Systec Controls deltawaveC User manual

deltawaveC
deltawaveCdeltawaveC
deltawaveC-
--
-P
PP
P Quickstart
QuickstartQuickstart
Quickstart
A
User Interface
User InterfaceUser Interface
User Interface:
::
:
Switch on / off. For switching off please press button for ca. 5 sec.
Activates the background lighting
To navigate through the different menus please use the keys located on the left and right beside the
display.
Move cursor in specific direction
Confirm your settings
Confirm your settings and moves to next menu
Back to previous menu
Increase of values
Decrease of values
XYZ Activates a certain function (depending on chosen menu)
No function
B
Set
SetSet
Set-
--
-up your flow measu
up your flow measuup your flow measu
up your flow measur
rr
rement in 5 steps
ement in 5 stepsement in 5 steps
ement in 5 steps
1. Choose suited mounting position for your transducers
2. Parameterize your flow transmitter
3. Mounting of ultrasonic transducers on your pipe
4. Set zero point (if possible)
5. Start your flow measurement
Pipe needs to be filled completely for clamp-on measurement

C
Pa
PaPa
Parameterization and mounting
rameterization and mountingrameterization and mounting
rameterization and mounting
1. Switch on flow transmitter
2. Choose menu „quick setup“
3. Select diameter or circumference (depending on what figure you have) of your pipe
4. Insert value for diameter or circumference
5. Insert value for wall thickness of your pipe
6. Select pipe material
7. Select lining (if there is a lining)
8. Select type of ultrasonic transducer
 XUC-FW 21 DN15…DN100
 XUC-FW 20 DN15…DN100 replaced by sensor Model XUC-FW 21 DN15…DN100
 XUC-FW10 DN32…DN400
 XUWF5 DN200…DN600
9. Select method of mounting. Standard is V-mounting.
10. Now the display is showing the required distance between the two transducers in mm and also as
Index-No. Index-No. shows the distance (in “holes”) when using the spacer bar. When using horizontal pipe we
recommend mounting the transducers at 10 o’clock or 2 o’clock position to avoid any influence of gas bubbles
might accumulated on top of pipe. Straight run should be 10x diameter (inlet) and 3x diameter (outlet) in order to
achieve best accuracy.
1 2 3 4 5 = Bar Index 5
The displayed bar index is only valid in combination with
the correct space bar type (long or short)
11. Set Zero Point (if possible)
If there is the chance to stop flow please do it and then select „Zero Setup“ and set zero point.
12. Go back to main menu and select button „MEAS“. You then entering the measuring
menu where you see the calculated flow, velocity,….
Change units:
->Go to main menu and select SETUP - > COMPL SETUP. Then select „UNITS SETUP“ to change units.
Gas bubbles
Pipe
Sedimentation
Distance
Mounting without spacer bar:
Please use the distance given in mm.
Distance is calculated from inner fronts
of the
2 transducers
Mounting with spacer bar
:
After parameterization the display is showing the required
distance between the two transducers in mm and also as Index-
No. Index-No. means the number of holes to be used for
mounting with the spacer bar. The first hole after the first
transducers is hole No. 1, the last hole is the hole where second
transducer is put into the spacer bar (threaded bar with milled
screws).
See picture for example.
Fix transducers
Please always give some coupling grease on
surface of transducers before mounting. Please
loosen milled screw. Please fix transducers with chains
(only little contact pressure). Then screw the
transducers towards pipe by using milled screw. Also
only little contact pressure is required.
