TaiDoc TD-1261 Technical manual

311-1261000-060
機器說明書/CLEVER/英
L353*W250mm/3折/銅版紙100P/雙黑
Tsaiyi
K100 K75
Part no.
Product name
Spec
Color
Designer

311-1261000-060
Version 3.0 2015/10
IMPORTANT SAFETY INSTRUCTIONS
READ THIS BEFORE USING AND KEEP THESE INSTRUCTIONS
Thank you for choosing TD-1261 ear thermometer.This innovative medical device relies on advanced
infrared (IR) technology to measure temperature instantly.
TD-1261 ear thermometer is intended for the intermittent measurement and monitoring of human
body temperature from ear canal.The device is intended for use by people of all ages for home and
professional use.
The accuracy cannot be ensured for a person who has deformity in the ear such that the
thermometer probe cannot be properly inserted into the ear canal.
The accuracy cannot be ensured when blood or drainage is found in the ear canal.
If ear drops or medications have been placed in an ear, take measurements from the other ear.
For a person who wears ear plug or hearing aid, remove the device and wait for 15 minutes before
taking temperature.
CAUTIONS AND WARNINGS
As with any thermometer, proper technique is crucial to getting accurate temperature readings.
Please read this manual thoroughly and carefully before using.
temperature readings. Please read this manual thoroughly and carefully before using.
Always operate the thermometer in an operating temperature range 10°C to 40°C (50°F to 104°F),
and relative humidity less than 95%.
Always store the thermometer in a cool and dry place: temperatures between -20°C to 60°C (-4°F
to 140°F); relative humidity less than 95%. Avoid direct sunlight.
Avoid dropping the thermometer.
Use only TD-1261 probe covers for the infrared ear thermometer.
For proper hygiene, do not re-use probe cover. Damaged probe cover may result in error display.
Do not disassemble the thermometer.
Basic safety precautions should always be observed, especially when the thermometer is used on
or near children and disabled persons.
This thermometer is not intended to be a substitution for a consultation with your physician.
Keep probe covers out of reach of children.
Temperature measurements may differ from left to right ear. Always measure by using same ear.
RESTRICTIONS OF USE
USING THE DEVICE
The following basic safety precautions should always be taken.
Replacing Probe Cover
Step 1
Check the probe cover
is clean and new.
Measuring Temperature
Step 1
Press and release the
On / Memory
button to turn on the
thermometer.
When ready, the
thermometer displays
the last measurement.
Step 2
Attach new probe cover
onto the probe.
Now, you can start to test
your ear temperature.
Step 2
Gently fit the probe with
clean probe cover into the
ear canal.
Your thermometer stores 10 recent readings in the memory.
Step 5
Press ejection button
to discard used
probe cover into trash.
Never try to clean inside the ears. You may accidentally damage the eardrum or its
surrounding tissues. Remove excess earwax only when you can reach it with a clean
cloth. Consult a physician if you suspect the presence of excess earwax.
NOTE
1. Close supervision is necessary when the thermometer is used by, on, or near children, handicapped
persons or invalids.
2. Use the thermometer only for the intended use described in this manual.
3. Do not use the thermometer if it is not working properly, or if it has suffered any damage.
4. Do not use accessories which are not supplied or recommended by the manufacturer.
5. Proper maintenance is essential to the longevity of your device. If you are concerned about your
accuracy of measurement, please contact the local customer service or place of purchase for help.
This thermometer is clinically proven to produce accurate temperature measurements. However,
please be advised if you have the following situations:
APPEARANCE AND KEY FUNCTIONS OF THE THERMOMETER
INTRODUCTION
INTENDED USE
The thermometer measures the infrared heat generated by the eardrum and its surrounding tissue.
The thermometer then converts it into a temperature value shown on LCD.
HOW DOES IT WORK
Ear Thermometer Operation Instruction
TD-1261
If a probe cover is not attached on the probe, LCD will show “ ” until a new probe
cover is firmly attached to the probe.
The used probe cover should be removed after each measurement to ensure
accuracy reading.
To ensure proper hygiene, attach a new probe cover each time and do not touch its tip.
NOTE
Turn off the thermometer by pressing On / Memory button twice. It will automatically
turn off if left idle for 3 minutes.
If the reading is ≦31.9°C (89.5°F ), the display will show “Lo” together with red
backlight.
If the reading is ≧32°C (89.6°F) and < 37.9 °C (100.3°F), the display will show
together with green backlight.
If the reading is ≧38 °C (100.4°F) and < 43°C (109.4°F), the display will show together
with red backlight.
If the reading is ≧43.1°C (109.5°F), the display will show “Hi” together with red
backlight.
NOTE
Step 1
Be sure the
thermo-meter is OFF
before recalling this
memory.
Step 2
Press the On / Memory button to turn on the
thermometer.
RESULT INDICATORS
RECALLING THE MEMORY
HINTS ON TAKING EAR TEMPERATURES
Message What it means
Temperature measurement falls outside the displayed temperature range
(ear temperature range from 32°C to 43°C (89.6°F to 109.4°F), is shown on the
display with red LED.
Hi-temperature
≧ 43.1°C (109.5°F)
Lo-temperature ≦ 31.9°C (89.5°F
)
1. As with other thermometers, you may observe slight variations in consecutive measurements. It is
recommended that you take 3 temperature readings and use the highest one for the following
situations:
Infants younger than 3 months old.
Children younger than 3 years old and who have a compromised immune system and
the presence / absence of fever is critical.
When you are learning to use the thermometer.
2. Do not take a reading while the patient is moving and / or talking.Wait 30 minutes after any of the
following situations before taking a measurement:
When the ear has been covered.
After the patient has been exercising, swimming, or taking a bath.
When the patient has been exposed to extreme temperature.
3. To take accurate readings, the ear must be free from excess earwax build-up.
LCD SCREEN
1
Ear temperature indicator
Probe cover missing
Temperature scanning in progress
Temperature display
Memory mode
2
3
4
5
Record numbers
Low battery indicator
Temperature unit
Communication symbol
(for TD-1261F only)
6
7
8
9
1 9234
7 8
6
5
1
Probe cover
Probe cover ejection button
On/Memory button
Manufacturing label
Battery cover
Data port
Probe lens
Probe
Probe cover detector
Scan button
Bluetooth indicator (for TD-1261F only)
2
3
4
5
6
7
8
9
10
11
1
2
3
4
7
8
9
10
11
5
6
Step 3
Press and release the
Scan button.
You will hear a beep to
indicate measurement
is complete and
thermometer may be
removed.
Step 4
Read the result.
“ ” is shown together
with a temperature value.
The communication
symbol is for TD-1261F
only.

Transmitting Data via RS232 Cable (for TD-1261B)
TaiDoc Technology Corporation
B1-7F., No. 127, Wugong 2nd Rd., Wugu Dist.,
New Taipei City 248, Taiwan (R.O.C.)
www.taidoc.com
MedNet GmbH
Borkstraβe 10, 48163
Mϋnster, Germany
Fever indicates that the body temperature is higher than normal. This symptom may be caused by
infection, overdressing or immunization. Some people may not experience fever even when they are
ill. These include, but are not limited to, infants younger than 3 months old, persons with compro-
mised immune systems, persons taking antibiotics, steroids or antipyretics (aspirin, ibuprofen,
acetaminophen), or persons with certain chronic illnesses. Please consult your physician when you feel
ill even if you do not have a fever.
Body temperature can vary from one individual/person to next. It also varies by location on the body
and time of day. Below shows the statistical normal ranges from different sites. Please keep in mind
that temperatures measured from different sites, even at the same time, should not be directly
compared.
ABOUT NORMAL BODY TEMPERATURE & FEVER
SYMBOL INFORMATION
SPECIFICATIONS
Model no.: TD-1261
Dimension & Weight: 160.5mm x 45.9mm x 32.5mm, 100g (include 2 x1.5V AAA batteries)
Battery: 2 x 1.5 V AA alkaline batteries
External output: RS232 interface cable (For TD-1261B)/ Bluetooth (For TD-1261F)
Displayed temperature range: 32°C to 43°C (89.6°F to 109.4°F)
Display resolution: 0.1°C /0.1°F
Accuracy: Meet the accuracy requirement specified in ASTM E1965-98
±0.2°C (±0.4°F) for the range of 36.0°C to 39.0°C (96.8°F to 102.2°F)
±0.3°C (±0.5°F) from 34.0°C to 35.9°C (93.2°F to 96.6°F) and from 39.1°C to 42.2°C (102.4°F to 108.0°F)
Temperature unit: Fixed °C or °F
Operating temperature range: 10°C to 40°C (50°F to 104°F)
Operating humidity: 95% RH or less
Storage temperature range: -20°C to 60°C (-4°F to 140°F)
Storage humidity: 95% RH or less
Memory capacity: 10 measurements
Expected service life: 3 years
REFERENCE STANDARDS
Device Standard:
Device Corresponds to the requirements of the standard for infrared thermometers
ASTM E1965-98
EN ISO 80601-2-56:2012
EN 60601-1-2:2007/AC:2010
EN 60601-1:2006+A12:2014
EN 60601-1-6:2010
The specifications may be changed without prior notice.
Electromagnetic Compatibility:
Device fulfills the stipulations of the standard EN 60601-1-2
The stipulations of EU-Directive 93/42/EEC for Medical Devices Class Ila have been fulfilled.
Message What it means What to do
Appear when environmental
temperature is below or
above system operation
range.
Probe cover is missing. Please replace probe cover onto
probe.
Problem with the
thermometer.
Review the instructions and
re-start the measurement
procedure. If the steps do not work,
contact dealer.
Please replace new batteries.
Appears when the batteries
can’t provide enough power
for a test.
Please replace new batteries as soon
as possible.
Put the thermometer under operating
temperature range of
10°C to 40°C (50°F to 104°F)
TROUBLESHOOTING
The table below shows problems you may encounter. All error messages below would be shown
together with red backlight. Please follow "what to do" to resolve problems. If the problem still exists,
please call your local dealer for help.
Battery is low and “ ”appears
on LCD.
Table *1 Body Site Normal Temperature Range
*1. Chamberlain, J. M. Terndrup, T. E., New Light
on Thermometer Readings,Contemporary
Pediatrics, March 1994.
Body Site Normal Temperature Range
Oral 35.5°C - 37.5°C (95.9°F - 99.5°F)
34.7°C - 37.3°C (94.5°F - 99.1°F)
36.6°C - 38.0°C (97.9°F - 100.4°F )
35.8°C - 38.0°C (96.4°F - 100.4°F )
Rectal
Ear
Axillary
(underarm)
CARE & CLEANING
The probe is not waterproof. Please wipe with a clean and dry cotton swab
to clean the probe on the inside.
Do not attach new probe cover for 30 minutes.The cleaning process
cools the probe and can affect accuracy.
The body of the thermometer is not water-resistant. Never put the
thermometer under a running tap or submerge it into water. Use a soft and
dry cloth to clean it. Do not use abrasive cleaners.
Store the thermometer in a cool and dry location. Free from dust and away
from direct sunlight.
TD-1261 has 2 types of transmission methods; your meter uses either RS232 interface cable or
Bluetooth to transmit the data, please check your meter box for the transmission method of your
meter.
You can transmit your temperature data from the meter to your device via Bluetooth. Please contact
your local customer service or place of purchase for assistance. Please note that you must complete
the pairing between meter and Bluetooth receiver before transmitting data.
1. Install Software
Install Health Care System Software on your computer by following the instructions
provides on TaiDoc's website.
2. Connect to Personal Computer
Connect the RS232 interface cable to a serial port on the back of your computer. With the
thermometer turned off, connect the other end of the RS232 interface cable to the data
port located at the bottom of the thermometer.Then“PCL”will appear in the display,
indicating that the thermometer is ready to transmit data.
3.Transmit Data
Follow the instructions provided in the software to transmit data. Results transmitted will
include date and time. Remove the cable and the thermometer will automatically turn off.
Transmitting Data via Bluetooth (for TD-1261F)
2.Turn on the Bluetooth function of your device so that it can begin searching for the ear
thermometer. When the name of the ear thermometer appears on the pairing list, select and add it
to the list.
3. On your device, the ear thermometer will be shown as a paired device, suggesting successful
pairing.
1.Turn on the meter, press and firmly hold
On/Memory button and Scan button at the same
time until "CLr" shows on the display. The
Bluetooth indicator will flash quickly, which means
the meter is in Bluetooth pairing mode.
VIEWING RESULTS ON PERSONAL COMPUTER OR DEVICE
• While the meter is in transmission mode, it will be unable to perform a test.
• Make sure your device has the Bluetooth function turned on and the meter is within
the receiving range before transmitting the data.
WARNING
Step1
Remove the battery
cover.
Step2
Place the new batteries
in the battery compart-
ment and press it in until
the batteries are secured.
Step 3
Reattach the
battery cover.
REPLACING THE BATTERY
The thermometer comes with two 1.5 V AAA alkaline batteries. Replace it when“ ” appears. Please
follow the steps to replace new batteries.
Bluetooth Indicator on the Thermometer
Bluetooth Indicator Status
Flash fast Pairing mode.
Flash slowly Connection mode.
Lit solid The connection is
established.
Bluetooth Indicator
When the memory is full, the oldest result is deleted as the new one added. When the last
record is displayed in the LCD, press On / Memory button again to return the first record.
Step 4
Exit the memory.
Press the Scan button and LCD will show latest results with flashing“ ” .Then press
On/Memory button again and LCD will show“ OFF ” to exit memory.
Although the thermometer works when " " appears, we still recommend that you
change the batteries to obtain an accurate result.
Remove the batteries if stored for a long period of time.
The batteries should be kept out of children. If they are swallowed, promptly see a
doctor for help.
Properly dispose of the batteries according to your local environmental regulations.
NOTE
Step 3
Press the On / Memory button for 3 seconds
to enter memory mode.
Each time you press the On / Memory button,
a result will be displayed in the order of dates
(latest result shown first), together with“ ”
and number ( from 1 to 10 ).
Symbol Referent
Consult instructions for use
Manufacturer
Type BF Equipment
Temperature limitation
Humidity limitation
Serial number
Caution, consult accompanying
Collection for electrical and electronic
equipment
documents
Symbol Referent
Authorized representative in the
European Community CE mark
