Takstar SHADE User manual

USER MANUAL
用户使用手册
扫一扫，了解更多产品
Scan for more
product information
TM

若存在有疑问或者您有宝贵的建议，可通过拨打得胜官方服热线 400 6828 333
或使用微信扫描二维码关注得胜官方公众号与我们联系。
产品特性：
󱁾 Ø40mm的钕铁硼驱动单元，具有灵敏度高、响应宽和动态大等出色表现
󱁾 采用复合材质膜片，高中低频段呈现分明，低频纯净、中频透彻和高频细腻
语音信号线配备高灵敏度麦克风，带来出色的游戏对话体验
柔软舒适的头梁套和耳垫，亲肤舒适，长时间佩戴无压迫感
整体结构应用人体工程学设计，适合于不同人体头型佩戴
配备耳机信号线和延长转换线，满足移动设备、PC等更多场合
󱁾
󱁾
󱁾
󱁾
-1-
适用范围：
适用于PC、MAC、 PS4™、 Xbox One和移动设备
技术参数：
单元类型：动圈式
单元直径：Ø40mm
单元阻抗: 26Ω±15%
频率响应: 10Hz～20KHz
灵 敏 度：95±3dB at:1mW 1KHz 318仿真耳
峰值功率: 40mW
额定功率: 15mW
耳麦信号线：Ø4mm x 1.3m
耳机信号线：Ø4mm x 1.2m
延长转换线：Ø4mm x 2m
产品重量：235g (不含线）
-2-
标准配置:
① 电竞头戴耳机...........................................................................................................................................1台
② 耳麦信号线...............................................................................................................................................1条
③ 耳机信号线...............................................................................................................................................1条
④ 延长转接线...............................................................................................................................................1条
⑤ 防风棉......................................................................................................................................................1个
⑥ 用户手册..................................................................................................................................................1份
频率响应图
10Hz
130
耳听八方，方能自"游"战场！——TAKSTAR 得胜是中国电声行业广为人知的先驱品牌，“自由玩家”
是得胜公司自主研发、生产的电竞级专业耳机，产品基于得胜多年来音频领域技术积累而开发，拥有强劲
的性能和舒适的佩戴体验，强调为玩家提供电竞优势的同时，也赋予玩家不一样的生活体验！
人生正如电竞，处处充满游戏规则，在游戏里尽情享受自由的电竞玩家，在游戏外也能做到认真生
活，享受人生。遵守规则但从不拘泥于方寸之间，为热爱之事去拼尽全力的你即是自由玩家。好游戏，好
生活，要有好耳机。

-3-
Xbox One连接:
注意：Xbox One控制器没有3.5mm接口，
需搭配Xbox One耳机适配器
耳麦信号线
线控使用方法:
音量旋钮：逆时针转动音量减小
顺时针转动音量增大
麦克风开关：开关切换到 关闭
麦克风
PC/Mac/Mobile连接:
耳麦信号线
注意：• 兼容CTIA标准接口设备
• 如果你的电脑是独立的耳机/麦克风接口，请使
用耳机/麦克风二合一转换线
注意：• 设定▶周边机器▶声音装置▶输出至耳机▶所有声音
• 设置▶设备▶音频设备▶输出到耳机▶选 择所有音频
PS 4™连接:
耳麦信号线
-4-

-5-
正确使用方法：
为了避免听力受损，请务必在连接耳机前将播放设备音量调小。在将耳机佩戴入耳内/耳上之后，再
逐步调大至您聆听舒适的音量。噪音是以分贝（dB）为计量单位的，外界任何85分贝及以上的噪音都会
导致听力逐渐受损。
请注意您的使用习惯。音量和时间对听力损失的影响成正反比的关系：音量越大，您聆听的时间越
短；音量越舒适，您聆听的时间越长。长时间使用较高的音量会对您的听力造成伤害。
此分贝（dB）表对某些常见声音进行比较，并列出了他们可能对听力的潜在危害等级。
“普通人能够以70%的音量每天安全地聆听音乐4.6小时，了解聆听音乐的音量和时长尤为重要。”在安
全的音量级别下，充分利用您的设备，享受出色的声音表现。
以直接使用干布搽试，切勿直接投入水中清洗；
• 在高温高湿的场所长时间使用耳机，容易造成耳机损坏或降低使用寿命;
• 耳机在放置时要避免和强磁体接触，以免使耳机的恒磁体去磁，使耳机的灵敏度降低而影响耳机音色。
• 使用一段时间后，应对耳套进行清洁处理。耳套可用带有中性肥皂水或清洁剂的毛巾轻轻擦洗，也可
保养及维护：
声音来源 噪声等级 听力影响
低声细语
安静的办公室
吸尘器/吹风机
食物料理机
垃圾清理机/混泥土搅拌机
电锯/电钻
摇滚音乐会（因情况而异）
30dB
50-60dB
70dB
85-90dB
100dB
110dB
非常安静
舒适的听力级别在60dB以下
有一定入侵性，造成干扰妨碍电话交谈
85dB是开始造成听力受损（连续8小时）的级别
建议无保护措施而暴露在90-100dB声音之下的时间不要超过15分钟
经常暴露于超过100dB的声音1分钟以上会有听力受损的风险
110-140dB 感觉疼痛的阀值在120dB左右开始
注意事项：
危险
• 为确保您的人身安全，请勿将该耳机佩戴或放置在离心脏起博器过近的位置（小于10cm）。
• 请勿将线材插头插入电源插座。
• 为了您与其他交通参与者的安全，驾驶车辆、骑自行车或马路上行走时，请勿使用耳机。
• 请勿将耳机靠近明火或置于火中，以免发生爆炸。
禁止
禁止
执行
禁止
• 额定功率为15mW，请不要超负荷使用，以免造成耳机损坏。
注意
警告
• 儿童应在成人监督下使用本产品。本产品并非玩具。
• 使用该产品时需遵守相关安全规定，法律法规明确禁止使用场合请勿使用本机，以免导致意外事故。
• 请储存于干燥洁净环境，使用中避免液体进入机身内部、跌落或碰撞，以免损坏。
• 请不要自行拆机改装或维修，以防止故障发生。
禁止
执行
执行
执行
禁止拆卸
-6-

10Hz
130
Features：
󱁾 Ø40mm NdFeB driver unit features high sensitivity, wide frequency response and large dynamic range
󱁾 Adopts compound material diaphragm, pure LF, penetrating MF and delicate HF
󱁾 Vocal signal cable designed with high sensitivity microphone for outstanding gaming dialogue experience
󱁾 Soft headband and ear pads for comfortable wearing
󱁾 Ergonomic design suits for various head shape wearing
󱁾 Provided with headphone signal cable and Y-type extension cable to meet the application of mobile
device, PC, etc
-7-
Application：
PC，MAC，PS4™，Xbox One, mobile device
Specification：
Unit Type: dynamic
Unit Diameter: Ø40mm
Unit Impedance: 26Ω±15%
Frequency Response: 10Hz～20KHz
Sensitivity: 95±3dB at:1mW 1KHz 318 simulation ears
Peak Power: 40mW
Rated Power: 15mW
Headphone/Microphone Signal Cable: Ø4mm x 1.3m
Headphone Signal Cable: Ø4mm x 1.2m
Y-type Extension Cable: Ø4mm x 2m
Net Weight: 235g (w/o cable）
Product Content:
① ........................................................................................................................... 1 pc
② Headphone/microphone signal cable .............................................................................................. 1 pc
③ Headphone signal cable .................................................................................................................... 1 pc
④ Y-type extension cable ....................................................................................................................... 1 pc
⑤ Windscreen ......................................................................................................................................... 1 pc
⑥ User manual ....................................................................................................................................... 1 pc
Gaming headphone
-8-
Frequency Response Curve
Listening to all directions, you can "play" the battlefield!-------- TAKSTAR is the well known leading
brand in China electro-acoustic industry. Liberty Gamer is the professional gaming headset developed
by Takstar based on many years of technology accumulation. It features high performance and
comfortable wearing and emphasizes on providing competition advantages and brilliant gaming
experience.
Life is full of rules just like gaming. Enjoy the gaming freely and enjoy your life. Gamers obey the rules
but are not limited by the rules. Try your best to enjoy the gaming and you are the liberty gamer.
Gaming well and living well, you need a good headset.

In-line Controller Operation:
Microphone switch: set
the switch to turn off
the microphone.
Volume knob: turn it
counterclockwise to turn
off the microphone, and
clockwise to increase the
volume
Xbox One Connection:
Note：If Xbox One controller has no 3.5mm connector,
it needs an Xbox One headphone adapter.
Headphone/microphone signal cable
PS 4™ Connection:
PC/Mac/Mobile Connection:
Note: Compatible with the equipment of CTIA standard connector.
˙If your PC has independent headphone/microphone connectors,
please use headphone/microphone splitter cable.
˙
-9--10-
Headphone/microphone signal cable
Note: ˙setup ▶ peripheral equipment ▶ sound device ▶ output to headphone ▶ all sound
˙setup ▶ equipment ▶ audio equipment ▶ output to headphone ▶ select all audio
Headphone/microphone signal cable

Usage:
To avoid hearing loss, please set the playing equipment volume to minimum before connecting the
headphone (or earphone). After wearing the headphone (or earphone), increase the volume to a proper
level. The noise is calculated by dB. The noise above 85 dB leads to hearing loss.
Please pay attention to your operation habit. The relationship of volume & hearing time and hearing
loss as below: the higher the volume is, the shorter the hearing time should be. The more proper the
volume level is, the longer the hearing time can be. The long time hearing at high volume level leads
to permanent hearing loss.
This dB table lists the comparison of some normal sounds and the potential hurt level to your hearing.
The average person can hear the music safely at 70% volume for 4.6 hours every day. It is very important
to know the volume and time when hearing music. Use your equipment sufficiently at safe volume level
to enjoy the outstanding sound performance.
Noise Level
30dB
50-60dB
70dB
85-90dB
100dB
110dB
110-140dB
Quiet office
Vacuum cleaner/hair drier
Food processor
Electric motor saw/electric drill
Sound Source
Whisper
Garbage cleaning machine or cement mixer
Rock & roll concert (it depends)
Consequence on Hearing
It is recommended to hear the sound of 90-100dB for less than 15
minutes
Very quiet
It has some invasion and interference to the telephone talking
85dB (continuously 8 hours) is the level to hurt the hearing
The painful hearing threshold is about 120dB
Hearing the sound over 100dB without any protective measure
leads to permanent hearing loss
Comfortable hearing level is below 60dB
Maintenance:
• After the operation for some time, please use dry cloth or the tower with neutral soapsuds or
detergent for cleaning. Do not put it into water for cleaning.
• Operating the headphone in high temperature or high humidity leads to headphone damage or
shortening the headphone life.
Prohibition
Caution:
DANGER
• To guarantee personal safety, do not wear or keep the headphone close (less than 10cm)
to the pacemaker.
• To guarantee personal safety, do not operate the headphone (or earphone) during driving
or riding or walking.
• Do not connect the cable plug with AC power socket.
• Keep the headphone (or earphone) away from fire to avoid explosion.
WARNING
CAUTION
• Please keep the headphone (or earphone) in dry and clean environment. During operation,
prevent the headphone (or earphone) from water entering into it or dropping or colliding
to avoid damage.
• Supervise the children when they are using this product because this product is not a toy.
• Abide by the relative regulation or law during operation. Do not use this headphone if it is
prohibited by regulation or law to avoid accident.
• The rated power of is 15mW. Please do not operate it at overload status to avoid headphone
(or earphone) damage.
• Please do not disassemble or repair the headphone by yourself to avoid problem happens.
Prohibition
Prohibition
Implementation
Prohibition
Implementation
Disassembly
Prohibited
Implementation
Implementation
• Keep the headphone away from strong magnet to avoid demagnetizing or headphone sensitivity
decreased.
