Taga Harmony Pro Audio PSL User manual

PSL
Point Source Loudspeakers
Instruction Manual
Edition 12-2018

2
Introduction
Congratulations for purchasing TAGA Harmony Pro Audio loudspeakers!
The PSL series of loudspeakers is designed for use in a variety of applications
including installations in conference rooms, restaurants, cafes, clubs, bars, shops,
gymnasiums, education facilities or other commercial venues.
The PSL series is an e󰀩cient, cost-e󰀨ective solution to bring high quality sound and
easy installation for indoor sound systems.
Cabinet Care
This loudspeaker is intended for indoor use.
Use a soft, dry cloth to remove dust or dirt. Do not use paper towels or other abrasive
materials as it may damage the nish.
Important remarks
Please read this instruction manual carefully before installation and keep it for future
reference.
• Please do not dismantle any parts of the loudspeaker as this may void your warranty
– servicing should be performed only by a qualied TAGA Harmony repair center
• When connecting the loudspeaker make sure to power o󰀨 your audio equipment
(amplier, power mixer, sound processor etc.).
• Make sure that all connections are done according to this manual and a manual
provided with your audio equipment.
• Make sure that your audio equipment output power and working impedance are
compatible with this loudspeaker. Using unsuitable audio equipment may damage the
loudspeaker and/or audio equipment and void your warranty.
• The loudspeaker may be damaged by too high output power as well as by an
underpowered output signal [distortions of sound].
• Do not use very high volume levels for a long period of time – this may damage the
loudspeaker and void your warranty.
• When switching on and o󰀨 your audio equipment, turn down the volume to avoid
strong electrical impact to be delivered to the loudspeaker.
• Position the loudspeaker in ventilated and dry atmosphere and do not expose it to
sun or other heat sources.
• Install the loudspeaker on a stable and hard surface. We recommend to have a
licensed professional engineer or designer reviewed the design and installation of the
system focusing on safety and performance of the application. Check “Placement and
Installation” for more details.
• As safety precautions to avoid tip-over / fall of the loudspeaker we recommend
to anchor it to the wall or other permanent construction. Check “Placement and
Installation” for more details.
• To protect the drivers do not remove the protective grille.
Specications
Full technical specications are available on the www.TagaHarmony.com website.

3
Contents
Introduction 2
Unpacking the loudspeaker 4
Placement and installation 4
Hooking up the wires 6

4
Unpacking the loudspeaker
If you notice any damages in transportation, report it immediately to your dealer/
installer.
Placement and installation
We recommend that your sound system is designed and installed by a licensed
professional engineer or designer (installer).
When designing and installing the sound system make sure to review safety and
performance aspects of the installation which are applicable in the place of installation.
The placement and installation method for the loudspeaker varies on the intended
application.
MOUNTING SYSTEM
Contact TAGA Harmony or our dealer for recommendations regarding the mounting
system.
Make sure to obtain a mounting system from a reputable manufacturer. Select a
system design applicable for this loudspeaker and its intended use.
• This loudspeaker is ready for the following installation options:
Flying and suspend systems: the loudspeaker is equipped with M8 threaded-insert
hang points on the top, bottom, rear and two side walls of the cabinet. The threaded-
insert hang points are protected with screws – remove them in order to use the hang
points. For detailed number of hang points and their placement check your model
specications.
• Loudspeaker stands (tripod): the loudspeaker is equipped with a single Ø36 mm
speaker stand socket on the bottom of the cabinet.
Note!
• Install the loudspeaker on a stable and hard surface.
• The loudspeaker should not be hung using the handles as hang points.
• Use only high grade installation hardware.
• Do not attempt to alter the threaded hang points which are located in the cabinet.
• Make sure to anchor the loudspeaker as provided below in this chapter.
• Flying or suspend systems, loudspeaker stands nor installation hardware are not
provided with this loudspeaker. They should be purchased separately.
ANCHORING THE LOUDSPEAKER
As safety precautions to avoid tip-over / fall of the loudspeaker we recommend to
anchor it to the wall or other permanent construction.
We recommend to use a safety cable and to rmly attach one end to the loudspeaker
cabinet at a point other that the mounting system and the other end to the wall or
other permanent construction. This is recommended even if it is not required by local
construction and safety regulations.
Note! An anchoring system nor a safety cable is not provided with this loudspeaker. It
should be purchased separately.

5
Placement and installation
REMOVABLE LOGO BADGE
The loudspeaker is equipped with the magnetic logo badge which is mounted in the
recess on the front grill.
Depending on the placement (for instance horizontal or vertical orientation) and
intended application the logo badge can be mounted in di󰀨erent positions in the recess.
To remove the badge pull it gently forward. To install the badge back gently attach it to
the recess in the new position.
Note! Make sure not to scratch the loudspeaker during removing / installing the badge.
choose
your way
You can choose logo
badge orientation by:
0°, 90°, 180° or 270°.

6
Hooking up the wires
Note! Make sure to power o󰀨 your audio equipment before connecting this
loudspeaker. Consult your local TAGA Harmony dealer/installer for further information
about cables and connection options.
We recommend that your sound system is designed and installed by a licensed
professional engineer or designer (installer).
When designing and installing the sound system make sure to review safety and
performance aspects of the installation which are applicable in the installation venue.
Speaker sockets (connected in parallel)
This loudspeaker is equipped with two (2) 4-pole speaker sockets located on the rear
speaker panel which allow to connect 4-pole female speaker twist connectors.
The sockets are connected in parallel. You can use either of them for signal input from
your audio equipment.
The second speaker socket may be used to “loop through” to other loudspeaker in the
installation (for instance to power more loudspeakers from a single amplier).
Note! Never connect two (2) speaker sockets simultaneously to a single amplier
output or connect two ampliers to a single loudspeaker – this loudspeaker is not
designed for bi-amp. Use only one (1) speaker socket for the input signal – otherwise
you may damage the loudspeaker and/or audio equipment and void your warranty.
Check the below wiring diagram for the connector (single channel):
Note! The connector and speaker wires are not supplied with this loudspeaker. They
should be purchased separately.
Most connectors can accommodate up to 10 AWG bare speaker cables. It is
recommended to leave about 150 cm (5 feet) of extra cable at the speaker end to
facilitate positioning and installation of the speaker. Do not use staples, nails or other
metal objects to secure the speaker cables.

7
Hooking up the wires
Note! Make sure to avoid short-circuit of the speaker wires – this may damage the
loudspeaker and/or your audio equipment and void your warranty.
Check the below diagram for connecting two (2) loudspeakers to a single amplifer:
Note! When using more than one (1) loudspeaker connected in parallel make sure to
check whether your amplier can handle the nal system impedance – otherwise you
may damage the loudspeaker and/or audio equipment and void your warranty.

www.TagaHarmony.com
We strongly advise that your sound system is designed and installed by a licen-
sed professional engineer or designer (installer).
We recommend using high quality TAGA Harmony cables and other installation
accessories.
IMPORTANT!
Your product is marked with the symbol as showed on the left.
For EU (European Union) member users:
According to the WEEE (Waste electrical and electronic equipment)
Directive, do not dispose of this product as household waste or commercial waste.
Waste electrical and electronic equipement should be appropriately collected and
recycled as required by practices established for your country.
For information on recycling of this product, please contact your local authorities, your
household waste disposal service or the shop where you purchased the product.
Your product is marked with the symbol as showed on the left.
For EU (European Union) member users:
This product has been tested and found in compliance with
requirements of the European Community
2014/108/EC directive.
