Targus AMP08AP User manual

USER GUIDE
2.4GHz 4 Key
Laser Wireless
Presenter
Features and specifications are subject to change without notice. All
trademarks are the property of their respective owners © 2007, Targus
Group International, Inc. and Targus, Inc. Manufacturer / Importer:
Unit 1202-07, 12/F, Tower 2, Metroplaza, No. 223 Hing Fong Road,
Kwai Fong, N.T. Hong Kong
AMP08AP / 410-1177-006A

TABLE OF CONTENTS
Targus 2.4GHz 4 Key Laser Wireless Presenter ...........2
˧˔˥˚˨˦ྤᒵዝᝑᕴփᆜᥲ୴ق......................10
˧˔˥˚˨˦㡰优ዝ兄ᕴ㡕ᆜᖿ٠قᕴ..........................18
{Gⱨ㉔GYU[no¡䘸⤼㥔䉤....................................26
ϟΦυϙϧϏΩπυϗϟέλϟηϏυϫϣυϨόϔτπυϨϏσζϨωτπϏτηϫϟηϏυϫϟχϟέϏυϫΤϏΩ
䎷䎤䎵䎪䎸䎶䮳䯃䭽䯃䮤䭫䮺䮆ઃ䮶䭫䮫䮳䮀䮞䮳䮃䮺䮆䯃䎃 .............42
1

AVOID EXPOSURE--HAZARDOUS ELECTROMAGNETIC RADIATION EMITTED FROM THIS
APERTURE.
LASER RADIATION. DO NOT STARE INTO THE BEAM OR VIEW DIRECTLY WITH OPTICAL
INSTRUMENTS. CLASS 2 LASER PRODUCT.
NEVER POINT A LASER BEAM INTO A PERSON’S EYES OR VIEW A LASER BEAM
DIRECTLY, AS PROLONGED EXPOSURE CAN BE HAZARDOUS TO THE EYES.
MOMENTARY EXPOSURE FROM A LASER POINTER, SUCH AS AN INADVERTENT SWEEP
OF THE LIGHT ACROSS A PERSON'S EYES, MAY CAUSE TEMPORARY FLASH BLINDNESS
SIMILAR TO THE EFFECT OF A CAMERA FLASH BULB. ALTHOUGH THIS CONDITION IS
TEMPORARY, IT CAN BECOME MORE DANGEROUS IF THE EXPOSED PERSON IS
ENGAGED IN A VISION-CRITICAL ACTIVITY SUCH AS DRIVING.
CAUTION: ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE
PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S AUTHORITY TO
OPERATE THE EQUIPMENT.
THIS DEVICE AND ITS ANTENNA(S) MUST NOT BE CO-LOCATED OR OPERATING IN
CONJUNCTION WITH ANY OTHER ANTENNA OR TRANSMITTER.
YOUR DEVICE CONTAINS A LOW POWER TRANSMITTER. WHEN DEVICE IS TRANSMITTED
IT SENDS OUT RADIO FREQUENCY (RF) SIGNAL.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.
SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE
EQUIPMENT.
2

TARGUS 2.4GHZ 4 KEY
LASER WIRELESS
PRESENTER
Introduction
Congratulations on your purchase of the Targus 2.4GHz 4 Key
Laser Wireless Presenter. This combination presenter / laser
pointer features four control buttons that emulate the
command keys in PowerPoint®. It offers true plug-and-play
capability, with no need for software drivers, and 2.4GHz RF
technology for controlling your presentations up to 50 feet
away (15m).
Package Contents
• Wireless presenter
• USB receiver
• 1 x AAA battery (Non-rechargeable)
• Carrying pouch
• User guide
System Requirements
Hardware
• USB port
Operating System
• Windows® 2000/XP
• Windows Vista™
3

Setting Up Your Wireless
Presenter
Targus 2.4GHz 4 Key Laser Wireless Presenter
Installing the Battery
2. Insert the supplied battery, making sure the positive (+)
and negative (-) ends of the battery match the polarity
indicators inside the battery housing.
Battery
Cover
1. Press the battery cover hinge on the bottom of the
presenter and open the cover.
3. Close the battery cover back into position until it “clicks”
firmly into place.
4

Targus 2.4GHz 4 Key Laser Wireless Presenter
Synchronizing Your Wireless
Presenter
The receiver and presenter should synch up automatically.
However, in some cases they may not synchronize properly
due to environmental interference or other causes. If this is the
case, you must re-establish the link. To do this press and
release the connect button on the receiver, then press and
release the connect button on the bottom of the presenter.
Connect button
NOTE: TO TURN THE PRESENTER OFF, SIMPLY PLACE THE USB RECEIVER BACK INTO
THE STORAGE SLOT. THIS WILL MAXIMIZE BATTERY LIFE WHEN NOT IN USE.
Connecting The Receiver
Plug the USB receiver into an open USB port on your
computer. Your computer's operating system will identify the
receiver and install the default driver.
5

Targus 2.4GHz 4 Key Laser Wireless Presenter
(2)
(3)
(1)
(4)
6

Targus 2.4GHz 4 Key Laser Wireless Presenter
Using Your Wireless
Presenter
Page up
Laser button
Page down
Darken screen
Laser pointer
Safety Measures
• To avoid possible eye damage, never point the
presenter's laser at people, especially their faces, or look
directly into the presenter's laser beam.
• Avoid pointing the presenter's laser beam at a mirror or
other highly-reflective surface.
• Keep the presenter away from young children.
• Never view the presenter's laser beam using telescopic
devices, such as a microscope or binoculars.
• Any attempt to disassemble, adjust or repair the
presenter may result in exposure to laser light or other
safety hazards.
7

Transmitter
Receiver
RF • 2400-2483.5Mhz
Interface • USB 1.1 or later
Power • USB Bus Powered 5V DC
Product Specification
RF • 2400-2483.5Mhz
Laser Pointer • Laser Wavelength: 640nm - 665nm
• Laser Output Power: < 1mW
• Safety: Class II
Battery Type • Alkaline battery AAA
Effective RF
Communication Range • up to 15 meters
RF output Power • 1.5mW max
Power Consumption • Max 62mA
Targus 2.4GHz 4 Key Laser Wireless Presenter
Troubleshooting
What do I do if the response time of the presenter is slow
or it intermittently stops working?
• Make sure that the presenter is within 50 feet (15 m) of its
receiver.
• Increase the distance between the presenter's receiver and
the base units of other wireless devices.
• Turn off any wireless devices and their base units that are
near the presenter's receiver.
• Replace the battery.
• Synchronize the receiver and presenter. See “Synchronizing
Your Wireless Presenter”
8

Regulatory Compliance
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesired operation.
FCC Statement
Te s t e d t o C o m p l y
This equipment has been tested and found to comply with the
limits of a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna;
• Increase the separation between the equipment and receiver;
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected;
• Consult the dealer or an experienced radio/TV technician for
help.
Changes or modifications not authorized by the party responsible
for compliance could void the user’s authority to operate this
product.
Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries. All trademarks and registered
trademarks are the properties of their respective owners. All rights reserved.
Targus 2.4GHz 4 Key Laser Wireless Presenter
9
