Tablo QUAD 4-TUNER User manual

QUICK START GUIDE
4-TUNER
TV Antenna DVR with Dual-Band WiFi

Tablo
OTA DVR
Quick Start
Guide
Power
Supply
Ethernet
Cable
WHAT’S INCLUDED
CONTENTS
Quick Start Guide
STEP 1: Getting Connected..................................................................1
STEP 2: Download the Tablo App .......................................................2
STEP 3: Connecting Your Tablo to the Internet ...............................2
STEP 4: Follow the Tablo DVR Setup Wizard ...................................4
STEP 5: Program Guide Data Download...........................................5
STEP 6: Connecting Additional Playback Devices...........................5
Tablo App Feature Highlights .......................................6
Troubleshooting—Tablo DVR and App Initial Set Up ....7
About the Tablo Guide Data Service.............................8
Need Help? ...................................................................9
Warranties & Returns....................................................9

1
PowerUSBAntenna
SATA
CompartmentEthernet
STEP 1 Getting Connected
1. Connect Your HDTV Antenna
For optimal OTA reception, place your antenna near a window or outdoors, pointing towards your local
broadcast towers. Next, connect your antenna to your Tablo DVR via the coaxial connection. Ensure the
connector is tightly secured.
2. Connect a USB or SATA Hard Drive
BEFORE you connect the power adapter, connect a USB hard drive (1 TB to 8 TB in size) to the USB port
OR unscrew and slide off the SATA Compartment cover to insert and connect a 2.5” SATA hard drive
(standard 7 mm or 9.5 mm height, 1TB–4TB in size).
3. Connect Tablo to Your Home Network
Use the Ethernet cable (provided) to connect your Tablo DVR to your router. If your antenna placement does
not enable you to connect via Ethernet, connect Tablo to your home network via WiFi. See page 2 for details.
4. Connect the Power Adapter
In order to function correctly, your Tablo DVR must be powered on at all times, including overnight.
For help with antenna selection and positioning, a list of recommended hard drives,
additional set-up instructions and troubleshooting tips visit www.TabloTV.com/setup.

2
STEP 3 Connecting Your Tablo to the Internet
Connecting Your Tablo Via Ethernet
If you’ve connected your Tablo to your router via Ethernet in STEP 1, skip ahead to STEP 4 (on page 4).
Connecting Your Tablo Via WiFi
To connect your Tablo to your router via WiFi, read and follow these next instructions carefully.
IMPORTANT: The Ethernet cable provided must NOT be connected to Tablo during WiFi setup. The device you use
for setup (PC/MAC, smartphone, tablet) must already be connected to your home network via WiFi.
Your home network must also use WPA/WPA2 authentication, which is supported by all modern routers.
STEP 2 Download the Tablo App
We recommend completing rst time set up using the
Tablo app on your Apple/Android smartphone OR tablet.
Links to all apps can be found at www.TabloTV.com/apps.

3
Using one of the devices outlined in STEP 2 (on page 2),
open the Tablo app and select ‘Add via WiFi’.
Your Tablo will then begin broadcasting its own unique
WiFi network (Tablo_XXXX).
Next, leave (but don’t close) the Tablo app and navigate
to your device’s network settings screen. Find and
connect to the WiFi network called Tablo_XXXX.
You may now close down your device’s
network settings screen.

4
Next, return to the Tablo app and select the name of your
home’s WiFi network. You will be asked to enter your home’s
WiFi network password.
Your Tablo should then be connected via WiFi and ready to
proceed to STEP 4 (below).
Having trouble? Visit www.TabloTV.com/wi for device
specic instructions, tips, and a how-to video.
STEP 4 Follow the Tablo DVR Setup Wizard
The setup wizard will perform a channel scan to determine what channels can be received by your antenna.
You can add/remove recommended channels from your
guide at this time. Be sure to select ‘Rescan’ if you change or
adjust your antenna’s position after the initial channel scan.
The wizard will also ask to format your USB or SATA hard drive.
Is your lineup missing local channels you expected to see? Is
your Tablo DVR not nding any channels during a scan? Visit
www.TabloTV.com/channelscan for help.

5
STEP 5 Program Guide Data Download
Once you select ‘Add to Guide’ the rst 24 hours of the program guide will begin
to download. This process will take several minutes per channel. For best results,
please wait to watch TV or set recordings until the status indicator at the top of
the app’s sidebar has changed from ‘Updating Guide’ to a green dot beside the
word Tablo.
Your Tablo DVR is now ready to enjoy!
Missing or incorrect guide data? Visit www.TabloTV.com/guide for help.
Tablo DVRs support a wide variety of mobile devices, streaming media and gaming systems as well as select
Smart TVs for playback of live TV and recordings.
In order to enjoy Tablo content on those devices, you will need to download the appropriate Tablo app and follow
the on-screen prompts to connect it to your Tablo DVR.
A full list of supported devices and apps can be found at www.TabloTV.com/apps.
STEP 6 Connecting Additional Playback Devices

6
Tablo App Feature Highlights
Tablo apps make it easy to discover, record and stream beautiful Over-the-Air TV on all the devices inside and
outside your home. Here are some of the awesome features you can enjoy.
Live TV
To begin watching live TV, select the channel ID
on the far left of the Live TV grid guide. In this view,
you can also browse and schedule recordings for
programs airing in the next 24 hours.
Guide
In the guide screens (TV Shows, Movies, and Sports)
browse programs airing over the next 14 days and
schedule recordings by series (ALL or ALL NEW)
or by episode.
Recordings
View, play, delete, and protect completed recordings
from the recordings screen.
Skip to the Good Stuff
Fast-forward preview thumbnails are available
on completed recordings to help you skip ahead
or rewind the best parts.
Closed Captioning
Closed captioning is available for live TV and
recordings on most playback devices. For details
visit www.TabloTV.com/cc.
Settings
View, edit, and manage your Tablo guide data
subscription, storage space, recording/playback
quality, and more from the settings screen.
Tablo Connect
Also in settings, enable Tablo Connect for full access
to your Tablo while away from home via PC/MAC,
mobile, and Android TV devices.
5.1 Surround Sound
Also in settings, enable Surround Sound to receive
high quality sound on supported devices.
Note: Screen and feature availability may vary between apps.
All Tablo features and screens are available via the web app at my.TabloTV.com.

7
Troubleshooting—Tablo DVR and App Initial Set Up
Only 24 Hours of Guide Data Visible
The Live TV grid guide will always display 24 hours
of guide data. To browse the full 14 days of guide
data available, consult the guide screens including
TV shows, Movies, and Sports.
Guide Data is Incorrect or Missing
For incorrect data or data missing from specic
channels, contact Tablo Support for assistance.
While we work to correct your guide data problem,
try entering a zip/postal code from a neighboring area
by selecting ‘edit location’ in the settings screen.
Video Playback is Loading or Pausing Frequently
This is typically a home network bandwidth issue.
First, reduce the Recording Quality and Live TV Quality
in the settings screen. (Note: Changes to these settings
will apply immediately to live TV and then to all future
recordings.) If possible, connect your playback device
and/or Tablo via Ethernet instead of WiFi to rule out
potential WiFi interference and/or network congestion
Video Playback is Pixelated/Audio Drops Out
OTA antenna signal strength is inadequate or reduced.
Check your antenna’s connection to Tablo and/or its
position. Run a new channel scan within settings
to determine current signal strength.
Recordings Incomplete or Failed
OTA antenna signal and/or hard drive were unavailable
at the time of the recording. Antenna and/or hard drive
may require attention.
Hard Drive Not Recognized
If you have connected a hard drive and its details are not
shown in your settings screen and/or you have not yet
received a prompt to format it during the setup process,
try rebooting the Tablo using the blue reset button on
the back. If you still do not receive a prompt to format
the drive, contact Tablo Support for assistance.
Tablo Shows ‘Your Router Requires Manual
Conguration’ When Tablo Connect is Enabled
in Settings
Consult www.TabloTV.com/portforwarding for
additional instructions or contact Tablo Support
for assistance.
More detailed instructions, user manuals, and troubleshooting tips can be found online in the Tablo Knowledge
Base at support.TabloTV.com.

8
About the Tablo Guide Data Service
Each new Tablo DVR unit comes with a free 30-day trial of the Tablo guide data subscription. The trial is activated
automatically as soon as you complete the setup process.
At any time, you can verify your subscription status near the top of the settings screen of your Tablo app.
Without a Tablo subscription, you can still watch live TV and set manual recordings by date/time/channel.
In order to maintain access to a full 14 days of TV guide data as well as Tablo’s advanced DVR features, you must
select and purchase a subscription at account.TabloTV.com before your trial expires. Note: Your paid subscription
will begin at the end of your 30-day trial.
Need additional details and pricing? Visit www.TabloTV.com/subscription.

9
Federal Communication Commission Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Need Help?
Find answers to common questions, how-to guides, and troubleshooting tips at www.TabloTV.com/support.
Or, ask other Tablo users on our community forum at community.TabloTV.com.
Or, speak directly with our helpful team of support gurus:
[e-mail]
1-844-TABLOTV (822-5688)
Twitter.com/TabloSupport
Support hours of operation are Monday–Friday, 9:30 a.m. to 5:30 p.m. ET, excluding Canadian holidays. Messages
received outside of those hours will be returned within 1 business day.
Warranties & Returns
We hope you love your Tablo, but if you’re unhappy for any reason we offer a 30-day return policy on new units
purchased through TabloTV.com. For units purchased through retail partners, the retailer’s return policy applies.
All Tablo units include a 100% repair or replacement warranty for 12 months from the original purchase date.
Tablo’s complete warranty and return policy can be found on our website at www.TabloTV.com/warranty-returns.
Industry Canada Statement
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to
the following two conditions: (1) This device may not cause interference; and (2) This device
must accept any interference, including interference that may cause undesired operation of
the device.
Déclaration d’Industrie Canada
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre
le fonctionnement.

#NUV-TQ-NS-005
© 2022 Nuvyyo, Inc. All rights reserved. The Tablo logo is a registered trademark of Nuvyyo, Inc.
Other trademarks or registered trademarks are the property of their respective owners.
Having trouble? Contact us rst!
Do not return this product to the store!
For questions, setup assistance, or other concerns, please contact us directly
at 1-844-TABLOTV (822-5688) or email us at [e-mail].
