Tatung TICT-1506MW User manual

Model: TICT-1506MW
Pre-set Timer Function
Power Temp. warm
This manual contains important safety instructions.
Please read the manual thoroughly before use.
Owner’ s Induction Cooktop Manual

CONTENTS
1
PRODUCT INTRODUCTION
OPERATING INSTRUCTIONS
COMPATIBLE COOKWARE
CLEANING AND MAINTENANCE
TROUBLESHOOTING
WARRANTY & DISCLAIMER
10
8
SAFEGUARDS & SAFETY INSTRUCTIONS 2
13
14
14
15

SAFEGUARDS & SAFETY INSTRUCTIONS
IMPORTANT:
Read all instructions before operating the unit.
When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, property damage,
electrical shock and personal injury, including the following:
2
Safeguards & Safety Instructions
SAVE THESE INSTRUCTIONS.
Do not touch hot surfaces.
To protect against electrical shock do not immerse cord/plugs in
water or other liquid.
Close supervision is necessary when the unit is being used, especially near
children.
Unplug unit when not in use and before cleaning. Allow unit to cool
before moving or cleaning.
Never operate the unit with a damaged cord or plug or after the unit has
malfunctioned or have been damaged in any manner. Return
appliance to Tatung’s service facility for examination, repair or adjustments.
The use of accessories or cooking pans which are not recommended by
Tatung may cause fires or injuries.
Do not use outdoors or for commercial use. This unit is for household use only.
Do not let power cord hang over edge of table or counter, or touch hot surfaces.
Do not place on or near a hot gas, electric burner, or in a heated oven.
Extreme caution must be used when moving an appliance containing hot
oil or other hot liquids.
Always attach plug to appliance first, then plug cord into the wall outlet. To
disconnect, turn off all controls then remove plug from wall outlet
Do not use appliance for other than intended use.
POLARIZED PLUG: This appliance has a polarized plug (one blade is wider
than the other). As a safety feature, this plug will fit in a polarized outlet
only one way. If the plug does not fit fully in the outlet, then try pluggin it
in the other way. If it still does not fit, contact a qualified electrician. Do not
attempt to defeat this safety feature.
Be cautious when opening any lid while cooking.
Do not use if ceramic cooktop should break or crack, as cleaning solutions
and spillovers may penetrate the broken cook-top and may create
a risk of an electric shock.
Clean Cook-Top with Caution – If a wet sponge or cloth is used to wipe
spills on a hot cooking to avoid steam burns; somearea, be careful
cleaners can produce noxious fumes if applied to a hot surface.
Do not place metallic objects such as knives, forks, spoons and lids on
or near the appliance
If you have any questions or do not understand anything from this manual
please contact Tatung at 800-829-2850 Ext. 816

SAFEGUARDS & SAFETY INSTRUCTIONS
(1) This device may not cause harmful interference.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(2) This device must accept any interference received, including
interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
product.
NOTE: This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on.
The user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorientate or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
the dealer or an experiencedwhich the receiver is connected. Consult
radio/TV technician for help.
Power Cord Safeguards:
A short power-supply cord is provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord.
If a long detachable power-supply cord or extension cord is used:
3
Safeguards & Safety Instructions
• The marked electrical rating of the cord or extension cord should be at
least as great as the electrical rating of the appliance.
• The cord should be a grounding 3-wire cord Connect only to properly.
grounded outlet
• Do not let power cord hang over edge of table or counter, or touch hot
surfaces.
• If using an extension cord to connect the Induction Cooktop, please note
that a damaged extension cord can cause the unit to malfunction. Always
check your extension cord for damage and be sure it is compliant with the
required voltage. Be sure not to place the cord where people can trip over it

SAFEGUARDS & SAFETY INSTRUCTIONS
4
Safeguards & Safety Instructions
Never heat food in sealed containers, such
as compressed products, cans, or coffee
pots, to avoid explosion caused by heat
expansion.
To avoid affecting product performance and
to prevent injury, do not heat empty pots.
When in use, do not leave the appliance
without supervision for a long time. When
leaving the appliance without supervision,
make sure there is enough water in the pot.
To avoid accidents, do not place the
induction cooker, when in use, on a gas
stove.(The magnetic lines can heat the
metal parts of the gas stove).
The utensils provided for the induction
cooker can only be used for cooking with it.
These cooking utensils cannot be used on
both induction cooker and gas stove.
Do not heat iron items on the induction
cooker heating plate to avoid danger
caused by high temperatures.
For safety reasons and to avoid damage to the appliance or
injuries to people, please abide by all the safety instructions
presented in the manual. Ignoring safety warnings may
result in injuries or fires. The appliance should never be
operated by children and special care should be taken when
the unit is in their presence.
Pacemakers:
People with heart pacemakers should
consult a doctor before using or going near
the inductions cooker.

5
Safeguards & Safety Instructions
SAFEGUARDS & SAFETY INSTRUCTIONS
To avoid danger, do not insert any foreign
object, such as iron wire, nor block the air
ventilation opening or air entry port.
To avoid danger, do not place paper,
aluminium foil, cloth or other unsuitable
articles onto the induction cooker heating
plate for indirect heating.
When using the induction cooker, do not
put it on any metal platform (such as iron,
stainless steel or aluminium), or place a
non-metal pad less than 10cm thick on the
heating plate.
>5” >5”
Unplug the power cord from the outlet after
use to avoid fire and/or damage to the
electronic components, caused by
prolonged electrical connection.
Avoid impact damage to the heating plate.
If damaged, please stop using it and
contact Tatung’s Service Department
Allow at least 5” of sufficient space around
the cooking area and always place unit on
a flat level surface. Do not block the
ventilation opening as this may cause the
appliance to overheat.
Do not let children operate the
appliance. Also, use close supervision
when children are near.
Do not immerse the induction cooker
in water or any liquids.

6
Safety Instructions
≥15A
To avoid danger, if the power cord is
damaged please contact Tatung to replace
the power cord.
Please keep the Induction Cooker clean.
Protect the induction cooker from bugs,
dust and humidity. When not in use for a
long period, please properly store it
after cleaning
To avoid cracks and other damages,
please do not touch the product with
sharp objects. If a crack is found, turn
off the appliance to avoid any electrical
shock that might occur and contact Tatung.
Do not use the induction cooker near a gas
stove, kerosene stove, gas cooker or in any
space with an open fire or an environment
with high temperature.
Metal objects, such as knives, forks, spoons
and lids, should not be put on the surface of
the cooking area.
The cooker cannot be overloaded.
Overloading the plate may damage the
plastic cover and cooker plate.
I.SAFETY INSTRUCTIONS
Always operate the unit on a flat,
leveled, non-metallic surface. Do not
use the induction cooker on
flammable surfaces like carpet or
table cloth.
Use only a high quality power outlet
with the power rating, equal or above
15A. Do not connect the Induction
Cooktop to the same outlet with other
household appliances such as air
conditioners, microwaves, etc. As it
could overload the outlet.
The max weight capacity is 8 kg.

7
Safety Instructions
When operating the appliance or after
moving the pot, the cooking area will remain
hot for a period of time. Do not touch it. Be
careful of scalding caused by the high
temperature.
Danger of
scalding
Periodically check that there are
are no object (glass, paper, etc)
that could obstruct the inlet under
under your induction cooker
Note: All the test and authentication
of this product is based on the
SUS430 cookware(bottom diameter
180±10mm).The other cookwares
can not guarantee the best results
and performance.
The instructions shall state that
appliances are not intended to be
operated by means of an external
timer or separate remote-control
system.
Clean after each use. Wipe down the unit
with a damp cloth.
This product is intended for household
use only. Not for commercial use.
Never cook with an empty pot.
Anyone who has not fully understand
all operating and safety instructions
in this manual is not qualified to
operate nor clean the appliance

8
Product Introduction
II.PRODUCT INTRODUCTION
Model
TICT-1506MW
Applied
voltage/frequency
Rated
power
Dimension
(Inches)
Weight
(lbs)
120Vac,60Hz 1500W 14x11.4x2.4 5.5
Specifications
The induction cooker is able to meet various kinds of cooking
demands by electromagnetic heating. High thermal efficiency,
is safe and reliable, and easy to clean.
Air vent
ne
Ceramic plate
Control panel
Cooking zo
indicator
Power cord
Air entry
Pre-set Timer Function
Power Temp. warm
Identifying Parts

9
Product Introduction
Control Panel
Before using New Induction cooker
Read this guide, and taking special note of the “Safeguards
and Safety Instructions” section.
Remove any protective film that may still be on your ceramic
plate.
Pre-set Timer Function
Power Temp. warm
1. ON/STANDBY 2. Power regulating
3. Timer 4. Function select
5. Pre-set
1
2435
The controls respond to touch, so you don't need to apply
any pressure.
Use the ball of your finger, not its tip.
You will hear a beep each time a touch is registered.
Make sure the controls are always clean, dry, and that
there is no object (e.g. a utensil or a cloth) covering them.
Even a thin film of water may make the controls difficult to
operate.
Using the Touch Controls

10
Operation Instructions
III. OPERA INSTRUCTIONTING S
Installation
Turn on
After pressing the “ON/STANDBY” button, the induction
cooker is ready for heating. Press the function tobutton
select the required mode
After pressing the “ON/STANDBY” button, if no function
button is pressed for 10 seconds, the induction cooker
will switch off automatically.
After pressing the function button, if there is no proper
pot on the ceramic plate, the induction cooker will not
heat up and the alarm will sound to indicate that a pot is
required then ten seconds later the unit will power off
automatically.
Function
After switching on the induction cooker, press the
corresponding function button to enter the desired
cooking mode.
You can adjust the power level by pressing “+” or “-”
Select a safe location to use the induction cooker. Make
sure it is 5” away from other appliances, walls, or other
objects.
Make sure that the pot is placed in the center of the ceramic
plate. Refer to page 13 in this manual for approved
ferromagnetic cookware.
Plug in the power cord; a beep will sound.
The power and temperature of different levels are as following
form:
Level
Power /W
Temp. / ℉
1 2 3 4 5 6 7 8 9 10
120 300 400 600 800 900 1000 1100 1300 1500
140 175 212 245 280 320 355 370 390 425

11
Operation Instructions
III. OPERAT INSTRUCTIONSING
Function
Temperature Mode
Power Mode
Keep Warm Mode
Press the “Function” button, choose “Temp.”mode, the
buzzer will sound and “Temp.” indicator lamp will light up.
When in temperature mode, the default temperature level
shall be level 5, you can by pressingadjust the temperature level
the “+” or “-” button.
Press the “Function” button, choose “Power” mode, the
buzzer will sound
and then the “Power” indicator lamp
indicator lamp will light up.
When in power mode, the default power level shall be
level 8, y the “+” orou can adjust the power level by pressing
“-” button.
Press the “ ” button, choose “
,
Function Keep Warm”mode
the buzzer and “Keepwill sound the Warm”
indicator lamp will light up.
In this mode, the fire level CAN NOT be adjusted.
Timer
Press the “ ” button to enter the timer mode. WhenTimer
the timer indicator lights up and the numbers blink on the
display, press the “+” or “-” button to adjust the time
duration. from 1 minute to 3 hours.The timer can be adjusted
Once the number on thethe time is set
on the display will blink for several seconds.
The induction cooker counting down.will start
Once the timer is complete, the induction cooker
will automatically power off.

12
III. OPERAT INSTRUCTIONSING
How To Lock
Press the “+” and “-” button at the same time to enable the “Lock
function. The indicator Now only the“Lock” lamp will light up.
“ON/STANDBY” button can be used to switch off the
induction cooker, areall other operating functions not permitted
Press the “+” and “-” button at the same time for several
seconds to the lock function. The “ ” indicatordisable Lock
lamp will turn off.
Power Off
When the operating time is over, the induction cooker
will automatically.power off
To “Power Off” the unit manually simply press the
“ON/STANDBY” button to turn the appliance off.
Preset
Press the “Preset” button ,then press the “+” or “-”
button to adjust the preset time.
After the preset is finished, the induction cooker will
count down to the preset time.
When the preset time is met, the induction cooker will
automatically return to the normal working mode.
Operation Instructions
10
The default time of each function is two hours, which is
irrelevant to the function mode.
Level
Default time of
function（Hour）
Default time of function

IV. COMPATIBLE COOKWARE
Iron oil frying
pan
Stainless steel Iron pan Iron kettle
Enamel stainless
steel kettle
Enamel cooking
utensil
Iron plate
Induction-compatible cookware contains ferromagnetic
materials – in other words, it contains iron, or has a layer with
magnetic properties.
Cookware must have a flat smooth bottom with the diameter
more than 4½’’ and less than 8’’.
After the first use, some white spots may appear at the
bottom of the pot. Please note that this is normal
To clean the white spots, simply pour vinegar into the pot and heat
Aluminum, copper or glass cookware will not work unless they
have a layer on the bottom with magnetic properties.
it to 140℉-180℉, then wipe the spots away with a brush.
If the pot is removed the induction cooker will stop heating
immediately buzzer 10 seconds, then it will go into, a will sound for
standby mode automatically. Note: To tell if a pot or pan is
induction-compatible, hold a magnet to the bottom. If it clings,
the cookware will work on an induction cooktop
V. CLEANING AND MAINTENANCE
After a period of time the opening air inlets/outlets will collect dust
please wipe with a soft dry cloth. Dust in the air inlet
and outlet can be cleaned by using a soft brush or a mini
vacuum cleaner.
Note: Never rinse the unit in water
13
Compatible Cookware
Always unplug the appliance and allow the unit to cool down
before cleaning.

Is the cookware compatible Refer to page 13
V. CLEANING AND MAINTENANCE
VI. TROUBLESHOOTING
Issue Cause (Points to Check)
pressing the “ON/STANDBY” key, the
indicator and display do not light up.
The “ON/STANDBY” indicator lights
up and the display works normally,
but heating does not start.
Is the power plug properly connected?
Is the switch, power outlet, fuse or power cord
damaged?
Is the cookware compatible.Refer to page 13.
Is the appliance in a “Preset” working status?
Is the temperature of the oil too high when frying
dishes?
Is the environment temperature high?
Is the air inlet or air outlet of the induction cooker
blocked?
Is the default heating time of the induction cooker
over?
The self-safety protection of the induction cooker
starts, wait for several minutes and connect power
to use it.
Code of failure
E3 E6
Wait a moment and press the “ON/STANDBY” button
when the temperature of the hotplate becomes normal
the induction hotplate will operate as usual.
E7 E8 Turn off the hotplate, when the voltage becomes
normal, and then turn on the hotplate; it will operate as
usual.
E1 E2 E4
EcE5 Eb
Emergency
14
Troubleshooting
Please contact our service dept. 1-800-827-2850 Ext. 816
clean oil spots on the cooker plate, use a soft moist c loth
with a little toothpaste or mild detergent.
When product is not in use for a long period of time, disconnect
the power plug from the power outlet and store the induction
cooker away from any dust or bugs
cord. If product fails to work properly please contact our service department at
800-827-2850 Ext. 816 or email us at [email protected]
To
During use if the product is not working properly please immediately unplug the power
After plugging in the power cord and
While cooking the induction
cooker stops heating up.

15
VII.WARRANTYnf
in this User's Manual is s ubject to change without notice .Tatung
assumes no responsibility for any inaccuracies that may be contained in this
User's Manual. If you find information in this manual that is incorrect, misleading,
or incomplete, we would appreciate your comments and suggestion
VII.
s
DISCLAIMER
Tatung USA One Year Limited Warranty
1. One year carry in waranty from day of purchase.
2. During the warranty, Tatung USA will not be responsible for any of the
following conditions:
a. Improper use or self-disassembly.
b. Improper maintenance.
c. No receipt.
d. Exceeds one year from the purchased date.
e. Natural disaster or product was not used with required voltage.
f. Commercial use
3. During the warranty period, Tatung USA is only resposible for product
repairs, product replacement, and return delivery fee after product is
serviced. Customers are responsible for the postage fee for shipping
products for repair or replacement to Tatung USA.
Tatung USA Customer Service
2000 E. Carson Street
Carson, CA 90810
1-800-827-2850 Ext. 842
Warranty
Information
[email protected]

Pre-set Timer Function
Power Temp. warm
電 磁 爐 使 用 說 明 書
型號：TICT-1506MW
本說明書包含重要安全說明。在使用之前請先詳細閱讀本使用說明書。

1
目錄
安全注意事項和安全說明 。。。。。。。。。。。。。。。。。。。。。。。。 。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。2
產品介紹 。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。8
操作說明 。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。 10
適用炊具 。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。
。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。
。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。 。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。13
清潔與維護 。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。13
異常現象自檢 。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。
。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。
。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。
。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。
。。。。。。。。。。。。。。。。。。。。。。。。14
保修和免責聲明 。。。。。。。。。。。。。。。。。
。。。。。。。。。。。
。15

2
Important Safeguards
注意事項：
在使用電器前，請閱讀全部說明。
在使用電器時，為了減少火災、財產損失、觸電和人身傷害，應
務必遵循包括
如下內容的基本安全注意事項：
請不要觸摸熱表面。
為了避免觸電，請不要將電源線或插座放入水或其他液體內。
使用電磁爐時，特別是有兒童在旁邊時，請務必密切監護。
在設備不使用和拆除部件清洗時前，請務必從插座上拔掉插頭。在搬動或清理
設備之前，請將設備冷卻。
電源線或插頭損壞，或電器出現故障，或以任何方式損壞，請不要使用此電器。
請將電器送往附近的Tatung公司授權維修中心檢查、修理或調節。
使用電器製造商不推薦的附件或炊具可能導致火災或傷害。
請不要室外使用或用於商業用途。本電器僅供家庭使用。
請不要將電源線掛在桌櫃邊緣上，或接觸灼熱表面。
請不要將該設備放在熱氣或電氣燃燒器上面或附近，或加熱的烤箱內。
在移動裝有熱油或其他灼熱液體的設備時，請必須極為小心。
使用時，先插好電磁爐的插頭，然後插好牆壁插座上插頭。為斷開電源，請關
閉所有控制開關，然後從牆壁插座上拔掉插頭。
請不要將電磁爐用於非預期用途。
極化插頭：本電器配有一個極化插頭（一個插片比另一個寬）。考慮到安全特
性，這種插頭只單向插入極化插座。如果插頭沒有完全插入插座內，則嘗試用
另外一個方向插入。如果還插不進去，請與合格的電工聯繫。請不要試圖消除
這種安全特性。
烹飪時，拿掉蓋子必須極為小心。
陶瓷面板損壞或破裂時不要烹飪，如果灶面板損壞，洗滌液和溢出物可能滲透
到破裂的灶面板內，可能會導致觸電風險。
請小心清洗爐灶面板。如果用濕海綿或布擦拭灼熱烹飪區域的溢出物時，一定
要小心，避免蒸汽灼傷，有些清洗劑如果應用到灼熱表面可能會產生有毒氣體。
金屬物體如刀、叉、勺和蓋不要放在或接近電器烹飪區域表面。
請保管好本說明書！
如果您對本產品有任何問題或對本說明書有任何疑問，
請撥打電話800-829-2850轉816 聯繫大同美国公司。
安全注意事項和安全說明

3
Important Safeguards
安全注意事項和安全說明
操作時，請遵守如下兩個條件：
（1）本裝置不能引起有害的干擾。
（2）本裝置必須接受收到的任何干擾，包括可能導致不适操作的干擾。
小心：如沒有经过厂商明確批准的變更或修改，會使用戶丧失操作本產
品的權利，与产品保固责任。
注釋：本設備產生、使用並輻射無線電頻率能量，如果沒有按照說明書安裝與
使用，可能對無線電通信造成有害干擾。所以，不能保證特殊裝置內不會發生
干擾。如果該設備確實對無線電或電視接收造成有害干擾，可以通過打開和關
閉設備來確定。
重新定向或重新定位接收天線。
增加設備和接收器之間的距離。
將設備連接到電路上的一個插座，該插座與接收器連接的插座不同。請諮詢經
銷商或有經驗的無線電/電視技術人員尋求幫助。
電源線安全保護：
本产品提供短電源線，以減少較長電源線纏繞或絆倒的風險。
在使用較長的可拆卸電源線或延長線時：
電源線或延長線的標記電氣額定值應至少與電器的電氣額定值一樣大。
電源線應為接地三線電源線。僅在接地插座連接正確時使用。
請不要將電源線掛在桌櫃邊緣上，或接觸灼熱表面。
如果使用延長線連接電磁爐時，請知悉破損的延長線會引起電器故障。請確保
檢查延長線是否破損以及使用的電壓是否符合要求。請確保人不會被電源線無
意絆倒。
