Tactic FPV-T1 Operating and maintenance instructions

FPV-T1
TM
5.8GHZ 25mW TRANSMITTER
Tactic’s FPV-T1 first person video
transmitter (Tx) is intended for sending
video signals from a camera (available
separately) mounted inside an R/C hobby
model to a 5.8GHz receiver (Rx) on the ground. Three bands with a total of 22 frequencies in the 5.8GHz spectrum can be user
selected. For optimum use, operate the system away from other 5.8GHz transmitters, in areas having as few obstructions
possible between the Tx and Rx. For best signal, use a clean and stable DC power source (battery, voltage regulator, etc.).
Allow for maximum space from other electronic components such as ESCs and cables, R/C receivers, high power servos,
telemetry radios, etc.
Carefully thread the included antenna onto the RP-SMA receptacle on the Tx, being careful not to cross-thread. Turn the mounting
screw until snug – do NOT overtighten. Do NOT apply power to the transmitter if the antenna is disconnected as it could cause
the Tx to overheat!
The included Y-wire harness connects the Tx to a camera and battery
(both available separately). Attach the adapter’s white connector to the Tx.
Connection polarities are as follows:
CAMERA CONNECTION: Attach the white/yellow/black wire
to the camera’s A/V signal output. Make sure the polarities
on the camera’s input matches those of the adapter. Use
the included gray/yellow/black cable extension with USB
Mini-B plug if necessary.
BATTERY CONNECTION: Attach the red/black wire to the
battery. Use the included cable extension with red connector
if necessary. IMPORTANT: Make sure polarities match! Do
NOT exceed the acceptable input voltage range of 7.4 – 22.2
volts, which can be achieved with a 2S-6S lithium-polymer
(LiPo) battery.
Refer to the charts below to determine the frequency to transmit the video signal. The frequency number is shown at the
bottom of each switch diagram:
ON
CH1 5.865G
12345
ON
CH2 5.845G
12345
ON
CH3 5.825G
12345
ON
CH4 5.805G
12345
ON
CH5 5.785G
12345
ON
CH6 5.765G
12345
ON
CH7 5.745G
12345
ON
CH8 5.745G
12345
BAND A
ON
CH1 5.733G
12345
ON
CH2 5.752G
12345
ON
CH3 5.771G
12345
ON
CH4 5.790G
12345
ON
CH5 5.809G
12345
ON
CH6 5.828G
12345
ON
CH7 5.847G
12345
ON
CH8 5.866G
12345
BAND B
ON
CH1 5.740G
12345
ON
CH2 5.760G
12345
ON
CH3 5.780G
12345
ON
CH4 5.800G
12345
ON
CH5 5.820G
12345
ON
CH6 5.840G
12345
ON
CH7 5.860G
12345
ON
CH8 5.860G
12345
BAND F
BAND SELECTION: Switches 4 and 5 are used to set either band A, B, or F. Place both switches UP for band A, switch 4 down
and switch 5 up for band B, and both switches DOWN for band F.
CHANNEL SELECTION: Switches 1, 2, and 3 are used to set the frequency. Set each respective switch to the location which
matches that shown in the chart for band A, B, or F, depending on your desired frequency.
ANTENNA INSTALLATION
CONNECT TO CAMERA AND INPUT POWER
To Camera
To Battery
Red
Black
Yellow
White
Black
SELECT THE CHANNEL/FREQUENCY
Yellow = Video
White = Audio
Black = Ground
Red = 7.4-22.2V
Black = Ground

Determine the best location to mount this Tx on the model, using double-sided tape, hook-and-loop material, etc. For optimum
results, mount the Tx to allow for the least amount of obstructions as possible between the antenna and open air.
WARNING! Keep all components clear of moving parts in/on the model!
This device complies with part 15.249 of the FCC rules. Changes or modications not expressly approved by Tactic will
void the user’s authority to operate this Tx. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body.
Instructions for Disposal of Waste Equipment by Private Users in the European Union:
This symbol on the product or its packaging indicates this product must not be disposed of with other household waste.
Instead, it is the user’s responsibility to dispose of their waste equipment by handing it over to a designated collection
point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste
equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner
that protects human health and the environment. For more information about where you can drop off your waste equipment for
recycling, please contact your local city ofce, your household waste disposal service or location where you purchased the product.
Declaration of Conformity:
Product: Tactic FPV-T1 5.8GHz 25mW Transmitter
Item number: TACZ5000
Tactic warrants this product to be free from defects in materials and workmanship for a period of one (1) year from the date
of purchase.
For service on your Tactic product if purchased in the U.S.A.
or Canada, send it postpaid and insured to:
HOBBY SERVICES
3002 N. Apollo Dr., Suite 1
Champaign, IL 61822
Tel: [phone] (9:00am - 5:00pm CST, M-F)
E-mail: [email protected]
If purchased in the European Union, send it postpaid and
insured to:
Service Abteilung Revell GmbH
Henschelstrasse 20-30
32257 Bünde Germany
Tel: [phone] (nur für Deutschland)
Email: [email protected]
•This product is suitable only for people of 14 years and older. This is not a toy!
•WARNING: CHOKING HAZARD - May contain small parts. Keep away from children under 3
years. Please retain packaging for future reference.
•No part of this manual may be reproduced in any form without prior permission.
•The contents of this manual are subject to change without prior notice.
•Tactic is not responsible for the use of this product.
MOUNTING THE TX
FCC STATEMENT
CE COMPLIANCE INFORMATION FOR THE EUROPEAN UNION
SPECIFICATIONS
Range: * 300 meters
FCC ID: IYFFPVT1
Dimensions w/case: 37x24x11mm (1.5x1.0x0.4") w/o antenna connection
Weight w/o antenna: 11.2g (0.40 oz.) with case, 6.6g (0.24 oz.) w/o case
* maximum range in open areas free of signal obstructions
Input power: 7.4-22.2V (2-6S LiPo)
Channels: 22
Frequencies: 5.733 – 5.866GHz
Output power: 25mW
Antenna gain: 3 dBi
1-YEAR LIMITED WARRANTY
© 2015 Hobbico, Inc
All rights reserved
TACZ5000Mnl
Made in China
