Taurus 11010 User manual
N26704
10.8V LI-ION
CORDLESS DRILL
INSTRUCTION MANUAL
AFTER SALES SUPPORT
TEL: 1300 922 271
EMAIL: [email protected]
MODEL NUMBER BT-CD 10.8/3 Li
Cordless Lithium-Ion Cordless Drill
What your 3 year warranty means
Great care has gone into the manufacture of this product and it should therefore provide you with years
of good service when used properly. In the event of product failure within its intended use over the
course of the rst 3 years after the date of purchase, we will remedy the problem as quickly as possible
once it has been brought to our attention. In the unlikely event of such an occurrence, or if you require
any information about the product, please contact us via our after sales support services, details of
which can be found in this manual and on the product itself.
Welcome Section
Congratulations on choosing to buy a TAURUS TITANIUM® product.
All products brought to you by TAURUS TITANIUM® are manufactured to the highest standards of
performance and safety, and, as part of our philosophy of customer service and satisfaction, are backed
by our comprehensive 3Year Warranty.
We hope you will enjoy using your purchase for many years to come.
Table of Contents
1. Safety regulations
2. Layout and items supplied
3. Proper use
4. Technical data
5. Before starting the machine
6. Operation
7. Cleaning, maintenance and ordering of spare parts
8. Disposal and recycling
2
4 5
Caution
Read the operating instructions to reduce the risk of injury.
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Wear safety goggles.
Sparks generated during working or splinters, chips and dust emitted by the device
can cause loss of sight.
4
5
a
8
1
6
10
11
6 7
2
3
7 a
Wear a breathing mask.
Dust which is injurious to health can be generated when working on wood and other
materials. Never use the device to work on any materials containing asbestos!
GENERAL SAFETY RULES
SAVE THESE INSTRUCTIONS
1. Work area
a. Keep work area clean and well lit. Cluttered and
dark areas invite accidents.
b. Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a. Power tools plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded)
power tool. Unmodied plugs and matching
outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk
of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the inuence of drugs, alcohol or medication. A
moment of inattention while operating power
tools may result in serious personal injury.
b. Use safety equipment. Always wear eye
protection. Safety equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will
reduce personal injuries.
c. Avoid accidental starting. Ensure the switch is in
the off-position before plugging in. Carrying
power tools with your nger on the switch or
plugging in power tools that have the switch on
invites accidents.
d. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to rotating part of the power tool may
result in personal injury.
e. Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving
parts.
g. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
these devices can reduce dust-related hazards.
4. Power tool use and cars
a. Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b. Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
c. Disconnect the plug from the power source and/
or the battery pack from the power tool before
making any adjustments, changing accessories,
or storing power tools. Such preventive safety
measures reduce the risk of starting the power
tool accidentally.
d. Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tools operation. If damaged, have the
power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
g. Use the power tool, accessories and tool bits
etc. in accordance with these instructions and
in the manner intended for the particular type
of power tool, taking into account the working
conditions and the work to be performed. Use of
the power tool for operations different from
those intended could result in a hazardous
situation.
5. Service
a. Have your power tool serviced by a qualied
repair person using only identical replacement
parts. This will ensure that the safety of the
power tool is maintained.
5
WARNING! Read all instructions Failure to
follow all instructions listed below may result
in electric shock, re and/or serious injury. The
term ’’power tool’’ in all of the warnings listed
below refers to your mains-operated (corded)
power tool or battery-operated (cordless) power
tool.
Important!
When using equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating manual with
due care. Keep this manual in a safe place, so that
the information is available at all times. If you give
the equipment to any other person, give them these
operating instructions as well.
We accept no liability for damage or accidents
which arise due to non-observance of these
instructions and the safety information.
1. Safety regulations
Please refer to the booklet included in delivery for
the safety instructions.
CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, re
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
2. Layout (Fig. 1)
1. Torque selector
2. Changeover switch
3. ON/OFF switch
4. Battery pack
5. Pushlock button
6. Selector switch for 1st gear to 2nd gear
7. Quick-change drill chuck
8. Charging adapter
9. Battery charger
10. Battery capacity indicator
11. Switch for battery capacity indicator
3. Proper use
The cordless drill/screwdriver is designed for
tightening and undoing screws, as well as for
drilling in wood, metal and plastic.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or
injuries of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or
industrial applications. Our warranty will be
voided if the machine is used in commercial,
trade or industrial businesses or for equivalent
purposes.
4. Technical data
Motor power supply: 10.8V DC
Idling speed: 0-350 rpm
0-1200 rpm
Torque settings: 19 + 1
Forward and reverse rotation: Yes
Chuck capacity: 10mm
Battery charging voltage: 12V DC
Battery charging current: 500 mA
Mains voltage for charger: 240V~50 Hz
Weight: 1.2 kg
Max. screw diameter: 6mm
Sound and Vibration
Sound and vibration values were measured in
accordance with EN 60745.
LpA sound pressure level 64 dB(A)
KpA uncertainty 3 dB
LWA sound power level 75 dB(A)
KWA uncertainty 3 dB
Wear ear-muffs.
The impact of noise can cause damage to
hearing.
Total vibration values (vector sum of three
directions) determined in accordance with
EN 60745.
Screwing without hammer action
Vibration emission value ah≤0,153 m/s2
K uncertainty = 1,5 m/s2
6
m
Important!
The vibration value changes according to the
area of application of the electric tool and
may exceed the specied value in exceptional
circumstances.
Keep the noise emissions and vibrations to a
minimum.
• Only use appliances which are in perfect
working order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the
appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever
necessary.
• Switch the appliance off when it is not in
use.
• Wear protective gloves.
5. Before starting the
machine
Be sure to read the following information before
you use your cordless drill for the rst time:
1. Charge the battery pack with the charger
supplied.
2. Only ever use screwdriver bits which are
suitable for the purpose and in faultless
condition.
3. Always check for concealed electric cables
and gas and water pipes when drilling and
screwing in walls.
6. Operation
6.1 Charging the LI battery pack (Fig. 2/3/4)
The battery is protected from exhaustive
discharge.An integrated protective circuit
automatically switches off the equipment when
the battery is at. In this case the bit chuck will
cease to turn.
Warning! Do not press the ON/OFF switch any
more if the protective circuit has actuated. This
may damage the battery.
1. Remove the battery pack (4) from the
handle, pressing the pushlock buttons (5) on
the left and right sides to do so.
2. Check that your mains voltage is the same
as that marked on the rating plate of the
battery charger. Plug the mains plug of the
charger (9) into the mains socket outlet.
1. Remove the battery pack (4) from the
handle, pressing the pushlock buttons (5) on
the left and right sides to do so.
2. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Plug the mains plug of the charger
(9) into the mains socket outlet.
3. Connect the charging cable (a) to the
charging adapter (8).
4. The green LED on the charger will come
on. Plug the battery (4) into the charging
adapter (8). Now the red LED will come on
to indicate that the battery pack is being
charged. When the charging period is
completed after approx. 3 hours, the red
LED goes out again. The temperature of the
battery (4) may rise during the charging
operation. This is normal.
If the battery pack fails to become charged, please
check
• whether there is voltage at the socket-outlet
• whether there is good contact at the
charging contacts of the battery station (8).
If the battery still fails to become charged, please
return
• the charger and charging adapter
• the battery pack to our Customer Service
Department.
To ensure that the LI battery pack provides long
service you should take care to recharge it
promptly. You must recharge the battery pack
when you notice that the power of the cordless
drill drops.
Never fully discharge the battery pack. This will
cause the LI battery pack to develop a defect.
6.2 Torque setting (Fig. 5 / Item 1)
The cordless drill is tted with a mechanical
torque selector.
The torque for a specic size of screw is selected
with the set-collar (1). The correct torque depends
on several factors:
• on the type and hardness of material in
question
• on the type and length screws used
• on the requirements needing to be met by
the screwed joint.
The clutch disengages with a grating sound to
indicate when the set torque is reached.
Important! The tool must be at a standstill when
you set the torque with the setting ring.
6.3 Drilling (Fig. 5 / Item 1)
For drilling purposes, move the set-collar to the
laststep “Drill“. In this setting the slip clutch is
inactive. The maximum torque is available in
drilling mode.
7
Warning! Do not press the ON/OFF switch any
more if the protective circuit has actuated. This
may damage the battery.
m
6.4 Forward/Reverse switch (Fig. 6 / Item 2)
With the slide switch above the On/Off switch you
can select the direction of rotation of the battery
powered drill/screwdriver and secure it against
being switched on accidentally. You can choose
between clockwise and anticlockwise rotation. To
avoid causing damage to the gearing it is advisable
to change the direction of rotation only when the
tool is at a standstill. The On/Off switch is blocked
when the slide switch is in centre position.
6.5 On/Off switch (Fig. 6 / Item 3)
Innitely variable speed control is possible with the
On/Off switch. The further you press the switch, the
higher the speed of the battery-powered
drill/screwdriver.
6.6 Battery capacity indicator (Fig. 5/Item 10)
Press the button for the battery capacity indicator
(11). The battery capacity indicator (10) indicates the
charge state of the battery on 3 colored LEDs.
All LEDs illuminate:
The battery is fully charged.
The yellow and red LED illuminate:
The battery has an adequate remaining charge.
Red LED:
The battery is empty, recharge the battery.
6.7 Changing the tool (Fig. 7)
Important. Set the changeover switch (2) to its
centre position whenever you carry out any work
(for example changing the tool, maintenance work,
etc.) on the cordless drill.
• The cordless drill is tted with a quickaction
chuck (7) with an automatic spindle stop.
• Open the chuck (7). The chuck opening (a)
must be large enough to hold the tool (drill bit
or screwdriver bit).
• Select the suitable tool. Push the tool as far as
possible into the chuck opening (a).
• Tighten the chuck (7) and then check that the
tool is secure.
6.8 Screwdriving
We recommend using self-centering screws (e.g.
Torx screws, recessed head screws) designed for
reliable working. Be sure to use a bit that matches
the screw in shape and size. Set the torque, as
described elsewhere in these operating instructions,
to suit the size of screw.
6.9 Selecting 1st gear to 2nd gear (Fig. 5/Item 6)
By adjusting the selector switch, you can work with
a faster or slower turning speed. Change the gear
only when the drill is at a standstill. If you fail to
observe this point, the gearing may be damaged.
7. Cleaning, maintenance
and ordering of spare parts
Always pull out the mains power plug before
starting any cleaning work.
7.1 Cleaning
• Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
• We recommend that you clean the device
immediately each time you have nished
using it.
• Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could
attack the plastic parts of the equipment.
Ensure that no water can seep into the
device.
7.2 Maintenance
There are no parts inside the equipment which
require additional maintenance.
8. Disposal and recycling
The unit is supplied in packaging to prevent its
being damaged in transit. This packaging is raw
material and can therefore be reused or can be
returned to the raw material system.
The unit and its accessories are made of various
types of material, such as metal and plastic.
Defective components must be disposed of as
special waste. Ask your dealer or your local
council.
TAURUS TITANIUM®is a registered trademark of
ALDI Stores.
ALDI Guarantee
Specially made for ALDI Stores to our stringent
quality specications. If you are not entirely
satised with this product, please return it to
your nearest ALDI store within 60 days from the
date of purchase for a full refund or replacement,
or take advantage of our after sales support by
calling the Customer Service Hotline.
Einhell Australia Pty. Ltd.
6/166 Wellington St
Collingwood,
Victoria, 3066
Australia
01/2011
8
This manual suits for next models
1
Table of contents
Other Taurus Power Screwdriver manuals
