TaoTronics TT-SK019 Instruction manual

Soundbar Connection
Instructions
1 2 3
Optical Input Coaxial Input DC Input RCA AUX Input
L
AUXCOAXIAL DC18V2.2AOPTICAL
R
Overview of the Ports
Option 1: Optical (Preferred)
A: Cable Connection
Note: Make sure to remove the protective covers on the ends of
the cable.
Incorrect insertion will damage the port and / or the connector.
Connect to your TV Set:
OPTICAL IN
OPTACAL OUT
OPTICAL
OUT
OPTICAL
B. Sound Bar
Press the OPT button on the remote or press the Power Button on the sound bar
to select Optical Mode, the “OPT” indicator will light up on the display.
OPT
AUX
Option 2: AUX (RCA)
A. Cable Connection
B. Sound Bar
R
AUX
L
(RED)
(WHITE)
AUDIO OUT
Match the R / L (RED/WHITE) ports for correct connection. Press the AUX button
on the remote or the Power Button on the sound bar to turn on AUX mode, the
AUX Indicator will light up.
BT AUX
OPT
COAX
BT AUX
OPT
COAX

4 5 6
Option 3: Coaxial
A. Cable Connection
B. Sound Bar
Press the COAX button on the remote, the COA Indicator will light up.
BT AUX
OPT
COAX
COAX
Connecting with Other Host Appliances
Note
·If you choose the 3.5mm to RCA cable, be sure to select the audio output
port on the TV. To connect with the optical cable, please set your TV audio
output to PCM on your TV remote (TV Setting – Sound - Select Speaker to
External Speaker / Turn o TV Speaker).
·This Soundbar does not support Dolby Audio and DTS.
OPTICAL
DIGITAL IN
VIDEO
DVD
Blue-ray Disc
COAXIAL
R
AUX
L
(RED)
(WHITE)
AUDIO OUT
COAXIAL OUT
COAXIAL
DIGITAL
OUT
Coaxial Cable Not Included
Optical Input Coaxial Input DC Input RCA AUX Input
L
AUXCOAXIALOPTICAL
R
Drill 2 holes of 0.3 in / 8 mm in diameter each on the wall, refer to the diagram below for
installation.
Wall-Mounting the Sound Bar
27.5
in
(70.
0
c
m)
COAXIAL
TV
W
A
L
L
WA
L
L
DC18V2.2A
