Tavistock SLE520 Installation guide

DIFFUSE ILLUMINATED MIRROR Product code: SLE520
Installation & care instructions
Please retain for future reference
Tavistock, Brassmill Lane Trading Estate, Bath, BA1 3JF
T. 01225 787870 | F. 01225 448877 | E. [email protected] | W. www.tavistock-bathrooms.co.uk
ILLUMINATED MIRROR
SLE520
Before you start
1
2
It is recommended that the mirror is secured to a suitably reinforced wall to ensure stability. Wall plugs are only suitable for solid stone/ brick walls. For plasterboard walls use
specialist wall plugs (not supplied).
Wear suitable eye protection when drilling. Take care when using power tools near water - the use of a residual current device (RCD) is recommended. Beware of hidden pipes or
cabels. Take care when drilling tiled surfaces as the drill might slip. Use a piece of masking tape to prevent the drill from wandering.
Strip wires to a suitable
length. DO NOT connect
to a plug & socket outlet.
THIS PRODUCT IS MANUFACTURED TO CLASS I
CATEGORY AND MUST HAVE AN EARTH CONNECTION.
! IF IN DOUBT CONSULT YOUR ELECTRICIAN !
Colour Coding:
L - Live
= Brown
N - Neutral = Blue
- Earth
= Green & Yellow
Operating Instructions
Lighting is turned on / off using the infra red switch on the bottom edge of the mirror. To operate, wave your hand
underneath the sensor. The heated pad is on when the light is on. DO NOT leave on for prolonged periods of time.
Ref: MB.05.13 | V.1.00
Mount the Mirror onto the fixing bracket fitted to the wall. The fixing bracket will inside the frame of the mirror.
This mirror can be installed in a portrait or landscape orientation. To ensure the mirror is securely mounted, add a
bead of silicone to the bottom edge where the mirror meets the wall.
Installation Procedure
Before installation. Decide on a desired location for your mirror. This
mirror can be mounted in a portrait or landscape orientation. If mounting
Landscape the mirror must be mounted a minimum of 150mm from an
adjacent wall or obstruction to ensure correct function of IR sensor.
1) Mount the mirror fixing bracket to the wall using the fixing kit supplied.
Supplied wall plugs are only suitable for solid stone/ brick walls. For
plasterboard walls use specialist wall plugs (not supplied). The holes for
the fixing bracket should be 50mm below the desired height of the top
of the mirror. Ensure this plate is level using a spirit level before
mounting your mirror
.
2) The next step is to make the electrical connection from the mirror to
the mains supply. Use the connection wire found at the rear of the
mirror to make the necessary connections in accordance with the
current IEE regulations. A second person will need to hold the mirror in
place whilst electrical connections are made.
Important
Mirror Location
150mm
Minimum
distance
Infrared sensor

Compliance
This product complies with all relevant British and European safety standards:-
Wiring
This product is manufactured to class I category and must have an earth connection.
Colour Coding:
L - Live = Brown
N - Neutral = Blue
- Earth = Green & Yellow
Lights
1 x 12v DC LED Light Strip
To obtain replacement led strips if faulty or broken contact customer services
(see details at foot of page)
Distances from a bath tub or shower tray
Electrical Safety Instructions (Applicable to UK Installations only)
All fittings must be installed by a competent person, in accordance with current IEE wiring regulations. If in doubt consult a qualified electrician
Important
Always switch off the electrical supply at the mains during installation and maintenance. It is recommended that the fuse is withdrawn or the circuit
breaker is switched off for the necessary circuit before installation commences.
Fitting in Bathrooms is subject to the appropriate zone in accordance with IEE Regulations. This product is suitable for zone 2 and outside zones. IT
IS NOT suitable for installation in Zone 0 or Zone 1. It is also not suitable for installation in saunas, steam rooms or shower cubicles. This product is
only suitable for permanent installation. DO NOT connect to a trailing plug and socket outlet. Although this product has an Ingress Protection rating of
IP44 it is only suitable for indoor use. Do not attach the product to surfaces that are damp or otherwise electrically conductive.
Installation safety and care
DO NOT strike glass components with hard or pointed items. DO NOT place very hot or very cold items against or in close proximity to glass surfaces
unless an adequately thick insulation material is used to prevent such items coming in contact with the glass. The nominal thickness of the mirror glass
used in this product is 5mm and is film backed for safety. If the glass becomes chipped or broken replace immediately.
This product should be positioned well away from curtains and other fabrics. Never cover the mirror. This product is heated, we recommend that it is
turned off after use and should never be left on for prolonged periods of time
This product could be dangerous and is only to be installed by a competent person.
Cleaning
It is recommended that the unit is cleaned with a soft, dry, non abrasive cloth when turned off. Never use cleaning agents or abrasive materials on any
type of surface finish. Do not allow moisture to come into contact with the electrical components.
DIFFUSE ILLUMINATED MIRROR Product Code: SLE510
Installation & care instructions
Please retain for future reference
Tavistock, Brassmill Lane Trading Estate, Bath, BA1 3JF
T. 01225 787870 | F. 01225 448877 | E. [email protected] | W. www.tavistock-bathrooms.co.uk Ref: MB.05.13 | V.1.00
22
2
2
OUTSIDE
ZONES
Z
O
N
E
2
Z
O
N
E
1
0.75m
m
5
2.
2
m0
.
3
0.6m
m
6
.0
0.6m
0.75m
BATHROOM ZONES DIAGRAM
EN 55015:2001; BS EN 60598-1: 2004, AMD:2001, AMD:2003; BS EN
60598-2-1: 1989. EN 60529: 1992 & A1, A2, A3.
