TCL W10W91 User manual

1
Hi! Let’s Get Started.
5K-12K Window AC
English / Spanish / French

2
DO NOT RETURN TO STORE
TCL SUPPORT:
www.tclusa.com/support
1-800-825-6747
contact us first
with any questions
WE ARE
READY TO
HELP
BE CAREFUL WHEN REMOVING
THE AIR CONDITIONING UNIT
Register and protect your purchase
Enjoy exclusive benefits with registration:
Text a photo of the
camera icon to 71403
Or register online at register.tcl.com
Need help? Visit photoregister.com/help
or text HELP to 71403
TCL-WACDGT
Text to Register
Expedited support and service Insider tips on your appliance
Exclusive oers and promotions Verification of ownership
Add a TCL Protection Plan when you register
your product and be covered from life’s mishaps
Thank you for choosing TCL. We want your ownership experience to
bring you as much joy as the appliance you purchased does, so we’re
oering you a special price on TCL Protection Plans when you
purchase during registration. Add a TCL Protection Plan within your
first 30 days of ownership to receive the best value at the best price.

IMPORTANT SAFETY INSTRUCTIONS
Before installing and using your air conditioner, please read this owner’s manual carefully. Store this manual in a safe place for future
reference. Your safety and the safety of others is very important to us. Please pay attention to all safety messages outlined in this
owner’s manual.
WARNING: To reduce the risk of fire, electrical shock or injury when using your air conditioner, follow the following basic precautions:
ELECTRICAL REQUIREMENTS
The electrical ratings for your air conditioner are listed on the model and serial number label located on the front right hand side of the
unit (when facing the front).
REGISTER YOUR APPLIANCE
You can register your appliance online by going to register.tcl.com
Be sure to retain your original sales receipt. A valid proof of purchase is required for all warranty claims.
BATTERY WARNING STATEMENT
Do not mix old and new batteries and do not mix alkaline, standard (carbon-zinc) or rechargeable (ni-cad, ni-mh, etc.) batteries
Document your model and serial numbers here:
Model #___________________________________ Serial #___________________________________
You can locate your 20 digit serial number underneath the bar code (On the right hand side of the AC).
WARNING Specific electrical requirements are shown in the diagram below. Follow the
requirements below for the type of plug on the power supply cord.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove the ground prong.
Do not use an adapter
Do not use an extension cord.
Failure to follow these instructions can result in
death, fire, or electrical shock
Wiring Requirements Power Supply Cord
RECOMMENDED GROUND METHOD
For your personal safety, this air conditioner must be grounded. This air conditioner is equipped with a 3 prong power supply cord
with a grounded plug. To minimize the possibility of electrical shock, the cord must be plugged into a 3 prong outlet and grounded in
accordance with all local codes and ordinances. If a 3 prong outlet is not available, it is the customer’s responsibility to have a properly
grounded 3 prong outlet installed by a qualified electrician.
FCC CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The distance between user and device should be no less than 20cm.
• 115 Volt (103 min – 127 max)
• (5K-8K) (0-8 amps)
• (10K-12K) (0-12 amps)
• (5-8K) (10 amp time-delay fuse or circuit breaker)
• (10K-12K) (15 amp time-delay fuse or circuit breaker)
• Use on single outlet circuit only
DO NOT RETURN TO STORE
TCL SUPPORT:
www.tclusa.com/support
1-800-825-6747
contact us first
with any questions
WE ARE
READY TO
HELP
BE CAREFUL WHEN REMOVING
THE AIR CONDITIONING UNIT

3
What’s in the box
Open the carton and remove the below parts.
NO. APPEARANCE PART NAME QUANTITY
1Top Rail 1
2AC Unit 1
3Filler Panels
(labeled “Left” & “Right”) 2
4Remote Control 1
5Sash Lock 1
6Battery (AAA) 2
7Lock Frame 2
83/8’’ Screws 4
91/2’’ Screws 3
10 3/4’’ Screws 4
11 Window Sash Seal 1
12 Foam Top Window Gasket 1
13 Foam Insulation
(only for E-star models) 2
Tip! Before unboxing, cut the tape
along the top of the box to loosen
contents inside. Once you lift and
remove the box, check the inside of
the box as some parts may be stuck
at the top. You can find the screws
and other parts located in the tray
beneath the AC unit.
5K - 6K Units
12
11
13
1
3
2
5-6k
8K
10-12K
12
11
10
13
3
5
6
2
7
8
4
9
1
10
5
6
7
8
9
4
12
11
10
13
3
5
6
2
7
8
49
1

4
What’s in the box
Open the carton and remove the below parts.
NO. APPEARANCE PART NAME QUANTITY
1Top Rail 1
2AC Unit 1
3Filler Panels
(labeled “Left” & “Right”) 2
4Remote Control 1
5Sash Lock 1
6Battery (AAA) 2
7Lock Frame 2
83/8’’ Screws 4
91/2’’ Screws 3
10 3/4’’ Screws 4
11 Window Sash Seal 1
12 Foam Top Window Gasket 1
13 Foam Insulation
(only for E-star models) 2
Tip! Before unboxing, cut the tape
along the top of the box to loosen
contents inside. Once you lift and
remove the box, check the inside of
the box as some parts may be stuck
at the top. You can find the screws
and other parts located in the tray
beneath the AC unit.
8K Units
12
11
13
1
3
2
5-6k
8K
10-12K
12
11
10
13
3
5
6
2
7
8
4
9
1
10
5
6
7
8
9
4
12
11
10
13
3
5
6
2
7
8
49
1

5
What’s in the box
Open the carton and remove the below parts.
NO. APPEARANCE PART NAME QUANTITY
1Top Rail 1
2AC Unit 1
3Filler Panels
(labeled “Left” & “Right”) 2
4Remote Control 1
5Sash Lock 1
6Battery (AAA) 2
7Lock Frame 2
83/8’’ Screws 4
91/2’’ Screws 3
10 3/4’’ Screws 4
11 Window Sash Seal 1
12 Foam Top Window Gasket 1
13 Foam Insulation
(only for E-star models) 2
Tip! Before unboxing, cut the tape
along the top of the box to loosen
contents inside. Once you lift and
remove the box, check the inside of
the box as some parts may be stuck
at the top. You can find the screws
and other parts located in the tray
beneath the AC unit.
10K-12K Units
12
11
13
1
3
2
5-6k
8K
10-12K
12
11
10
13
3
5
6
2
7
8
4
9
1
10
5
6
7
8
9
4
12
11
10
13
3
5
6
2
7
8
49
1

6
Let’s get started!
Step 1: Testing
Before you install the AC, let’s test it to make sure it made it safely to your home and your outlet
is proving proper power. Place it on a flat surface, plug it directly into a wall outlet, and turn it
on. Next use the Mode button on your control panel and put the AC into Cool Mode and press
the down arrow to set the temperature to the lowest setting. After 3 minutes, the AC should be
blowing cool air. If so, please continue on to the next step. If not, see detailed troubleshooting tips
at tclusa.com/support.
Step 2: Installation
A few quick notes before installing:
• This unit is made to fit inside a standard double-hung window.
• Check the size of your window before installing.
1. Use the (4) included 3/8” screws to fasten the top mounting rail to the unit.
2a. 2b. 2c.
Top Mounting Rail (4) 3/8” Screws
Top Mounting Rail
Filler panel Filler panel
Bottom Rail
Window
Frame
Window sill
Top Mounting Rail
Bottom Rail
4a./4b.
(2) 3/4” Screws
(3) 1/2” Screws
1/4”
2. Fasten the accordion styled window panel expander pieces to the unit. They are marked
“Right” and “Left”. Pull the leading edge of them to its maximum width. Then slide the panel
expanders into the grooved notches (slide downward) on the sides of the unit, and make sure
they are inserted into the metal rails tightly.
2a. 2b. 2c.
Top Mounting Rail (4) 3/8” Screws
Top Mounting Rail
Filler panel Filler panel
Bottom Rail
Window
Frame
Window sill
Top Mounting Rail
Bottom Rail
4a./4b.
(2) 3/4” Screws
(3) 1/2” Screws
1/4”

7
3. Carefully place the window air conditioner into the window where it is to be installed
(2 people are recommended for this step). Close the window securely. The AC unit should be
slightly tilted to the outside area to allow water to drain out from the unit.
2a. 2b. 2c.
Top Mounting Rail (4) 3/8” Screws
Top Mounting Rail
Filler panel Filler panel
Bottom Rail
Window
Frame
Window sill
Top Mounting Rail
Bottom Rail
4a./4b.
(2) 3/4” Screws
(3) 1/2” Screws
1/4”
4a. Fasten the air conditioner to the window frame, using the included ½” screws. Fasten each of
the panel extenders (Left and Right). You may have to drill a pilot hole in the window frame to
fasten these screws to the window sash.
4b. Attach the lock frame between the panel extender and the window sill and fasten them
together with the included ¾” locking screw. Repeat for each side.
2a. 2b. 2c.
Top Mounting Rail (4) 3/8” Screws
Top Mounting Rail
Filler panel Filler panel
Bottom Rail
Window
Frame
Window sill
Top Mounting Rail
Bottom Rail
4a./4b.
(2) 3/4” Screws
(3) 1/2” Screws
1/4”
4c. Attach the sash lock between the top of the sliding window and window frame, using 1 of the
included ¾” screws to secure the window closed.
Sash Lock
3/4” Screw
Window sill
Lock frame
Filler panel
Sash Seal

8
4d. To prevent outside air from entering the room, insert the foam top window gasket, cut to the
width of the window.
Sash Lock
3/4” Screw
Window sill
Lock frame
Filler panel
Sash Seal
5. Plug the unit into the electrical outlet as specified above in the electrical requirements.
Move the control to the COOL mode.
How to Control Your AC
All the basics you need to know to stay cool!
1. Power – turn the air conditioner on and o.
2. and Buttons – use these buttons on the control panel or
remote control to increase or decrease the desired temperature,
or time using the Timer. The temperature range is: 61 -88 degrees
Fahrenheit or 16 - 31 degrees Celsius.
3. Display – By pressing the Display button on the remote, it can switch
o/on all lights and LED Display. When the timer is not in use, the
operation mode and the set temperature will be displayed. Time will
be displayed under the timer setting.
4. Modes – Press the mode button on the control panel to cycle and
select a MODE, OR select a MODE by pressing the desired button on
the remote.
• Auto Mode – press the MODE button on the panel or the Auto
Mode button on the remote - In AUTO mode the unit automatically
chooses the mode of operation (COOL, DRY or FAN). In this mode
the temperature will be set according to the room temperature
(tested by the temperature sensor which is incorporated in the
indoor unit.).
• Cool Mode - press the MODE button on the panel or the Cool
button on the remote - The cooling function allows the air
conditioner to cool the room and at the same time reduces air
humidity. Adjust the fan speed and air temperate to your desired
comfort level. In this mode, if Eco is not enabled, the fan may
continue to run after reaching the desired temperature.
• Eco Mode – press the ECO MODE button on the panel or the ECO button on the remote
- When the unit is in ECO mode, the light will turn on. In ECO mode, the unit will turn o
once the room is cooled to the user-set temperature. The unit will turn back on when the

9
room temperature rises above the user-set temperature. While in ECO mode the fan will
occasionally turn on for a few seconds in order to take a accurate temperature reading.
• Fan Mode – press the MODE button on the panel or the Fan Only button on the remote.
This Fan Only mode only works when the air conditioner is vented.
• Fan Speed – press the FAN SPEED button on the panel or the Fan Speed button on the
remote - Press the FAN SPEED button to choose the fan speed options. You can choose Hi,
Med, Lo or auto speed in COOL mode and choose Hi, Med, Lo in FAN mode.
• Dry Mode – available only by pressing MODE button on the panel - This function reduces
the humidity of the air to make the room more comfortable. Press the MODE button to set
the DRY mode. An automatic function of alternating cooling cycles and air fan is activated.
5. Timer Button – press the TIMER button on the panel or the Timer button on the remote to set
the timer.
• Set Timer On: With the AC o, press the Timer button and then use the and
buttons to set the desired temperature. Press the Timer button again and use the
and buttons to set the desired amount of time before the AC turns on. Press the
timer button again to start the countdown.
• Set Timer O: With the AC on, press the Timer button and then use the and
buttons to set the length of time before the AC will turn o. Press the timer button again to
start the countdown.
Note: It can be set to automatically turn o or on in 0.5-24 hours. Each press of the buttons will
increase or decrease the timer. The Timer can be set in 0.5 hours increment below 10 hours and
1 hour increments for 10 hours or above.
The SET light will turn on while setting. To cancel the set function, press the TIMER button again.
6. Sleep Button – press the SLEEP button on the panel or the Sleep on the remote – by doing
so, all of the display lights will turn o after a while, but the Sleep light is always on. In SLEEP
mode, the air conditioner will automatically adjust the temperature and fan speed to make the
room more comfortable during the night. The set temperature will automatically raise every
30-60 minutes, and at most change six times until the set temperature is 81 or 82 degrees.
7. Filter Button – After the fan motor runs for 500 total hours, the Filter Check light will turn on
to remind the user to clean the filter. After you clean the filter, you can turn o the light by
pressing the Filter button.
Normal Operating Sounds
You may hear a pinging noise, caused by the water hitting the condenser on rainy days, or when
the humidity is high. This design feature helps remove moisture and increase eciency.
You may hear the thermostat click when the compressor cycles on and o. Water will collect in the
base pan on rainy days, or high humidity days. The water may overflow and drip from the unit on
the outside. The fan may run, even when the compressor is not on.

10
Troubleshooting
Having trouble completing installation? Don’t worry, it’s usually an easy fix.
PROBLEM POSSIBLE CAUSES SOLUTIONS
Air Conditioner
will not start
The air conditioner is unplugged • Make sure the air conditioner is plug is
pushed completely into the outlet
The fuse is blown/circuit breaker
is tripped
• Check the house fuse/circuit breaker box
and replace the fuse or reset the breaker
Power Failure
• The unit will automatically re-start when
power is restored
• There is a protective time delay (approx.
3 minutes) to prevent damage to the
compressor. For this reason, the unit may
not start normal cooling for 3 minutes after
it is turned back on.
The current interrupter device is tripped
• Press the RESET button located on the
power cord plug
• If the RESET button will not stay
engaged, discontinue use of the air
conditioner and contact a qualified service
technician.
Air Conditioner does not
cool as it should
Airflow is restricted
• Make sure there are no curtains, blinds,
or furniture blocking the front of the air
conditioner
The temperature control may not be set
correctly
• Lower the set thermostat
temperature
The air filter is dirty • Clean the filter. See the Cleaning
and Care Section of the manual
The room may be too warm • Please allow time for the room to cool
down after turning on the air conditioner
Cold air is escaping • Check for open furnace registers and cold
air returns
The Cooling Coils are frozen • See “Air Conditioner Freezing Up” below
Air Conditioner
is freezing up
Ice blocks the air flow and stops the air
conditioner from cooling the room
• Set the MODE to HIGH FAN or
HIGH COOL and set the thermostat to a
higher temperature
Remote Control
is not working
The batteries are inserted incorrectly • Check the position of the batteries
The batteries may be dead • Replace the batteries
Water is dripping outside Hot and humid weather • This is normal
Water is dripping inside
the room
The air conditioner is not correctly tilted
outside
• For proper water drainage, make sure the
air conditioner is slightly tilted downward
from the front of the unit to the rear
Water collects in the
base pan
Moisture removed from the air is draining
into the base pan
• This is normal for a short period in areas
with low humidity and normal for a longer
period in areas with high humidity
Digital Display reads
“E1”, “E2” A sensor has failed • Contact customer service

11
Wi-Fi App Installation and Instruction Manual
(for wifi models only)
Step 1: Download and Install the TCL Home Comfort App
1. Using your camera function on your smartphone, please scan the QR code below to be
directed to download the latest App for your TCL branded air conditioner.
If your phone does not currently have a QR scanner installed you can download and install
one from your App store.
tcl.link/homeconnectapp
Note: The TCL Home Comfort App is supported on 2.4 GHZ Wi-Fi Channels only.
Please be sure your connection is using a Wireless channel broadcasting in 2.4GHZ
2. After navigating to the TCL Home Comfort App select DOWNLOAD, INSTALL, and then
OPEN.

12
Step 2: Activate the TCL Home Comfort App
1. The first time you access the App after downloading, an activation screen will appear. Scan
the activation QR code using your phones camera (click the “Scan” button and scan the QR
code below).
Note: If scanning the QR code, TCL Home Comfort must be provided permission to access the
camera.
If permission is not granted, the alternative method of entering the TCL activation code is still
available.
2. You can also type in the activation code TCL after clicking on the Enter Activation Code
prompt at the bottom of the screen.

13
Step 3: Register Your Account
1. Once you download the App, you will need to create an account. Click the “Register” button
to begin the registration process. You can register with your email address OR with a mobile
phone number.
Register with an email address:
Register with a mobile phone number: Select “or Register with Mobile number” on the bottom of
the screen. You will be sent a verification code via text to complete the registration process.

14
Step 4: Login to Your User Account
1. Once you have registered and created an account, click the “Login” button. You will be able to
login with either the email account or mobile phone number you registered with.
2. For phone number login: You will be requested each time to validate login with a login code
sent via text. Press the “Sign In with SMS” button to enter the login screen. Type in your
phone number and press “Get” to receive a verification code. Once the verification code is
received, type it into the login screen and press “Login”.
Forgot Password?
If you forget your password, you can retrieve it by following these instructions:
1. Press the “Forgot password” button to enter the next page.
2. Type in the registered phone number or email address and press
the “Next” button to continue.
3. You will receive a verification code to continue. Type in the code received and set a new
password. Press the “Confirm” button to finish.

15
Step 5: Add Your AC Unit
After installing the TCL Home Comfort App on your mobile device, you must then add your AC
unit to be controlled by your installed app. Follow the directions below:
1. Press the “Add Device” and click the type of product you are connecting to.
Step 6: Connect Your AC Unit to the Wireless Network
There are two setup Modes/Methods to connect the AC unit to the wireless network.
Reminder: The TCL Home Comfort App only works on 2.4 GHZ networks.
Note: The default set-up mode will be CF mode when first starting the AC unit.
CF Mode - When setting up your AC unit using a Wi-Fi connection using the CF mode, the AC unit
being connected for Wi-Fi operation will automatically search for an available wireless
network and connects automatically when the setup directions are followed. The unit
and device will be synced together afterwards.
AP Mode - If your AC unit does not connect to the mobile device through the wireless network
using the setup instruction in CF mode, you can connect the mobile device to the
AC unit using the air conditioner’s Wi-Fi adapter or “Device hotspot”. The AC unit
will show as a wireless network under the mobile devices Wi-Fi connections as
“TCLHomeComfort -xxxx”. You can then connect the mobile device from the AC unit’s
hotspot. After the AC unit is turned o/on the next time you use it, the AC unit will
connect to the wireless network the phone is connected to.

16
Add the AC Unit to the Wireless Network using “CF Mode”
1. The App and AC unit automatically defaults to CF mode upon start up. Follow the prompts
on the screen and then press “ Next Step” to continue.
Note: If the AC unit is not in CF mode, press Display on the remote 6 times. After 8 to 10 seconds
your will hear two beeps and the AC will display CF.
2. Select the network you wish to connect to, enter the router password and press “Next” to
continue.
Note: If having diculties finding or joining your wireless network you may need to give the TCL
Home Comfort App permission to enable Location. This setting can typically be found by going to
Settings > Apps > TCL Home Comfort and then select to enable Location. The exact location and
method to enable this setting varies by phone OS and version.

17
3. After connecting to the wireless network, The TCL Home Comfort App software will
automatically try to pair with the AC unit. The AC unit’s LED screen may display “PP” or “SA”,
indicating it is searching for the network signal. This may take 10-15 seconds to connect the
AC to the network.
4. After successfully pairing the AC unit to the network, the page will display as below. You can
“Rename” the AC unit as you like, share with family, or press “Done” to start to controlling the
device.
Note: If at any time you need to start over, pressing “Display” on the remote control 6 times will
reset the wireless setup configuration on the AC unit back to CF mode. Pressing the “Display”
button an additional 6 times after CF mode appears will switch the unit to AP mode.
Please allow the unit 10-15 seconds to switch modes if toggling from CF to AP modes.

18
Add the AC Unit to the Wireless Network using “AP Mode”
If connections to the wireless network fail using the “CF mode”, you can connect using the “AP
mode” (using the AC unit as a mobile hotspot).
1. On the App page indicating CF mode, click “AP mode” in the top, right-hand corner as
illustrated.
2. AP should show on the page as illustrated below. Press “Next Step” to continue.
3. To the switch the AC unit over to AP mode - Press “Display” on the remote control 6 times
within 6 seconds so the AC unit switches from “CF mode” to “AP mode”. Allow the unit 10-15
seconds to switch modes and AP will flash on the AC unit display screen when complete.

19
4. Select the Wi-Fi network you are trying to connect to, type in the password, and press “Next”
to continue.
5. Open your mobile device settings to get to Wi-Fi connections.
6. “TCLHomeComfort-xxxx” should show as an available network connection option. Connect to
the TCLHomeComfort-xxxx network.
7. After connecting to “TCLHomeComfort -xxxx” network using the AC unit’s Wi-Fi adapter,
return to the TCL Home Comfort App to resume setup.
Note: You may need to manually navigate back to the TCL Home Comfort App.
