TCL 32B2800 User manual

Need assistance?
visit our website at www.tclusa.com
or call 1-877-300-8837 (for mainland 48 States),
or 1-877-800-1269 (for AK, HI, and Puerto Rico).
User’s Guide
For use with model: 32B2800
Figures and illustrations in this User’s Guide are
provided for reference only and may dier from
actual product appearance. Product design and
specications may be changed without notice.

they exit
is

Table of Contents
3
Chapter 1: Introduction
Chapter 2: General Operation
Chapter 3: Advanced Functions
Chapter 4: Other Information
16
4
4
4
4
4
4
4
5
5
6
7
7
8
8
9
9
9
10
10
11
13
14
14
14
15
15
Precautions .........................................................................................................................................
Product .............................................................................................................................................
Power and Plug ................................................................................................................................
Power Cord and Signal Cable ..........................................................................................................
Use Environment ..............................................................................................................................
Cleaning ...........................................................................................................................................
Hanging the TV Set on the Wall .......................................................................................................
...............................................................................................................................
Sockets ................................................................................................................................................
Remote Control Functions .................................................................................................................
Buttons on the TV
.......................................................................................................................................
Switching off .......................................................................................................................................
Setup Wizard .......................................................................................................................................
S .....................................................................................................................................
....................................................................................................................................................
.................................................................................................................................................
Switching on
Source elect
Menu
Sound ..................................................................................................................................................
Time .....................................................................................................................................................
Setup ....................................................................................................................................................
Lock ....................................................................................................................................................
................................................................................................................................................
........................................................................................................................................................
......................................................................................................................
....................................................................................................................................................
Photo ...................................................................................................................................................
Music ..................................................................................................................................................
Channel
PC
AV / Component / HDMI
Media
Troubleshooting ..................................................................................................................................
16
..................................................................................................................................Base Installation
Important Information..........................................................................................................................1
Important Safety Instructions..............................................................................................................2
17
............................................................................................Battery Caution & Disposal Information
17
Care and Cleaning ...............................................................................................................................
17
....................................................................................................................Television Specifications
18
Limited Warranty .................................................................................................................................
20
............................................................................................Legal Statement of TCL ..........................

Introduction
4
Chapter 1
Precautions
Product
Read all of the instructions before operating the set.
Keep these instructions well for future use.
Do not block or cover the ventilation openings on the
back cover.
Do not push objects of any kind into this unit through
the cabinet slots as they could touch the current
carrying parts or short-circuit parts, resulting in fire,
electric shock, or damage to the unit.
as this may cause
damage
Do not touch the screen surface with fingers as this
may scratch or mar the TV screen.
Do not impact the TV screen with hard pressure as
this may damage the TV screen severely.
Do not attempt to open the cabinet
. There are no parts inside you can service by
yourself. Refer all servicing to qualified personnel.
Cleaning
Dust the set by wiping the screen and the cabinet with
a soft, clean cloth or some special liquid cleaner.
Do not apply excessive force to the screen when
cleaning.
Do not use water or other chemical cleaner to clean the
screen as this may damage the surface of the TV
screen.
Unplug the set under the following conditions:
- If the set will not be used for a long period of time.
- If the power cord or the power outlet/plug is damaged.
- Follow the instructions to install and adjust the
product. Adjust those controls that are covered in this
operating instructions as improper adjustment of other
controls may result in damage. If this happens, unplug
the set and refer to the service personnel.
- If the set is subject to impact or has been dropped to
have the cabinet damaged.
Where the mains plug or an appliance coupler is
used as disconnect device, the disconnect device
shall remain readily operable.
(* Where an all-pole mains switch is used as the
disconnect device, the switch shall remain readily
operable.)
Power and Plug
Do not allow anything to rest on or roll over the power
cord and the signal cable.
Protect the power cord and the signal cable from being
trampled.
Do not overload the power cord or the power outlet.
Do not expose the power cord and the signal cable to
moisture.
Power Cord and Signal Cable
Do not place the set on an unstable cart, stand, or table.
Place the set on a place that allows good ventilation.
Do not use the set near damp, and cold areas. Protect
the set from overheating.
Keep the set away from direct sunlight.
Apparatus shall not be exposed to dripping or splashing
and no objects filled with liquids, such as vases, shall be
placed on the apparatus.
Do not use the set near dust place.
Use Environment
Hanging the TV Set on the Wall
Warning: This operation requires two people.
To ensure a safe installation, observe the following safety
notes:
Check that the wall can support the weight of the TV
set and wall mount assembly.
Follow the mounting instructions provided with the wall
mount.
The TV set must be installed on a vertical wall.
Make sure to use only screws suitable for the material
of the wall.
Make sure that the TV set cables are placed so that
there is not danger of tripping over them.
All other safety instructions about our TV sets are also
applicable here.
Note：
Graphics contained within this publication are
presentation only.
Warning: the batteries shall not be exposed
excessive heat such as sunshine, fire or the like.

5
USB socket (input)
Sockets
Note: The location and names of the sockets on the TV may vary according to
TV model, and not all sockets available on all models.
USB This socket can be used to connect an USB device.
Introduction
1. / button MENU
Turns the TV on or standby.
menu or press to return to the previous menu.Before enter menu, long press
/MENU button for 2 seconds to display Source Select. Long press it for 5
seconds to go to Standby.
The TV is on,press it,brings up the main
Buttons on the TV
Take a certain model for an example:
Note: Under USB condition, CH.+ button acts like INPUT button in remote to select different sources and
. Press CH.- button to display or cancel the menu at bottom. /Menu button
can act like the OK button on the remote.
CH.+/- button
can’t work act like up/down direction buttons
3. CH. +/- button
Scans up/down through the channel list. In the menu system, they act like the up/down
remote and adjust menu controls.
direction buttons on the
2. VOL. +/- button
Increases/decreases the volume. In the menu system, they act like the right/left
direction buttons on the remote and adjust menu controls. (Note: In some menus,
VOL.+ also acts like the OK button on the remote.)
HDMI 1
HDMI1 and HDMI2 socket (input)
HDMI 2
( HL)M
or The HDMI can be used to connect a
PC with a compatible video card installed, certain DVD players or a high-definition
compatible digital satellite decoder. This socket p
(High-Definition Multimedia Interface) socket
rovides an uncompressed digital
connection that carries both video and audio data by way of an integrated mini-plug
cable.
NOTE: HDMI2 support MHL.
AV(VIDEO)/YPbPr component sockets (input)
Y/VIDEO
Pb
Pr
COMPONENT / AV
IN
These AV(VIDEO)/Y sockets can be used to connect a device that has component
video sockets, such as a DVD player. The component sockets can recognize if the
device you're connecting to is Y Pb Pr compatible. The component sockets provide
excellent picture quality because the video is separated into three separate parts.
CH.
-
CH.+
+
R
L
AV &PC&COMPONENT
AUDIO IN
AV & PC & AUDIO IN COMPONENT
These AUDIO IN L & R sockets can be used to connect a range of equipment,
including video recorders, camcorders, satellite receivers, DVD players, or games
consoles. AUDIO IN sockets are shared by AV,VGA and YPbPr sockets.
SPDIF SPDIF/AUDIO sockets (output)
PC socket (input)
This socket can be used to connect a computer.
PC IN
AC IN~ AC In socket (input)
This socket can be used to connect a . AC supply

6
Introduction
Remote Control Functions
Most of your television's functions are available via the menus that appear on the
screen. The remote control supplied with your set can be used to navigate through
the menus and to configure all the general settings.
-In TV source, use these buttons to enter channel
/

7
RF IN
long press /MENU button for 5 seconds

8
General Operation
Setup Wizard
Connect an RF cable from the Tv s input called
“RF-In”and to your TV Aerial socket.
Select Language
1. Press / button on the remote control to select
the language to be used for menus and message.
2. Press / button on the remote control to select
go to next step and press OK/ button to go.
Time
3. Press / button on the remote control to select
go to next step and press OK/ button to go.
Setup Wizard
Menu Language
Go to next step
Please select your preferred language
Move Select Clear
MENU
2. Press / button on the remote control to select
the time zone, daylight saving time and time format
you want to.
1. Press / button on the remote control to adjust
time zone.
Setup Wizard
Select the time zone & Daylight saving time
Time Zone
Daylight Saving Time
Time Format
Go to next step
Pacific
Off
12-hour
Move Select Return
MENU
English
1. Press / button on the remote control to select
the antenna type.
2. Press / button on the remote control to select
go to next step and press OK/ button to start auto
scan.
Setup Wizard
Air/Cable
Go to next step
Select the antenna type then auto scan
Setup Wizard
Clear
MENU
Analog :
Digital :
RF CH :
7
Total Found
:
Move Select Return
MENU
Cable
0
Source elect S
Press INPUT button to display the input source list,
Press / button to select the input source.
Press OK button to enter the input source,
Press Clear button to quit.
Source Select
TV
Component
HDMI1
HDMI2
PC
Media
AV
Setup Wizard
TV Location
Go to next step
Please select your preferred mode
Move Select Clear
MENU
Retail Mode
Setup Wizard
Home mode defaul settings are recommended for
in-home use, ENERGY STAR@ qualified.retail mode is
intended for in-store display
Select Return
MENU
Are you sure you select your retail mode
TV Location
1. Press ◄/► button on the remote control to select
Home Mode or Retail mode.
2. Press ▲/▼ button on the remote control to select
go to next step and press OK button to go.
Note: Choosing “Home Mode” for the TV assigns the
optimal picture settings for most home environments.
Choosing “Retail mode”, which is not ENERGY STAR
compliant, sets the unit up with predefined settings
for retail displays. In this setting, the power
consumption may exceed the requirements of the
ENERGY STAR®qualification.
Retail mode
Press ◄/► button on the remote control to select Yes/No.
Note:
If you select Yes, a screen menu will proceed to select the
antanna type.
If you select No, a screen menu will go back to the previous
menu to select Home Mode.

9
Advanced Functions
Chapter 3
Sound
Press MENU to enter the main menu, Press / button
to select.
Press to enter.
Press MENU again to exit or back to parent menu.
【Noise Reduction】
Set options to reduce video noise.
Off Select to turn off video noise detection.
Low Detect and reduce low video noise.
Medium Detect and reduce moderate video noise.
High Detect and reduce enhanced video noise.
【Dynamic Backlight 】
Press / button to select (Off/Low/Hight).
【Picture Mode】
Adjust picture mode to change picture appearance.
Press / button to select(Standard / Vivid / Soft / User /
Power Saving).
Standard Produces a highly defined image in a
normally lit room.
Vivid Produces a highly defined image in a
brightly lit room
Soft Produces a highly defined image in a
soft lit room.
User Select to customize picture settings.
【Brightness】
Adjust darkness of black sections in the picture.
Press / button to adjust.
Power Saving Under power saving condition, it can
meet “Energy Star” requirement.
Main Menu Operation
1. Press MENU to enter the main menu, Press /
button to select.
2. Press to enter.
3.Press / button to select among Picture Mode /
Brightness / Contrast / Color / Tint / Sharpness /
Color Temperature / Advanced Settings.
5.Press / button to adjust.
6.Press MENU again to exit or back to parent menu.
Move Select
MENU
Picture Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temperature
Advanced Settings
User
50
50
50
Normal
Return
50
50
Pict ur e Sou nd Tim e Se tup Loc k Chann el
Picture Sound Time Setup Lock Channel
Menu
1. Press MENU to display the main menu or return to the
previous menu or close the main menu.
2. Press / to highlight the desired menu icon.
【Tint】
Adjust the hue(Red,Green) of the picture.
Press button to adjust. /
【Sharpness】
Object edges are enhanced for picture detail.
Press button to adjust. /
【Color Temperature】
Change the overall color cast of the picture.
Normal
Warm
Cool
Produces a vivid image.
Produces a red-hued image.
Produces a gentle blue-hued image.
【Advanced Settings】
Adjust advanced video features to fine tune the picture.
Press OK/ button to enter.
【Aspect Ratio】
Adjust how the picture fills the screen.
Normal
Wide
Zoom
Cinema
Automatically adjust Aspect Ratio
based on TV size and TV program.
Use to watch wide screen(16:9)
content.
Expands image to fill screen. Top and
button maybe cut off.
Stretches image at edges but keeps a
clear image in the center.
【Contrast】
Adjust the white level of the picture.
Press / button to adjust.
【Color】
Adjust the color intensity of the picture.
Press button to adjust. /
Bass
Treble
Audio Language
AVL
Digital Audio Output
Surround Sound
50
50
English
RAW
Off
Off
Balance 0
MTS Stereo
Move Select Return
MENU
Pict ur e Sou nd Tim e Se tup Loc k Channel
Sound Mode Standard
“Power Saving”
【Dynamic Contrast】
Automatically adjust picture detail and brightness.
Press / button to select (Off/On).

Advanced Functions
10
Pict ur e Sou nd Tim e Se tup Loc k Chann el
Time
Press MENU to enter the main menu, Press /
button to select.
Press to enter.
Press MENU again to exit or back to parent menu.
1.Press / button to select among Sleep Timer /
Time Zone / Daylight Saving Time / Time Format /
Auto Clock / Clock
Sleep Timer
Time Zone
Daylight Saving Time
Time Format
Auto Clock
Clock 1980/01/06 12:00 AM
Off
Pacific
Off
12-hour
On
Move Select Return
MENU
2. Press / button to select among Sound Mode
/ Bass / Treble / Balance / MTS / Audio Language
/ Digital Audio Output /Surround Sound / AVL
1.Press to enter.
3.Press / button to adjust.
4.Press MENU again to exit or back to parent menu.
【MTS】
Configures the multi-track sound. It is only available in ATV.
Press button to select(Mono/Stereo/SAP). /
Mono Sets the sound to mono.
Stereo Sets the sound to stereo when stereo
is not available, the sound is
automatically switched to mono.
SAP Sets the sound to the second audio
program.
【Audio Language】
Select the language supported by the chosen digital
channel. It is available Only in DTV.
Press button to select(English / / ). / French Spanish
【 】Digital Audio Output
Send digital audio to external audio system.
Press button to select. /
PCM Select to output audio in 2-channel
stereo.
RAW Passes through RAW audio sound.
【 】Surround sound
Press / button to select(On / Off).
【AVL】
Set the auto volume control.
Press / button to select(On / Off).
2.Press / button to adjust.
3.Press MENU again to exit or back to parent menu.
【Sleep Timer】
Set a timer for the TV to turn off automatically.
Press / button to select(Off / 5min / 10min
/ 15min / 30min / 60min / 90min / 120min / 180min
/240min).
Pict ur e Sou nd Tim e Se tup Loc k Channel
3.Press / button to select among Menu Language /
Transparent / OSD Timeout / Closed Caption /
Input Label / Other settings / Restore Default /
Setup Wizard.
2.Press to enter.
4.Press button to adjust. /
5. ENU again or back to parent menu. Press Mto exit
【Menu language】
Press button to select your desired menu
language(English/French/Spanish).
/
【Transparent】
2. Adjust the transparency of the OSD (on screen display)
Menu.
1.Press / button to adjust.
Menu Language
Transparent
OSD Timeout
Closed Caption
Input Label
Other Settings
Restore Default
Setup Wizard
English
25%
Setup
1.Press MENU to enter the main menu, Press /
Button to select.
5 Sec.
Select Move Clear
MENU
【Time Zone】
Select your time zone.
Press / button to select(Eastern / Central /
Mountain / Pacific / Alaska / Hawaii / Samoa /
Newfoundland / Atlantic).
【 】Daylight Saving Time
Set the daylight saving time for your area.
Press button to select(On / Off). /
【 】Time Format
Select your time format.
Press button to select(12-hour / 24-hour). /
【 】Auto Clock
Note: when Auto Clock is Off, you may adjust the
clock.
Use to synchronize the display automatically.
Press button to select. /
【OSD TimeOut】
2.Adjust the duration of the OSD (on screen display)
menu.
1.Press button to select. /
【 】Clock
Use to adjust time manually.
Press / button to select. / /

11
Advanced Functions
Pict ur e Sound Ti me S etu p Lo ck Channel
Close Caption
【 Label】Input
Press / button to enter. OK
Move Next Return
MENU
Component
HDMI1
HDMI2
PC
Media
Default
Default
Default
Default
Default
【Other Settings】
Set the parameter of audio only.
Press / button to enter. OK
Lock
1.Press ENU to enter the main menu, Press M /
button to select.
2.Press to enter.
3.Enter your 4-digital password. Default password is
0000.
Note: If you forget the password, enter 0432 to override
any existing codes.
【Audio Only】
Play the audio with the picture turned off. When you
turn the Audio Only on , the panel will be dark; and
except VOL+, VOL-, POWER and MUTE buttons, press
any key to exit the Audio Only status.
【Restore Default】
Restore the settings of user interface to the default.
Press / button to enter. OK
【Setup Wizard】
Set the first time installation.
Press / button to enter. OK
For detail please refer to page 8.
Press button to select(On / Off). /
【ption】O
Adjust the digital Closed Captioning setting.
Press OK / button to enter.
【 】Mode
Set the Mode of digital Closed Captioning. Automatic
uses broadcaster s style.
Press button to select(Default / Custom). /
【 】Font Style
Select from 8 font styles.
Press button to select(Default / Font 0 / Font 1 / /
Font 2 / Font 3 / Font 4 / Font 5 / Font 6 / Font 7).
TV Default
AV Default
Close Caption
【 】CC Mode
Turn Closed Captioning on/off.
Press button to select(CC Off / CC On / CC /
On Mute).
【 】Analog CC
Set Closed Captioning for standard(analog) program.
Press button to select(CC1 / CC2 / CC3 / /
CC4 / Text1 / Text2 / Text3 / Text4).
【 】Digital CC
Set Closed Captioning for digital program.
Press button to select(Off / Service1 / Service2 / /
Service3 / Service4 / Service5 / Service6).
【BG 】Opacity
Adjust the digital Closed Captioning background
transparency.
Press button to select(Default / Solid / /
Flashing / Translucent / ). Transparent
*Note: All the options can be adjust while the mode
is Custom.
【Closed Caption】
Adjust Closed Captioning settings. only available under
TV and AV source.
Press / button to enter. OK

12
Advanced Functions
Pict ur e Sound Ti me S etu p Lo ck Chan nel
【System Lock】
Lock or unlock the buttons on the TV.
Press button to select(Off / On). /
【Input Block】
Block or unblock the input sources.
Press OK / button to enter.
Press button to select(Unblock / Block). /
【US Rating】
Restrict movie and TV programs by US Ratings.
Only available when "System Lock" is "on".
Press OK / button to enter.
【Canada Rating】
Restrict movie and TV programs by Canadian Ratings..
Only available when "System Lock" is "on".
PressOK/ button to enter.
For detail please refer to page 12.
RRT Setting】【
Display an advance V-Chip rating table for digital
channels.
The item is available only When current stream has
downloadable rating data.
【Reset RRT】
Reset the RRT to default.
The item is available only When current stream has
downloadable rating data.
US Rating
For the United States, the rating setting basically
include the following options: TV, MPAA.
TV
The TV rating compose of two aspects: age-based
and content-based.
Move Next Return
MENU
TV Rating
Press OK to Lock or Unlock
: Block
TV-Y
ALL
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
Age
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
Define
General audience
Parental guidance suggested
Parents strongly cautioned
Retricted
No one 17 and under admitted
Adult audience only
Note: The content ratings will increase depending on
the level of the age-based rating.
For example, a program with a TV-PG V(violence)
rating may contain moderate violence, while a TV-14 V
(violence) rating may contain intense violence.
So locking a higher level option will automatically
cause locking the options that has more sensitive level.
MPAA
This system defines the rating control which come from
MPAA rules.
Rating
Off
G
PG
PG-13
R
NC-17
X
Define as
Close
General audience. All ages admitted.
Parental guidance suggested. Some
material may not be suitable for children.
Parents strongly cautioned. Some
material may be inappropriate for children
under 13.
Restricted. Children under 17 require
accompanying parent or adult guardian.
No one 17 and under admitted.
Adult audience only.
FV V S L D
【Change Password】
1.Press OK/ button to enter.
2.Enter a new 4-digital password then re-enter it to
confirm.
Pict ur e Sou nd Tim e Se tup Loc k Channel
Move Select Return
MENU
Component
HDMI 1
PC
Media
UnBlock
TV
HDMI 2
UnBlock
UnBlock
UnBlock
UnBlock
UnBlock
AV UnBlock
Pict ur e Sou nd Tim e Se tup Loc k Chann el
Lock
Move Select Return
MENU
System Lock
Change Password
On
Input Block
US Rating
Canada Rating
RRT Setting
Reset RRT
4.Press / button to select among Change Password /
System Lock / Input Block / US Rating / Canada Rating /
RRT Setting / Reset RRT.
5.Press ENU again to exit or back to parent menu.M
Pict ur e Sound Ti me S etu p Lo ck Chan nel
0-9 To Enter Return
MENU
Enter Password
-----

Pic tu re S ou nd Ti me S et up L oc k Ch an nel
Move Select Return
MENU
Are you sure to Auto
Scan?
No Yes
Pict ur e Sound Ti me S etu p Lo ck Channel
Pict ur e Sound Ti me S etu p Lo ck Channel
Advanced Functions
French
Canada
For Canada, the rating setting include the following options:
Canada English, Canada .
Canada English
These ratings are for programs which are using
English rating system.
Rating
13
Rating
Off
C
C8+
G
PG
14+
18+
Defined as
Close
Children
Children 8 years and older
General programming
Parental guidance
Viewers 14 and older
Adult programming
Rating
Off
G
8 ans+
13 ans+
16 ans+
18 ans+
Defined as
Close
General
Not recommended for children
under age 8
Not recommended for children
under age 13
Not recommended for children
under age 16
This program is restricted to adults
Canada
The ratings are for programs which are using
French rating system.
French
Channel
Press ENU to enter the main menu, Press M /
button to select.
2.Press / button to select among Air/Cable、 Auto
Scan 、Favorite 、Channel List、Show/Hide、Channel
Number、 Channel Label.
1.Press to enter.
3.Press button to adjust. /
4.Press ENU again to exit or back to parent menu. M
【Air/Cable】
Select signal type.
Press button to select(Air/Cable). /
Move Select Clear
MENU
Favorite
Channel List
Show/Hide
Channel Number
Channel Label
Auto Scan
Air
Air/Cable
3-0
【Auto Scan】
Automatically search for channels.
Press / button to enter. OK
Analog
Digital
RF CH
Total Found
1
4
1
:
:
:
:
【Favorite】
Add channels to create a favorite list.
Press button to enter.OK /
【Channel List】
Press button to adjust. /
【Show/Hide】
Show or hide the channels in your program list.
Press OK / button to enter.
【Channel Number】
Show the channel number.
Press button to adjust. /
【Channel Label】
Create labels for channels, up to 7 characters.
Press OK change
3-0
Prev Next
Channel Channel Label
MOVE Return
MENU
Return
MENU
1/1

Pict ur e Sound Ti me S etu p Lo ck Chan nel
Pict ur e Sou nd Tim e Lo ck
Move Adjust Return
MENU
V-Pos
Clock
Phase
Auto
50
50
25
Move Next Return
MENU
25%
English
Menu Language
Transparent
OSD Timeout
Closed Caption
Input Label
Pc Settings
Other Settings
Restore Default
14
Advanced Functions
【H-Pos】
Adjust the horizontal position of the picture.
Press button to adjust. /
【V-Pos】
Adjust the vertical position of the picture.
Press button to adjust. /
【Clock】
Minimize vertical stripes in the screen image.
Press button to adjust. /
【Phase】
Minimize horizontal distortion.
Press button to adjust. /
【Auto】
Adjust to the PC signal timing automatically.
Press button to enter. / OK
Notes:
1.Advanced settings in Picture menu is different,
other descriptions are the same as that for TV
mode. Select Advanced settings in Picture menu,
Aspect Ratio can select Full 100% or Point to Point.
Noise Reduction and Dynamic Contrast is invalid.
2.TIME menu and description are the same as that
for mode.TV
3.Close Caption in SETUP menu is invalid.
4.US, Canada, RRT Setting and Reset RRT in LOCK
menu is invalid.
5. mode has no CHANNEL menu.PC
AV / COMPONENT / HDMI
1. PICTURE menu and description are the same as
that for mode.TV
2. TIME menu and description are the same as that for
mode.TV
3.The function of Close Caption is available only in
AV/TV mode.
4.US Rating, Canada Rating is available only in AV
/TV mode. RRT Setting and Reset RRT in LOCK
menu is invalid.
5. mode has no CHANNEL AV / COMPONENT / HDMI
menu.
Note: Before operating Media menu,Plug in USB device,
then press INPUT button to set the Input Source to Media.
Press / button to select Media in the Source menu,
then press OK button to enter.
Media
PC
Press to select PC source.INPUT
Press ENU to enter the main menu, Press buttonM /
to select Setup menu.
Press to select PC Settings.
2.Press / button to select among H-Pos / V-Pos /
Clock / Phase / Auto .
1.Press OK / to enter.
3.Press button to adjust. /
4.Press ENU again to exit or back to parent menu. M
Press / button to select the option you want to adjust
in the main Media menu, then press OK button to enter.
15 Sec.
H-Pos 50
Setu p Channel
Photo Music
USB 2.0
C
Return
1/1

15
Press / button to select the file you want to watch in
the file selecting menu, then press OK button to play.
Press OK button again to display and operate file details.
When highlighting the option you select, the file information
will appear on the right.
Press / button to select menu in the bottom you
want to run, then press OK button to operate.
Music
Press / button to select MUSIC in the main menu, then
press OK button to enter.
Press / button to select drive disk you want to watch,
then press OK button to enter.
Press / button to select return option to back to the
previous menu.
Press / button to select the file you want to watch in
the file selecting menu, then press OK button to display
picture.
Press / button to select PHOTO in the main menu,
then press OK button to enter.
Press / button to select drive disk you want to watch,
then press OK button to enter.
Press / button to select return option to back to the
previous menu.
Note: Only support JPG format
Note: Only support MP3 format
ON
Advanced Functions

Troubleshooting
Most problems you encounter with your TV can be
corrected by consulting the following troubleshooting list.
No picture, no sound
1. Check if the fuse or circuit breaker is working.
2. Plug another electrical device into the outlet to make
sure it is working or turned on.
3. Power plug is in a bad contact with the outlet.
4. Check the signal source.
No color
1. Change the color system.
2. Adjust the saturation.
3. Try another channel. Black-white program may be
received.
Remote control does not work
1. Change the batteries.
2. Batteries are not installed correctly.
3. Main power is not connected.
No picture, normal sound
1. Adjust the brightness and contrast.
2. Broadcasting failure may happen.
Normal picture, no sound
1. Press the Vol+ button to increase volume.
2. Volume is set to mute, press the mute button to restore
sound.
3. Change the sound system.
4. Broadcasting failure may happen.
Unorderly ripples on the picture
It is usually caused by local interference, such as cars,
daylight lamps and hair driers. Adjust the antenna to
minimize the interference.
Blank screen in VGA mode
Perhaps the TV can not recognize the resolution set by
the PC. Suggest to change to the best resolution or other
standard resolutions of the Windows system.
Snowy dots and interference
If the antenna is located in the fringe area of a television
signal where the signal is weak, the picture may be marred
by dots. When the signal is extremely weak, it may be
necessary to install a special antenna to improve the
reception.
1. Adjust the position and orientation of the indoor/outdoor
antenna.
2. Check the connection of antenna.
3. Fine tune the channel.
4. Try another channel. Broadcasting failure may happen.
Ignition
Black spots or horizontal streaks appear, or the picture
flutters or drifts. This is usually caused by interference
from car ignition system, neon lamps, electric drills, or
other electrical appliance.
Ghost
Ghosts are caused by the television signal following two
paths. One is the direct path, the other is reflected from
tall buildings, hills, or other objects. Changing the direction
or position of the antenna may improve the reception.
Radio frequency interference
This interference produces moving ripples or diagonal
streaks, and in some case, loss of contrast in the picture.
Find out and remove the radio interference source.
Chapter 4 Other Information
16

Chapter 4 Other Information
17

18

19
