Tailulu HQZZ-260 User manual

User's Manual of Air Purifier
Child Lock
Low Noise Level
3- Stage
Filtration System
True HEPA Filter
Model: HQZZ-260

Our customer service team is standing by to assist
you if you have any questions or concerns.
CUSTOMER SERVICE
www.tailulu.com
[email protected]
1-833-368-8825

CONTENT
Product introduction
Picture of the product
Preparation before use
Control panel and functionse
Name of each part
Method of use
Maintenance
Specifications
Matters needing attention
Analysis of common problemse
1
2
3
4
5
6
7
8
9
10
-----------------------------
-----------------------------------
----------------------------------------------
-----------------------------------------------
---------------------------------------------
-----------------------------------------
--------------------------------
-------------------------------------
---------------------------------------
----------------------------------------

Product introduction1
Dear users, thank you tor choosing Tailulu air purifier. Please
read this instruction manual before using the product to ensure its
safety and convenience of use.
HQZZ-260 air purifier efficiently improves air purity by absorbing,
decomposing, or transforming various air contaminants. Tailulu
air purifier with its distinct visual design provides users with an
aesthetic experience.

Picture of the product 2
Control Panel
Top Air Outlet
Body
Rear Air Inlet
* The product's appearance or components may differ depending
on the model.

BEFORE USING THE APPLIANCE3
1. Unpack the appliance, remove packing tape and filter protec-
tive bag before using the appliance. Install the filter in the unit.
Insert the cover into the fixing grooves and close the cover.
2. Place the air purifier at least 1ft/30cm away from the wall or
furniture.
3. Connect the power supply. When the power is turned on, the
key light flashes.

Control panel and functionse 4
Power ON/OFFPower ON/OFF
Air speed
Sleep mode
Time setting
Auto keve
Child-proof lock
Filter reset key

Name of each part5
Air Outlet
Filter
Air Inlet
Body

1. ON/OFF key: After the power is turned on, press once, the
value will be displayed in the middle,and it will operate at 2F
level.
2. Manual mode: Press once to manually adjust the air speed
from level 1 to 3.
3. Sleep mode: Press once to enter the sleep mode.
4. Timer function: Press once to start sleep timer function. It
can be set to shutdown after 2H, 4H, 6H, 8H , 10H, and 12H. The
setting time will be displayed in the way of countdown. The button
blinks when the filter screen expires. After the filter screen is
replaced, hold down the button for 3 seconds to complete the
reset when the light turns off.
5. Auto mode: Press in any other running mode, and the
machine will enter the auto mode. In the auto mode, the AUTO
key light is on, and the machine will automatically select the
appropriate speed based on the air quality signal detected by the
sensor.
6. Child-proof lock function: Press to start child-proof lock
function to lock other keys. Longpress for 5 seconds to cancel.
Method of use 6
AUTO
AUTO

Maintenance7
1. Reference time for daily cleaning and maintenance of filter:
about once a month. The surface of the filter can only be cleaned
with a brush and dry cotton cloth. It is not allowed to wash the
filter with water or detergent. The filter is easy to be damaged
and deformed. Do not press and pull hard during cleaning. If it is
damaged, replace it with a new filter in time.
2. Reference for replacement interval of filter: Replace it once
every 3 to 6 months. It varies according to the place and method
of use. The replacement interval of the filter may be shortened in
heavily polluted areas, when family members smoke, etc. Please
replace the filter in time when the filtering effect is not good.
3. Appearance cleaning: wipe the outer surface and air inlet and
outlet with a soft cloth that is wrung dry. Do not clean the surface
with chemical cleaner.
4. Shutdown for a long time: Unplug the power plug and clean the
outer surface and filter. Put on plastic bags and store in a place
with less moisture.
Always unplug the power before any maintenance!

Specifications 8
Air purifier:
295x165×410mm
340x195×445mm
3.75KG
4.2KG
HQZZ-260
Touch key
120V AC 60Hz
52W
Product name:
Product size:
Package size:
Net weight:
Gross weight:
Product model:
Operation mode:
Input voltage:
Rated Power:

Matters needing attention9
1. It is not allowed to wash or spill the product with liquid.
2. Do not put your hands or foreign matters into the air inlet and
outlet since there is a high-speed wind wheel rotating in the
purifier
3. Try to place the purifier out of the reach of children. It is not a
toy for children to play with.
4. Keep hair, fabric, etc. away from the main unit to prevent them
getting involved or blocking the air inlet and outlet.
5. In order to improve the purification effect, try to close the doors
and windows when using the product. (Please keep good ventila-
tion when using with combustion device to avoid carbon monox-
ide poisoning.)
6. Do not use the purifier in the bathroom and other places with
high temperature, humidity andwater.

Analysis of common problemse 10
Phenomenon Cause and solutions
Odor
No air at outlet
No effect
Motor stop running-Check the power supply and
contact the maintenanceservice
The filter is too dirty and has not been replaced for a
long time- replacethe filter.
Water has got in the filter or the purifier has been
used in humid environment- replace the filter.
Reuse after storage for some time clean the filter or
replace the filter if the problem can not be solved.
Burning smell-Stop use immediately and disconnect
the power and contact the maintenance service.
Filter failure-replace the filter.
Use in inappropriate places (too large)

www.tailulu.com
[email protected]
1-833-368-8825
Intertek
