Tabuchi Electric EHW-S55P3B-PNUS User manual

Français
Manuel de l'utilisateur
Onduleur solaire hybride (5,5 kW, Extérieur)
EHW-S55P3B-PNUS
•Pour garantir un bon usage de ce produit, veuillez lire
attentivement ce Manuel de l'utilisateur.
•Avant d'utiliser ce produit, veuillez vous familiariser tout
particulièrement avec les "Précautions de sécurité" (pages
58 et 59).
•Conservez ce Manuel de l'utilisateur dans un endroit sûr
pour future référence.
Nous vous remercions d'avoir acheté ce produit de marque
Tabuchi Electric. Modes et mécanismes …62
Guide de référence rapide
Opération quotidienne …68
Fonctionnement en autonome …72
Dépistage des pannes …102
User’s Manual
Hybrid Solar Inverter (5.5 kW, Outdoor)
EHW-S55P3B-PNUS
•Read this User’s Manual carefully to ensure safe use of this
product.
•Completely familiarize yourself especially with the “Safety
Precautions” (Pages 4 to 5) before using this product.
•Keep this User’s Manual in a safe handy place for future
reference.
Thank you for purchasing this product from Tabuchi Electric.
Modes and Mechanisms …8
Quick Reference Guide
Grid-tied Operation …14
Stand-alone Operation …18
Troubleshooting …48
Conformité à la FCC(Commission Fédéraledes Communications)
Détecteur d'arc électrique
Notes
Cet équipement a été testé et s'avère conforme aux limites des dispositifs numériques de classe B
conformément à l'article 15 des règlements de la FCC. Ces limites sont conçues pour fournir une protection
raisonnable contre les interférences nuisibles lorsque l'équipement fonctionne dans une installation
résidentielle. Cet équipement génère, utilise et peut émettre une énergie de fréquence radio qui, s'il n'est
pas installé et utilisé en conformité avec le manuel d'instructions, peut entraîner une interférence nuisible
aux communications radio. Le fonctionnement de cet équipement dans une zone résidentielle peut entraîner
une interférence nuisible et dans ce cas, il sera demandé à l'utilisateur de corriger cette interférence à ses
propres frais.
L'onduleur est certifié conforme à la norme UL1699B.
Il dispose d'un détecteur d'arc électrique causé par les cellules photovoltaïques.
DOC01-7101D
Tabuchi Electric Co., Ltd.

23
Living of solar power 24 hours a day
Contents
Introduction
Safety Precautions
System Diagram
Modes and Mechanisms
Names of Parts
Notes on Usage
This Hybrid Solar Inverter uses the electric power generated by the sun during the day. Surplus power
is continuously stored in the lithium-ion storage batteries. (Charging differs according to the operating
mode.) The power stored in the storage batteries is used to stabilize the daytime power supply as well
as a nighttime power source at night.
After DC power from the PV panels is converted into AC power by the Hybrid Solar Inverter, it is
connected to the commercial power grid and used to power electric appliances.
Moreover, DC power stored in the storage batteries is used to drive the modes below, so daily
operation is not necessary.
Grid-tied Operation Page 14
■MAX POWER EXPORT Mode
Daily operation is not necessary.
Storage batteries are charged by the commercial power grid at night. Power stored in the storage
batteries is used during the daytime to cover any PV system generation shortages and avoid peak
rate grid charges.
■ECONOMY Mode
Surplus power generated by the PV system is not only sold to the power company, but it is also
stored in the storage batteries for use at night.
■HOME BACKUP Mode
Storage batteries are kept fully charged at all times as a safeguard against power outages on the
commercial power grid.
Operating modes can be selected according to
personal lifestyle.
As long as the solar panels are generating power or the storage batteries retain a charge, the inverter
will keep running in the event of an outage on the commercial power grid by automatically switching
to stand-alone operation (Page 20).
Carefully read the precautions on stand-alone operation (Page 18) before use.
Stand-alone Operation Page 18
Automatically switches to stand-alone operation in
the event of a power outage.
Before Using the Inverter for the First Time
4
6
Preparations
System Startup
13
13
8
10
Grid-tied Operation
Daily Operation
Controlled Output
If an Outage Occurs on the Commercial Power Grid
Equipment Troubleshooting
14
16
17
17
Stand-alone Operation (In a Power Outage)
Stand-alone Operation Precautions
Stand-alone Operation Startup (Power Outage)
Restoration of Grid-tied Operation
Operation during a Power Outage
18
20
21
22
12
Other
How to Stop Inverter Operation
Settings
Viewing System Records
Energy Saving Assistance
Troubleshooting
Equipment Checks and Maintenance
Specifications
24
25
48
51
40
46
53
Read before use!
English
English

23
Living of solar power 24 hours a day
Contents
Introduction
Safety Precautions
System Diagram
Modes and Mechanisms
Names of Parts
Notes on Usage
This Hybrid Solar Inverter uses the electric power generated by the sun during the day. Surplus power
is continuously stored in the lithium-ion storage batteries. (Charging differs according to the operating
mode.) The power stored in the storage batteries is used to stabilize the daytime power supply as well
as a nighttime power source at night.
After DC power from the PV panels is converted into AC power by the Hybrid Solar Inverter, it is
connected to the commercial power grid and used to power electric appliances.
Moreover, DC power stored in the storage batteries is used to drive the modes below, so daily
operation is not necessary.
Grid-tied Operation Page 14
■MAX POWER EXPORT Mode
Daily operation is not necessary.
Storage batteries are charged by the commercial power grid at night. Power stored in the storage
batteries is used during the daytime to cover any PV system generation shortages and avoid peak
rate grid charges.
■ECONOMY Mode
Surplus power generated by the PV system is not only sold to the power company, but it is also
stored in the storage batteries for use at night.
■HOME BACKUP Mode
Storage batteries are kept fully charged at all times as a safeguard against power outages on the
commercial power grid.
Operating modes can be selected according to
personal lifestyle.
As long as the solar panels are generating power or the storage batteries retain a charge, the inverter
will keep running in the event of an outage on the commercial power grid by automatically switching
to stand-alone operation (Page 20).
Carefully read the precautions on stand-alone operation (Page 18) before use.
Stand-alone Operation Page 18
Automatically switches to stand-alone operation in
the event of a power outage.
Before Using the Inverter for the First Time
4
6
Preparations
System Startup
13
13
8
10
Grid-tied Operation
Daily Operation
Controlled Output
If an Outage Occurs on the Commercial Power Grid
Equipment Troubleshooting
14
16
17
17
Stand-alone Operation (In a Power Outage)
Stand-alone Operation Precautions
Stand-alone Operation Startup (Power Outage)
Restoration of Grid-tied Operation
Operation during a Power Outage
18
20
21
22
12
Other
How to Stop Inverter Operation
Settings
Viewing System Records
Energy Saving Assistance
Troubleshooting
Equipment Checks and Maintenance
Specifications
24
25
48
51
40
46
53
Read before use!
English
English

4 5
English
English
Safety Precautions
The symbols below indicate the potential hazards
of improper use of this product.
Observethefollowingprecautionsinadditiontoperformingtherequiredequipmentchecks.
•TabuchiElectricassumesnoresponsibilityforaccidentsorequipmentfailureiftheequipmentisusedinany
mannerotherthanspecifiedinthisUser'sManualorindisregardofthesafetyprecautions.
•Theseprecautionsexplainwhatmustbeobservedtopreventpersonalinjuryandpropertydamage.
The symbols below indicate prohibited use of this
product and safety precautions.
Prohibited use of this product.
Mandatory safety precautions.
May result in serious injury or
death.
May result in minor injury or
property damage.
Please note the following items when the inverter is shutdown for an inspection or maintenance.
WARNING
CAUTION
■Handling and Usage
■Observe all safety precautions.
WARNING
This may result in fire, electric shock,
burns, injury or equipment failure.
Do not cover the inverter vents.
Do not detach the front panel, or
disassemble or remodel the inverter.
If the inverter continues running in this
state, it may result in equipment failure,
electric shock, or fire. Contact the
vendor for servicing.
If the inverter emits strange odors, shut
it off, and set the grid breaker in the
Main Panel to the OFF position.
This may result in fire or equipment
damage.
Do not subject the inverter to
any vibrations or impacts.
The inverter’ s temperature rises while
running. Carelessly touching the inverter
may result in burns. Especially keep an
eye on children and elderly persons.
Do not carelessly touch the inverter
while it is running.
Failure to shut off the inverter and grid
breaker or shutting them off in the wrong
order may result in electric shock or burns.
Before cleaning the inverter, shut it
off and set the grid breaker in the
Main Panel to the OFF position.
The inverter may adversely affect
pacemakers.
Keep persons with pacemakers away
from the inverter.
Do not climb on or hang from the inverter.
PROHIBITED
PROHIBITED
MANDATORY
Do not touch the inverter during
disasters or if there is lightening.
This may result in electric shock, injury,
or burns.
The inverter may topple over, resulting
in injury, electric shock or equipment
failure.
Do not place or use gasoline, benzene, or
other flammable agents near the inverter. This
may result in fire or equipment failure.
Keep gasoline, benzene, or other flammable
agents away from the inverter.
Do not use insecticides or other combustible
products near the inverter.
PROHIBITED
This may result in electric shock, current leaks
or equipment failure.
Do not expose the inverter to water or oil
vapors.
Do not use heaters or equipment that releases
steam near the inverter.
Do not use heaters, rice cookers, humidifiers,
or other equipment that releases steam near
the inverter. This may result in fire or
equipment failure.
PROHIBITED
Do not locate the inverter in poorly
ventilated area where the vents are blocked.
Do not cover the vents with tablecloths,
sheets, or towels, etc. Internal temperature
may rise, resulting in fire, equipment failure,
or a shortened service-life.
Keep objects off the inverter.
Objects may heat up and catch fire
during operation.
■Near the Equipment
■During Stand-alone Operation
CAUTION
DO NOT
TOUCH
PROHIBITED
DO NOT
TOUCH
CAUTION
MANDATORY
The amount of electric power generated during stand-alone
operation varies according to weather and storage battery
charge. The inverter stops stand-alone operation if it generates
less electric power than that consumed by the electric
appliances connected to its stand-alone outlets. Do not use
the appliances listed below with the inverter as personal injury
or property damage may occur if the power shuts off.
• Any kind of medical or home security equipment
• Desktop computers and other information-related
equipment and peripherals
• Rice cookers, microwave ovens, and other cooling
equipment
• Heaters that use kerosene or gas
• Other equipment that may cause personal injury or
property damage if the power shuts off
Confirm the backup panel, related wiring, and electrical
fixtures are in good safe condition before commencing
stand-alone operation.
If strange odors or noises are detected after starting
stand-alone operation, promptly stop stand-alone operation.
Do not connect the below electric appliances listed below
to the stand-alone outlets.
WARNING
CAUTION

4 5
English
English
Safety Precautions
The symbols below indicate the potential hazards
of improper use of this product.
Observethefollowingprecautionsinadditiontoperformingtherequiredequipmentchecks.
•TabuchiElectricassumesnoresponsibilityforaccidentsorequipmentfailureiftheequipmentisusedinany
mannerotherthanspecifiedinthisUser'sManualorindisregardofthesafetyprecautions.
•Theseprecautionsexplainwhatmustbeobservedtopreventpersonalinjuryandpropertydamage.
The symbols below indicate prohibited use of this
product and safety precautions.
Prohibited use of this product.
Mandatory safety precautions.
May result in serious injury or
death.
May result in minor injury or
property damage.
Please note the following items when the inverter is shutdown for an inspection or maintenance.
WARNING
CAUTION
■Handling and Usage
■Observe all safety precautions.
WARNING
This may result in fire, electric shock,
burns, injury or equipment failure.
Do not cover the inverter vents.
Do not detach the front panel, or
disassemble or remodel the inverter.
If the inverter continues running in this
state, it may result in equipment failure,
electric shock, or fire. Contact the
vendor for servicing.
If the inverter emits strange odors, shut
it off, and set the grid breaker in the
Main Panel to the OFF position.
This may result in fire or equipment
damage.
Do not subject the inverter to
any vibrations or impacts.
The inverter’ s temperature rises while
running. Carelessly touching the inverter
may result in burns. Especially keep an
eye on children and elderly persons.
Do not carelessly touch the inverter
while it is running.
Failure to shut off the inverter and grid
breaker or shutting them off in the wrong
order may result in electric shock or burns.
Before cleaning the inverter, shut it
off and set the grid breaker in the
Main Panel to the OFF position.
The inverter may adversely affect
pacemakers.
Keep persons with pacemakers away
from the inverter.
Do not climb on or hang from the inverter.
PROHIBITED
PROHIBITED
MANDATORY
Do not touch the inverter during
disasters or if there is lightening.
This may result in electric shock, injury,
or burns.
The inverter may topple over, resulting
in injury, electric shock or equipment
failure.
Do not place or use gasoline, benzene, or
other flammable agents near the inverter. This
may result in fire or equipment failure.
Keep gasoline, benzene, or other flammable
agents away from the inverter.
Do not use insecticides or other combustible
products near the inverter.
PROHIBITED
This may result in electric shock, current leaks
or equipment failure.
Do not expose the inverter to water or oil
vapors.
Do not use heaters or equipment that releases
steam near the inverter.
Do not use heaters, rice cookers, humidifiers,
or other equipment that releases steam near
the inverter. This may result in fire or
equipment failure.
PROHIBITED
Do not locate the inverter in poorly
ventilated area where the vents are blocked.
Do not cover the vents with tablecloths,
sheets, or towels, etc. Internal temperature
may rise, resulting in fire, equipment failure,
or a shortened service-life.
Keep objects off the inverter.
Objects may heat up and catch fire
during operation.
■Near the Equipment
■During Stand-alone Operation
CAUTION
DO NOT
TOUCH
PROHIBITED
DO NOT
TOUCH
CAUTION
MANDATORY
The amount of electric power generated during stand-alone
operation varies according to weather and storage battery
charge. The inverter stops stand-alone operation if it generates
less electric power than that consumed by the electric
appliances connected to its stand-alone outlets. Do not use
the appliances listed below with the inverter as personal injury
or property damage may occur if the power shuts off.
• Any kind of medical or home security equipment
• Desktop computers and other information-related
equipment and peripherals
• Rice cookers, microwave ovens, and other cooling
equipment
• Heaters that use kerosene or gas
• Other equipment that may cause personal injury or
property damage if the power shuts off
Confirm the backup panel, related wiring, and electrical
fixtures are in good safe condition before commencing
stand-alone operation.
If strange odors or noises are detected after starting
stand-alone operation, promptly stop stand-alone operation.
Do not connect the below electric appliances listed below
to the stand-alone outlets.
WARNING
CAUTION

Solar Panel
Hybrid Solar Inverter
Storage Battery Unit
Remote Controller
Backup Panel
Main Panel
To individual circuits
AC
DC
Signal Wire
To appliances you want to
keep during a power outage
Generate electricity
Smartly uses electricity
Stores electricity
Power Company
English
English
System Diagram
6 7

Solar Panel
Hybrid Solar Inverter
Storage Battery Unit
Remote Controller
Backup Panel
Main Panel
To individual circuits
AC
DC
Signal Wire
To appliances you want to
keep during a power outage
Generate electricity
Smartly uses electricity
Stores electricity
Power Company
English
English
System Diagram
6 7

123456789 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
123456789 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
Power purchasing
over 2.0 kVA
Ⓒ
Ⓓ
Ⓑ
Ⓐ
(Initial mode)
8 9
English
English
Modes and Mechanisms
HOME BACKUP Mode keeps the storage batteries fully charged at all times. Once charged, the system goes on
standby as a safeguard against power outages on the commercial power grid.
The display may not show that the storage batteries are fully charged due to a margin of error.
Use the inverter as an emergency power supply for instances such as rolling blackouts, etc. Use of the Storage
Mode is recommended since it keeps the storage batteries fully charged at all times. If an outage is anticipated
while using the inverter in another mode, you can switch to the Storage Mode ahead of time and minimize the
impact of the outage by having the storage batteries fully charged.
The following three modes are available during grid-tied operation. To switch modes, see the "Remote Controller"
section (Page 10) of the User's Manual.
Surplus PV-generated power is used to charge the storage batteries.
Any power that cannot be stored in the storage batteries is sold.
Power is discharged from the storage batteries. If there is not enough
power coming from the PV system and storage batteries, power is
purchased from the power company.
Power is sold
MAX POWER EXPORT Mode
When power is contracted
by the hour
MAX POWER EXPORT Mode minimizes use of “peak electricity” and
“purchased electricity” by charging the storage batteries at night when
utility rates are low and discharging the stored power during the day
and evening to run connected electric appliances.
ECONOMY Mode ECONOMY Mode minimizes the amount of purchased electricity
purchased from the grid by utilizing PV-generated power during the day, in the
evening, and at night.
HOME BACKUP Mode
A
Power is
purchased
Surplus PV-generated power is
sold to the commercial power grid.
Power cannot be generated at night or when it rains.
When there is not enough power coming from the PV
system or storage batteries, power is supplied by the
power company.
B
Power is stored
C
Stored power is
discharged
D
Time
PowerGenerated,
HouseholdLoad(kW)
PowerGenerated,
HouseholdLoad(kW)
5
4.5
4
3.5
3
2.5
2
1.5
1
0
0.5
Time
5
4.5
4
3.5
3
2.5
2
1.5
1
0.5
0
Charging up to
max. 1.5 kW
Power Selling
Household Load
Household Load
Solar Power Generation
Solar Power Generation
Nighttime Charging 1.5 kW
Discharge up to
max. 2.0 kVA
Discharge up to
max. 2.0 kVA
Power Selling

123456789 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
123456789 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
Power purchasing
over 2.0 kVA
Ⓒ
Ⓓ
Ⓑ
Ⓐ
(Initial mode)
8 9
English
English
Modes and Mechanisms
HOME BACKUP Mode keeps the storage batteries fully charged at all times. Once charged, the system goes on
standby as a safeguard against power outages on the commercial power grid.
The display may not show that the storage batteries are fully charged due to a margin of error.
Use the inverter as an emergency power supply for instances such as rolling blackouts, etc. Use of the Storage
Mode is recommended since it keeps the storage batteries fully charged at all times. If an outage is anticipated
while using the inverter in another mode, you can switch to the Storage Mode ahead of time and minimize the
impact of the outage by having the storage batteries fully charged.
The following three modes are available during grid-tied operation. To switch modes, see the "Remote Controller"
section (Page 10) of the User's Manual.
Surplus PV-generated power is used to charge the storage batteries.
Any power that cannot be stored in the storage batteries is sold.
Power is discharged from the storage batteries. If there is not enough
power coming from the PV system and storage batteries, power is
purchased from the power company.
Power is sold
MAX POWER EXPORT Mode
When power is contracted
by the hour
MAX POWER EXPORT Mode minimizes use of “peak electricity” and
“purchased electricity” by charging the storage batteries at night when
utility rates are low and discharging the stored power during the day
and evening to run connected electric appliances.
ECONOMY Mode ECONOMY Mode minimizes the amount of purchased electricity
purchased from the grid by utilizing PV-generated power during the day, in the
evening, and at night.
HOME BACKUP Mode
A
Power is
purchased
Surplus PV-generated power is
sold to the commercial power grid.
Power cannot be generated at night or when it rains.
When there is not enough power coming from the PV
system or storage batteries, power is supplied by the
power company.
B
Power is stored
C
Stored power is
discharged
D
Time
PowerGenerated,
HouseholdLoad(kW)
PowerGenerated,
HouseholdLoad(kW)
5
4.5
4
3.5
3
2.5
2
1.5
1
0
0.5
Time
5
4.5
4
3.5
3
2.5
2
1.5
1
0.5
0
Charging up to
max. 1.5 kW
Power Selling
Household Load
Household Load
Solar Power Generation
Solar Power Generation
Nighttime Charging 1.5 kW
Discharge up to
max. 2.0 kVA
Discharge up to
max. 2.0 kVA
Power Selling

10 11
English
English
Names of Parts
■Hybrid Solar Inverter
■Remote Controller
The indicated amount of GENERATION, CHARGE/DISCHARGE, BUY/SELL, and
CONSUMPTION are not completely accurate. Use them as a reference. (This
product is not subjected to regulations under the Weights and Measures Law.)
Displays functions that are executed from
the below operating buttons shown on the panel.
(Indications change according to the screen.)
Press the operating buttons below to execute the
desired functions.
(The display is not a touch screen panel.)
To select [ENTER], press the operating button directly
below it.
The home screen is the screen that is typically displayed while the Hybrid Solar Inverter is running.
Vents
Front Panel
Hybrid Solar Inverter
DC Switch-disconnector
Base
Display
Execute the functions that appear
on the display. (If the display goes out, pressing any
of the operating buttons to light up the display. The
home screen will appear.)
Operating Buttons
Display
Green : Running grid-tied operation
Red : Running stand-alone operation
Flashing red : Automatically stopped
Lights OFF : Grid-tied operation manually stopped
Stand-alone operation manually stopped
Grid-tied operation is on standby
Stand-alone operation is on standby
How to read LED Indicators
This button is inoperable during an
outage, if solar power is not being
generated, or if the storage
batteries have no charge (drained,
disconnected, or stopped due to an
error).
How to read RUN/STOP Button
GRID-TIED MODE : Green(SELL)
: Orange(BUY)
STAND-ALONE MODE:Green
Others : Lights OFF
RUN/STOP Button
Hybrid Solar Inverter Operating Status
GRID CONNECT→…Preparing to start grid-tied operation.
GRID TIED MODE …Running normally off the grid.
MANUAL GRID STOP …Grid-tied operation was manually stopped.
AUTOMATIC STOP …Operation was stopped due to an error, etc.
STAND-ALONE→…Preparing to start stand-alone operation.
STAND-ALONE MODE …Solar power and battery power are being supplied to the backup panel for
stand-alone operation.
STAND-ALONE STOP …Stand-alone operation was manually stopped.
A
B
C
D
NOTE
Time/Date
Displays the current time, day, month and year.
Operating Mode
Displays the current operating
mode during grid-tied operation
(MAX POWER EXPORT Mode,
ECONOMY Mode, and HOME
BACKUP Mode.)
Controlled Output Status Display
Displays the controlled output status of the inverter as a
message: “VOLTAGE REGULATION,” “TEMPERATURE
SUPPRESSION” or “TEMPERATURE . VOLTAGE
SUPPRESSION”.
A message will not appear during normal operation.
Error Code
Displays an error code if an
error occurs.
A code will not appear during
normal operation.
Operating Status
Displays the current operating
status of the inverter.
Displays the amount of solar power the
system is currently generating.
Displays the amount of power that is sold
to or purchased from the power company.
When power is sold, “SELL” is displayed
and when the power is purchased, “BUY”
is displayed.
Displays the amount of power that is
currently consumed in the home.
Displays the amount of power charged in
or discharged from the storage battery.
When the battery is fully charged,
“CHARGE” is displayed, when the battery
is discharged, “DISCHARGE” is displayed
and when the battery stops charging/
discharging, “STANDBY” is displayed.
In addition, if a fault occurs with the
storage battery, “FAULT” is displayed.
5 . 5 0 kW
GENERATION
1 . 5 0 kW
CHARGE
1 . 5 0 kW
DISCHARGE
1 . 5 0 kW
BUY
1 . 5 0 kW
SELL
1 . 5 0 kW
CONSUMPTION
– . – – kW
STANDBY
– . – – kW
FAULT
A
C
D
B

10 11
English
English
Names of Parts
■Hybrid Solar Inverter
■Remote Controller
The indicated amount of GENERATION, CHARGE/DISCHARGE, BUY/SELL, and
CONSUMPTION are not completely accurate. Use them as a reference. (This
product is not subjected to regulations under the Weights and Measures Law.)
Displays functions that are executed from
the below operating buttons shown on the panel.
(Indications change according to the screen.)
Press the operating buttons below to execute the
desired functions.
(The display is not a touch screen panel.)
To select [ENTER], press the operating button directly
below it.
The home screen is the screen that is typically displayed while the Hybrid Solar Inverter is running.
Vents
Front Panel
Hybrid Solar Inverter
DC Switch-disconnector
Base
Display
Execute the functions that appear
on the display. (If the display goes out, pressing any
of the operating buttons to light up the display. The
home screen will appear.)
Operating Buttons
Display
Green : Running grid-tied operation
Red : Running stand-alone operation
Flashing red : Automatically stopped
Lights OFF : Grid-tied operation manually stopped
Stand-alone operation manually stopped
Grid-tied operation is on standby
Stand-alone operation is on standby
How to read LED Indicators
This button is inoperable during an
outage, if solar power is not being
generated, or if the storage
batteries have no charge (drained,
disconnected, or stopped due to an
error).
How to read RUN/STOP Button
GRID-TIED MODE : Green(SELL)
: Orange(BUY)
STAND-ALONE MODE:Green
Others : Lights OFF
RUN/STOP Button
Hybrid Solar Inverter Operating Status
GRID CONNECT→…Preparing to start grid-tied operation.
GRID TIED MODE …Running normally off the grid.
MANUAL GRID STOP …Grid-tied operation was manually stopped.
AUTOMATIC STOP …Operation was stopped due to an error, etc.
STAND-ALONE→…Preparing to start stand-alone operation.
STAND-ALONE MODE …Solar power and battery power are being supplied to the backup panel for
stand-alone operation.
STAND-ALONE STOP …Stand-alone operation was manually stopped.
A
B
C
D
NOTE
Time/Date
Displays the current time, day, month and year.
Operating Mode
Displays the current operating
mode during grid-tied operation
(MAX POWER EXPORT Mode,
ECONOMY Mode, and HOME
BACKUP Mode.)
Controlled Output Status Display
Displays the controlled output status of the inverter as a
message: “VOLTAGE REGULATION,” “TEMPERATURE
SUPPRESSION” or “TEMPERATURE . VOLTAGE
SUPPRESSION”.
A message will not appear during normal operation.
Error Code
Displays an error code if an
error occurs.
A code will not appear during
normal operation.
Operating Status
Displays the current operating
status of the inverter.
Displays the amount of solar power the
system is currently generating.
Displays the amount of power that is sold
to or purchased from the power company.
When power is sold, “SELL” is displayed
and when the power is purchased, “BUY”
is displayed.
Displays the amount of power that is
currently consumed in the home.
Displays the amount of power charged in
or discharged from the storage battery.
When the battery is fully charged,
“CHARGE” is displayed, when the battery
is discharged, “DISCHARGE” is displayed
and when the battery stops charging/
discharging, “STANDBY” is displayed.
In addition, if a fault occurs with the
storage battery, “FAULT” is displayed.
5 . 5 0 kW
GENERATION
1 . 5 0 kW
CHARGE
1 . 5 0 kW
DISCHARGE
1 . 5 0 kW
BUY
1 . 5 0 kW
SELL
1 . 5 0 kW
CONSUMPTION
– . – – kW
STANDBY
– . – – kW
FAULT
A
C
D
B

12 13
English
English
Notes on Usage Before Using the Inverter for the First Time
The rated output of solar panels is based on certain conditions. The actual amount of output will vary
according to the intensity of sunlight, surrounding temperature and the direction and angle at which the
panels are installed. Therefore, even on clear days, the rated output may not always be generated. On clear
days, the generated power should be about 70 to 80% of the rated output.
Preparations
IMPORTANT INFORMATION to KNOW
■Generated power
•The very first time the inverter is used, it can be started by pressing the [RUN/STOP] button.
•Once the inverter starts up, it runs automatically in the set operating mode according to the amount of
sunlight, time of day, battery charge, etc.
•At night, when it is raining, or when inverter output is insufficient to run connected appliances because the
battery charge is low, power is automatically supplied from the commercial power grid.
■Daily operation is not necessary.
Although the inverter is automatically supplied by stored battery power when a power outage occurs, the
power supply is briefly interrupted when the inverter switches over to stand-alone operation.
Once the commercial power grid operation is restored after an outage, the inverter automatically resumes
grid-tied operation.
■When a power outage occurs, the inverter automatically engages stand-alone operation.
Before using the inverter for the first time, have the installer perform the operations described below
in the “Preparations” and “System Startup” sections.
The Hybrid Solar Inverter is for outdoor use.
Check the operating status of the inverter.
Set the grid-tied breaker in the Main Panel to the ON position.
System Startup
When the grid-tied breaker is set in the ON position, the display
indicates that grid-tied operation has been manually stopped as
shown in the image on the right.
When “STAND-ALONE STOP” is displayed on the screen, press and hold the
[RUN/STOP] button for 5 seconds or more, and confirm that the operating
status changes to “MANUAL GRID STOP.”
Press the [RUN/STOP] button. “GRID CONNECT→” appears on the
display for a few minutes before grid-tied operation starts.
“GRID CONNECT→” appears on the display for a few minutes before
grid-tied operation starts.
1
Start inverter operation.
2
When grid-tied operation resumes after the commercial power grid
restores from an outage, “GRID CONNECT→” appears on the
display for a few minutes.
• The inverter stops during the daytime if an outage occurs on the commercial power grid.
• The inverter occasionally makes noise during operation. This is normal.
NOTE
NOTE
•Where there is a minimal amount of oily smoke and dust.
•Where not exposed to corrosive gases or liquids.
■Secure a location for the inverter that meets the
following requirements.
Those products may not work properly.
■Do not use electric products that are vulnerable to
electrical noise near the inverter.
200 mm (7.8 in) or more
200 mm (7.8 in)
or more
500 mm (19.7 in)
or more
800 mm (31.5 in)
or more
■Do not use radios, cellphones or receivers of any
kind near the inverter so as to avoid signal reception
interference.
■Ensure a minimum of 800 mm (31.5 in) in front, a
minimum of 500 mm (19.7 in) on the left, and
200 mm (7.8 in) above and on the right of the
inverter for equipment checks and maintenance.

12 13
English
English
Notes on Usage Before Using the Inverter for the First Time
The rated output of solar panels is based on certain conditions. The actual amount of output will vary
according to the intensity of sunlight, surrounding temperature and the direction and angle at which the
panels are installed. Therefore, even on clear days, the rated output may not always be generated. On clear
days, the generated power should be about 70 to 80% of the rated output.
Preparations
IMPORTANT INFORMATION to KNOW
■Generated power
•The very first time the inverter is used, it can be started by pressing the [RUN/STOP] button.
•Once the inverter starts up, it runs automatically in the set operating mode according to the amount of
sunlight, time of day, battery charge, etc.
•At night, when it is raining, or when inverter output is insufficient to run connected appliances because the
battery charge is low, power is automatically supplied from the commercial power grid.
■Daily operation is not necessary.
Although the inverter is automatically supplied by stored battery power when a power outage occurs, the
power supply is briefly interrupted when the inverter switches over to stand-alone operation.
Once the commercial power grid operation is restored after an outage, the inverter automatically resumes
grid-tied operation.
■When a power outage occurs, the inverter automatically engages stand-alone operation.
Before using the inverter for the first time, have the installer perform the operations described below
in the “Preparations” and “System Startup” sections.
The Hybrid Solar Inverter is for outdoor use.
Check the operating status of the inverter.
Set the grid-tied breaker in the Main Panel to the ON position.
System Startup
When the grid-tied breaker is set in the ON position, the display
indicates that grid-tied operation has been manually stopped as
shown in the image on the right.
When “STAND-ALONE STOP” is displayed on the screen, press and hold the
[RUN/STOP] button for 5 seconds or more, and confirm that the operating
status changes to “MANUAL GRID STOP.”
Press the [RUN/STOP] button. “GRID CONNECT→” appears on the
display for a few minutes before grid-tied operation starts.
“GRID CONNECT→” appears on the display for a few minutes before
grid-tied operation starts.
1
Start inverter operation.
2
When grid-tied operation resumes after the commercial power grid
restores from an outage, “GRID CONNECT→” appears on the
display for a few minutes.
• The inverter stops during the daytime if an outage occurs on the commercial power grid.
• The inverter occasionally makes noise during operation. This is normal.
NOTE
NOTE
•Where there is a minimal amount of oily smoke and dust.
•Where not exposed to corrosive gases or liquids.
■Secure a location for the inverter that meets the
following requirements.
Those products may not work properly.
■Do not use electric products that are vulnerable to
electrical noise near the inverter.
200 mm (7.8 in) or more
200 mm (7.8 in)
or more
500 mm (19.7 in)
or more
800 mm (31.5 in)
or more
■Do not use radios, cellphones or receivers of any
kind near the inverter so as to avoid signal reception
interference.
■Ensure a minimum of 800 mm (31.5 in) in front, a
minimum of 500 mm (19.7 in) on the left, and
200 mm (7.8 in) above and on the right of the
inverter for equipment checks and maintenance.

Grid-tied Operation
14 15
English
English
■Daily Operation
*1. Daytime and nighttime hours must be set when installing the inverter.
*2. The emergency backup charge is not discharged.
*3. Battery discharging stops when the amount of sunlight increases and power is sold to the power company.
*4. The storage batteries are charged whenever the emergency backup charge is low.
*5. The storage batteries do not charge further once full.
*6. Surplus solar power that cannot be stored in the power batteries is sold.
*7. Even while the storage batteries are discharging power, 0.2 kW or more power is purchased from the power company.
*8. Even while solar power is used to charge the storage batteries, power is sold and purchased according to power consumption in the home.
The storage batteries are fully charged during
the nighttime hours. *1, 4
Time of Day
Solar Power
MAX POWER
EXPORT Mode
Remote Controller (Example) Remote Controller (Example)
Once the storage batteries are full,
charging/discharging is stopped until the
daytime hours. *1, 4
If there is an insufficient amount of sunlight and
the storage batteries are low,
charging/discharging is stopped. *2, 4
ECONOMY
Mode
Remote Controller (Example)
The storage batteries are charged until full
regardless of the time of day or the amount of
sunlight. *8
HOME BACKUP
Mode
(Initial mode)
Remote Controller (Example)
If the amount of sunlight increases, surplus solar
power is used to charge the storage batteries.
*4, 5, 6, 8
Remote Controller (Example)
The storage batteries are discharged to supplement
power shortages (when power is purchased from the
power company) during the daytime hours up until
the nighttime hours begin. *1, 2, 3, 4, 7
Remote Controller (Example)
If the storage batteries run low,
charging/discharging is stopped until the
nighttime hours. *1, 2, 4
Remote Controller (Example)
The storage batteries are discharged to
supplement power shortages (when power is
purchased from the power company). *2, 3, 4, 7
Remote Controller (Example)
Though the storage batteries are full,
charging/discharging is stopped as a safeguard
against power outages on the commercial power grid.
Remote Controller (Example)
If there is an insufficient amount of sunlight and
the storage batteries are low,
charging/discharging is stopped. *2, 4
Remote Controller (Example)
The PV system starts generating power when the amount of sunlight increases. The PV system stops generating power when the amount of sunlight decreases.
2:00 AM2:00 AM 11:00 PM11:00 PM5:00 PM5:00 PM7:00 AM7:00 AM
Night Morning Evening Night

Grid-tied Operation
14 15
English
English
■Daily Operation
*1. Daytime and nighttime hours must be set when installing the inverter.
*2. The emergency backup charge is not discharged.
*3. Battery discharging stops when the amount of sunlight increases and power is sold to the power company.
*4. The storage batteries are charged whenever the emergency backup charge is low.
*5. The storage batteries do not charge further once full.
*6. Surplus solar power that cannot be stored in the power batteries is sold.
*7. Even while the storage batteries are discharging power, 0.2 kW or more power is purchased from the power company.
*8. Even while solar power is used to charge the storage batteries, power is sold and purchased according to power consumption in the home.
The storage batteries are fully charged during
the nighttime hours. *1, 4
Time of Day
Solar Power
MAX POWER
EXPORT Mode
Remote Controller (Example) Remote Controller (Example)
Once the storage batteries are full,
charging/discharging is stopped until the
daytime hours. *1, 4
If there is an insufficient amount of sunlight and
the storage batteries are low,
charging/discharging is stopped. *2, 4
ECONOMY
Mode
Remote Controller (Example)
The storage batteries are charged until full
regardless of the time of day or the amount of
sunlight. *8
HOME BACKUP
Mode
(Initial mode)
Remote Controller (Example)
If the amount of sunlight increases, surplus solar
power is used to charge the storage batteries.
*4, 5, 6, 8
Remote Controller (Example)
The storage batteries are discharged to supplement
power shortages (when power is purchased from the
power company) during the daytime hours up until
the nighttime hours begin. *1, 2, 3, 4, 7
Remote Controller (Example)
If the storage batteries run low,
charging/discharging is stopped until the
nighttime hours. *1, 2, 4
Remote Controller (Example)
The storage batteries are discharged to
supplement power shortages (when power is
purchased from the power company). *2, 3, 4, 7
Remote Controller (Example)
Though the storage batteries are full,
charging/discharging is stopped as a safeguard
against power outages on the commercial power grid.
Remote Controller (Example)
If there is an insufficient amount of sunlight and
the storage batteries are low,
charging/discharging is stopped. *2, 4
Remote Controller (Example)
The PV system starts generating power when the amount of sunlight increases. The PV system stops generating power when the amount of sunlight decreases.
2:00 AM2:00 AM 11:00 PM11:00 PM5:00 PM5:00 PM7:00 AM7:00 AM
Night Morning Evening Night

16 17
English
English
Grid-tied Operation
■Controlled Output ■If an Outage Occurs on the Commercial Power Grid
If “VOLTAGE REGULATION” appears on the Display
Excessively high voltage from the commercial
power grid can harm electric appliances. If
“VOLTAGE REGULATION” appears on the Remote
Controller, the inverter is temporarily regulating
output to prevent voltage from rising.
This message disappears once the voltage returns
to normal.
• Both “TEMPERATURE SUPPRESSION” and “VOLTAGE
REGULATION” may be displayed at the same time. In that case, the
display reads “TEMPERATURE.VOLTAGE SUPPRESSION”.
• If “TEMPERATURE SUPPRESSION,” “VOLTAGE REGULATION” OR
“TEMPERATURE.VOLTAGE SUPPRESSION” often appear on the
display or remain on the display for long periods of time, contact the
service center.
If a large number of households use their electricity at the same time, the power supply voltage may drop to a
level set by the power company. Inversely, voltage can rise when electricity consumption decreases.
If the voltage on the commercial power grid exceeds the level set by the power company, the inverter
regulates the amount of generated power in order counter the voltage rise on the grid, and displays
“VOLTAGE REGULATION.”
Once voltage on the commercial power grid returns to normal, the “VOLTAGE REGULATION” message
disappears and the inverter resumes normal operation.
If “VOLTAGE REGULATION” often appears on the display, contact the service center.
If “TEMPERATURE SUPPRESSION” appears on the Display
If “TEMPERATURE.VOLTAGE SUPPRESSION” appears on the Display
Excessively high temperatures inside the inverter
can harm the equipment. If “TEMPERATURE
SUPPRESSION” appears on the Remote Controller,
the inverter is temporarily regulating output
regardless of the surrounding temperature, to
prevent temperature from rising.
This message disappears once the temperature
returns to normal.
About Voltage Regulation
If the inverter does not run for a long period of time whether because grid-tied operation or stand-alone
operation was manually stopped, an outage has occurred on the commercial power grid, or due to an issue
with the equipment, the equipment, the storage batteries are not charged. If left in this condition, the switch
inside the storage battery unit automatically shuts off to prevent over-discharging. Once this switch shuts off,
servicing is required before the inverter can be used again.
If operation cannot be restored after trouble occurs, contact the service center.
If the Inverter Is Shutdown for Long Periods of Time
If an outage occurs on the commercial power grid, an error
message and error code are displayed on the Remote Controller.
In an outage on the commercial power grid, the inverter
temporarily stops operating. However, after about 10 seconds, it
engages stand-alone operation and starts supplying power again.
A few minutes after power from the commercial power grid is
restored, the inverter automatically restarts grid-tied operation.
(You do not need to press the [RUN/STOP] button.)
■Equipment Troubleshooting
If there is an equipment failure and an error message and error
code displayed are on the Remote Controller, resolve the issue as
explained in “Troubleshooting” (Page 48).
Error Message
Press the [BACK] button to
return to the home screen.
Error Code
CENTER.
GRID ABNORMALITY DETECTED.
WILL RESTART IN 5 MIN. ONCE GRID IS
BACK TO NORMAL. PLEASE CONTACT THE
SERVICE CENTER IF THE ERROR MESSAGE
CONTINUES MORE THAN 5 MIN.

16 17
English
English
Grid-tied Operation
■Controlled Output ■If an Outage Occurs on the Commercial Power Grid
If “VOLTAGE REGULATION” appears on the Display
Excessively high voltage from the commercial
power grid can harm electric appliances. If
“VOLTAGE REGULATION” appears on the Remote
Controller, the inverter is temporarily regulating
output to prevent voltage from rising.
This message disappears once the voltage returns
to normal.
• Both “TEMPERATURE SUPPRESSION” and “VOLTAGE
REGULATION” may be displayed at the same time. In that case, the
display reads “TEMPERATURE.VOLTAGE SUPPRESSION”.
• If “TEMPERATURE SUPPRESSION,” “VOLTAGE REGULATION” OR
“TEMPERATURE.VOLTAGE SUPPRESSION” often appear on the
display or remain on the display for long periods of time, contact the
service center.
If a large number of households use their electricity at the same time, the power supply voltage may drop to a
level set by the power company. Inversely, voltage can rise when electricity consumption decreases.
If the voltage on the commercial power grid exceeds the level set by the power company, the inverter
regulates the amount of generated power in order counter the voltage rise on the grid, and displays
“VOLTAGE REGULATION.”
Once voltage on the commercial power grid returns to normal, the “VOLTAGE REGULATION” message
disappears and the inverter resumes normal operation.
If “VOLTAGE REGULATION” often appears on the display, contact the service center.
If “TEMPERATURE SUPPRESSION” appears on the Display
If “TEMPERATURE.VOLTAGE SUPPRESSION” appears on the Display
Excessively high temperatures inside the inverter
can harm the equipment. If “TEMPERATURE
SUPPRESSION” appears on the Remote Controller,
the inverter is temporarily regulating output
regardless of the surrounding temperature, to
prevent temperature from rising.
This message disappears once the temperature
returns to normal.
About Voltage Regulation
If the inverter does not run for a long period of time whether because grid-tied operation or stand-alone
operation was manually stopped, an outage has occurred on the commercial power grid, or due to an issue
with the equipment, the equipment, the storage batteries are not charged. If left in this condition, the switch
inside the storage battery unit automatically shuts off to prevent over-discharging. Once this switch shuts off,
servicing is required before the inverter can be used again.
If operation cannot be restored after trouble occurs, contact the service center.
If the Inverter Is Shutdown for Long Periods of Time
If an outage occurs on the commercial power grid, an error
message and error code are displayed on the Remote Controller.
In an outage on the commercial power grid, the inverter
temporarily stops operating. However, after about 10 seconds, it
engages stand-alone operation and starts supplying power again.
A few minutes after power from the commercial power grid is
restored, the inverter automatically restarts grid-tied operation.
(You do not need to press the [RUN/STOP] button.)
■Equipment Troubleshooting
If there is an equipment failure and an error message and error
code displayed are on the Remote Controller, resolve the issue as
explained in “Troubleshooting” (Page 48).
Error Message
Press the [BACK] button to
return to the home screen.
Error Code
CENTER.
GRID ABNORMALITY DETECTED.
WILL RESTART IN 5 MIN. ONCE GRID IS
BACK TO NORMAL. PLEASE CONTACT THE
SERVICE CENTER IF THE ERROR MESSAGE
CONTINUES MORE THAN 5 MIN.

18 19
English
English
Stand-alone Operation
(In a Power Outage)
Stand-alone Operation Precautions
During stand-alone operation, power is supplied only to the stand-alone outlets. During a power outage, other outlets cannot be used.
• Use the stand-alone outlets.
Power output from the PV system and storage batteries can be unstable due to weather conditions and charge. If output
drops, stand-alone operation stops automatically.
• Electric appliances running off stand-alone operation may shut off.
The backup power provided by the inverter is envisioned to supply electricity to run refrigerators, TVs, lighting fixtures, laptop
computers and cellphones. Many lighting fixtures and refrigerators have protective circuits that trip and prevent the product from
running in case there is a surge in current when the power is turned on. Do not connect air conditioners, washing machines, and
other appliances to stand-alone outlets that may draw a large current when turned on.
• When power is supplied to electric appliances connected to the stand-alone outlets, inrush current may trip
protective devices and prevent the appliances from running.
• If stand-alone operation automatically stops due to high power consumption, the electric appliances that were
running stop temporarily. Although stand-alone operation resumes automatically when power consumption decreases,
connected appliances that have protective circuits are prevented from resuming operation.
The maximum amount of current that can be drawn during stand-alone operation is 16.6 A. Only connect electric appliances
that consume less than 16.6 A. Though this will vary by appliance, a maximum of 16.6 A at 120V AC equates to somewhere
between 1.5 - 2.0 kVA. Moreover, 0.1 - 0.3 kW are needed to keep the inverter running.
If the electric appliances connected to the stand-alone outlets consume more power than is generated by the PV system and
supplied by the storage batteries, stand-alone operation shuts down.
Many lighting fixtures and motor-driven appliances (e.g., vacuum cleaners. refrigerators, dryers, etc.) draw a large current when
turned on, and consequently will not run. Using these appliances may also trip protective circuits and keep them from running.
• There is a limit to the amount of power that can be drawn at one time.
• Stand-alone operation is automatically engaged if a power outage occurs.
Circuitry has been designed to enable lighting fixtures, communication equipment and other electric appliances
to be used in the event of a power outage without having to unplug and plug them back in again.
During the morning and daytime hours, the solar panels and storage batteries cooperatively supply the electric power
necessary for household consumption. Surplus power is used to charge the storage batteries. During the evening and
nighttime hours, power is supplied by the storage batteries.
■Recharging the Storage Batteries using the Solar Panels
■Electric Appliances Connected to Stand-alone Outlets during
an Outage Can Be Used without Plugging Them Back in.
Electric power generated by the solar panels can be efficiently stored in the storage batteries. This is useful during
extended power outages that last several days.
* Battery charge will vary according to the amount of power generated by
the PV system and the amount of household consumption.
Recharging Pattern (Example)
●
100% 45% 100% 10% 100%
Clear Cloudy Clear Rain Clear
1st Day
Battery Charge
Weather
Length of Outage 2nd Day 3rd Day 4th Day 5th Day
PROHIBITED
MANDATORY
The amount of electric power generated during stand-alone operation
varies according to weather and storage battery charge. The inverter
stops stand-alone operation if it generates less electric power than that
consumed by the electric appliances connected to its stand-alone
outlets. Do not use the appliances listed below with the inverter, as
personal injury or property damage may occur if the power shuts off.
• Any kind of medical or home security equipment.
• Desktop computers and other information-related equipment and
peripherals.
• Rice cookers, microwave ovens, and other cooking equipment.
• Heaters that use kerosene or gas.
• Other equipment that may cause personal injury or property damage
if the power shuts off.
•Confirm the backup panel, related wiring, and electrical fixtures
are in good safe condition before commencing stand-alone
operation.
•If strange odors or noises are detected after starting
stand-alone operation, promptly stop stand-alone operation.
Do not connect the electric appliances listed below to the stand-alone outlets.
WARNING
CAUTION
The desktop PC must be connected to the UPS as power will be temporarily disrupted when switching to
stand-alone operation.
NOTE

18 19
English
English
Stand-alone Operation
(In a Power Outage)
Stand-alone Operation Precautions
During stand-alone operation, power is supplied only to the stand-alone outlets. During a power outage, other outlets cannot be used.
• Use the stand-alone outlets.
Power output from the PV system and storage batteries can be unstable due to weather conditions and charge. If output
drops, stand-alone operation stops automatically.
• Electric appliances running off stand-alone operation may shut off.
The backup power provided by the inverter is envisioned to supply electricity to run refrigerators, TVs, lighting fixtures, laptop
computers and cellphones. Many lighting fixtures and refrigerators have protective circuits that trip and prevent the product from
running in case there is a surge in current when the power is turned on. Do not connect air conditioners, washing machines, and
other appliances to stand-alone outlets that may draw a large current when turned on.
• When power is supplied to electric appliances connected to the stand-alone outlets, inrush current may trip
protective devices and prevent the appliances from running.
• If stand-alone operation automatically stops due to high power consumption, the electric appliances that were
running stop temporarily. Although stand-alone operation resumes automatically when power consumption decreases,
connected appliances that have protective circuits are prevented from resuming operation.
The maximum amount of current that can be drawn during stand-alone operation is 16.6 A. Only connect electric appliances
that consume less than 16.6 A. Though this will vary by appliance, a maximum of 16.6 A at 120V AC equates to somewhere
between 1.5 - 2.0 kVA. Moreover, 0.1 - 0.3 kW are needed to keep the inverter running.
If the electric appliances connected to the stand-alone outlets consume more power than is generated by the PV system and
supplied by the storage batteries, stand-alone operation shuts down.
Many lighting fixtures and motor-driven appliances (e.g., vacuum cleaners. refrigerators, dryers, etc.) draw a large current when
turned on, and consequently will not run. Using these appliances may also trip protective circuits and keep them from running.
• There is a limit to the amount of power that can be drawn at one time.
• Stand-alone operation is automatically engaged if a power outage occurs.
Circuitry has been designed to enable lighting fixtures, communication equipment and other electric appliances
to be used in the event of a power outage without having to unplug and plug them back in again.
During the morning and daytime hours, the solar panels and storage batteries cooperatively supply the electric power
necessary for household consumption. Surplus power is used to charge the storage batteries. During the evening and
nighttime hours, power is supplied by the storage batteries.
■Recharging the Storage Batteries using the Solar Panels
■Electric Appliances Connected to Stand-alone Outlets during
an Outage Can Be Used without Plugging Them Back in.
Electric power generated by the solar panels can be efficiently stored in the storage batteries. This is useful during
extended power outages that last several days.
* Battery charge will vary according to the amount of power generated by
the PV system and the amount of household consumption.
Recharging Pattern (Example)
●
100% 45% 100% 10% 100%
Clear Cloudy Clear Rain Clear
1st Day
Battery Charge
Weather
Length of Outage 2nd Day 3rd Day 4th Day 5th Day
PROHIBITED
MANDATORY
The amount of electric power generated during stand-alone operation
varies according to weather and storage battery charge. The inverter
stops stand-alone operation if it generates less electric power than that
consumed by the electric appliances connected to its stand-alone
outlets. Do not use the appliances listed below with the inverter, as
personal injury or property damage may occur if the power shuts off.
• Any kind of medical or home security equipment.
• Desktop computers and other information-related equipment and
peripherals.
• Rice cookers, microwave ovens, and other cooking equipment.
• Heaters that use kerosene or gas.
• Other equipment that may cause personal injury or property damage
if the power shuts off.
•Confirm the backup panel, related wiring, and electrical fixtures
are in good safe condition before commencing stand-alone
operation.
•If strange odors or noises are detected after starting
stand-alone operation, promptly stop stand-alone operation.
Do not connect the electric appliances listed below to the stand-alone outlets.
WARNING
CAUTION
The desktop PC must be connected to the UPS as power will be temporarily disrupted when switching to
stand-alone operation.
NOTE

20 21
English
English
■Stand-alone Operation Startup (Power Outage)
After a power outage occurs, an error message appears on the screen and the inverter
automatically switches from grid-tied operation to stand-alone operation. If power is restored on the commercial power grid during stand-alone operation, the inverter automatically reengages grid-tied operation.
1
2
■Restoration of Grid-tied Operation
3
After a power outage has been detected,
error code “gxxx” appears on the Remote
Controller.
After about 10 seconds, the Remote
Controller automatically changes the
operating status message to
“STAND-ALONE MODE”.
The status lamp will light up red. Then
the electrical appliance which are
connected to the back-up breaker box
can be powered.
After a power outage has been detected,
the Remote Controller automatically
changes the operating status message to
“STAND-ALONE→”.
1
2
Once input from the commercial power
grid is detected, “GRID CONNECT→”
appears on the Remote Controller for a few
minutes.
Grid-tied operation resumes a few minutes
afterwards.
The status lamp lights up green.
Stand-alone Operation
(In a Power Outage)
GRID ABNORMALITY DETECTED.
WILL RESTART IN 5 MIN. ONCE GRID IS
BACK TO NORMAL. PLEASE CONTACT THE
SERVICE CENTER IF THE ERROR MESSAGE
CONTINUES MORE THAN 5 MIN.
