Tangerine TMX-3200 PRO User manual

MX 2042USB
INSTRUCTION MANUAL
TO PREVENT ELECTRONIC SHOCK, DO NOT REMOVE TOP OR BOTTOM COVERS.
DO NOT TRY TO REPAIR IT UNLESS YOUR’RE QUALIFIED SERVICE PERSONNEL.
DISCONNECT POWER CORD BEFORE REMOVING BACK PANEL COVER TO
ACCESS GAIN SWITCH.
WARNING
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT EXPOSE THIS EQUIPMENT
TO RAIN OR MOISTURE!
Mag etic field
CAUTION! DO otice se sitive high-gai equipme t such as pre amplifiers of tape decks
directly above or below the u it. Because the amplifier has a high power de sity It has a
stro g mag etic field which ca i duce hum i to u shielded devise that are locati g
earby.
The field is stro gest just above a d below the u it. If a equipme t rack is used. We
recomme d locati g the amplifier(s) i the bottom of the rack a d the pre amplifier or other
se sitive at the top.
1

WATCH FOR THESE SYMBOLS:
The exclamatio tria gle is used to importa t operati g or mai te a ce i structio s.
The light i g bolt tria gle is used to alert the user to the risk of electric shock.
A. FRONT PANEL SECTION FEATURES
1. MIC1: potentiometer for MIC 1 input volume adjustment.
2. MIC2: potentiometer for MIC 2 input volume adjustment.
3. TALK OVER: mute potentiometer switch
4. CHANNEL 1: dividing volume push rod.
2

5. CROSS FADER: signals volume push rod.
6. CHANNEL 2: dividing volume push rod.
7. AUX: dividing volume push rod.
8. PHONES: headphone volume control
9. TOUCH BUTTON: MP3 Player Control Keyboard
Keyboard note：
Keyboard has six keys, in addition to CMD key, other keys are shortcut keys, which are
Previous, Next, Volume increase, volume reducin and Play / Pause button. To enter the
menu, press CMD button, the Next key corresponds to the first function selection key,
press Vol+ and Vol- button to adjust key parameters and press Play/Pause button to
confirm.
10. MP3 Display
11. d LEVEL: left and right channels level indicator.
12. US PORT: Connect US disk to play MP3 file.
13. POWER SWITCH: Turns the unit ON or OFF. Always turn level controls down before turning
on the unit.
14.AUX/CD: aux and CD input selecting switch
15. MP3/MOVIL: MP3 and MOVIL input selecting switch.
16. LINE/DVD: LINE and DVD input t selecting switch.
B. BACK PANEL SECTION FEATURES
1. AC connection, plug in your power cord here.
2. PHONE, 6.35mm jack.
3. OUTPUT, RCA jack.
3

4. AUX INPUT, RCA jack.
5. CH 2 INPUT, RCA jack.
6. CH 1 INPUT, RCA jack.
7. MIC 2 INPUT, 6.35mm jack.
8. MIC 1 INPUT, 6.35mm jack.
SPECIFICATIONS
INPUT:
DJ Mic ······························1.5mV 2K Ohm balanced
Phono ·······································3mV 47K Ohm
Line ········································150mV 27 Ohm
OUTPUT:
Main ·····································0d 1V 600 Ohms
GENERAL:
Frequency Response ·····················20Hz – 20KHz + /2d
Distortion ···········································0.02%
S/N Ratio ···································better than 80d
Headphone impedance ·······························160 Ohm
Power source ·······························AC 9V 5W
4
