD card slot

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 11/29
Fig. 1 Block diagram miniITX-Board (all functions)
Important Note
Check the product variant carefully for the supported functions.

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 12/29
2.2 Product Variants
The COMPACTc7 is available in different functional variants and enclosures.
Bold printed functions are available at the front, italic printed functions are available as internal interfaces
only.
Function
CPC/MITX7i3H-A101
CPC/MITX7i5H-A101
CPC/MITX7i7H-A101
CPU
Intel i3-7100U 2.4 GHz
Intel i5-7300U 2.6 GHz
Intel i7-7600U 2.8 GHz
Memory
4GB (Up to 16GB)
8GB (Up to 16GB)
16GB
LAN1
LAN1
LAN1
LAN1
LAN2
LAN2
LAN2
LAN2
COM1
X1 (RS232)
X1 (RS232)
X1 (RS232)
COM2
X2 (RS232)
X2 (RS232)
X2 (RS232)
USB1/2
USB1/2
USB1/2
USB1/2
USB3/4
USB3/4
USB3/4
USB3/4
USB7/8
USB7/8
USB7/8
USB7/8
USB9/10
USB9/10
USB9/10
USB9/10
DP 1
DP++
DP++
DP++
DP 2
DP++
DP++
DP++
Audio
Out / Mic
Out / Mic
Out / Mic
SATA0
SATA0 (X51)
SATA0 (X51)
SATA0 (X51)
SATA1
SATA1 (X52)
SATA1 (X52)
SATA1 (X52)
M.2
m.2 type B (X10)
m.2 type B (X10)
m.2 type B (X10)
Micro SIM
microSIM (X11)
microSIM (X11)
microSIM (X11)
Micro SD
SDXC (X60)
SDXC (X60)
SDXC (X60)
mPCIe
PCIe (X8)
PCIe (X8)
PCIe (X8)
PCIe
PCI e x4 (X7)
PCI e x4 (X7)
PCI e x4 (X7)
RTC Backup
Li battery
Li battery
Li battery
Tab. 1 Product Variants

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 13/29
3Hardware Description
3.1 Overview
The COMPACTc7 hardware may be configured by software (CMOS setup). Custom BIOS configuration
can be programmed into the BIOS flash on request (ask Syslogic technical support for custom BIOS
configuration).
3.2 Peripheral Devices
3.2.1 DisplayPort Interface
The DisplayPort signals (DP++) are available on the DisplayPort connectors DP1 and DP2 for direct
connection of DisplayPort compatible monitors. These connectors support DP/HDMI/DVI displays with a
resolution of up to 4096 x2160@60 Hz.
3.2.2 High Definition Audio
The COMPACTc7 has a high definition audio codec (Realtek ALC888S) mounted on it. The line output
signals and the MIC signals are routed to connectors Line-OUT and MIC-IN.
MIC-IN
Connector type: 3-pin, 3.5 mm single audio jack
Pin Number
Jack
Signal
Remarks
1
Tip
MIC1_L
Microphone - left channel
2
Ring
MIC1_R
Microphone - right channel
3
Sleeve
A_GND
Analog ground
Tab. 2 MIC-IN Pinout Description
Line-OUT
Connector type: 3-pin, 3.5 mm single audio jack
Pin Number
Jack
Signal
Remarks
1
Tip
SDATA_IN
Line-OUT - left channel
2
Ring
SDATA_OUT
Line-OUT - right channel
3
Sleeve
Analog ground
Analog ground
Tab. 3 Line-OUT Pinout Description

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 14/29
3.2.3 SATA Interface (internal)
The COMPACTc7 provides two SATA ports on standard SATA connectors (X51 and X52). The SATA ports
support data rates up to 6 Gbps.
SATA0 (X51) supports eSATA devices.
SATA1 (X52) supports SATADOM
Connector Type: X51, X52: Standard SATA connector
3.2.4 SATA Power (internal)
Pin Number
Signal
1
+3.3V
2
+3.3V
3
+3.3V
4
GND
5
GND
6
GND
7
+5V
8
+5V
9
+5V
10
GND
11
GND
12
GND
13
12V
14
12V
14
12V
Tab. 4 X12: 15-pin standard SATA power connector
Important Note
Do not power more than two devices at the same time.
The +3.3V, +5V and +12V voltage rails have maximum current of 2A each.

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 15/29
3.2.5 M.2 Slot (internal)
The conga-COMPACTc7 offers an M.2, type 3042/2242 slot (X10) for connecting SATA or PCIe x2 SSDs
and WWAN devices.
Pin Number
Signal
Pin Number
Signal
1
CONFIG_3
2
+ 3.3V
3
GND
4
+ 3.3V
5
GND
6
FULL_CARD_PWROFF#
7
USB_D+
8
W_DISABLE_1#
9
USB_D-
10
LED1 (optional)
11
GND
12
Key
13
Key
14
15
16
17
18
19
20
NC
21
CONFIG_0
22
NC
23
WoWWAN#
24
NC
25
NC
26
W_DISABLE_2#
27
GND
28
NC
29
PER1-
30
UIM_RESET
31
PER1+
32
UIM_CLK
33
GND
34
UIM_DATA
35
PET1-
36
UIM_PWR
37
PET1+
38
DEVSLP
39
GND
40
GNSS_SCL
41
PER0-/SATA_B+
42
GNSS_SDA
43
PER0+/SATA_B-
44
GNSS_IRQ
45
GND
46
NC
47
PET0-/SATA_A-
48
NC
49
PET0+/SATA_A+
50
RESET#
51
GND
52
CLKREQ#
53
REFCLK-
54
PEWAKE#
55
REFCLK+
56
NC
57
GND
58
NC
59
NC
60
NC
61
NC
62
NC
63
NC
64
NC
65
NC
66
NC
67
RESET#
68
SUSCLK
69
CONFIG_1
70
+ 3.3V
71
GND
72
+ 3.3V
73
GND
74
+ 3.3V
75
CONFIG_2
-
Tab. 5 X10: M.2 type 3042/2242 interface

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 16/29
Important Note
Per default the M.2 interface is used for an M.2 flash card of 256GB
3.2.6 Micro SD Card (internal)
The conga-COMPACTc7 offers a micro-SD slot on connector X60. The SD card slot complies with SDXC
card specification 3.0 with support for up to 104MBps data rate.
Connector type: Micro-SD card socket
Pin Number
Signal
Remarks
1
SD_D2
Data line (bit 2)
2
SD_D3
Data line (bit 3)
3
SD_CMD
Command response
4
+3.3V
Supply voltage
5
SD_CLK
Serial clock
6
GND
Ground
77
SD_D0
Data line (bit 0)
8
SD_D1
Data line (bit 1)
Tab. 6 Connector X60 Pinout Description
3.2.7 Serial Ports
The COMPACTc7 systems provides two fully featured RS232 interfaces (COM 1 and 2). The COM ports
support data rates up to 250 kbps with worst-case loads of 3kΩ, in parallel with 1nF.
Connector type: DSUB-9 male
Pin Number
Signal
Pin Number
Signal
1
DCD
6
DSR
2
RXD
7
RTS
3
TXD
8
CTS
4
DTR
9
RI
5
GND
Tab. 7 Serial Ports COM1/2 on DSUB-9 male X1, X2

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 17/29
3.2.8 USB Interface Front
The COMPACTc7 system features four USB 3.0 ports at the front
Connector type: USB 3.0 Type A
Maximum 0.5A per port
Port 1 (left bottom)
Port 2 (left top)
Pin Number
Signal
Pin Number
Signal
1
VBUS
10
VBUS
2
D-
11
D-
3
D+
12
D+
4
GND
13
GND
5
StdA_SSRX-
14
StdA_SSRX-
6
StdA_SSRX+
15
StdA_SSRX+
7
GND_DRAIN
16
GND_DRAIN
8
StdA_SSTX-
17
StdA_SSTX-
9
StdA_SSTX+
18
StdA_SSTX+
Tab. 8 USB1/2 Interface Connector (Dual Type A)
Port 3 (right bottom)
Port 4 (right top)
Pin Number
Signal
Pin Number
Signal
1
VBUS
10
VBUS
2
D-
11
D-
3
D+
12
D+
4
GND
13
GND
5
StdA_SSRX-
14
StdA_SSRX-
6
StdA_SSRX+
15
StdA_SSRX+
7
GND_DRAIN
16
GND_DRAIN
8
StdA_SSTX-
17
StdA_SSTX-
9
StdA_SSTX+
18
StdA_SSTX+
Tab. 9 USB3/4 Interface Connector (Dual Type A)

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 18/29
3.2.9 USB Interface internal
The COMPACTc7 system features four USB 2.0 ports internally
Connector type: 2.54mm, 2x5 pin header
Maximum 0.5A per port
Pin
Signal
Description
Pin
Signal
Description
1
VBUS
+5V supply
2
VBUS
+5V supply
3
D7-
USB Port 7, Data-
4
D8-
USB Port 8, Data-
5
D7+
USB Port 7, Data+
6
D8+
USB Port 8, Data+
7
GND
GND
8
GND
GND
9
No Pin
No Pin
10
NC
Not Connected
Tab. 10 USB7/8 on interface connector X16
Pin
Signal
Description
Pin
Signal
Description
1
VBUS
+5V supply
2
VBUS
+5V supply
3
D9-
USB Port 9, Data-
4
D10-
USB Port 10, Data-
5
D9+
USB Port 9, Data+
6
D10+
USB Port 10, Data+
7
GND
GND
8
GND
GND
9
No Pin
No Pin
10
NC
Not Connected
Tab. 11 USB9/10 on interface connector X15
Important Note
Maximum cable length allowed for USB connection is 3m. If longer cables are used, special
overvoltage and filtering elements must be installed to comply with the requirements of EMI/RFI
"CE"-certification. Only use high quality industrial USB devices with sufficient EMI compatibility.
Use shielded cables for maximum EMI protection.
Drawing excessive power might disturb operation.
3.2.10 Ethernet LAN Interface
The COMPACTc7 features two Gigabit Ethernet ports. The Ethernet interface drives two LED’s (yellow and
green) integrated into the RJ45 connector for status information.
LAN1 (Intel i219 Ethernet controller) and LAN2 (Intel i211 Ethernet controller) both support
10/100/1000Mb/s, Auto Negotiation and Auto MDIX functions.
Connector type: RJ45

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 19/29
3.2.11 Power supply
The processor and its peripherals are powered by a non-isolated, integrated power supply which
generates all the necessary voltages.
Connector type: PhoenixContact DFK-MC 1,5/ 4-GF-3,81
Mating connector: Weidmueller BCZ 3.81/04/180F SN SW (Ordercode 1792970000)
The mating connector can be ordered directly at your local Weidmueller distributor
Pin Number
Signal
Remarks
1
NC
Not Connected
2
NC
Not Connected
3
+24VDC
+12V...+24V DC
4
GND
Tab. 12 Power supply connector
For normal operation the external power supply has to be connected to the pins 3 (+24VDC) and 4 (GND)
of the connector.
3.2.12 Power button
To turn on the system the power has to be applied and then the power button can be pressed once. A
blue illuminated power button indicates a running system.
The function of the power button can be defined in the OS as a “normal” power button in any other PC
system.
Important Note
The COMPACTc7 system must only be operated indoors and must be connected to an indoor
power supply. Maximum cable length allowed for power supply connection is 3m. If longer cables
are used, special overvoltage and filtering elements must be installed to comply with the
requirements of EMI/RFI "CE"-certification.

CPC/MITX7ixY-Azzz: user documentation
DOC/MITX7ixY; V1.1
© Syslogic Datentechnik AG, Switzerland, http://www.syslogic.com 20/29
4Technical Data
4.1 General Electrical Data
Important Note
Do not operate the COMPACTc7 outside of the recommended operating conditions. Otherwise lifetime and
performance will degrade. Operating the board outside of the absolute maximum ratings may damage the
hardware.
Absolute Maximum Ratings (over free air temperature range)
Parameter
Symbol
min
nom
max
Unit
isolation logic to chassis (AC, 60s, 500m a.s.l., Ta=25°C)
100
500
Vrms
isolation Ethernet to logic (AC, 60s, 500m asl, Ta=25°C)
500
Vrms
creepage distance logic to chassis and PCB border
0.5
mm
creepage distance Ethernet to logic
1.0
mm
creepage distance Ethernet to chassis and PCB border
1.0
mm
storage temperature range
Tst
-20
70
°C
Tab. 13 General Absolute Maximum Ratings
Recommended Operating Conditions
Parameter
Symbol
min
nom
max
internal logic supply voltage
Vcc
11.4
12/24
25.2
Vdc
Battery backup voltage
Vbatt
2.7
3.0
3.3
V
operating free-air temperature range1
Ta
0
55
°C
Cold start temperature range
Ta
0
55
°C
Operating humidity (not condensing)
Rh
8
90
%
USB 2.0 Supply Current per port
Iusb2
500
mA
USB 3.0 Supply Current per port
Iusb3
500
mA
Tab. 14 General Recommended Operating Conditions
Maximum cable length
Interface
Maximum Length
Comment
RS232
<30m
USB (2.0)
<3m
USB (3.0)
<3m
Ethernet
<100m
Tab. 15 Maximum cable length
1
100% CPU Load, 1 x GBit Ethernet, 1x DP++, 2x USB device, Ptot<29W
