Taco D’MAND Assembly instructions

INSTRUCTIONS
1. Unplug the D’Mand System power cord.
2. Connect Black, Green and Red leads from Motion Sensor to corre-
sponding Black, Green and White leads from Black 3-wire cord on
D’Mand System Pump (see wiring diagram). Use wire nuts provided
in kit. Use wire nuts or electrical tape to isolate Red and Black wire
leads in Gray Cord if round starter button is not installed.
D’MAND®SYSTEM
Motion Sensor
Installation and Wiring Instructions
102-205
PUMP
POWER
CORD
GRAY
2-WIRE
CORD
RED
BLACK
BLACK 3-WIRE
CORD
BLACK BLACK
GREEN
WHITE
GREEN
RED
MOTION SENSOR
ROUND
STARTER
BUTTON
Plant ID No. 001-3886 Supersedes: December 1, 2008 Effective: January 1, 2011
A Taco resource – saving product

3. Remove electrical box cover and carefully remove electronics con-
trol board from terminal strip.
4. Turn control board over and locate voltage dip switches in top left
corner of board. (See diagram below.)
5. Slide dip switch connector from pin marked “5v” to pin marked
“12v”. (See diagram below.)
6. Insert control board firmly into terminal strip and replace electrical
box cover.
7. Place Motion Sensor at a convenient location to detect motion in
the room but out of view from adjoining rooms or hallways.
8. Plug in the D’Mand System power cord. Pump will start automatically,
run until hot water is detected by the temperature sensor, and then
stop.
9. A 4 minute time delay will start after each cycle to prevent repeated
activation. After 4 minutes, D’Mand System will revert to automatic
motion detection mode.
D'MAND SYSTEM CONTROL BOARD
5v 12v
VOLTAGE
DIP SWITCHES
(Set on 12v for
Motion Sensor activation)
ΔT ADJUSTMENT
(Set on 12 o’clock
position for 5˚ ΔT)
Do it Once. Do it Right.®
