TA-CMI is a computer programmed measuring instrument. It is a handheld instrument for
measuring differential pressure, temperature, and flow through balancing valves in hydronic
systems. It consists of a sensor unit and a instrument unit that has been programmed with the
TA valve characteristics, which makes it possible to take a direct reading of flow and differen-
tial pressures.
The TA-CMI has two main components:
• A sensor unit which contains a piezoresistive pressure sensor, one measurement valve,
connections and rechargeable NiMH batteries. The measurement valve has a safety function
which protects the sensor from too high differential pressures.
• An instrument unit which contains a micro computer, input touch pad, LCD display and
rechargeable NiMH batteries.
The instrument and the sensor units communicate wirelessly or by cable.
= Warning – read the manual.
The TA-CMI can be cleansed with a damped cloth and a lenient cleaning-agent.
General
General
Guarantee
TA-CMI is guaranteed to be free of material or performance defects in normal use and service. The
guarantee period is five years, starting from and including the day of delivery. A guarantee period
of 180 days applies for repairs and service.
This guarantee applies only for the original purchaser and does not include consumable materials
or measuring instruments which, in TA´s opinion, have been used incorrectly, have been neglected
or have been damaged as a result of accident or abnormal use or handling.
Tour & Andersson AB guarantees that its software operates in all significant respects in accordance
with its performance specification. TA does not guarantee that its software is fault-free or that it will
operate without crashing.
TA´s obligations in respect of its guarantee are restricted to full replacement of the purchase cost or
cost-free repair or replacement of defective products delivered to a Tour&Andersson AB authorised
service centre during the guarantee period, at Tour&Andersson AB's discretion. To claim service
under guarantee, either contact the nearest TA authorised service centre or send the product,
carriage-paid (FOB) and insured, to the nearest Tour & Andersson AB authorised service centre with
a description of the problem. TA does not accept the risk of damage to the product during transport.
After repair under guarantee, the product will be returned carriage-paid (FOB) to the purchaser.
If TA is of the opinion that the fault has been caused by incorrect use, modifications, accident or
abnormal use or handling, we will submit an estimate for the cost of repairs and await approval of
this estimate before starting work. After repair, the product will be returned carriage-paid to the
customer, after which the customer will be invoiced for the cost of repair and of returning the
product (FOB).
Note! If the warranty seal is broken or tampered with, this guarantee is null and void.
Guarantee
FCC Notification and ETL markings
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Caution: Changes or modifications of the equipment, not expressly approved by the party
responsible for compliance, could void the user´s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protections against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
ETL LISTED: Conforms to UL std. 61010B-1: Certified to CAN/CSA std. C22.2 No.1010.1-92

5
TA-CMI
4
TA-CMI
Important information
Important information
Charging of batteries
Radio frequency communication
TA-CMI uses radio frequency to communicate wirelessly between the instrument and
sensor units. Always turn off radio communication when there is risk that
TA-CMI disturbs other vital electronic devices, i.e. near medical equipment
and implanted cardiac pacemakers, in health care facilities, aircrafts, blasting
areas, areas with potentially explosive atmosperes and other areas posted
“turn off two-way radio”! You turn off radio communication by setting the radio
channel to “OFF” in the Instrument setup menu (see page 30).
Storage recommendations
• Never leave water in the sensor unit when there is a risk of freezing (i.e. in a car during
winter)!
• Storage above 40°C reduces battery life.
Unpacking
Check that these items are delivered.
Unpacking
TA-CMI
Doknr-01/2003.06
GBManual............................................................1
SEManual..........................................................xx
TA-CMI
1
2
3
4
5
678
9
10
11 12
1. Instrument unit
2. Sensor unit
3. Case
4. Connection cable
5. Temperature sensor Pt 1000
6. Charger Mascot 9725, 5.0 V
7. Measuring hose, 400 mm red with shut off valve
8. Measuring hose, 400 mm blue
9. Measuring needles
10. Chain for mounting
11. User Manual
12. Calibration certificate
5 hours!
Note! Both the sensor unit and the instrument unit contains batteries that need to be
charged. For best charging performance keep the connector clean. The supplied charger
from TA must be used!
Following batteries must be used (user not allowed to change batteries):
Instrument unit: 3 pcs NiMh type AA/R6
Sensor unit: 2 pcs NiMh type AAA/R03
Warning! Do not open the instrument as this could damage the warranty seal and void
your guarantee! See page 2 for further information.
!

TA-CMI
7
TA-CMI
6
Keyboard and display
Keyboard and display
Radio communication between the instrument and sensor unit is on.
Sensor unit battery capacity
Instrument battery capacity
Valve type
Valve setting (number of turns, see next page)
Media
Temperature
Radio communication between the instrument and sensor unit is off.
The sensor unit is connected to the instrument via the cable.
Symbols
These symbols are used in the instrument:
Valve setting
Valve setting
This section shows how you set or determine the number of valve turns on a TA valve.
The valve’s opening position can be read on the digital handwheel.
Closed valve
Valve open to 2.3 turns
Keyboard
(two keys) Functions according to text in display (see picture)
Navigating up/increasing digit or character/changing unit
Navigating down/decreasing digit or character/changing unit
Selecting digit, character or unit to change/go to selected function
Selecting digit, character or unit to change/go to selected function
Go to selected function/confirming settings (Enter)
Turning power to the instrument on and off. Press the start key for at least 2 seconds.
Returning to previous menu (Escape)

TA-CMI
9
TA-CMI
8
5. Press OK.
When the “radio on” symbol is displayed
at the top of the LCD, you can disconnect the
cable.
6. Select Functions. The main function menu of
the TA-CMI is displayed.
You select different functions from the main
function menu by pressing the down (or up) key
repeatedly and then pressing Enter on the desired
selection.
1. Start the instrument by pressing the start key
for at least 2 seconds.
Normal start of the instrument
Normally you start the instrument according to below.
2. Select Functions. The main function menu of
the TA-CMI is displayed.
You select different functions from the main
function menu by pressing the down (or up) key
repeatedly and then pressing Enter on the desired
selection.
Starting the instrument
1. Start the instrument by pressing the start key
for at least 2 seconds.
2. Navigate to the line corresponding to your
language by repeatedly pressing the down (or
up) key.
3. Press Enter on the desired selection, e.g.
desired selection English.
4. Connect the cable.
Starting the instrument
Starting the instrument for the first time
The first time you use the instrument and after the radio channel has been in “Sleeping” (see
page 30), you start the instrument according to below.
Starting the instrument

TA-CMI
11
TA-CMI
10
3. Connect the measuring needles to the measuring points.
Note! The shut off valve on the red measuring hose must be open when measuring.
Connection to measuring points
Risk of burn if the media is hot! Always connect the measuring needles and the
measuring hoses to the sensor unit (1 – 2) before connecting the measuring needles to
the measuring points (3).
Connection to measuring points
2. Connect the measuring needles to the measuring hoses.
Connection to measuring points
1. Connect the measuring hoses to the sensor unit.
Note! The connections with the red markings on the sensor unit and the measuring hose shall
be connected to the pressure test point with the red marking (the test point with the highest
pressure). The connections with the blue markings on the sensor unit and the measuring hose
shall be connected to the pressure test point with the blue marking (the test point with the
lowest pressure).
!

TA-CMI
13
TA-CMI
12
3. Disconnect the measuring hoses from the sensor unit.
Disconnection from measuring points
Risk of burn if the media is hot! Always disconnect the measuring needles from the
measuring points (1) before disconnecting the bayonet couplings at the measuring
hoses and the sensor unit (2 – 3).
Disconnection from measuring points
1. Disconnect the measuring needles from the measuring points.
Disconnection from measuring points
2. Disconnect the measuring needles from the measuring hoses.
!

TA-CMI Measure Valve
15
Measure Valve TA-CMI
14
6. Go to the Valve size menu by pressing the
down key, then pressing Enter.
7. Select the correct valve size by pressing the
down (or up) key repeatedly, then pressing
Enter.
9. Enter the actual number of valve turns by
using the up and down keys. Use the right key
to move the cursor to the next digit.
(See page 7 for description of how you
determine number of valve turns on a TA
valve.)
10. Confirm the entered value.
8. Open the Valve turns dialog by pressing the
down key, then pressing Enter.
If you are measuring on a valve without adjustment possibility (e.g. TA
LOOP) go directly to step 12 on page 16, otherwise continue below.
If you enter an invalid valve setting, e.g. 9 turns for STAF 125, this error
message is displayed.
MeasureValve
1. Connect the sensor unit to the measuring points on the valve according to pages 10 – 11.
Risk of burn if the media is hot! Always connect the measuring needles and the
measuring hoses to the sensor unit before connecting the measuring needles to the
measuring points.
You use this function if you want to measure differential pressure and/or flow through a valve
in a water bourne heating/cooling system.
3. Press Enter.
The Define Valve menu appears.
4. Go to the Valve type menu by pressing Enter
again.
5. Select the correct valve type by pressing the
down (or up) key repeatedly, then pressing
Enter on the desired valve.
If you are measuring on a non TA valve, see section “Entering the valve factor (Kv value) for
other valve types” on page 18. Otherwise continue below.
2. Navigate to Measure Valve in the main
function menu by pressing the down or up key
if necessary.
!

TA-CMI Measure Valve
17
Measure Valve TA-CMI
16
Measurement now begins. TA-CMI displays the differential pressure and
flow. It is important that the correct media type (e.g. water or glycol) is
specified, so that the instrument will display the appropriate flow value.
If the correct media type is displayed in the Measure Valve menu the
appropriate flow value is now displayed.
If the media type displayed does not correspond to actual media type,
define appropriate media according to page 20.
13. Release the calibration button on the sensor unit.
11. When the correct valve setting is specified,
press Done.
If an error message is displayed, press OK.
The setting is automatically changed to the
maximum value possible, or if you have tried to
enter a too small value, to the minimum value
possible.
Then enter the correct number of turns by using
the up, down and right keys. Confirm the new
value by pressing Enter.
12. Press the calibration button on the sensor unit.
When you have finished measuring the valve, disconnect the sensor unit from the measuring
points according to pages 12 – 13.
Risk of burn if the media is hot! Always disconnect the measuring needles from the
measuring points before disconnecting the bayonet couplings at the measuring hoses
and the sensor unit.
!

TA-CMI Measure Valve
19
Measure Valve TA-CMI
18
Entering the valve factor (Kv value) for other valve types
This section applies only to non TA valves.
1. Select valve type “Other”.
2. Confirm. 8. Enter a suitable valve name by using the up,
down and right keys.
3. Open the Valve factor dialog by pressing the
down key, then pressing Enter.
9. Confirm the entered valve name.
4. Enter the appropriate valve factor, by using
the up and down keys. Use the right key to
move the cursor to the next digit.
5. Confirm.
10. After you have entered the appropriate valve
factor (and perhaps valve name) press Done.
Then continue with step 12 on page 16.
If you want to enter a name for the valve (optional), do this according to steps 6 – 9. Otherwise
go directly to step 10.
6. To enter a name for the valve, select
Functions.
7. Then select Add Valve.

TA-CMI Measure Valve
21
Measure Valve TA-CMI
20
5. Open the Media Temperature dialog by
pressing the down key, then pressing Enter.
8. Open the Media weight dialog by pressing the
down key, then pressing Enter.
9. Enter the appropriate media weight in percent-
age, by using the up, down and right keys.
10. Confirm the entered value.
11. Press Done.
6. Enter the appropriate media temperature, by
using the up and down keys. Use the right key
to move the cursor to the next digit.
7. Confirm the entered value.
Define media
If the media type displayed in the Measure Valve menu does not
correspond to actual media type you have to define appropriate media
according to below.
1. Navigate to the media type line by repeatedly
pressing the down key.
Note! This section is only applicable to TA valve types STAD, STAF and TBV.
2. Open the Define Media menu by pressing
Enter.
3. Go to the Media type menu.
4. Select media type by pressing the down key
repeatedly, then pressing Enter.
If the system contains ethylene glycol or propylene glycol, enter the media temperature and the
media weight (% of glycol) according to steps 5 – 11 below.
If the system contains “other” media type you have to enter the density and the viscosity of the
media according to steps 12 – 18 on pages 22 – 23.

TA-CMI Measure Valve
23
Measure Valve TA-CMI
22
18. Press Done.
The appropriate flow value is now displayed.
The temperature displayed in the Measure Valve
menu is in this case without importance.
17. Confirm the entered value.
If the selected valve is any other than TA valve types STAD, STAF or TBV
and you try to set the media to anything other than water, this error
message is displayed and the media setting is automatically changed to
water. The reason for this is that the correction method that TA-CMI uses
to calculate the flow when using media types other than water, can only be
made with these valve types.
If the system contains water, ethylene glycol or propylene glycol you can stop reading here.
The appropriate flow value is now displayed.
If the system contains any other media type, enter the density and the viscosity of the media
according to below.
12. Open the Media density dialog by pressing
the down key, then pressing Enter.
13. Enter the appropriate media density, by using
the up, down and right keys.
14. Confirm the entered value.
15. Open the Media viscosity dialog by pressing
the down key, then pressing Enter.
16. Enter the appropriate viscosity, by using the
up, down and right keys.
While measuring differential pressure (and flow)
or temperature (see pages 24 – 25) you can freeze
measurements by pressing Freeze.
The measured values will be freezed, i.e. so that
you will have time to make a note of them.
Press Start when you want to restart measurement.
Freezing measurements

TA-CMI
25
TA-CMI
24
3. Press Enter.
The actual temperature is displayed.
If you try to measure the temperature without having connected the temperature sensor, the
value will be displayed as “– – –.–”.
Save as media temperature
It is possible to save the measured temperature as “media temperature” for later valve measure-
ments. This means that the media temperature is preset when you define media for flow
calculations (see pages 20 – 21).
Save the measured temperature as media temperature according to below.
1. In the Measure Temp menu, press Functions.
2. Select “Save as media temp” by pressing
Enter.
3. Press Yes.
The measured temperature is saved and will be
used in valve measurements to calculate flow
values, until a new media temperature is specified.
Measure Temperature
MeasureTemperature
1. Connect the temperature sensor to one of the measuring points on the valve.
2. Navigate to Measure Temp in the main
function menu, by pressing the down (or up)
key.
Measure Temperature

TA-CMI
27
TA-CMI
26
6. Select the appropriate valve size by pressing
the down (or up) key repeatedly, then pressing
Enter.
7. Press Done.
8. Enter desired flow by pressing the up and
down keys repeatedly. Use the right key to
move the cursor to the next digit.
9. Confirm the entered value.
10. Enter desired differential pressure by using
the up, down and right keys.
11. Confirm the entered value.
The calculated valve setting (number of turns) is
displayed. (See page 7 for description of how you
set the number of valve turns on a TA valve.)
If you enter a combination of desired flow and pressure the chosen valve
cannot produce, an error message will be displayed.
Handwheel Setting calculation
Handwheel Setting calculation
This function is used to calculate the valve setting that corresponds to a given flow and
differential pressure for a specific valve. The function includes no measuring.
For non TA valves, the valve factor (Kv value) that corresponds to a given flow and differential
pressure will be calculated.
2. Press Enter.
The Define Valve menu appears.
3. Go to the Valve type menu.
4. Select the appropriate valve type by pressing
the down (or up) key repeatedly, then pressing
Enter.
1. Step to Handwheel Setting in the main
function menu, by pressing the down (or up)
key.
5. Go to the Valve size menu, by pressing the
down key and then pressing Enter.
If you want to calculate the valve factor for a non TA valve, see section “Calculation of the
valve factor (Kv value) for other valve types” on page 29. Otherwise continue below.
Handwheel Setting calculation

TA-CMI Measure Valve
29
Measure Valve TA-CMI
28
2. Confirm.
4. Press Done.
5. Enter the desired flow and differential
pressure according to steps 8 – 11 on page
27.
The valve factor is displayed.
Handwheel Setting calculation
If an error message is displayed, press OK.
Then enter the appropriate flow by using the up,
down and right keys. Confirm the new value by
pressing Enter.
The calculated valve setting (number of turns) is
displayed.
If the pressure value is out of the pressure range
(0.5-200 kPa) for TA-CMI, an error message is
displayed, press OK.
Finally enter the appropriate differential pressure
and press Enter.
The calculated valve setting (number of turns) is
displayed.
Calculation of the valve factor (Kv value) for other valve types
This section applies only to non TA valves. The valve factor that corresponds to a given flow
and differential pressure will be calculated.
1. Select valve type “Other”.
Handwheel Setting calculation
3. If you want to enter a name for the valve
(optional), do this according to steps 6 – 9 on
page 19.

TA-CMI
31
TA-CMI
30
Instrument Setup and Information
Instrument Setup and Information
Instrument Setup
In the Instrument Setup menu you can set the parameters described in this
section.
Language
When you change language, the default measurement units will automatically be changed to
the most commonly used in the corresponding country. You can adapt the unit settings accord-
ing to your requirements in the Units menu (see below).
Backlight
The backlight will stay on after any key is pressed. Here you can set the duration it stays on
from 30 seconds to 5 minutes.
Contrast
Setting the LCD contrast for optimal reading
Sleep
TA-CMI will go into sleep mode after a period when the keys are not pressed. Here you can set
the period from 1 to 10 minutes. If Sleep delay is set to “OFF” the instrument will not go into
sleep mode when it is not used.
Key beep
Turning on and off the key beep sound
Radio
Turning on and off radio communication between the instrument and sensor units. Selecting
radio communication channel. If the radio channel is set to “Sleeping”, the radio communica-
tion is off until the sensor unit has been connected to the instrument unit via the cable.
Instrument Setup and Information
Information
In the Information menu you can access information about:
• The instrument unit program version
• The instrument unit battery status (volt, current, temperature, capacity,
charge)
• The sensor unit program version
• The sensor unit battery status (volt, current, temperature, capacity,
charge)
You access information about the different areas
by pressing the down or up key repeatedly, then
pressing Enter.
Units
Setting the measurement units for temperature, differential pressure and flow
Always set the radio channel to “OFF” when there is risk that TA-CMI disturbs
other vital electronic devices, i.e. near medical equipment and implanted cardiac
pacemakers, in health care facilities, aircrafts, blasting areas, areas with poten-
tially explosive atmosperes and other areas posted “turn off two-way radio”!
2. You then set the current parameter by pressing
the down or up key repeatedly, then pressing
Enter.
3. Leave the Instrument Setup menu and save
your settings by pressing Done.
1. You select any of the parameters by pressing
the down or up key repeatedly, then pressing
Enter.
Shown below is an example of how you set any of the parameters described on previous page.
!

TA-CMI
33
TA-CMI
32
Technical dataClearing faults, service and calibration
Clearing faults, service and calibration
Service
If you have tried to clear a fault according to above but the fault remains, contact your nearest
Tour & Andersson office. If the unit has to be sent in for repair, please enclose a description
of the fault.
Calibration
A calibration certificate for TA-CMI is issued after the delivery control. The equipment used is
traceable to national standards according to ISO 9001 or equivalent. Customers, who want a
regular calibration of the TA-CMI can order that from Tour&Andersson AB. Please mark
“Calibration” when you order. How frequent calibration of the instrument is necessary are
dependent upon usage and if it is required according to standards. As a general rule a calibra-
tion interval of 1 year is recommended.
Clearing faults
Automatic restart
If the instrument detects a lockup condition (the keyboard is not working), the instrument
restarts itself within 5 seconds. All saved data in the instrument will be unchanged.
No radio communication between instrument and sensor units
If the “radio off” symbol is displayed at top of the LCD, start radio
communication by connecting the cable between the instrument and sensor
units (see page 8).
Note! When you connect the instrument unit via the cable to a sensor unit,
you synchronise that particular sensor unit to communicate with your
instrument unit.
Incorrect function
If the instrument works incorrectly, i.e. due to
static electricity discharge, keep the start key
depressed and within one second also press the
first function key and the left key. This makes the
instrument restart but all saved data in the instru-
ment will be unchanged.
Blank LCD
If it is not possible to see the menus in the LCD,
press the Escape key for more than 2 seconds. The
LCD contrast will increase as long as the Escape
key is depressed.
Technical data
Measurement range
Total pressure ...................................................................................................... max 2 500 kPa
Differential pressure ............................................................................................... -9 – 200 kPa
Pressure range during flow measurements ........................................................ 0.5 – 200 kPa
Temperature air measurement .................................................................................-20 – 120°C
Temperature liquid medium measurement .............................................................-20 – 120°C
Measurement deviation
Differential pressure ............................... 0.2 kPa or 1% of reading, whichever is the highest
Flow .................................................................. As for differential pressure + valve deviation
Temperature ...................................................................................... <0.2°C + sensor deviation
Battery capacity, operating and charge times
Instrument unit battery capacity .............................................................................. 1 300 mAh
Instrument unit battery operating time (with backlight on) .............................................. 18 h
Instrument unit battery charge time to full capacity ........................................................... 5 h
Sensor unit battery capacity......................................................................................... 600 mAh
Sensor unit battery operating time (continuous measurements) ...................................... 18 h
Sensor unit battery charge time to full capacity .................................................................. 5 h
Ambient temperature
During operation ........................................................................................................... 0 – 40°C
During charging ............................................................................................................ 0 – 40°C
During storage*) .......................................................................................................... -20 – 60°C
*) Do not leave water in the sensor when there is a risk of freezing.
Storage above 40°C reduces battery life.
Humidity
Ambient humidity (not condensing) ....................................................................... max. 90%RH
Sealing
Class ...................................................................................................................................... IP 54

TA-CMI
34 35
TA-CMIAccessories
Accessories
Measuring points
STAF-SG, DN 20-50 39 mm 1/4” 52 179-009
103 mm 1/4” 52 179-609
STAF, DN 65-300 39 mm 3/8” 52 179-008
103 mm 3/8” 52 179-608
Measuring nipples
Connection tread 1/2” 52 197-303
Connection tread 3/4” 52 197-304
TA No
Measuring hoses
3 m extension, red with shut off valve 52 197-093
3 m extension, blue 52 197-094
150 mm with twin needle 52 198-801
Spanners
Spanner for measuring points, older valves 52 187-004
Allen key 3 mm, balancing 52 187-103
Allen key 5 mm, draining 52 187-105
Chucks
Chuck, red for old valves 52 198-802
Chuck, blue for old valves 52 198-803

36
TA-CMI
