SYSOLUTION E2 Series User manual

E2X Series Screen Configuration
And TAXIHUB Platform
Instructions
Version：V.1.1

Statement
Dear user friend, thanks for choosing Shanghai Xixun Electronic Technology Co., Ltd.
(hereinafter referred to as Xixun Technology) as your LED advertising equipment control
system. The main purpose of this document is to help you quickly understand and use the
product. We strive to be precise and reliable when writing the document, and the content may
be modified or changed at any time without notice.
Copyright
The copyright of this document belongs to Xixun Technology. Without the written
permission of our company, no unit or individual may copy or extract the content of this
article in any form.
Trademark
is a registered trademark of Xixun Technology.

Catalog
Overview............................................................................................................................................................... 1
Functions And Features....................................................................................................................................2
Interfaces Description.......................................................................................................................................3
Technical Parameters.........................................................................................................................................5
Hardware Connection Diagram..................................................................................................................... 7
Software Operation Procedures.....................................................................................................................8
LED Display Smart Setup................................................................................................................................. 9
1. Software Connection............................................................................................................................ 9
2. Network Configuration........................................................................................................................ 9
3. Cloud platform account binding.................................................................................................... 10
4. WiFi Configuration..............................................................................................................................10
5. 3G/4G Configuration..........................................................................................................................12
Platform Release Program.............................................................................................................................14
1. Add AD...................................................................................................................................................14
2. Release Advertisement...................................................................................................................... 16
End Of Page.......................................................................................................................................................19

Update Record
No.
Version
Details
Date
1
Ver.1.0
Initial
2020.09.08
2
Ver.1.1
Content change
2020.12.16
Note: The document is subject to change without prior notice.
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
1
Overview
With the growth of LED vehicle signs, more and more end users require wireless
transmission, remote cluster management and joint with third party applications via WiFi or
4G internet, also require to operate by smart phone.
Shanghai Xixun SYSOLUTION designed E2X for all those requirements, which will lead the
development of led vehicle signs market and make users to accessing in a simple way.
E2X series including E22, E24 and E26 modes, all adopt Qualcomm MSM8909 platform
solution, MSM9809 CPU is made by 28nmLP CMOS technology, with four core main
frequency 1.1GHz, storage 1GB+8GB(compatible with 2GB+16GB) LPDDR3. It is a highly
integration product, which can support GSM, WCDMA, TD - SCDMA,EVDO,TDD - LTE,FDD -
LTE etc.
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
2
Functions And Features
1. E22 integrates 2+1 HUB75E port； E24 has 4+1 HUB75E port； E26 has 6+1 HUB75E port；
2. Designed for led vehicle text sign, with“Guest”and“NO Guest”independent interfaces；
3. Onboard WiFi modem, support AP and Station mode；
4. Support customized development and cloud web platform control；
5. Build in Web server, support editing local web page, also allow to editing and sending
programs from laptop, iPhone, android phone, with offline LEDOK express software to
send programs within local network；
6. Support RGB module with1-32 scanning and static types；
7. Industrial on board Flash：8GB.
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
3
Interfaces Description
E22 interfaces & description
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
4
E24 interfaces & description
E26 interfaces & description
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
5
Technical Parameters
Features
Description
Type
E22
E24
E26
Resolution
256*32
（has 2 HUB75 port）
No need receiving
card
256*64
（has 4 HUB75 port）
No need receiving
card
256*192
（has 6 HUB75 port）
No need receiving
card
Communication type
4G full Netcom、WiFi、USB
CPU
Quad-core A7（32bit）four cores 1.1GHz
GPU
A307 409.6MHz
RAM
8GB Emmc+1GB LPDDR3
Operation system
Android 5.1
WiFi
IEEE 802.11b/g/n 2.4G
GPS
GNSS GPS/Beidou/Glonass
Bluetooth
Bluetooth BT4.1
3G/4G frequency
（optional）
-China
FDD-LTE:B1/3
TDD-LTE:B38/39/40/41
TDSCDMA:B34/39
WCDMA:B1/8
CDMA 1X/EVDO:BC0
GSM:B3/5/8
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
6
Audio
support
Camera
support
Weather forecast
support
Readback display
content
support
Software
Easyboard
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
7
Hardware Connection Diagram
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
8
peration Procedures
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
9
LED Display Smart Setup
1. Software Connection
Dial the control card dial code to AP, the computer will search the AP hotspot
(EXX-XX-XXXXX) released by the control card, click "Connect" and enter the password (the
default password is 12345678).
2. Network Configuration
Click "System network server configuration" on the main interface of EasyBoard to
configure the cloud platform account and network.
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
10
3. Cloud platform account binding
Enter the web server address and company ID and click “Save”.
The server address in China is：www.taxihub.cn
The foreign server address is：www.ledaips.com
4. WiFi Configuration
(1) Enable “WiFi switch” , waiting for 3 seconds, and click “Scanning WiFi”, select the WiFi
name and write down the WiFi password. Click “Save”.
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
11
(2) After set the WiFi parameters, adjust the switch to WIFI mode, For Y/M series controller,
just remove LAN cable will be ok.
(3) Wait for about 3 minutes, controller will come online. Please watch the “Internet” light,
if it flashing regularly means online success, go to Taxihub platform and check it.
Notes：
If could not scanning the WiFi, please try to turn on/turn off Software or WiFi Switch.
If controller can’t get access to internet through WiFi, please double check the steps below:
1) WiFi antenna plug correctly;
2) WiFi password is correct or not;
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
12
3) If the Wireless router being accessed too many terminals?
4) E series controller switch on WIFI mode?
5) Try another WIFI hot spot.
6) Y/M series controller, please make sure the LAN cable removed.
5. 3G/4G Configuration
(1) Enable 3G/4G option, Choose correct country code, 460 is Chinese code for example (If
do not know your country code, please click Network status detection button and check
IMSI number, the first 3 numbers are the country code).
(2) Select the Operator name and input or auto-recognize the APN, then click “Save”.
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
13
(3) After save 3G parameters, waiting for about 5 minutes, please check if card online in
Taxihub platform. “Internet” light will flashing fast for dialing up then flashing regularly
means get online success.
Notes：
If controller can’t get online success, please checking followingthings：
1) 4G antenna has plugged correctly?
2) Y/M series controller, make sure the LAN cable removed.
3) APN is correct or not?
4) SIM card has activate? SIM card has enough money and 4G data service?
5) Check 4G signal at least 13 and above？Click Network status detection to check 4G signal.
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
14
Platform Release Program
1. Add AD
(1) Enter the "Release By Grouping" interface, and click to add a program.
(2) Edit "Campaign Name".
(3) Open the "Media Library", select an existing material or upload a local material, and then
click .
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
15
(4) Select "Duration", the image can choose the existing time long or a custom duration. (Unit
is second, video animation automatic identification time)
(5) Select the vehicle terminal group that plays the advertisement, and click .
Shanghai XiXun Electronics Co.,Ltd.

www.sysolution.net
16
(6) Click to complete the ad addition.
2. Release Advertisement
(1) Go back to the "Campaign List" unreleased page.
