TCL C935U User manual

5.1.2 Channel Soundbar with Play-Fi / Dolby Atmos / DTS:X
C935U
User Manual

1
Contents
1 Before you begin ...................................................3
2 Welcome.................................................................6
What’s in the box ............................................................. 6
Overview of the Soundbar ............................................... 8
Overview of the wireless subwoofer .............................. 10
Set up your Soundbar system ....................................... 11
Position Your Soundbar and Subwoofer........................ 11
Mount your Soundbar on the wall.................................. 14
Install/replace the remote control batteries ................... 17
Overview of the Remote Control.................................... 18
3 Connect your Soundbar system ........................20
Connect your Soundbar to power supply...................... 20
Connect your wireless subwoofer to the soundbar....... 21
Connect with the HDMI cable........................................ 22
Optional: Connect your Blu-ray player .......................... 24
Connect with the optical cable ...................................... 25
Direction for setting up your Soundbar using an optical
cable .............................................................................. 26
Connect the Soundbar with your Bluetooth device....... 27
Add in Google home ...................................................... 28

2
Add in AirPlay 2.............................................................. 29
Use Spotify Connect...................................................... 30
Add in Amazon Alexa..................................................... 32
Online Firmware Update ................................................ 34
4 Use your Soundbar system ................................35
Use your Soundbar with the top panel or remote control .... 35
Listen to music from your Bluetooth device .................. 37
Use the USB cable or device for music playback ......... 38
5 Specications ......................................................39
6 Notice ...................................................................40
Disposal of your old product and battery.......................... 40
Trademarks........................................................................ 41
7 FAQ .......................................................................43

3
1 Before you begin
• Carefully read and observe all safety instructions in the
safety leaet.
• This soundbar is intended for indoor use only. In case it
accidentally gets in contact with small amounts of water,
unplug immediately and use a dry cloth to remove the
water.
• Unplug the soundbar if it is not used for long periods of
time or during lightning storms.
• Make sure the soundbar is installed on a solid surface
or solidly wall-mounted below your TV for the best
experience.
• Only use AAA 1,5V non-rechargeable batteries for the
remote control.
• In case any of the cables are visibly damaged or pinched,
unplug the soundbar and replace the cable.
• Be careful not to sharply bend the HDMI and optical
cable as they may affect the performance.
• Protect your hearing by adjusting to a proper volume.
Predefined and customizable sound settings are
available for your listening comfort.

4
The lightning flash with arrowhead symbol, within an equilateral triangle is
intended to alert the user to the presence of uninsulated dangerous voltage
within the product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the product.
This symbol indicates that this product incorporates double insulation
between hazardous main voltage and user accessible parts. When servicing,
use only identical replacement parts.
Warnings
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Make sure you read all the safety information before you use this product.
TCL ELECTRONICS AUSTRALIA PTY LTD bears no responsibility for accidents or damages caused by
unauthorized changes, modifications or improper use of the product.
User Manual can be found at www.tcl.com/au on the specific product page in the “Download” section.
滚滚长江东逝水
Important safety instructions
Safety
• Read these instructions - Read all the safety and operating instructions before operating the product.
• Retain these instructions - Retain the safety and operating instructions for future reference.
• Heed all warnings - Adhere to all warnings on the product and in the operating instructions.
• Follow all instructions - Follow all operating and use instructions.
• Do not use this apparatus near water - The appliance should not be used near water or moisture
– for example, in a wet basement or near a swimming pool and the like.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where it exits from the product. If the cord set is damaged, it must be replaced by a special cord set
available from the manufacturer or its service agent.
• Use only attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
CAUTION
• To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. This product
should not be exposed to dripping or splashing. No objects filled with liquids, such as vases, should be
placed on or near the product.
• The product is unstable if it is not properly placed or mounted to the wall. Be sure to follow the wall
mounting instructions provided in the user manual to ensure your safety.
• Do not expose batteries to excessive heat such as sunshine, fire, and so forth.
• To avoid the danger of suffocation, keep plastic packaging away from pets, babies, and children.
Do not use packaging bags in cribs, beds, carriages, or playpens.

5
• Unplug this apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
• The user must maintaina minimum distance of 20CM from the device at all time.
• This appliance is not intended for use by young children or infirm persons without supervision.
Young children should be supervised to ensure that they do not play with the appliance.
Cautions
• To prevent electric shock, match wide bladeof plug to wide slot, fully insert.
• Do not place any sources of danger on the product (for example: liquid filled objects, lighted candles).
• Disconnect the power cord to shut off when find trouble or not in use. The power cord shall be readily
operable.
• Use of controls or adjustments or performance of procedures other than those described herein, may
result in hazardous radiation exposure or other unsafe operation.
• The power cord/appliance coupler is used as the disconnect device, the disconnect device must remain
readily operable.
• The use of apparatus in tropical and moderate climates.
• The rating label is located at the bottom or back of the product.
Battery precautions
• Do not mix batteries (old and new or carbon and alkaline).
• Do not dispose of batteries in fire or water.
• Recycle or dispose of batteries as per state and local guidelines.
• Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
• When the remote control is not to be used for a long time (more than a month), remove the battery
from the remote control to prevent it from leaking.
with
• If the batteries leak, wipe away theleakage inside the battery compartment and replace the batteries
new ones.
• Keep away the batteries from heat or moisture.
• Do not carry or store batteries with other metallic objects. Doing so could cause batteries to short circuit,
leak or explode.
• If the battery compartment does not close securely, stop using the product and keep it away from children.
• Never recharge a battery unless it is confirmed to be a rechargeable type.
Disposal of your old product and battery
Your product is designed and manufactured with high quality materials and components, which can be
recycled and reused.
This product may contain lead and mercury. Disposal of these materials may be regulated due to
environmental considerations. For disposal or recycling information, please contact your local authorities.
This product contains batteries:
• Do not incinerate. Batteries may explode if overheated.
• For disposal or recycling information, please contact your local authorities.
CAUTION: Risk of explosion if the battery is replaced by an incorrect type.
CAUTION: Replacement of a battery with an incorrect type that can defeat a safeguard.
CAUTION: Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery,
that can result in an explosion.
CAUTION : Leaving a battery in an extremely high temperature surrounding environment that can result
in an explosion or the leakage of flammable liquid or gas.
CAUTION : A battery subjected to extremely low air pressure that may result in an explosion or the leakage of
flammable liquid or gas.

6
2 Welcome
Congratulations on the purchase of your new TCL
Soundbar! After it is set up and connected, you can
experience a superb sound quality and state-of-the-art
design to best t your home entertainment system. You are
recommended to read through this user manual which helps
you set up, connect and operate the product easily and
properly.
Let’s get started.
What’s in the box
Wireless SubwooferSoundbar
Remote control AC power cord x 2
AAA battery x 2

7
HDMI cable Wall mount kit (for
Soundbar)
Warranty card Manual
Wall mount template
Manual

8
Overview of the Soundbar
1
Short press to enter Sleep mode.
Long press to enter Standby mode.
2
Press to switch the audio source among
HDMI ARC/HDMI IN/OPT/BT/USB modes.
3
Press to select the Bluetooth function. Press and hold to
enter the pairing mode.

9
4
Press to increase or decrease the volume level.
5 LED Display
It indicates the Soundbar status (e.g. volume level,
Soundbar status).
6 White LED:
It indicates Wi-Fi connection status.
7 AC input power connector
8 USB Type A connector (only for music playback)
9 Optical input connector
10 Wi-Fi setup button
11 HDMI OUT (eARC/ARC) connector
12 HDMI 1 IN connector
13 HDMI 2 IN connector

10
Overview of the wireless subwoofer
1 AC input power connector
2 Amber LED indicator
• flashes slowly when the subwoofer is in standby
mode.
• ashes quickly when pairing is in progress.
• remains on solidly when pairing is successful.
3 PAIR
Press and hold button on the Soundbar main unit
for 5 seconds. Press and hold PAIR button on the
subwoofer untill pairing is complete. And then the amber
LED light will be solid up on the subwoofer.
Note
• Manual pairing is needed only in case of troubleshooting.

11
Set up your Soundbar system
Notes
• Make sure you read all the safety information before you
mount the Soundbar main unit on the wall.
• Make sure you use screws provided or specied by the
authorized manufacturer.
• TCL AUSTRALIA bears no responsibility for accidents or
damage caused by improper wall mounting and screws
installation or insufcient wall strength, etc.
• Additional tools (not supplied) are required for
installation.
• You can choose to place your Soundbar below the
center of your TV or mount it on the wall.
Position Your Soundbar and
Subwoofer
The ideal place to position the Soundbar main unit is
centered underneath your TV.
You are recommended to place the Soundbar main unit on
the top of the cabinet and right below the center of your TV.
The distance between the subwoofer and the Soundbar
main unit should be less than 3 meters.

12
TV
< 3m
< 3m
2m - 3.5m
AI Sonic-Adaptation
AI Sonic-Adaptation is a Room Calibration Technology
developed by TCL Audio Lab. To use this function, you need
to download TCL Home App and follow the instructions.
This Soundbar can be fully controlled by TCL-HOME App.
Features are not limited including power, volume, input,
effect, level, mode, AI Sonic-Adaptation etc. As well, TCL

13
Home App can help you to explore more smart features
without just a Soundbar. Please download from App stores.

14
Mount your Soundbar on the wall
1 Place the supplied wall mount template on the wall.
Make sure the wall mount template is at least 5cm
below the center of the TV.
2 Use a level to make sure the wall mount template is
positioned accurately.
3 Use tape to stick the wall mount template rmly on the wall.
4 Mark on the wall using each marking on the template
through the mounting holes.
5 Take away the wall mount template.
6 Drill a screw hole at each marking on the wall.

15
7 Insert the supplied screws into the hole of the wall
anchors.
8 Insert the sleeves into the hole of the wall anchors.
9 Fix and tighten the wall bracket screws on the wall.
10 Screw off the rubber cushions from the soundbar.
(Reserve the rubber cushions for future use)
* The rubber cushions can be used as soundbar mats
when you put the soundbar on the table.
Screw on the wall mount brackets to the soundbar.
11 Hang the Soundbar on the screws.
12 Ensure the soundbar is stable and safe hanging on the
wall.

16
Notes
• Check the installation location before you mount the
Soundbar on the wall (see ‘Mount your Soundbar on the
wall’ on page 14).
• You may consider to connect the cables first before
mounting the Soundbar on the wall.

17
Install/replace the remote control
batteries
Warnings
• Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Caution
1 Open the battery compartment, remove the old batteries
if necessary.
2 Place two new AAA batteries into the battery compartment
with the correct polarity (+/-).
3 Close the battery compartment.
Setup is complete. Your Soundbar is ready to use. For
more information about how to access different connection
options on your Soundbar, see the following chapter.

18
Overview of the Remote Control
1Screen display.
2Short press: mute / unmute the sound.
3Short press: power on / sleep
Long press: standby.
4Up/Down: increase/decrease the volume
Left/Right: Switch to previous/next music (Under
Bluetooth or USB mode).
5Short press: Play / Pause.
6Long press: Bluetooth Pairing
Short Press: switch to Bluetooth mode.
7Short press to enter input source menu.
Keep short press or use Up/Down/Left/Right to switch:
HDMI-eARC/Optical/USB/Bluetooth/HDMI 1/HDMI 2.
8Short press to enter the Level Menu. Switch different
