Tainet Venus Series User manual

USER'S MANUAL
VoIP Gateway
Venus Series SIP
Version: 1.7
Date: 2006/11/10
P/N: 07008-00085
Headquarters:
No. 25, Alley 15, Lane 120,
Sec. 1. Nei-Hu Rd,
Taipei 114, Taiwan
TEL: [phone]
FAX: [phone]
Beijing Branch:
3F, A Building,
113 Zhi Chun Lu,
HaiDian District,
Beijing, China
Zip Code: 100086
TEL: [phone]~87
FAX: [phone]

Venus Series SIP User’s Manual V1.7
i
Copyright © 2006 TAINET COMMUNICATION SYSTEM CORP.
All rights reserved
Notice
This document is protected by the international copyright law. No part of this publication
may be reproduced by any means without the expressed permission of Tainet
Communication System Corporation.
TAINET is a registered trademark, and Venus Series SIP is a trademark of Tainet
Communication System Corporation.
Other product names mentioned in this manual are used for identification purposes only
and may be trademarks or trademarks of their respective companies.
The information provided from Tainet Communication System Corporation is believed to
be accurate. Any changes and enhancements to the product and to the information
thereof will be documented and issued as a new release to this manual.
Trademark
All products and services mentioned herein are the trademarks, service marks, registered
trademarks or registered service marks of their respective owners.

Venus Series SIP User’s Manual V1.7
ii
About This Manual
This section guides users on how to use the manual effectively. The manual contains
information needed to install, configure, and operate TAINET’s VENUS Series VoIP SIP
Gateway. The summary of this manual is as follows:
Chapter 1: Overview
Chapter 2: Hardware Installation
Chapter 3: Configuration and Management
Chapter 4: Web Base Management
Chapter 5: Edit Configuration File
Chapter 6: Maintenance and Troubleshooting
Appendix A: Supplemental Telephone Features
Appendix B: Abbreviation
Appendix C: Flow Chart for Code Determination

Venus Series SIP User’s Manual V1.7
iii
Symbols Used in This Manual
3 types of symbols may be used throughout this manual. These symbols are used to
advise the users when a special condition arises, such as a safety or operational hazard,
or to present extra information to the users. These symbols are explained below:
Warning:
This symbol and associated text are used when death or
injury to the user may result if operating instructions are
not followed properly.
Note:
This symbol and associated text are used to provide the
users with extra information that may be helpful when
following the main instructions in this manual.
Caution:
This symbol and associated text are used when damages
to the equipment or impact to the operation may result if
o
p
eratin
g
instructions are not followed
p
ro
p
erl
y
.

Venus Series SIP User’s Manual V1.7
iv
LIMITED WARRANTY
TAINET’s DISTRIBUTOR shall be responsible to its customers for any and all warranties,
which it makes relating to Products, and for ensuring that replacements and other
adjustments required in connection with the said warranties are satisfactory. TAINET
warrants to DISTRIBUTOR that the Products to be delivered hereunder will be free of
defects in material and workmanship under normal use and service for a period of
twenty-four (24) months [twelve (12) months in Taiwan] following the date of shipment to
DISTRIBUTOR.
If during the warranty period, any component part of the equipment becomes defective by
reason of material or workmanship, and DISTRIBUTOR notifies TAINET of such defect
within seven days after knowing of such defect, TAINET shall, for any Product that TAINET
agrees is defective, at its option, supply a replacement part, request return of equipment
to its plant for repair, or perform necessary repair at the equipment’s location. At
TAINET's option, DISTRIBUTOR shall destroy any Product that TAINET agrees is
defective and shall provide satisfactory proof of such destruction to TAINET. TAINET is
not responsible for Products damaged by misuse, neglect, accident or improper
installation, or if repairs or modifications were made by persons other than TAINET’s own
authorized service personnel, unless such repairs by others were made with the written
consent of TAINET.
THE ABOVE WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED. THERE ARE NO WARRANTIES THAT EXTEND BEYOND THE FACE
HEREOF, INCLUDING, BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, AND IN NO EVENT SHALL TAINET BE
LIABLE FOR CONSEQUENTIAL DAMAGES. If DISTRIBUTOR extends to its customers
any additional warranty with respect to Products that is broader in scope than the warranty
provided by TAINET, DISTRIBUTOR shall be solely responsible for any and all liabilities,
obligations and damages resulting from the extension of such warranty.
TAINET shall not be liable to any person for any special or indirect damages, including,
but not limited to, lost profits, from any cause whatsoever arising from or in any way
connected with the manufacture, sale, handling, repair, maintenance or use of the

Venus Series SIP User’s Manual V1.7
v
Products, and in no event shall TAINET’s liability exceed the purchase price of the
Products.
Software Products are provided “as is” and without warranty of any kind. TAINET
disclaims all warranties including the implied warranties of merchantability and fitness for
a particular purpose. TAINET shall not be liable for any loss of use, interruption of
business or indirect, special, incidental or consequential damages of any kind. TAINET
shall do its best to provide end users with Software updates during the warranty period
under this Agreement.
TAINET has not been notified of any intellectual property rights or others which may be
infringed by the Products or the promotion, marketing, sale (or resale), or servicing thereof
in the Territory, but TAINET makes NO WARRANTY, EXPRESS OR IMPLIED, WITH
RESPECT THERETO.

Venus Series SIP User’s Manual V1.7
vi
CONTENTS
CHAPTER 1. OVERVIEW.....................................................................................1
1.1 PRODUCT OVERVIEW ............................................................................................................1
1.2 APPLICATIONS.......................................................................................................................4
1.3 PRODUCT DESCRIPTION ........................................................................................................7
1.3.1 Hardware Architecture................................................................................................................. 7
1.3.2 Software Architecture.................................................................................................................11
1.4 TECHNICAL SPECIFICATIONS ...............................................................................................14
1.5 STANDARD COMPLIANCE ....................................................................................................19
CHAPTER 2. HARDWARE INSTALLATION ..................................................21
2.1 UNPACKING.........................................................................................................................21
2.2 SITE REQUIREMENTS...........................................................................................................22
2.2.1 Site Selection............................................................................................................................. 22
2.2.2 AC Electrical Outlet Connection............................................................................................... 22
2.2.3 DC Power Source Connection................................................................................................... 22
2.2.4 Grounding.................................................................................................................................. 22
2.3 LED INDICATORS................................................................................................................25
2.4 FRONT PANEL CONNECTIONS ..............................................................................................26
2.4.1 Connecting the IP Network via Ethernet ................................................................................... 26
2.4.2 Connecting the Terminal............................................................................................................ 26
2.5 REAR PANEL CONNECTIONS................................................................................................28
2.5.1 Connecting the Power Source.................................................................................................... 28
2.5.2 Connecting the Telephony Devices ........................................................................................... 29
2.6 HARDWARE DIAGNOSIS.......................................................................................................33
2.7 BASIC CONFIGURATION.......................................................................................................34
CHAPTER 3. CONFIGURATION AND MANAGEMENT..............................35
3.1 CONNECTING THE TERMINAL..............................................................................................35
3.1.1 Setup PC .................................................................................................................................... 35
3.1.2 Power on VENUS Series...........................................................................................................37
3.1.3 Login.......................................................................................................................................... 38
3.2 NAVIGATION THE TERMINAL USER INTERFACE....................................................................39
3.3 ORGANIZATION OF THE TERMINAL MENU TREE ..................................................................41
3.4 MAIN MENU........................................................................................................................42
3.4.1 Configuration Menu................................................................................................................... 42
3.4.2 Monitoring Menu....................................................................................................................... 42

Venus Series SIP User’s Manual V1.7
vii
3.4.3 Device Control Menu ................................................................................................................ 42
3.4.4 Diagnosis Menu......................................................................................................................... 43
3.5 CONFIGURATION .................................................................................................................44
3.5.1 System Configuration................................................................................................................ 44
3.5.2 Interface..................................................................................................................................... 72
3.5.3 Life-Line.................................................................................................................................... 94
3.5.4 Routing Table............................................................................................................................. 94
3.5.5 Phone Book................................................................................................................................ 97
3.5.6 Security...................................................................................................................................... 98
3.6 MONITORING.....................................................................................................................100
3.6.1 Routing Table Monitoring........................................................................................................100
3.6.2 H/W Report Monitoring...........................................................................................................102
3.6.3 Statistics Monitoring................................................................................................................ 103
3.6.4 System Info Monitoring........................................................................................................... 106
3.7 DEVICE CONTROL .............................................................................................................107
3.7.1 Warm Start............................................................................................................................... 107
3.7.2 Restore Default........................................................................................................................ 108
3.7.3 Firmware Upgrade................................................................................................................... 109
3.8 DIAGNOSIS........................................................................................................................114
3.8.1 Ping...........................................................................................................................................114
3.8.2 STUN Type Diagnosis..............................................................................................................115
3.8.3 Trouble Shooting Menu (Command Line Interface) ................................................................115
CHAPTER 4. EDIT CONFIGURATION FILE................................................ 119
4.1 DOWNLOAD THE CONFIGURATION FILE............................................................................119
4.2 FILE FORMAT ....................................................................................................................122
4.3 COMMAND SETS................................................................................................................123
4.4 EXAMPLE FILE ..................................................................................................................134
CHAPTER 5. MAINTENANCE AND TROUBLESHOOTING.....................135
5.1 INSTRUMENTS ...................................................................................................................135
5.2 TROUBLESHOOTING ..........................................................................................................136
APPENDIX A SUPPLEMENTAL TELEPHONE FEATURES.......................141
APPENDIX B ABBREVIATION ........................................................................145
APPENDIX C CODE DETERMINATION FLOW CHART ...........................147
APPENDIX D VENUS SERIES POWER CONSUMPTION...........................149

Venus Series SIP User’s Manual V1.7
viii
FIGURES
Figure 1-1 - Typical SIP VoIPApplication..........................................................................................4
Figure 1-2 - Enterprise VoIP IntranetApplication..............................................................................5
Figure 1-3 - MTU/MDU Application...................................................................................................5
Figure 1-4 - The Front View of VENUS 2832A+ and 2832SD+........................................................7
Figure 1-5 - The Rear View of VENUS 2832SA+ .............................................................................7
Figure 1-6 - The Rear View of VENUS 2832SD+ .............................................................................7
Figure 1-7 – The Front View of VENUS 2832AE+ and 2832SDE+...................................................7
Figure 1-8 - The Rear View of VENUS 2832SAE+...........................................................................8
Figure 1-9 - The Rear View of VENUS 2832SDE+...........................................................................8
Figure 1-10 - The Front and Rear view of VENUS 2808S................................................................8
Figure 1-11 - The Front and Rear view of VENUS 2804S ................................................................8
Figure 1-12 - The 8-port FXS Module (FXS-8) .................................................................................9
Figure 1-13 - The FXS-8 with a FXS-8AAdd-on Module Mounted on the Top ...............................10
Figure 1-14 - The FXO-8 Module with an Add-on Module Mounted on the Top..............................10
Figure 1-15 - UTP-1 Module...........................................................................................................10
Figure 1-16 - UTP-2 Module...........................................................................................................11
Figure 1-17 - UTP-2F Module.........................................................................................................11
Figure 1-18 - Web Browser.............................................................................................................13
Figure 2-1 - DB-9F Console Interface.............................................................................................27
Figure 2-2 - VENUS 2832S Series Rear Panel Connections .........................................................28
Figure 2-3 - RJ-21 Female-Type Telcom Connector.......................................................................29
Figure 2-4 - The Copper Wire Cable...............................................................................................30
Figure 2-5 - The Fan-out Cable ......................................................................................................31
Figure 2-6 - TheAdapter Panel with the Extension Cable..............................................................32
Figure 3-1 - Connecting to the PC..................................................................................................35
Figure 3-2 - Initial Screen................................................................................................................37
Figure 3-3 - The Main Menu ...........................................................................................................38
Figure 3-4 - Navigating User Menu.................................................................................................39
Figure 3-5 - Logout the Terminal UI................................................................................................40
Figure 3-6 - SIP Basic Configuration ..............................................................................................45
Figure 3-7 - Proxy Server Configuration.........................................................................................46
Figure 3-8 - Registration Server Configuration...............................................................................47
Figure 3-9 - Public Account Configuration ......................................................................................48
Figure 3-10 - Registration Server Configuration.............................................................................49
Figure 3-11 - DHCP/BootP Configuration .......................................................................................50
Figure 3-12 - DHCP Server Configuration......................................................................................50
Figure 3-13 - DHCP Server FreeAddress Ranges Configuration...................................................51

Venus Series SIP User’s Manual V1.7
ix
Figure 3-14 -DHCP/BootP Client Configuration..............................................................................52
Figure 3-15 - DHCP Client Using ‘Trusted’ Server(s)......................................................................53
Figure 3-16 - The Boot Up Procedure with DHCP/BootP Client Enabled.......................................53
Figure 3-17 - SNMPAgent Configuration .......................................................................................54
Figure 3-18 - DNS Configuration ....................................................................................................55
Figure 3-19 - DNS Server...............................................................................................................56
Figure 3-20 - DDNS........................................................................................................................57
Figure 3-21 - Download Configuration File.....................................................................................58
Figure 3-22 - Download Procedure of the Configuration File..........................................................59
Figure 3-23 - Country Code Selection ............................................................................................60
Figure 3-24 - QoS Configuration Selection.....................................................................................60
Figure 3-25 - FAX Configuration Selection .....................................................................................61
Figure 3-26 - Call Features Configuration.......................................................................................62
Figure 3-27 - Play Ring Back Tone Configuration...........................................................................64
Figure 3-28 - Call Hold Configuration .............................................................................................64
Figure 3-29 - RTP Configuration.....................................................................................................65
Figure 3-30 - Phone Feature Configuration....................................................................................66
Figure 3-31 - DSP Configuration.....................................................................................................67
Figure 3-32 - Digitmap Configuration..............................................................................................68
Figure 3-33 - NTP Configuration.....................................................................................................69
Figure 3-34 - Web Server Configuration.........................................................................................70
Figure 3-35 – Provision Configuration ............................................................................................71
Figure 3-36 - FXS/FXO Configuration Menu...................................................................................72
Figure 3-37 - Individual FXS/FXO Port Configuration.....................................................................73
Figure 3-38 - Port’s Private Account Configuration.........................................................................74
Figure 3-39 - Hotline Configuration.................................................................................................74
Figure 3-40 - Call Forward Always Configuration ...........................................................................75
Figure 3-41 - Call Forward Busy & No Answer Configuration.........................................................76
Figure 3-42 - WAN Interface Configuration.....................................................................................77
Figure 3-43 - PPP over Ethernet Configuration..............................................................................78
Figure 3-44 - LAN Switch Mode Configuration ...............................................................................80
Figure 3-45 - Port-based VLAN Configuration................................................................................81
Figure 3-46- Router Mode Configuration........................................................................................81
Figure 3-47- NAT Configuration......................................................................................................82
Figure 3-48 - NAPT Configuration ..................................................................................................83
Figure 3-49- Ring Configuration......................................................................................................84
Figure 3-50 - Ring Frequency Configuration...................................................................................85
Figure 3-51 - Default Ring Cadence Configuration.........................................................................85
Figure 3-52 - Distinctive Ring Configuration...................................................................................86

Venus Series SIP User’s Manual V1.7
x
Figure 3-53 - Tone Configuration....................................................................................................87
Figure 3-54 - Busy Tone Configuration...........................................................................................88
Figure 3-55 - Ring Back Tone Configuration...................................................................................88
Figure 3-56 - Congestion Tone Configuration.................................................................................89
Figure 3-57 - Out of Service Tone Configuration ............................................................................89
Figure 3-58 - Disconnect Tone Configuration .................................................................................90
Figure 3-59 - Off-Hook Tone Configuration.....................................................................................90
Figure 3-60 - Dial Tone Configuration.............................................................................................91
Figure 3-61 - Off On Dial Tone Configuration..................................................................................91
Figure 3-62 - Reorder Tone Configuration......................................................................................92
Figure 3-63 - On Hold Configuration...............................................................................................92
Figure 3-64 - Call Waiting Configuration.........................................................................................93
Figure 3-65 - Long Loop Configuration...........................................................................................93
Figure 3-66 – Life-Line Configuration .............................................................................................94
Figure 3-67 - Static Routing Configuration......................................................................................95
Figure 3-68 - Default Gateway Configuration .................................................................................96
Figure 3-69 - Phone Book Configuration ........................................................................................97
Figure 3-70 - Phone book entry Configuration................................................................................98
Figure 3-71 - System Security Configuration..................................................................................99
Figure 3-72 - System Security Configuration..................................................................................99
Figure 3-73 - Routing Table Monitoring.........................................................................................100
Figure 3-74 - H/W Report Monitoring............................................................................................102
Figure 3-75 - Interface Statistics Monitoring .................................................................................103
Figure 3-76 - NAT Statistics Monitoring.........................................................................................105
Figure 3-77 - DHCP Server Statistics Monitoring..........................................................................106
Figure 3-78 - System Information Monitoring................................................................................106
Figure 3-79 - Reset the VENUS Series ........................................................................................107
Figure 3-80 - Restore Default .......................................................................................................108
Figure 3-81 - Firmware Upgrade...................................................................................................110
Figure 3-82 - Downloading the New Software.............................................................................. 111
Figure 3-83 - Writing to New Software into the Flash Memory .....................................................112
Figure 3-84 - Upgrade Completed................................................................................................112
Figure 3-85 - Execute the Trial Software ......................................................................................113
Figure 3-86 – Execute the trial Software.......................................................................................113
Figure 3-87 - Ping a Host..............................................................................................................114
Figure 3-88 - Stun Type Diagnosis................................................................................................115
Figure 3-89 - Entering the Command Line Interface.....................................................................116
Figure 3-90 - The “help” Command ..............................................................................................117
Figure 3-91 - The “venus” Command............................................................................................117

Venus Series SIP User’s Manual V1.7
xi
Figure 3-92 - The Spy Command..................................................................................................118
Figure 4-1 - DHCP Manager of the Windows NT Server..............................................................120
Figure 4-2 - DHCP Options –Adding the Reservation Fields.......................................................120
Figure 4-3 - Setup the TFTP Boot Server Host Name..................................................................121
Figure 4-4 - Setup the Configuration File Name...........................................................................121

Venus Series SIP User’s Manual V1.7
xii
TABLES
Table 1-1 - VENUS Series Technical Specification.........................................................................14
Table 2-1 - LED Description............................................................................................................25
Table 2-2 -10/100Base-T Connection.............................................................................................26
Table 2-3 - Pin definition of the Console Port connector.................................................................27
Table 2-4 - Pin Assignment of the RJ-21 Telcom Connector...........................................................29
Table 2-5 - Pin Assignment of the Copper Wire Cable....................................................................31
Table 3-1 - Terminal Emulation Software........................................................................................36
Table 3-2 - Function Keys used in the Terminal UI .........................................................................39
Table 3-3 - The Main Menu Items...................................................................................................42
Table 3-4 - The Configuration Menu Items......................................................................................44
Table 3-5 - The System Configuration Menu Items.........................................................................44
Table 3-6 - Description of SIP Configuration Items.........................................................................45
Table 3-7 - Description of Proxy Server Configuration Items..........................................................47
Table 3-8 - Description of Registration Server Configuration Items................................................48
Table 3-9 - Description of Public Account Items..............................................................................48
Table 3-10 - Description of NAT Pass Through Items.....................................................................49
Table 3-11 - Description of DHCP Server Configuration Items .......................................................51
Table 3-12 - DHCP/BootP Client Configuration ..............................................................................52
Table 3-13 - Description of SNMPAgent Configuration Items ........................................................54
Table 3-14 - Description of DNS Configuration Items.....................................................................56
Table 3-15 - Description of DDNS Configuration Items...................................................................57
Table 3-16 - Description of Download Configuration File Items......................................................58
Table 3-17 - Description of QoS Configuration Selection Items......................................................61
Table 3-18 - Description of FAX Configuration Item........................................................................62
Table 3-19 - Description of Call Features Configuration Items .......................................................63
Table 3-20 - Description of RTP Configuration Items......................................................................65
Table 3-21 - Description for Various Timeouts ................................................................................66
Table 3-22 - Description for DSP Configuration..............................................................................67
Table 3-23 - Description of NTP Server Configuration....................................................................70
Table 3-24 - Description of Web Server Configuration....................................................................70
Table 3-25 - Description of Provision Configuration........................................................................71
Table 3-27 - Description of FXS/FXO Port Items............................................................................73
Table 3-28 - Description of Call Forward Busy & No Answer Items................................................76
Table 3-29 - Description of WAN Interface Configuration Items......................................................77
Table 3-30 - Description of PPP over Ethernet Configuration Items...............................................78
Table 3-31 - Description of LAN Interface Configuration Items.......................................................80
Table 3-32 - The Analog Menu Items..............................................................................................83

Venus Series SIP User’s Manual V1.7
xiii
Table 3-33 - The Ring Menu Items..................................................................................................83
Table 3-34 - Description of Ring Configuration Items .....................................................................84
Table 3-35 - The “Tone” Menu Items...............................................................................................86
Table 3-36 - Description of Tone Configuration Items.....................................................................87
Table 3-39 - Static Routing Configuration .......................................................................................96
Table 3-40 - Description for Phone Book Entry Items.....................................................................98
Table 3-42 - Description of Routing Table Monitoring Items .........................................................101
Table 3-43 - Description of “Firmware Upgrade” Items.................................................................110
Table 3-44 - The “Diagnosis” Menu Items.....................................................................................114
Table 5-1 - Voice Codec Bandwidth..............................................................................................139
Table A-1 -Supplemental Telephony Features ..............................................................................141

Chapter 1 Overview
1
Chapter 1. Overview
1.1 Product Overview
TAINET VENUS Series, a critical part of the Next Generation Network (NGN),
functions as an interface gateway unit between the legacy Public Switched
Telephone Network (PSTN) and the IP packet network by performing the
conversion of the analog voice traffic to/from the IP-based media stream.
VENUS Series is a Voice-over-IP (VoIP) Gateway that provides cost-effective
and quality voice service over global IP packet network (Internet or Intranets)
for end-users, and, in the meanwhile, lowers the installation and maintenance
effort. With analog voice interface connecting to user’s existing telephone
handset or PABX, and the Ethernet interface connecting to the service
providers' IP network, VENUS Series bridges the PSTN and IP network.
Depending on the installed firmware, VENUS Series supports both Session
Initiation Protocol (SIP) and Media Gateway Control Protocol (MGCP), which
comply with IETF RFC 3261 and RFC 3435 respectively. This document is only
for VENUS Gateways installed with SIP firmware.
VENUS Gateway allows traditional PSTN users to make phone calls over the
Internet without changing their telephone operating procedure. Using a Proxy
Server or SoftSwitch together with the VENUS Series, service providers or
telecom companies are able to provision integrated voice and data service
over the IP network to their customers. Features like billing, accounting and
network management supported by the SoftSwitch are available as well.
VENUS Series installed with SIP firmware provides the following services and
functions:
 Support SIP protocol, which complies with IETF RFC 3261 standard.

Chapter 1 Overview
2
 Venus 2832 Series support up to 32 analog voice interfaces for traditional
POTS (Plain Old Telephone System) equipments (telephone handset,
FAX machines, … etc).
 Modularized analog FXS (Foreign Exchange Station) or FXO (Foreign
Exchange Office) telephony cards provide 8, 16, 24, or 32 telephone
interfaces for various customers. Each telephone interface can drive at
least three telephone handsets through up to 4 Km (13K feet) of 24 AWG
copper lines.
 Support ITU-T standard voice codecs.
 Apply quality VoIP technologies including: Real-time voice packet
encapsulation and voice play-out based on the Real-Time Protocol (RTP),
Adaptive Jitter Buffer, Echo Cancellation（ITU-T G.168/165）,
Compensation for Loss of Packet, Voice Activity Detection (VAD) and
Silence Suppression.
 Support T.30 Transparent FAX service or T.38 FAX Relay.
 Supplemental Class 5 features like Call Forwarding, Caller ID
Display/Blocking, Call Returning, Speed Dial, Call Waiting, Call Transfer,
Voice Message Indication, Hotline, and 3-way Conferencing… etc can be
easily supported.
 Use static IP address assignment or obtain the dynamic IP address from a
DHCP (Dynamic Host Configuration Protocol) Server or BootP (Bootstrap
Protocol) Server.
 Provide DHCP server function on LAN port.
 Provide PSTN life-line feature as backup.
 Support PPPoE function (Point-to-Point Protocol over Ethernet),
NAT/NAPT function (Network Address Translation/Network Address Port
Translation), port-based VLAN, VLAN ID and priority tagging, and QoS
function that including IEEE 802.1p and IEEE 802.1Q
 Support RFC-2833 RTP payload for DTMF Digits, Telephony Tones and
Telephony Signals
 Provide Terminal User Interface via the console port、TELNET or web
browser for easy and quick local or remote configuration and monitoring.

Chapter 1 Overview
3
 Provide SNMP MIB for integrating into service providers’ SNMP
management system.
 Support TFTP protocol for remote software upgrade and configuration file
download.
 User Interface is protected with User ID and Password from unauthorized
users.
 Provide two user accounts with two levels of access privilege.
 Compact 1U-High desktop unit with ear brackets for mounting up to a 19”
shelf.
 Provides a flexible dialing principles, as well as speed dial using hot key,
and hotline direct dial functions.

Chapter 1 Overview
4
1.2 Applications
VENUS Series, designed as a desktop or rack-mount unit, can be easily
installed in a telecommunication equipment room of a building. It uses the
standard 10/100 Base-T Ethernet to connect to the service providers' IP
backbone through the router or data communication equipment. Up to 32
traditional telephone handsets or FAX machines located in the rooms at each
floor of the building can be connected to the VENUS Series telephone ports
using copper wires (Figure 1-1). With various management features supported
on VENUS Series, service providers or telecomm companies can provide
toll-quality voice service to the customers. The deployment of an intelligent IP
packet network for integrated data and voice service with billing, accounting,
and management features can be soon built up.
Figure 1-1 - Typical SIP VoIP Application
Large or median sized enterprises are able to build-up the high quality, cheap
or free, private voice service based on the Intranet or Extranet network by
deploying VENUS Series units at corporate HQ and local branch offices. The
VENUS Series communicates with the SoftSwitch/SIP Proxy Server installed at
corporate HQ through managed IP leased line, such as DDN (Digital Data
Network) leased line or VPN (Virtual Private Network) network. With the
scalable voice capacity feature provided by VENUS Series, enterprises can
install proper amount of telephone interfaces for each branch (Figure 1-2).
