TaoTronics SoundLiberty Pro S20 User manual

User Manual
Questions or Concerns?
[email protected]
FCC ID: 2AVUHTT-BH100
TAOTRONICS
SoundLiberty Pro S20

CONTENTS
YOUR EARBUDS
(01-02)
SETTING UP YOUR EARBUDS
(03-04)
USING YOUR EARBUDS
(04-10)
CLEANING AND MAINTENANCE
(11)
TROUBLESHOOTING
(12-14)
WARRANTY AND SERVICE
(15)
IMPORTANT SAFETY INSTRUCTIONS
(16-17)

0201 SoundLiberty Pro S20 SoundLiberty Pro S20
Charging Indicator
Reset Button
USB-C Charging Port
S M
L XL
YOUR EARBUDS
Noise Cancelling
Microphone
Multifunction
Touch Control
Charging Cable User Manual Quick Start
Guide
Thank You
Card
Acessories
Microphone Charging
Contacts
Eartips (L has been attached to the earbuds)
QUICK
START
GUIDE
Charging Slot
Status Indicator

0403 SoundLiberty Pro S20 SoundLiberty Pro S20
SETTING UP YOUR EARBUDS
USING YOUR EARBUDS
Wearing
Power ON/OFF
Charging
1 2 3
We highly recommend that you fully charge the earbuds before using
them for the first time.
ON OFF
Uncover the lid
to power on.
Place earbuds back
and close the case to
power off.
• Place the two devices to be connected close to each other and turn
off other Bluetooth devices.
• The maximum effective Bluetooth range may vary with the
environmental circumstances. Obstacles (walls, fences, etc.) between
the two devices may shorten the effective range.
Bluetooth Caution
1. Place the earbuds into the charging case.
2. Close the case and connect to any USB charging port with the
included cable.

0605 SoundLiberty Pro S20 SoundLiberty Pro S20
Bluetooth Pairing - Binaural Mode
1. Uncover the lid to turn on the earbuds, they will connect with each other
automatically.
2. Turn on the Bluetooth function on your device and search for
nearby devices.
3. Find “SoundLiberty Pro S20” in the search results, tap to connect.
Each time you power on your earbuds, they will automatically connect
to your last successfully connected device if it is available within the
Bluetooth range.
Bluetooth Pairing - Mono Mode
When Bluetooth connected, you can use either one of the earbuds as per
your preference.
Take out one earbud, and make sure the other one is placed in the case with the
lid covered.
If you want to change to binaural mode, simply take out the other
earbud from the charging case, they will connect with each
other automatically.
Manually Pairing
When the earbuds fail to automatically pair with a new bluetooth device, you can
manually pair as instructed below without clearing pairing history.
1. Place both earbuds back in the charging case with the lid uncovered.
2. Press and hold the reset button for 3 seconds until the status indicator on the
charging case flashes white continuously.
1 2 3
ON SoundLiberty
Pro S20
Status Indicator
Blinking White
Pairing
Being Solid
Connected

0807 SoundLiberty Pro S20 SoundLiberty Pro S20
In-Ear Detection
When either of earbuds is
taken off under music, the
music will be paused and
earbuds will switch to ambient
mode automatically.
Controls and Functions
×1 ×2 ×3
Single Tap Double Tap Triple Tap Hold 2s Hold 4s
Previous Track
Volume Down
Next Track
Volume Up
×3 ×3
Play / Pause
×1 ×1
×2
Voice Assistant
Binaural
Mode
Mono
Mode
Binaural
Mode
Binaural Mode
under music
LR
R
L
R
L
L
Answer
×1
L/R
EQ Mode
ANC on/off
Ambient Mode
Reject
2s 4s
2s 2s
L/R
2s
2s
×2
L/R
Hang Up
L/R
Binaural Mode 4s
R

1009 SoundLiberty Pro S20 SoundLiberty Pro S20
Active Noise Cancelling
When in Binaural mode, ANC mode is turned on automatically after putting on both
earbuds. Tap and hold the touch control on the left earbud to turn on/off ANC mode.
Tap twice to activate ambient mode.
Resetting Your Earbuds
Reset the earbuds if they can not connect with your device properly.
SoundLiberty Pro S20
ABC-XXX
1
Remove "SoundLiberty Pro
S20" from the Bluetooth
device list.
Place the earbuds back into
the charging case and keep the
cover open.
2
3
Press and hold the reset button for
10 seconds until the indicator on
the case flash white three times.
4
Re-pair with your device
as instructed.
To pair with another Bluetooth device, deactivate the Bluetooth
function on the paired device or remove “SoundLiberty Pro S20” from
its Bluetooth list.
10s
Ambient Mode
Transparency
Normal
Mode
ANC Mode
Noise Cancellation
ON

1211 SoundLiberty Pro S20 SoundLiberty Pro S20
TROUBLESHOOTING
Cannot find the earbuds in the
Bluetooth list
• Deactivate the Bluetooth function of previously paired
device or remove the earbuds from the Bluetooth list and
connect again.
• Place the device to be connected close to the earbuds.
Cannot connect with your device
• Place the earbuds and your device close to each other.
Move both devices away from other Bluetooth devices,
microwaves, wireless routers, and other electronics.
• Make sure the Bluetooth function is activated
before pairing.
• Remove the earbuds from the Bluetooth list and
connect again.
• Reset the earbuds and pair again (see “Resetting
Your Earbuds”).
Intermittent Bluetooth connection
• Move the device closer to the earbuds.
• Remove the earbuds from the Bluetooth list and
connect again.
• Turn off other Bluetooth devices to decrease
the interference.
Cannot use a single earbud
• Make sure both earbuds are paired with your device first.
• Then follow the steps to pair the single (left or right)
earbud with your device.
Bluetooth
Connection
CLEANING AND MAINTENANCE
Wipe only with a dry, soft cotton swab or equivalent.
Never insert anything into the nozzle.
Wipe only with a dry, soft cotton swab or equivalent.
Remove the eartips and rinse with a mild detergent
and water.
Thoroughly dry before reattaching them to your earbuds.
• Clean the earbuds and the charging case regularly.
• Keep away from sharp objects to avoid scratches.
• Place in a dry and shady place if they are not in use for a long time.
• DO NOT clean with detergent or chemicals.

1413 SoundLiberty Pro S20 SoundLiberty Pro S20
No sound from one earbud
• Make sure the earbuds are within range of
each other.
• Make sure the in-ear detection sensor is not blocked.
• Place both earbuds back to the charging case and
then take them out.
Poor sound quality
• Clear any debris from the earbud nozzles.
• Place both devices close to each other or remove the
obstacles between them.
• Try with a different audio source.
Microphone does not receive sound
• Check that the microphone is not blocked
or covered.
• Make sure the microphone is not muted on
your phone.
• Remove the earbuds from the Bluetooth list and
connect again.
Cannot hear own voice while on a
phone call
• Check that the microphone is not blocked
or covered.
Cannot hear caller while on a phone call
• Set the volume to a higher level.
Sound Help
Earbuds do not turn on
• Battery low. Place both earbuds back into the charging
case to charge.
Failed to charge the Earbuds
• Place both earbuds in the charging case properly until
they magnetically snap into place.
• Make sure the charging case is
fully charged.
Earbuds do not respond to touch control
• Make sure you are touching the correct touch control
area.
• Make sure you put on the earbuds properly.
• Make sure your fingers are dry.
• Reset the earbuds and pair again (see “Resetting Your
Earbuds”).
The troubleshooting addresses the most common problems. If problems persist, feel
free to contact the Customer Support at suppor[email protected].
Earbuds

15 SoundLiberty Pro S20
WARRANTY AND SERVICE
This product is covered with TaoTroincs product and labor warranty for 12
months from the date of its original purchase.
The warranty will not apply in cases of:
• Accident, misuse, or repairs performed by unauthorized personnel.
• Any unit that has been tampered with or used for commercial purpose.
• Normal wear and tear of wearable parts.
• Use of force, damage caused by external influences.
• Damage caused by non-observance of the User Manual, e.g. connection to
an unsuitable mains supply or non-compliance with the instructions.
• Partially or completely dismantled appliances.
• Defects caused by or resulting from damages from shipping or from
repairs, service, or alteration to the product or any of its parts that have
been performed by a repair person not authorized by Boltune.
We can only provide after sales service for products that are sold by Boltune
or Boltune authorized retailers and distributors. If you have purchased your
unit from a different place, please contact your seller for return and warranty
issues.
* Please have your invoice and order ID ready before contacting Customer
Support.
IMPORTANT SAFETY INSTRUCTIONS
Caution
• DO NOT expose this product to high temperatures.
• DO NOT immerse the earbuds into water or expose them to humidity for a
long time.
Please read the instructions thoroughly before using this product and retain it
for future reference.
Hearing Safety
• DO NOT wear earbuds with high volume for a long time to avoid damaging
your hearing.
• Set the earbuds to low volume before you put them on, then increase the
volume gradually as per your preference.
• DO NOT set volume too high to stay aware of
your surroundings.
• Please refer to local laws and regulations if you want to answer phone calls
via this device during driving.
• For your safety, avoid distraction from music or phone calls when you are
driving or doing other activities with
potential dangers.
Warning: Please set the volume to proper level to avoid
hearing damages
16SoundLiberty Pro S20
