Taurus RT-SD 3.6 Li User manual

RT-SD 3.6 Li
Operating Instructions
Cordless Screwdriver
N16188
After Sales Support
TEL: [phone]
WEB: www.rossmac.com
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 1

After Sales Support TEL: [phone] WEB: www.rossmac.com
2
Cordless Screwdriver
What your 1 year warranty means
Great care has gone into the manufacture of this product and it should therefore provide you with years of good service when
used properly. In the event of product failure within its intended use over the course of the first 1 year after the date of
purchase, we will remedy the problem as quickly as possible once it has been brought to our attention. In the unlikely event of
such an occurrence, or if you require any information about the product please contact us via our after sales support services,
details of which can be found in this manual and on the product itself.
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 2

After Sales Support TEL: [phone] WEB: www.rossmac.com
3
1
2
12
11
34 5 6
8
12
13
9
10
10
7
3
4
3
2
9
14
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 3

After Sales Support TEL: [phone] WEB: www.rossmac.com
4
4 5
5
6
114
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 4

After Sales Support TEL: [phone] WEB: www.rossmac.com
5
“Caution - Read the operating instructions to reduce the risk of inquiry”
Wear ear-muffs.
The impact of noise can cause damage to hearing.

Wear safety goggles.
Sparks generated during working or splinters, chips and dust emitted by the device
can cause loss of sight.

Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 5

After Sales Support TEL: [phone] WEB: www.rossmac.com
6
Important!
When using equipment, a few safety
precautions must be observed to avoid injuries
and damage. Please read the complete
operating manual with due care. Keep this
manual in a safe place, so that the information
is available at all times. If you give the
equipment to any other person, give them
these operating instructions as well.
We accept no liability for damage or accidents
which arise due to non-observance of these
instructions and the safety information.
1. Safety information
General safety instructions for electric
tools
 CAUTION: Read all safety regulations
and instructions. Any failures made in
following the safety regulations and instructions
may result in an electric shock, fire and/or
serious injury.
Keep all safety regulations and instructions
in a safe place for future use.
The term “electric tool” used in the safety
instructions refers to electric tools operated
from the mains power supply (with a power
cable) and to battery operated electric tools
(without a power cable).
1.1. Workplace safety
Keep your work area clean and well
illuminated. Untidy or unlit work areas can
result in accidents.
Do not operate the electric tool in an
environment where there is a risk of
explosions and where there are
inflammable liquids, gases or dust.
Electric tools produce sparks which could
set the dust or vapours alight.
Keep the electric tool out of the reach of
children and other persons. If there is a
distraction, you may lose control of the
appliance.
1.2. Electrical safety
The connector plug from this electric
tool must fit into the socket. The plug
should never be altered in any way.
Never use adapter plugs together with
earthed electric tools. Unaltered plugs
and correct sockets reduce the risk of an
electric shock.
Avoid bodily contact with earthed
surfaces such as pipes, heating, ovens
and fridges. The risk of electric shock is
increased if your body is earthed.
Keep the tool out of the rain and away
from moisture. The ingress of water into
an electric tool increases the risk of an
electric shock.
Do not use the cable to carry the
electric tool, to hang it up or to pull it
out of the socket. Keep the cable away
from heat, oil, sharp edges and moving
parts of the appliance. Damaged or
entangled cables increase the risk of an
electric shock.
If you are working outdoors with an
electric tool, only use extension cables
which are designed specifically for this
purpose. Using specially designed outdoor
extension cables, the risk of electric shock
is reduced.
If operation of the electric tool in a
damp environment can not be avoided,
use a earth-leakage circuit-breaker. The
earth-leakage circuit-breaker reduces the
risk of an electric shock.
1.3. Safety of persons
Be careful, watch what you are doing
and use an electric tool sensibly. Do not
use the tool if you are tired or under the
influence of drugs, alcohol or
medication. A moment of inattention when
using the electric tool can result in serious
injuries.
Wear personal protection equipment
and always wear safety goggles.
Wearing personal protection (such as dust
masks, non-slip safety shoes, safety helmet
or ear protection, depending upon the type
and use of the electric tool) reduces the risk
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 6

of injury.
Make sure that the appliance cannot
start up accidentally. Ensure that the
electric tool is switched off before you
connect it to the power supply and/or
insert the battery, or pick up or carry the
tool. If your finger is on the switch whilst
carrying the electric tool or if you connect
the appliance to the mains when it is
switched on, this can lead to accidents.
Remove keys and wrenches before
switching on the electric tool. A tool or
key which comes into contact with rotating
parts of the appliance can lead to injuries.
Avoid abnormal working postures. Make
sure you stand squarely and keep your
balance at all times. In this way, you can
control the electric tool better in unexpected
circumstances.
Wear suitable work clothes. Do not wear
loose clothing or jewellery. Keep hair,
clothes and gloves away from moving
parts. Loose clothing, jewellery or long hair
can get trapped in moving parts.
If vacuuming devices and draining
devices can be fitted, make sure that
these are correctly attached and
correctly used. The use of a dust
extraction system can reduce the danger
posed by dust.
1.4. Usage and treatment of the electric tool
Do not overload the appliance. Use the
correct tool for your work. You will be
able to work better and more safely within
the given performance boundaries.
Do not use an electric tool with a
defective switch. An electric tool that
cannot be switched on or off is dangerous
and must be repaired.
Pull the plug out of the socket and/or
remove the battery before making any
adjustments to the appliance, changing
accessories or put the appliance down.
This safety measure prevents starting the
electric tool unintentionally.
Keep unused electric tools out of the
reach of children. Do not allow people
who are not familiar with the appliance
or who have not read these instructions
to use the appliance. Electric tools are
dangerous if they are used by
inexperienced people.
Clean your electric tool carefully. Check
whether moving parts are functioning
properly and not jamming, whether
parts are broken or damaged enough
that the functioning of this electric tool
is affected. Have damaged parts
repaired before using the appliance.
Many accidents are caused by badly
maintained electric tools.
Keep your cutting tools sharp and
clean. Carefully maintained cutting tools
with sharp cutting edges will jam less and
are easier to control.
Make sure to use electric tools,
accessories, attachments, etc. in
accordance with these instructions.
Take the conditions in your work area
and the job in hand into account. Using
electric tools for any purpose other than the
one for which they are intended can lead to
dangerous situations.
1.5. Service
Have your electric tool repaired only by
trained personnel using only genuine
spare parts. This will ensure that your
electric tool remains safe to use.
1.6. Careful handling and use of cordless
equipment
Ensure that the equipment is switched
off before you insert the battery.
Inserting a battery into an electric tool that is
switched on can cause accidents.
Only charge the batteries in chargers
that are recommended by the
manufacturer. A charger that is designed
for a certain type of batteries may pose a
fire risk if it is used with other types of
batteries.
Use only the correct batteries in the
electric tools. The use of other batteries
may result in injuries and a fire risk.
Keep unused batteries away from paper
After Sales Support TEL: [phone] WEB: www.rossmac.com
7
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 7

clips, coins, keys, nails, screws and
other metallic objects that could cause
a short circuit between the contacts. A
short circuit between the battery contacts
may cause burns or a fire.
In case of incorrect use, fluid may
escape from the battery. Avoid contact
with it. If you touch it by mistake, rinse
the affected area with water. If you get
the fluid in your eyes, also seek medical
advice. Leaking battery fluid can cause skin
irritation or burns.
Additional safety instructions
The battery pack supplied with your
cordless tool is not charged. The battery
pack has to be charged before you use the
tool for the first time.
The battery pack does not reach its
maximum capacitance until it has been
charged and discharged approximately five
times.
Battery packs lose their charge even when
they are not being used. Regular charging
is therefore recommended.
Please check the data marked on the rating
plate of the battery charger. Be sure to
connect the battery charger to a power
supply with the voltage marked on the
rating plate. Never connect it to a different
mains voltage.
Keep the battery charger and the cordless
tool out of children’s reach.
Wear suitable work clothes. Wear safety
goggles.
Never open the battery pack. Avoid contact
with a leaking battery pack. In case of
accidental contact, wash the affected area
of skin with soap and water. If battery acids
gets in your eye, rinse out the eye with
clear water for at least 10 minutes and seek
a doctor’s advice immediately. Neutralize
other affected areas with a mild acid such
as lemon juice or vinegar.
Protect the battery charger and its cable
from damage and sharp edges. Have
damaged cables repaired without delay by
a qualified electrician.
Make sure that the contacts of the battery
pack do not come into contact with other
metallic objects such as nails or screws.
There is a risk of short-circuiting!
Use only battery chargers that are intended
for the battery pack in question.
Do not use damaged battery chargers.
Leave repairs strictly to the appointed
service center or authorized dealers.
Do not use the supplied battery charger to
charge other cordless tools.
Never allow the battery pack to become
fully discharged. This will cause it to
develop a defect.
Timely recharging of the battery pack will
help it serve you well for a long time. You
must recharge the battery pack when you
notice that the power of the cordless tool
drops.
In heavy use the battery pack will become
warm. Allow the battery pack to cool to
room temperature before commencing with
the charging.
Protect your cordless tool and the battery
charger from moisture and rain.
Do not use the cordless tool or the battery
charger near vapors and inflammable
liquids.
Do not throw battery packs into an open
fire. There is a risk of explosion!
Use the battery charger only in dry
conditions and an ambient temperature of
10-40°C.
Do not keep the battery charger in places
where the temperature is liable to reach
50°C. In particular, do not leave the battery
charger in a car that is parked in the
sunshine.
Do not ignite the battery pack or expose it
to fire.
Do not lose these safety instructions.
Rechargeable batteries and cordless electric
machines and tools contain materials that are
potentially harmful to the environment. Never
place any cordless electric machines or tools in
your household refuse. When cordless electric
machines or tools become defective or worn,
remove the rechargeable batteries and return
them to Einhell Australia, PO Box 261,
After Sales Support TEL: [phone] WEB: www.rossmac.com
8
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 8

Essendon North, Victoria, 3041. If the
rechargeable batteries cannot be removed,
return the complete cordless machine or tool.
You can then be sure that the equipment will
be correctly disposed of by the manufacturer.
2. Layout (Fig. 1)
1. Bit chuck
2. Lamp
3. Magnetic screw holder
4. ON/OFF switch for lamp
5. Battery capacity indicator
6. Switch for battery capacity indicator
7. Charging control lamp
8. Charging connection
9. On/Off switch
10. Clockwise/Counter-clockwise selector
switch
11. Battery charger
12. Charging cable
13. Bag
14. 4 Bits
3. Proper use
The cordless screwdriver is designed for
tightening and undoing screws.
The machine is to be used only for its
prescribed purpose. Any other use is deemed
to be a case of misuse. The user / operator
and not the manufacturer will be liable for any
damage or injuries of any kind caused as a
result of this.
Please note that our equipment has not been
designed for use in commercial, trade or
industrial applications. Our warranty will be
voided if the machine is used in commercial,
trade or industrial businesses or for equivalent
purposes.
4. Technical data
Motor power supply: 3.6 V DC
Idling speed: 200 min-1
Clockwise/Counter-clockwise: Yes
Charge voltage for rechargeable battery:
6 V DC
Charge current for rechargeable battery:
300 mA
Battery charger supply voltage: 240 V ~ 50 Hz
Charging time: max. 5 hours
Battery type: Li-Ion
Weight: 0.4 kg
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
LpA sound pressure level 62 dB(A)
KpA uncertainty 3 dB
LWA sound power level 73 dB(A)
KWA uncertainty 3 dB
Wear ear-muffs.
The impact of noise can cause damage to
hearing.
Total vibration values (vector sum of three
directions) determined in accordance with EN
60745.
Screwing without hammer action
Vibration emission value ah≤2,5 m/s2
K uncertainty = 1,5 m/s2
Important!
The vibration value changes according to the
area of application of the electric tool and may
exceed the specified value in exceptional
circumstances.
After Sales Support TEL: [phone] WEB: www.rossmac.com
9
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 9

5. Before starting the equipment
Be sure to read the following information
before you use your cordless screwdriver for
the first time:
1. Charge the battery pack with the charger
supplied.
2. Only ever use screwdriver bits which are
suitable for the purpose and in faultless
condition.
3. Always check for concealed electric cables
and gas and water pipes when drilling and
screwing in walls.
6. Operation
6.1 Charging the battery (Fig. 1)
The battery is protected from exhaustive
discharge. An integrated protective circuit
automatically switches off the equipment when
the battery is flat. In this case the bit chuck will
cease to turn.
Warning! Do not press the ON/OFF switch any
more if the protective circuit has actuated. This
may damage the battery.
1. Check that your mains voltage is the same
as that marked on the rating plate of the
battery charger. Plug the battery charger in
the plug socket and connect the charging
cable to the charging connection. The
charging process starts as soon as the
charging cable is connected to the charging
adapter.
2. The red LED (7) will come on to indicate
that the battery pack is being charged.
3. The charging control lamp (7) goes out
when charging is completed.
Important! The handle may become a little
warm during the charging process. This is
normal.
If the battery pack fails to charge, please check
whether there is voltage at the socket-outlet
and check for proper contact with the
charging contacts in the battery charger.
If the battery still fails to charge, send
the battery charger
and the screwdriver
to our customer services department.
Timely recharging of the battery pack will help
it serve you well for a long time. You must
recharge the battery pack when you notice that
the power of the screwdriver drops.
6.2 Changeover switch (Fig. 2/Item 10)
The slide switch above the ON/OFF switch is
for setting the direction of rotation of the
cordless screwdriver and for preventing the
cordless screwdriver from being switched on
inadvertently. You can select between
clockwise and counter-clockwise rotation.
Change the direction of rotation only when the
equipment is at a standstill. If you fail to
observe this point, the gearing may become
damaged. When the slide switch is in the
middle position, the ON/OFF switch is blocked.
6.3 ON/OFF switch (Fig. 2 / Item 9)
Press the On/Off switch to switch the cordless
screwdriver on. Release the ON/OFF switch to
switch off the tool.
6.4 LED lamp (Fig. 3/Item 2)
The LED lamp (2) can be used in poor lighting
conditions to illuminate the area where you
want to screw.
To switch on, push the switch (4) forwards; to
switch off, pull the switch back again.
6.5 Magnetic screw holder (Fig. 3/Item 3)
Screws can be placed on the magnetic screw
holder for easy reach during operation.
6.6 Battery capacity indicator (Fig. 4/Item 5)
Press the button for the battery capacity
indicator (6). The battery capacity indicator (5)
indicates the charge state of the battery on 3
colored LEDs.
All LEDs illuminate:
The battery is fully charged.
After Sales Support TEL: [phone] WEB: www.rossmac.com
10
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 10

The yellow and red LED illuminate:
The battery has an adequate remaining
charge.
Red LED:
The battery is empty, recharge the battery.
6.7 Changing the tool (Fig. 5)
Important! Set the changeover switch to its
centre position whenever you carry out any
work (for example changing the tool,
maintenance work, etc.) on the cordless
screwdriver.
Insert the bit (14) into the bit chuck (1).
To remove the bit (14), pull it back out of the bit
chuck (1).
6.8 Screwdriving
We recommend using self-centering screws
(e.g. Torx screws, recessed head screws)
designed for reliable working. Be sure to use a
bit that matches the screw in shape and size.
Set the torque, as described elsewhere in
these operating instructions, to suit the size of
screw.
7. Cleaning, maintenance and
ordering of spare parts
Always pull out the mains power plug before
starting any cleaning work.
7.1 Cleaning
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
We recommend that you clean the device
immediately each time you have finished
using it.
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could
attack the plastic parts of the equipment.
Ensure that no water can seep into the
device.
7.2 Maintenance
There are no parts inside the equipment which
require additional maintenance.
7.3 Ordering replacement parts
Please quote the following data when ordering
replacement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part
required
For our latest prices and information please go
to www.isc-gmbh.info
8. Disposal and recycling
The unit is supplied in packaging to prevent its
being damaged in transit. This packaging is
raw material and can therefore be reused or
can be returned to the raw material system.
The unit and its accessories are made of
various types of material, such as metal and
plastic. Defective components must be
disposed of as special waste. Ask your dealer
or your local council.
After Sales Support TEL: [phone] WEB: www.rossmac.com
11
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 11

After Sales Support TEL: [phone] WEB: www.rossmac.com
12
Never place any electric tools in your household refuse.
Seek advice on correct disposal from local waste authorities.
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 12

After Sales Support TEL: [phone] WEB: www.rossmac.com
13
Technical changes subject to change
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 13

After Sales Support TEL: [phone] WEB: www.rossmac.com
14
The reprinting or reproduction by any other means, in whole or in part,
of documentation and papers accompanying products is permitted only
with the express consent of ISC GmbH.
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 14

After Sales Support TEL: [phone] WEB: www.rossmac.com
15
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 15

EH 07/2009 (01)
Anleitung_RT_SD_3_6_Li_SPK7_GB:_ 30.07.2009 11:22 Uhr Seite 16
