Tatung POS85M User manual

USER’S
MANUAL
POS85M
Intel®Pentium®M
15”Point-of-SaleTerminal
POS85M M1

Copyright Notice
POS85M POS System
With LCD / Touchscreen
OPERATION MANUAL
COPYRIGHT NOTICE
This operation manual is meant to assist users in installing and setting up the
system. The information contained in this document is subject to change
without prior any notice.
This manual is copyrighted July 2008. You may not reproduce or transmit in
any form or by any means, electronic, or mechanical, including photocopying
and recording.
ACKNOWLEDGEMENTS
All trademarks and registered trademarks mentioned herein are the property
of their respective owners.
CE NOTICE
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.

Copyright Notice
FCC NOTICE
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void your
authority to operate such equipment.
CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
WARNING! Some internal parts of the system may have high electrical voltage. And
therefore we strongly recommend that qualified engineers can open and disassemble the
system.
The LCD and Touchscreen are easily breakable, please handle them with extra care.

Contents
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION
1-1 About This Manual ....................................................... 1-2
1-2 POS Illustration ............................................................. 1-3
1-3 System Specification ..................................................... 1-6
1-4 Safety Precautions ......................................................... 1-10
CHAPTER 2 SYSTEM CONFIGURATION
2-1 Jumper & Connector Quick Reference Table ............... 2-2
2-2 Component Locations ................................................... 2-3
2-3 How to Set the Jumpers ................................................ 2-4
2-4 Printer Connector ……………………………………. 2-6
2-5 COM Port Connector ………………………………… 2-7
2-6 COM1 RI and Voltage Selection …………………….. 2-9
2-7 COM2 RI and Voltage Selection …………………….. 2-10
2-8 COM3 RI and Voltage Selection …………………….. 2-11
2-9 COM4 RI and Voltage Selection …………………….. 2-12
2-10 Keyboard & PS/2 Mouse Connector …………………. 2-13
2-11 USB Connector ………………………………………. 2-13
2-12 Cash Drawer Connector ……………………………… 2-14
2-13 Cash Drawer Power Selection ………………………... 2-15
2-14 LAN & USB Connector ……………………………… 2-16
2-15 VGA Connector ……………………………………… 2-17
2-16 Power Switch Connector …………………………….. 2-17
2-17 Power/HDD/LAN LED Connector ………………….. 2-18
2-18 External Speaker Connector …………………………. 2-18
2-19 Inverter Connector …………………………………… 2-18
2-20 MSR/ Card Reader Connector ……………………….. 2-19
2-21 LVDS Connector …………………………………….. 2-19
2-22 Hard Disk Drive Connector ………………………….. 2-20
2-23 Touch Panel Connector ………………………………. 2-21
2-24 FAN Connector ………………………………………. 2-21
2-25 Clear CMOS Data Selection …………………………. 2-22
CHAPTER 3 SOFTWARE UTILITIES
3-1 Introduction ................................................................... 3-2
3-2 VGA Driver Utility …………………………….……. 3-3
3-3 Flash BIOS Update ....................................................... 3-4
3-4 LAN Driver Utility ....................................................... 3-6

Contents
3-5 Sound Driver Utility ..................................................... 3-7
3-6 Intel® Chipset Software Installation Utility ................ 3-8
3-7 USB2.0 Software Installation Utility ………………… 3-9
3-8 Touch Screen Driver Utility ………………………….. 3-10
3-9 Wireless Driver Utility (Optional) …………………… 3-11
CHAPTER 4 AWARD BIOS SETUP
4-1 Introduction ................................................................... 4-2
4-2 Entering Setup ............................................................... 4-3
4-3 The Standard CMOS Features ….................................. 4-4
4-4 The Advance BIOS Features ….................................... 4-7
4-5 Advanced Chipset Features ........................................... 4-9
4-6 Integrated Peripherals ……........................................... 4-11
4-7 Power Management Setup ……………………………. 4-15
4-8 PNP/PCI Configuration ................................................ 4-16
4-9 PC Health Status …………………………………….. 4-17
4-10 Frequency Control ……………………………..…… 4-18
4-11 Load Fail-Safe Defaults ................................................ 4-19
4-12 Load Optimized Defaults .............................................. 4-19
4-13 Password Settings ......................................................... 4-20
4-14 Save & Exit Setup ......................................................... 4-21
4-15 Exit Without Saving ...................................................... 4-22
APPENDIX A SYSTEM ASSEMBLY
Exploded Diagram for POS85M Whole System Unit ….......... A-2
Exploded Diagram for Front Panel ……………………….... A-4
Exploded Diagram for POS85M Stand ……………………… A-6
Exploded Diagram for POS85M Rear Part ………………….. A-8
APPENDIX B TECHNICAL SUMMARY
Block Diagram ......................................................................... B-2
Interrupt Map ............................................................................ B-3
RTC & CMOS RAM Map ....................................................... B-4
Timer & DMA Channels Map .................................................. B-5
I/O & Memory Map ................................................................. B-6

Page:1-1
INTRODUCTION
This chapter gives you the information for POS85M. It also outlines the
System specifications.
Section includes:
zAbout This Manual
zSystem Specifications
zSafety precautions
Experienced users can skip to chapter 2 on page 2-1 for
a Quick Start.
CHAPTER
1

Chapter 1 Introduction
Page: 1-2 POS85M USER
′
S MANUAL
1-1. ABOUT THIS MANUAL
Thank you for purchasing our POS85M System. The POS85M is an updated
system designed to be comparable with the highest performance of IBM AT
personal computers. The POS85M provides faster processing speed, greater
expandability and can handle more tasks than before. This manual is designed
to assist you how to install and set up the whole system. It contains four
chapters. The user can apply this manual for configuration according to the
following chapters :
Chapter 1 Introduction
This chapter introduces you to the background of this manual. It also
includes illustration and the specification for the whole system. The final page
of this chapter indicates some safety reminders on how to take care of your
system.
Chapter 2 Hardware Configuration
This chapter outlines the POS85M component’s location and their function. In
the end of this chapter, you will learn how to set jumper and how to configure
this card to meet your own needs.
Chapter 3 Software Utilities
This chapter contains helpful information for proper installations of the Intel
Utility, VGA Utility, LAN Utility, Sound Utility, Touch Screen Utility and
Flash BIOS Update. It also describes the Wireless Utility.
Chapter 4 Award BIOS Setup
This chapter indicates you how to set up the BIOS configurations.
Appendix A System Assembly
This section gives you the exploded diagram for the whole system unit.
Appendix B Technical Summary
This section gives you the information about the Technical maps.

Chapter 1 Introduction
POS85M USER
′
S MANUAL Page: 1-3
1-2. POS SYSTEM ILLUSTRATION
POS85M

Chapter 1 Introduction
Page: 1-4 POS85M USER
′
S MANUAL
1-3. SYSTEM SPECIFICATIONS
MAINBOARD
zCPU TYPE :
Celeron M1.5 GHz, up to Pentium M1.8 GHz
zCHIPSET :
Intel 910GME + ICH6M
(Support FSB=400MHz)
zMEMORY :
Upto1GB
One 200-pin DDRII SO-DIMM socket on board.
zCACHE :
Depended on CPU
zREAL-TIME CLOCK / CALENDAR :
Embedded in Intel ICH6M South Bridge
zBIOS :
PhoenixAward PnP BIOS
4Mbytes with VGA BIOS
zKEYBOARD CONNECTOR :
PC/AT Compatible, with mini DIN connecter on rear panel.
zMOUSE CONNECTOR :
PS/2 Mouse, with mini DIN connecter on rear panel.

Chapter 1 Introduction
POS85M USER
′
S MANUAL Page: 1-5
zSERIAL PORT :
Four high speed 16550 Compatible UARTs
COM1, COM2, COM3, COM4 all for RS-232,
(All with 5v/12v power capability)
COM 1,COM2, COM 3 - External D-sub 9-pin connector on rear panel
zPARALLEL PORT :
Support SPP, ECP, EPP mode.
Bi-directional parallel port
zUNIVERSAL SERIAL BUS PORT :
Support up to 4 USB2.0 ports on rear panel.
zLED INDICATOR :
3 LED indicators (Power, HDD, LAN-on/working)
zLAN FUNCTION :
10/100Mbps Fast Ethernet.
Interface: RJ-45 Jack on board
zSOUND FUNCTION : (POS85M-MIT & POS85M-PPC)
Realtek ALC 202A, AC’97 Sound MAX® Codec
Integrated Sound Blaster / DirectSound AC97 audio.
1 Line-out connector on rear panel
1X2 pin header on board connecting to internal speaker (Max1.9Watt)
zVGA FUNCTION :
Built-in North Bridge
Support simultaneous display of CRT and LCD
zBOARD DIMENSION :
254mm x 205mm

Chapter 1 Introduction
Page: 1-6 POS85M USER
′
S MANUAL
LCD PANEL
Type
XGA
Max. Resolution
XGA (1024 x 768)
Size/Type
15” / TFT
Viewing Angel (degree)
Up
Down
Left
Right
40
60
60
60
Pixel Pitch
0.297 (W) x 0.297 (H)
Brightness
250 cd / m
2
Signal Interface (bit)
TTL (18-bit)
LCD MTBF
30,000
Back Light MTBF (Hrs)
30,000
TOUCHSCREEN (OPTIONAL)
TYPE
RESISTIVE
(5 wire)
Resolution
1024 x 768
Controller
USB Interface
Power Consumption
+5V
Durability (Lifetime)
10 million
TYPE
SURFACE CAPACITIVE
Resolution
1024 x 768
Controller
USB Interface
Power Consumption
+5V
Durability (Lifetime)
Over 160 million

Chapter 1 Introduction
POS85M USER
′
S MANUAL Page: 1-7
CARD READER (OPTIONAL)
TYPE Triple Track
Function Read
Interface Keyboard Wedge
Speed 10-100cm/sec
Recording Method F2F(FM)
Lift Cycle 300,000 passes
Voltage +5V
Standard ISO 7811
GENERAL INFORMATION
zPOWER ADAPTER :
Model: FSP120-ACB
Input: 100 Vac/ 240 Vac, 47Hz to 63 Hz
Output: 24V, 0A to 5A
Dimension: 167mm x 65mm x 37mm
zDISK DRIVE HOUSING :
One slim HDD
zHOUSING CONSTRUCTION:
High quality plastic frame architecture
zDIMENSION :
[POS85M]: 365 x 363 x 297 mm (14.37” x 14.37” x 11.69”)
zNET WEIGHT :
[POS85M]: 5.5kg (12.13lb)

Chapter 1 Introduction
Page: 1-8 POS85M USER
′
S MANUAL
1-4. SAFETY PRECAUTIONS
Following messages are safety reminders on how to protect your systems from
damages. And thus, helps you lengthen the life cycle of the system.
1. Check the Line Voltage
a. The operating voltage for the power supply should cover the range of
100VAC-240VAC, otherwise the system may be damaged.
2. Environmental Conditions
a. Place your POS85M on a sturdy, level surface. Be sure to allow
enough room on each side to have easy access.
b. Avoid extremely hot or cold places to install your POS85M Book-sized
PC.
c. Avoid exposure to sunlight for a long period of time (for example in a
closed car in summer time. Also avoid the system from any heating
device.). Or do not use POS85M when it‘s been left outdoors in a cold
winter day.
d. Bear in mind that the operating ambient temperature is from 0°C up to
+35°C.
e. Avoid moving the system rapidly from a hot place to a cold place or vice
versa because condensation may come from inside of the system.
f. Place POS85M against strong vibrations, which may cause hard disk
failure.
g. Do not place the system too close to any radio active device. Radio-
active device may cause interference.
h. Always shutdown the operation system before turning off the power.
3. Handling
a. Avoid putting heavy objects on top of the system.
b. The power of COM1 and COM4 is co-used with 2
nd
display, please be
sure COM1 and COM4 are set at RI mode while using 2
nd
display.
Otherwise, COM1 and COM4 may cause operating problem.
c. If the system isn’t full system in DOS mode, please adjust BIOS setting
as following instruction.
Advanced Chipset Feature => Boot display => choose “LFP”
4. Good Care
a. When the outside of the case is stained, remove the stain with neutral
washing agent with a dry cloth.
b. Never use strong agents such as benzene and thinner to clean the system.
c. If heavy stains are present, moisten a cloth with diluted neutral washing

Chapter 1 Introduction
POS85M USER
′
S MANUAL Page: 1-9
agent or with alcohol and then wipe thoroughly with a dry cloth.
d. If dust has been accumulated on the outside, remove it by using a special
made vacuum cleaner for computers.
e. Please don't contact the surface of capacitive touch before entering your
operation system, or capacitive touch may have position problem for
electrostatics interference.

Page 2-1
SYSTEM
CONFIGURATION
Helpful information that describes the jumper & connector settings,
and component locations.
Section includes:
zJumper & Connector Quick Reference Table
zComponent Locations
zConfiguration and Jumper settings
zConnector Pin Assignments
CHAPTER
2

Chapter 2 Hardware Configuration
Page: 2-2 POS85M USER
’
S MANUAL
2-1. JUMPER & CONNECTOR QUICK REFERENCE TABLE
Connector & Jum
p
er Name Pa
g
e
Printer Connector JPRNT1 2-6
COM Port Connector COM1, COM4
CN2 2-7
2-8
COM1 RI and Volta
g
e Selection JP
_
COM1 2-9
COM2 RI and Volta
g
e Selection JP
_
COM2 2-10
COM3 RI and Volta
g
e Selection JP
_
COM3 2-11
COM4 RI and Volta
g
e Selection JP
_
COM4 2-12
Ke
y
board & PS/2 Mouse Connector KB-MS1 2-13
USB Connector JUSB1, JUSB2 2-13
2-14
Cash Drawer Connector DRW1 2-14
Cash Drawer Power Selection JCASH1 2-15
LAN & USB Connector JRJ45USB1 2-16
VGA Connector J1 2-17
Power Switch Connector JPWR
_
SW1 2-17
Power/HDD/LAN LED Connector JLED1 2-18
External S
p
eaker Connector SPK
_
OUT1 2-18
Inverter Connector INV1 2-18
MSR/ Card Reader Connector J2 2-19
LVDS Connector J6 2-19
Hard Disk Drive Connector SATA1, IDE1 2-20
Touch Panel Connector JTP1 2-21
FAN Connector JFAN_CPU1 2-21
Clear CMOS Data Selection JP1 2-22

Chapter 2 Hardware Configuration
POS85M USER
’
S MANUAL Page: 2-3
2-2. COMPONENT LOCATIONS
POS85M Connector, Jumper and Component locations

Chapter 2 Hardware Configuration
Page: 2-4 POS85M USER
’
S MANUAL
2-3. HOW TO SET THE JUMPERS
You can configure your board by setting the jumpers. Jumper is consists of
two or three metal pins with a plastic base mounted on the card, and by
using a small plastic "cap", Also known as the jumper cap (with a metal
contact inside), you are able to connect the pins. So you can set-up your
hardware configuration by "opening"or "closing"pins.
The jumper can be combined into sets that called jumper blocks. When the
jumpers are all in the block, you have to put them together to set up the
hardware configuration. The figure below shows how this looks like.
JUMPERS AND CAPS
If a jumper has three pins for example, labelled PIN1, PIN2, and PIN3. You
can connect PIN1 & PIN2 to create one setting and shorting. You can either
connect PIN2 & PIN3 to create another setting. The same jumper diagrams
are applied all through this manual. The figure below shows what the manual
diagrams look and what they represent.

Chapter 2 Hardware Configuration
POS85M USER
’
S MANUAL Page: 2-5
JUMPER DIAGRAMS
JUMPER SETTINGS

Chapter 2 Hardware Configuration
Page: 2-6 POS85M USER
’
S MANUAL
2-4. PRINTER CONNECTOR
JPRNT1 : Printer Connector
The Printer Connector assignments are as follows :
PIN ASSIGNMENT PIN ASSIGNMENT
1 STBJ 14 ALFJ
2 PDR0 15 ERRJ
3 PDR1 16 PAR_INITJ
4 PDR2 17 SLCTINJ
5 PDR3 18 GND
6 PDR4 19 GND
7 PDR5 20 GND
8 PDR6 21 GND
9 PDR7 22 GND
10 ACKJ 23 GND
11 BUSY 24 GND
12 PE 25 GND
13 SLCTJ
Table of contents
