SYSTRONIK EUROLYZER S1 User manual

Read manual before use!
Observe all safety information!
Keep manual for future use!
04.2023
V2 525158.01
SYSTRONIK
Elektronik u. Systemtechnik GmbH
Gewerbestrasse 57
D-88636 Illmensee
Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]
Internet: www.systronik.com
Instruction Manual
Flue Gas Analysis Computer
EUROLYZER®S1

2 EUROLYZER® S1

EUROLYZER®S1 3
Table of contents
1About this instruction manual ............................................................................6
1.1 Warning Terms......................................................................................6
1.2 Explanation of symbols and typeface......................................................6
1.3 Liability information................................................................................7
2Safety..............................................................................................................7
2.1 Intended use .........................................................................................7
2.2 Incorrect use .........................................................................................7
2.3 Safe handling ........................................................................................8
2.1 Qualification of personnel.......................................................................8
2.2 Calibration.............................................................................................8
2.3 Modifications to the product....................................................................8
2.4 Usage of spare parts and accessories.....................................................8
3Product description...........................................................................................8
3.1 Measurement and calculation parameters ...............................................9
3.2 Measuring methods .............................................................................10
3.3 Technical specifications .......................................................................11
3.4 Calculation formulae (extract) ...............................................................15
3.5 Approvals, tests and conformities..........................................................16
4Product description.........................................................................................16
4.1 Front view ...........................................................................................16
4.2 Rear view............................................................................................17
4.3 Connections........................................................................................17
5Commissioning ..............................................................................................18
5.1 Mains unit / Battery ..............................................................................18
5.1.1 Charging .............................................................................................18
5.2 Switching the instrument on and off.......................................................19
5.3 Connect probes...................................................................................19
5.4 Operating concept ...............................................................................19
5.4.1 Keypad ...............................................................................................20
5.5 Use of the IR-printer (EUROprinter) ......................................................21
5.6 Connection with CAPBs®......................................................................22
5.7 Connection with EuroSoft®connect for iOS and Android.........................22
5.8 EuroSoft®connect Software for Windows..............................................23
6Operation ......................................................................................................24
6.1 User interface Start menu.....................................................................24
6.1.1 Info Menu............................................................................................25
6.1.2 Memory...............................................................................................26
6.1.2.1 Creating a new customer database on the instrument .................26
6.1.2.2 Create customer data on the instrument .....................................26

4 EUROLYZER® S1
6.1.2.3 Saved measurement report.......................................................27
6.1.3 Settings...............................................................................................28
6.1.4 Edit favorites list ..................................................................................29
6.1.4.1 Delete measuring program from thefavorites list ........................29
6.1.4.2 Add measuring program to favorites list......................................29
6.1.4.3 Replace measuring program in the favorites...............................30
6.1.5 Macro .................................................................................................30
6.1.5.1 Add / remove Macro program....................................................31
6.1.5.2 Name Macro program...............................................................31
6.1.5.3 Export / Import Macro program..................................................31
6.2 User interface measuring mode............................................................32
6.2.1 Main menu ..........................................................................................33
6.2.1.1 Draft (Option) ...........................................................................33
6.2.1.2 Measurement data....................................................................35
6.2.1.2.1 Reorder values ....................................................................35
6.2.1.3 Datalogger (Option) ..................................................................36
6.2.1.3.1 Change Datalogger Interval ..................................................36
6.2.1.3.2 Start Datalogger...................................................................36
6.2.1.3.3 Stopp Datalogger.................................................................36
6.2.1.4 Corestream ..............................................................................37
6.2.2 Shortcut Menu.....................................................................................38
6.2.2.1 Save........................................................................................38
6.2.2.2 Multi-Memory Function..............................................................39
6.3 Overview measurement programs ........................................................40
6.3.1 Fluegas measurement .........................................................................40
6.3.2 CO Ambient measurement ...................................................................41
6.3.3 Temperature Measurement ..................................................................41
6.3.4 Pressure measurement (Option)...........................................................42
6.3.5 Pressure loss measurement (Option)....................................................42
6.3.6 Leakage measurement (Option)............................................................43
6.3.7 Pitot measurement (Option)..................................................................44
7Battery management ......................................................................................44
7.1 Battery mode/charging mode................................................................44
7.2 Charging the batteries..........................................................................44
8Maintenance ..................................................................................................46
9Troubleshooting.............................................................................................46
10 Shutting down and disposal............................................................................47
11 Spare parts and accessories...........................................................................48
12 Warranty........................................................................................................49
13 Copyright.......................................................................................................49
14 Customer satisfaction.....................................................................................49

EUROLYZER®S1 5
15 Addresses.....................................................................................................49

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
6 EUROLYZER®S1
1About this instruction manual
This instruction manual is part of the product.
Read this manual before using the product.
Keep this manual during the entire service life of the product
and always have it readily available for reference.
Always hand this manual over to future owners or users of the
product.
1.1 Warning Terms
WARNING TERM
The type and source of danger is shown here.
Precautions to take in order to avoid the danger are shown
here.
There are three different levels of warning:
Warning term
Meaning
DANGER
Imminent danger!
Failure to observe the information will result in
death or serious injuries.
WARNING
Possible imminent danger!
Failure to observe the information may result in
death or serious injuries.
CAUTION
Dangerous situation!
Failure to observe the information may result in
minor or serious injuries as well as damage to
property.
1.2 Explanation of symbols and typeface
Symbol
Meaning

Activity consisting of a single step
1.
Activity consisting of several steps
•
Bulleted list
Text
Indication on a display
Highlighting
Highlighting

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
EUROLYZER®S1 7
1.3 Liability information
The manufacturer shall not be liable in any direct or consequential
damage resulting from failure to observe the technical instructions,
guidelines and recommendations.
The manufacturer or the sales company shall not be liable for costs
or damages incurred by the user or by third parties in the use or
application of this device, inparticular in case of improper use of the
device, misuse or malfunction of the connection, malfunction of the
device or of connected devices. The manufacturer or the sales
company shall not be liable for damage resulting from any use other
than the use explicitly stated in this instruction manual.
The manufacturer shall not be liable for misprints.
2Safety
2.1 Intended use
The flue gas analysis computer EUROLYZER®S1 is exclusively
suitable for:
•Professional settings and control measurements at all small
combustion systems (low temperature and burner value boilers
and thermal systems) for gas, oil and pellets fuel systems.
Any use other than the application explicitly permitted in this instruc-
tion manual is not permitted.
2.2 Incorrect use
The EUROLYZER®S1 flue gas analysis computer must never be
used in the following cases:
•Hazardous area (Ex)
If the device is operated in hazardous areas, sparks may cause
deflagrations, fires or explosions
•Use as a safety (alarm) unit or continuous measuring device
•Ambient air monitoring
•Use in humans and animals

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
8 EUROLYZER®S1
2.3 Safe handling
CAUTION
Improper handling
Do not touch live parts with the instrument or sensors.
Protect the product against impact
Use the product only indoor
Insulate the product from moisture
Failure to follow these instructions may result in property dam-
age.
2.1 Qualification of personnel
The product may only be installed, commissioned, operated, main-
tained, shut down and disposed of by qualified, specially trained
personnel.
Electrical work may only be carried out by qualified electricians in
accordance with local and national regulations.
2.2 Calibration
The flue gas analysis computer EUROLYZER®S1 must be cali-
brated annually by a recognized, relevant authority.
2.3 Modifications to the product
Changes or modifications made to the product by unauthorised per-
sons may lead to malfunctions and are prohibited for safety rea-
sons.
2.4 Usage of spare parts and accessories
Usage of unsuitable spare parts and accessories may cause dam-
age to the product.
Use only the manufacturer’s genuine spare parts and accesso-
ries of the manufacturer.
3Product description
The EUROLYZER®S1 flue gas analysis computer is a multiple-
function analyzer with integrated calculating functions
The EUROLYZER®S1 flue gas analysis computer has an infrared
printer interface, a Bluetooth®interface (Bluetooth®Smart). User-
friendly, color-coded menus support improved and intuitive opera-
tion. The individual measuring programs, configuration menus, etc.
are assigned distinctive colors.

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
EUROLYZER®S1 9
A state-of-the-art scroll wheel technology for one-hand operation
provides perfect user interface. Additionally, a robust Touchpad Dis-
play is available to control the instrument.
3.1 Measurement and calculation parameters
Value
Measured medium
Unit
Tgas
Flue gas temperature
°C, °F
Tair
Air temperature
°C, °F
O2
Oxygen concentration
Vol.-%
CO
Carbon monoxide concentration
ppm, mg/m³,
mg/kWh, mg/MJ,
Vol.-%
NO
Nitrogen monoxide concentration
(Option)
ppm, mg/m³,
mg/kWh, mg/MJ
Pressure
Draft/Pressure (Option)
Pa, hPa, kPa,
mbar, bar,
mmWs, mmHg,
inHg, Psi
CO2
Carbon dioxide
Vol.-%
COref
Carbon monoxide referenced to an
O2reference value
ppm, mg/m³,
mg/kWh, mg/MJ
Eta
Combustion efficiency value
%
Lambda
Excess air value

qA
Flue gas loss
%
Dewpnt
Fuel-specific dew point
°C, °F
T.Diff
Differential temperature (TG - TL)
°C, °F
NOx
Nitrogen oxide (Option)
ppm, mg/m³,
mg/kWh, mg/MJ
NOref
Nitrogen oxide referenced to an O2
reference value (Option)
ppm, mg/m³,
mg/kWh, mg/MJ
NOxref
Nitrogen oxides referenced to an O2
reference value (Option)
ppm, mg/m³,
mg/kWh, mg/MJ

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
10 EUROLYZER®S1
3.2 Measuring methods
Function
Explanation
Temperature measure-
ment
Thermocouple NiCr-Ni (type K)
O2measurement
Electrochemical measuring cell
CO measurement
Electrochemical measuring cell
NO measurement
(Option)
Electrochemical measuring cell
Pressure/draft (Option)
Piezo-resistive sensor with internal tem-
perature compensation
Measuring duration
Short-term, stable measurements of max.
60 minutes are possible, followed by a
new calibration phase with ambient air.
Flue gas measurement
Via an external water separator and filter,
the flue gas is supplied to the sensors by
means of a gas pump.
Sensor calibration
After switching on the instrument, there is
a calibration phase that takes 30 seconds
after a cold start.
CO-Sensor protection
The CO sensor with dynamic H2 compen-
sation is automatically protected when the
maximum measuring range limit (> 9,999
ppm) is reached by switching off the gas
pump. The measurement is resumed au-
tomatically as soon as the CO concentra-
tion is within the measuring range again.
Flue gas sampling
Flue gas sampling is done by means of a
probe which enables either a “one-point
measurement” (combi probe) or a “multi-
point measurement” (multi-hole probe).

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
EUROLYZER®S1 11
3.3 Technical specifications
Parameter
Value
General Specifications
Dimensions housing
(H x WxD)
218 x 80 x 44 mm
Weight
Approx. 500 to 550 g (depends on count of
sensors)
Material housing
2K ABS + PC
Protection type
IP 42 EN 60529
Display
High-resolution 4,3“ Touch Display
Battery
Lithium-Ionen-Akku (3,6 V/5.000 mAh)
Power adapter
USB power supply
Data communication
•Infrared printer interface
•Bluetooth®Smart interface (Bluetooth®
low energy)
•QR-Code
•USB-C
Data communication
Bluetooth Smart interface
Bluetooth radio class: class 2
Bluetooth specification: 5.0
Frequency band
2.4 GHz
Transmission power
Max. +9 dBm
Range
Up to 10 m in buildings, up to 50 m outdoor
The actual range depends on the environ-
ment and can be reduced by, for example,
walls and other obstacles

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
12 EUROLYZER®S1
Parameter
Value
Bluetooth certifica-
tion
EU countries:
Austria, Belgium, Bulgaria, Croatia, Czech
Republic, Denmark, Estonia, Finland,
France, Germany, Greece, Hungary, Ireland,
Italy, Latvia, Lithuania, Luxembourg, Malta,
Netherlands, Poland, Portugal, Republic of
Cyprus, Romania, Slovakia, Slovenia, Spain,
Sweden, United Kingdom
EFTA countries:
Iceland, Liechtenstein, Norway, Switzerland
Printer
External thermal printer (EUROprinter)
Memory
10.000 measurements
Temperature range
Ambient
0 °C to +40 °C
Medium
0 °C to +40 °C
Storage
-20 °C to +50 °C
Air pressure range
Ambient
750 hPa to +1100 hPa
Humidity range
Ambient
20 % rH to 80 % rH
Flue gas temperature measurement (T1 and T2)
Measuring range
0 °C to +1,150 °C
Max. deviation
±1°C + 1 Digit (0 °C to +300 °C)
±1.0 % of measured value (above +300 °C)
Resolution
0.1 °C
Sensor
Thermocouple NiCr-Ni (type K)
Combustion air temperature
Measuring range
-20 °C to +200 °C
Max. deviation
± 3 °C + 1 digit (-20 °C to 0 °C)
±1°C + 1 digit (0 °C to +200 °C)
Resolution
0.1 °C
Sensor
Thermocouple NiCr-Ni (type K)

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
EUROLYZER®S1 13
Parameter
Value
Draft / pressure measurement (Option)
Measuring range
± 70 hPa (Draft) / ± 150 hPa (Diff.-Pressure)
Max. deviation
± 2 Pa + 1 Digit (<2,00 hPa)
± 1 % reading (>2,00 hPa)
Resolution
± 0,01 hPa
Sensor
Semiconductor sensor
Pitot measurement (Option)
Measuring range
0.5 - 70 m/s
Max. deviation
± 0.8 m/s
Resolution
0.1 m/s
Sensor
Semiconductor sensor
O2-measurement
Measuring range
0.0 Vol. % to 21.0 Vol. %
Max. deviation
± 0.2 Vol. % by volume of measured value
Resolution
0.1 Vol. %
Sensor
Electrochemical measuring cell
Response time
(T90)
30 seconds
CO2- determination
Range
0 –CO2max
Max. deviation
±0.2 Vol.%
Resolution
0.1 Vol.%
Sensor
calculation from O2 value
Response time
(T90)
30 seconds

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
14 EUROLYZER®S1
CO- measurement (with H2compensation)
Measuring range
0 ppm to 4,000 ppm (nominal)
or 9,999 ppm (maximal)
Accuracy
5 ppm (to 50 ppm)
5 % of measured value (above 50 ppm)
Resolution
1 ppm
Sensor
Electrochemical measuring cell
Response time
(T90)
60 seconds
NO- measurement (Option)
Measuring range
0-2,000 ppm
Accuracy
5 ppm (to 50 ppm)
5 % of measured value
Resolution
1 ppm
Sensor
Electrochemical measuring cell
Response time
(T90)
60 seconds
NOlow- measurement (Option)
Measuring range
0-300 ppm
Accuracy
2 ppm (to 40 ppm)
2 % of measured value
Resolution
0.1 ppm
Sensor
Electrochemical measuring cell
Response time
(T90)
60 seconds

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
EUROLYZER®S1 15
3.4 Calculation formulae (extract)
Calculation of the CO2 value
CO2= CO2 max * (1 -
21
O2
) in %
CO2
Calculated carbon dioxide value in %
CO2max
Max. CO2value (fuel-specific) in % by volume
O2
Measured oxygen concentration in %
21
Oxygen concentration of the air in % by volume
Calculation of the flue gas loss
qA = (TG - TA) * (
2
2
O21A
−
+ B) in %
qA
Flue gas loss in %
TG
Flue gas temperature in °F or °C
TA
Combustion air temperature in °F or °C
A2, B
Fuel-specific factors
O2
Measured O2value
Calculation of the excess air value Lambda
Lambda =
2
max2
CO
CO
=
2
21
21
O−
Lambda
Excess air value
Calculation of the combustion efficiency value (Eta)
Effic. = 100 - qA in %
Effic.
Combustion efficiency value in %
Calculation of CO reference (CO ref), same for NO and NOx
COref. = CO *
2
2
21
21
O
Oref
−
−
COref.
Carbon monoxide reference
CO
Measured CO value
O2
Measured O2value
O2ref
O2reference value

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
16 EUROLYZER®S1
3.5 Approvals, tests and conformities
The EUROLYZER®S1 flue gas analysis computer is approved in
accordance with the German "1. BundesImmissionsSchutzVer-
ordnung" (1. BImSchV) and EN 50379-2, is TÜV-tested (VDI 4206)
and meets the applicable directives of 2004/108/EC.
The conformity of the product with the requirements of the EU direc-
tives is confirmed by the CE mark on the housing.
4Product description
4.1 Front view
1
Loop attachment
2
USB-interface/
mains connection
3
Touchscreen
4
Action button
5
Scroll wheel with
LEDs
6
On/Off button
7
Connections

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
EUROLYZER®S1 17
4.2 Rear view
1
Speaker
2
IR-Diode for
EUROprinter
3
Magnets
4
Gas outlet
4.3 Connections
1
Temperature connections (Type-K)
2
Gas inlet, Ø8mm
3
Draft connection, Ø7mm (Option)
4
Pressure connection,
Ø8mm (Option)

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
18 EUROLYZER®S1
5Commissioning
5.1 Mains unit / Battery
The EUROLYZER®S1 is supplied with an Li-Ion battery. Fully
charge the battery before using the measuring instrument.
Plug the USB cable into the USB-C port on the instrument and to
the mains plug. For charging connect the mains unit to a mains
socket. If the mains unit is connected to a mains socket, the meas-
uring instrument is automatically powered via the mains unit.
WARNUNG
Risk of electric shock
There is a risk of electric shock if used improperly.
Failure to follow these precautions can result in death, serious
injury, or property damage.
INFO
Only charge the energy storage unit at an ambient temperature of
0 to 45 °C.
5.1.1 Charging
1. Connect the plug of the mains unit to the USB-C mains unit
socket on the measuring instrument.
2. Connect the mains plug of the mains unit to a mains socket.
The charging process starts, the blue charging LED lights.
The charging process stops automatically when the energy
storage unit is fully charged. The blue charging LED switch off.
It is possible to set the instrument in a charging mode:
Status
Action
Function
Instrument on and get
charged (LED: light
blue)
Press “Power” button
for >1 second
Instrument is in charging mode. As
soon as the battery is fully charged,
the instrument will switch off.
Instrument in charging
mode (Battery icon is
visible)
Press “Power” button
Instrument is in measuring mode.
When using a fast-charging power supply, the EUROLYZER®S1
automatically switches to fast-charging mode.

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
EUROLYZER®S1 19
5.2 Switching the instrument on and off
Status
Action
Function
Instrument off
Press “Power” button
Instrument is switched on.
Instrument on
Press “Power” button for >1 second
Instrument is switched off.
5.3 Connect probes
Connect the flue gas probe with the gas hose / temperature plug
marked in yellow and the draft hose marked in blue. Insert the air
temperature sensor into the temperature socket marked in blue.
1
Flue gas temperature
2
Fluegas (Exhaust gas)
hose
3
Pressure valve for tight-
ness test (Option)
4
Draft (Option)
5
Ambient air sensor
INFO
Beforeusing the EUROLYZER®S1, a visual inspection of the en-
tire measuring equipment (measuring instrument including ac-
cessories) must be carried out to ensure fault-free operation of
the product.
5.4 Operating concept
The EUROLYZER®S1 has a dual operating concept and can be op-
erated either with the touchscreen or via the keypad.

Fel! Använd fliken Start om du vill tillämpa Überschrift 1 för texten som ska
visas här.
20 EUROLYZER®S1
Before operating the measuring instrument, familiarize yourself with
the operating concept. The execution of actions is mainly done by:
Action
Touchscreen
Keyboard
Select
Tap menu icons
Press Action button
Back
Tap back icon
Double press Action button
Navigation function for
up and down navigation
in the menu
Swipe up or down
Navigate with the scroll wheel.
5.4.1 Keypad
Some functions require the input of values ( figures, numbers, char-
acters). The values are entered via a keypad field, by touching or
selecting with the scroll wheel and confirming with the action key.
1
Caplock-key: Permanent capitaliza-
tion
2
Shift-key: Capitalization
3
Special letter key
4
Backspace-key: Deletes backwards
5
Delete-key: Deletes whole line
6
Enter key: Confirm
2x
