Tailulu HQZZ-160 User manual
Child Lock
Low Noise Level
3- Stage
Filtration System
True HEPA Filter
Model: HQZZ-160
Air Purifier
User Manual
Our customer service team is standing by to assist
you if you have any questions or concerns.
CUSTOMER SERVICE
www.tailulu.com
1-833-368-8825
CONTENT
Product introduction
Product overview
Before using the appliance
Control panel and function
Operation
Maintenance
Specifications
Matters needing attention
Troubleshooting Guide
1
2
3
4
5
7
8
9
10
--------------------------------------
-----------------------------------
---------------------------------------------
-----------------------------------------------
-------------------------------------------------
----------------------------------
--------------------------------
-------------------------------------------
----------------------------------------
To Reduce The Risk Of Fire Or Electric Shock, Do Not Use This Fan
With Any Solid-State Speed Control Device.
READ AND SAVE THESE INSTRUCTIONS
Product introduction1
Dear users, thank you for using our air purifier. Please read
this manual carefully before use and master the usage method
correctly.
This product is a small desktop air purifier. Its unique appearance
design can bring you aesthetic experience. The structure of air
inlet on four sides and air outlet on the top enables it better
circulate and purify the air. The compact size makes it placed on
the desktop without affecting your work. This air purifier can
absorb, decompose or convert various air pollutants and effec-
tively improve air cleanliness. It adopts multiple technologies and
media so that it can provide you with clean and safe air. A small
"body" can realize great effects!
1-833-368-8825suppo@tailulu.com
www.tailulu.com
PRODUCT OVERVIEW 2
Control panel
Top air outlet
Housing
Four-side air inlet
Built-in composite filter
Filter cover
Filter
1-833-368-8825suppo@tailulu.com
www.tailulu.com
BEFORE USING THE APPLIANCE3
1. Open the package, Take out the air purifier. Rotate the twist
handle counterclockwise to unlock the base cover.
2. Take out the power adapter (placed in the middle of the filter).
3. Remove the new filter protective film before installation
4. Place the filter into the air purifier and put the base cover back
(Align the base cover locking notches and rotate it clockwise until
it clicks into place.)
5. To better exert the performance of the air purifier, the air inlet
of the machine should be kept a certain distance (above 20 cm
recommended) from the obstruction.
6. Please insert the plug into the power socket firmly.
1-833-368-8825suppo@tailulu.com
www.tailulu.com
Control panel and functionse 4
Filter reset key
Child lock
Timer key
Power key
Speed key
Light key
Sleep key
1-833-368-8825suppo@tailulu.com
www.tailulu.com
5 OPERATION
1. “POWER" ON/OFF
Press the" " button to switch on the purifier, then you wil find the
filtration runs in speed 2automatically. Press the" " button again to
switch off the purifier.
2. Sleep mode:
Press the" " button to enter sleep mode,the air purifier will start
the lowest airflow speed.
3. Speed:
Press the " " button to adjust the speed level (I, 2, 3, 4) and
choose the most comfortable one for you. Please note the noise will
increase when the speed lever is increased.
4. Timer function:
Press the " " button to pick the required operating time (2, 4, 6,
8hours). Air purifier shuts off automatically at the end of the selected
period.
1-833-368-8825suppo@tailulu.com
www.tailulu.com
5. Child lock function:
Press the " " key, and other keys will be locked. Press and hold
"LOCK" key for 5s again to cancel Child lock function.
6. Atmosphere light button,
Press the " " key to turn on/off the ice blue light.
7. Filter reset function:
When the filter service life is over, the " " light will light up to remind
you that the filter needs to be replaced. After replacing the filter, press
and hold the "FILTER" button for 5 seconds to cancel the filter replace-
ment reminder.
OPERATION 6
1-833-368-8825suppo@tailulu.com
www.tailulu.com
Maintenance7
1.Recommended daily cleaning and maintenance frequency of
the filter: about once a month. The surface of the filter can only be
cleaned with a brush or dry cotton cloth. Do not clean the filter with
water or detergent. The filter is easy to be damaged and deformed, so
do not press or pull it hard during cleaning. Replace the filter with a
new one in case of damage.
2.Recommended replacement frequency of the filter: about once
every 3-6 months, depending on the place and the usage method. For
example, the filter replacement cycle may be shortened in case of
heavily polluted areas, smoking of family members, etc. Please
replace the filter in time if the filtering effect is not good.
3.Surface cleaning: Wipe the outer surface and the air inlet and
outlet with a wrung soft cloth. Do not clean the surface with chemical
cleaners.
4.Long-time idling: Unplug the power adapter, and clean the outer
surface and the filter. Put the purifier in a plastic bag and store it in a
place with less moisture.
Be sure to unplug the power adapter before any maintenance!
1-833-368-8825suppo@tailulu.com
www.tailulu.com
SPECIFICATIONS 8
Air purifier
220x220x330
250x250x360
1.95KG
2.36KG
HQZZ-160
Touch keys
100-240 V AC 50/60 Hz
24V DC
15W
Product name:
Product dimension:
Package dimension:
Net weight:
Gross weight:
Model:
Operation
Input voltage of the adapter:
Operating voltage
Rated power:
1-833-368-8825suppo@tailulu.com
www.tailulu.com
Matters needing attention9
Do not clean or sprinkle the product with liquid.
1.There is a high-speed wind wheel rotating in the purifier, so do
not put your hands or foreign matters into the air inlet and outlet.
2.Keep the purifier away from children, and do not let them play
with this product.
3.Keep hair, fabric, etc. away from the machine to avoid being
caught in or blocking the air inlet and outlet.
4.Close the doors and windows to improve the purification effect
when using the product. (Please ventilate when using the purifier
with a combustion device to avoid carbon monoxide poisoning.)
5.Do not use power adapters of different specifications. Please
install the power adapter attached to this product.
Do not use this purifier in high-temperature, humid, and
water-stained places such as bathrooms.
1-833-368-8825suppo@tailulu.com
www.tailulu.com
TROUBLESHOOTING GUIDE 10
Faults Cause and solutions
The air purifier
produces a
strange smell.
No wind at
the air outlet
Can't feel
the effect
The motor is not running - Check the power supply,
replace the povwer adapter or contact customer
support team.
The filter is too dirty and has not been replaced for
a long time-replace the filter.
Water has entered the filter or the machine has been
used in a humid environmentreplace the filter.
Reuse after sealed for a period of time-clean the filter,
if it cannot be solved replace the filter.
Filter failure - Replace the filter.
Used in inappropriate places (too large area)
If there is a burning smell-stop using it immediately,
unplug the power supply and contact customer
support team.
