High Capacity Feeder (HFC) Setup Guide 1
High Capacity Feeder (HCF) Setup Guide
The optional HCF unit allows for high volume printing.
1. Unpack the High Capacity Feeder from the shipping container
2. Ensure that the printer power switch is set to the OFF [ O ] position.
WARNING: To prevent the danger of electric shock, before installing any options be sure to
turn the power switch of the printer to the off [O] position and disconnect the power cord
from the wall outlet.

Publication No. GEK-89570 Dec 98
2High Capacity Feeder (HFC) Setup Guide
3. Disconnect the power cord from the wall outlet.
4. Lock the two front casters of the HCF unit.

Dec 98 Publication No. GEK-89570
High Capacity Feeder (HFC) Setup Guide 3
5. With the assistance of another person, gently lower the printer onto the HCF unit while
noting the alignment.
6. Pull Tray 2 of the main unit all the way out until it stops. Then lift it up slightly and com-
pletely remove it. Repeat the same for Tray 3, the top cassette in the HCF unit. Remove any
packing materials still inside the cassettes.
CAUTION: The printer weighs about 106 lbs (48 kg). Always carry the printer with the assis-
tance of at lease one other person.When lifting the machine, firmly grip the recessed areas
on the bottoms of both sides of the printer. When lifting the machine, get a firm footing and
bend your knees to avoid possible injuries to your back. Before moving the printer, be sure
to unplug the printer from the AC outlet. The power cord, if damaged, may cause a fire haz-
ard or electric shock.

Publication No. GEK-89570 Dec 98
4High Capacity Feeder (HFC) Setup Guide
7. Locate the two supplied connecting parts and screws.
8. Using one of the thumbscrews, tighten the right connecting part to the printer as indicated.
9. Using the other thumbscrew, similarly secure the left connecting part to the printer.

Dec 98 Publication No. GEK-89570
High Capacity Feeder (HFC) Setup Guide 5
10. Insert Trays 2 and 3 back into the printer and HCF unit respectively.
11. Remove the tape securing the connecting cable of the HCF unit. Securely plug the HCF
cable into the tray connector on the printer.

Publication No. GEK-89570 Dec 98
6High Capacity Feeder (HFC) Setup Guide
12. Connect the power cord to the wall outlet.
13. Turn the printer power switch to the ON [ I ] position.
The installation of the optional High Capacity Feeder (HCF) is now complete.
◆◆◆
