Takuma AS-1 READER User manual

AS-1 READER User Manual Rev.1.0 1/6
Rev.1.0
TAKUMA SEIKO CO., LTD
Rev.1.0
TAKUMA SEIKO CO., LTD
TEL [phone]
FAX [phone]
User Manual
AS-1 READER

AS-1 READER User Manual Rev.1.0 2 / 6
Rev.1.0
TAKUMA SEIKO CO., LTD
Contents
1 Introduction ........................................................................................................................................... 3
2 Appearance............................................................................................................................................. 3
3 Specification........................................................................................................................................... 3
4 Part names............................................................................................................................................. 4
5 Interface ................................................................................................................................................. 4
6 Operation ............................................................................................................................................... 5
7 REGULATORY COMPLIANCE INFORMATION................................................................................ 6
8 Revision History..................................................................................................................................... 6

AS-1 READER User Manual Rev.1.0 3 / 6
Rev.1.0
TAKUMA SEIKO CO., LTD
1Introduction
This address sensor unit (AS-1) is an RFID low-frequency (LF) 134.2kHz reader/writer
unit for address tag for AGV (Automated Guided Vehicle) system with internal loop antenna.
Address tags are used by the AGV to determine its position while driving.
AS-1 has two types of the functions by factory default, AS-1 READER is an RFID reader function
for use with AGV, AS-1 WRITER is an RFID writer function for writing an ID to a tag.
This user manual describes the AS1 READER unit.
2Appearance
* The appearance of AS-1 WRITER is almost the same as above.
3Specification
Compliant : ISO 11784/11785 134.2kHz RFID
ID Tag type : RI-TRP-WR3P-30 (23mm Glass), RI-TRP-WR2B-30 (32mm Glass)
Dimension : 88mm (W), 73mm (D), 27mm (H)
Weight : 100g
Voltage : DC +12V
Current : 0.5A
A
S-1 READER front view
A
S-1 READER back view

AS-1 READER User Manual Rev.1.0 4 / 6
Rev.1.0
TAKUMA SEIKO CO., LTD
4Part names
5Interface
CN1 (JST B12B-PH-K-S)
Pin No. Pin Name Function Description
1 GND - Ground
2 DC +12V Power
3 /Stop I RF output stop signal to sleep (L: Stop mode)
4 /Clock O Data enable signal (100msec) for Data
5 /D7 O Data bit 7
6 /D6 O Data bit 6
7 /D5 O Data bit 5
8 /D4 O Data bit 4
9 /D3 O Data bit 3
10 /D2 O Data bit 2
11 /D1 O Data bit 1
12 /D0 O Data bit 0
CN1

AS-1 READER User Manual Rev.1.0 5 / 6
Rev.1.0
TAKUMA SEIKO CO., LTD
6Operation
Normal operation:
-Turn on the power.
-AS-1 READER can be read ID value (D7-D0) from RFID tag with /Clock = L.
-User system will be known an ID value by /Clock = L 100msec width.
Stop mode:
-AS-1 READER can be entered stop mode (low power consumption) by /Stop = L.
-Recommendation: If the AGV is not moving, set Stop mode (/Stop = L).

AS-1 READER User Manual Rev.1.0 6 / 6
Rev.1.0
TAKUMA SEIKO CO., LTD
7REGULATORY COMPLIANCE INFORMATION
Product Name: Address sensor unit
Model Name: AS-1 READER
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
TOMITA U.S.A INC. (HEADQUARTERS)
7801 Corporate Blvd. Ste. G, Plain City, OH. 43064 U.S.A.
TEL：[phone] FAX：[phone]
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference
at his own expense.
8Revision History
Rev. Description
1.00 1st release
