PH SERIES Single Output, DC/DC Converter 50W-600W
PH 600 S 280 − 5
■ Model naming method
Nominal output voltage
Nominal input voltage
Function
S: Simple function
F: Full function
Output power
Series name
■ Applications
Y
E
A
R
S
warranty
2
■ Features
● Conduction cooling
● High e󱐰ciency
● High power density: 61.6W/inch3 (600W type)
● Full-function model (F type)
N+1 parallel redundancy operation
Current sharing (load current balance)
IOG (inverter operation monitoring signal)
AUX (AUX-BIAS power output)
● Internal capacitor
PH50-150/300F: Aluminum electrolytic (output smooth-
ing), ceramic
PH300S/PH600S: Ceramic capacitor only (high reliability)
※PH300F24-*はUL、CSAおよびEN規格準拠
Please see the following page.
■ Product Line up
医 療 計 測 F A 半導体 その他
その他
ks
その他
ph
pf-a
hk-a
hws
alpha
dlp
fps
フォーマット
コンピュータ 通 信 F A 半導体
その他
コンピュータ 通 信 医 療 計 測 F A 半導体
その他
コンピュータ 通 信 医 療 計 測 F A 半導体
その他
コンピュータ 通 信 医 療 計 測 F A 半導体
その他
コンピュータ 通 信 医 療 計 測 F A 半導体
その他
医 療 計 測 F A 半導体 その他
その他
ks
その他
ph
pf-a
hk-a
hws
alpha
dlp
fps
フォーマット
コンピュータ 通 信 F A 半導体
その他
コンピュータ 通 信 医 療 計 測 F A 半導体
その他
コンピュータ 通 信 医 療 計 測 F A 半導体
その他
コンピュータ 通 信 医 療 計 測 F A 半導体
その他
コンピュータ 通 信 医 療 計 測 F A 半導体
その他
This means that, in conformity with EU Directive 2002/95/
EC, lead, cadmium, mercury, hexavalent chromium, and
specic bromine-based ame retardants, PBB and PBDE,
have not been used, except for exempted applications.
■ Conformity to RoHS Directive

PH
B-300
・All specifications are subject to change without notice.
■ Produce Line up
PH SERIES
48V input (1)
Output
Voltage
50W 75W
Output
Current
Model (S)
Output
Current
Model (F)
2V ― ― 15A PH75F48-2
3.3V 10A PH50S48-3.3 15A PH75F48-3.3
5V 10A PH50S48-5 15A PH75F48-5
12V 4.2A PH50S48-12 6.3A PH75F48-12
15V 3.4A PH50S48-15 5A PH75F48-15
24V 2.1A PH50S48-24 3.2A PH75F48-24
28V 1.8A PH50S48-28 2.7A PH75F48-28
48V ――――
24V input
Output
Voltage
50W 100W 300W
Output
Current
Model (S)
Output
Current
Model (F)
Output
Current
Model (F)
2V ― ― 20A PH100F24-2 ― ―
3V ― ― 20A PH100F24-3 ― ―
3.3V 10A PH50S24-3.3 ――――
5V 10A PH50S24-5 20A PH100F24-5 ― ―
12V 4.2A PH50S24-12 8.4A PH100F24-12 20A PH300F24-12
15V 3.4A PH50S24-15 6.7A PH100F24-15 ― ―
24V 2.1A PH50S24-24 4.2A PH100F24-24 ― ―
28V 1.8A PH50S24-28 3.6A PH100F24-28 10.8A PH300F24-28
48V input (2)
Output
Voltage
75W 100W 150W 300W
Output
Current
Model (S)
Output
Current
Model (S)
Output
Current
Model (F) Model (S)
Output
Current
Model (F)
Output
Current
Model (S)
2V 15A ―――30A PH150F48-2 60A PH300F48-2
3.3V 15A PH75S48-3.3 20A PH100S48-3.3 30A PH150F48-3.3 PH150S48-3.3 60A PH300F48-3 50A PH300S48-3.3
5V 15A PH75S48-5 20A PH100S48-5 30A PH150F48-5 PH150S48-5 60A PH300F48-5 50A PH300S48-5
12V 6.3A PH75S48-12 8.4A PH100S48-12 12.5A PH150F48-12 PH150S48-12 25A PH300F48-12 25A PH300S48-12
15V 5A PH75S48-15 6.7A PH100S48-15 10A PH150F48-15 PH150S48-15 20A PH300F48-15 20A PH300S48-15
24V 3.2A PH75S48-24 4.2A PH100S48-24 6.3A PH150F48-24 PH150S48-24 12.6A PH300F48-24 12.6A PH300S48-24
28V 2.7A PH75S48-28 3.6A PH100S48-28 5.4A PH150F48-28 PH150S48-28 10.8A PH300F48-28 10.8A PH300S48-28
48V ―――――― ―――6.3A PH300S48-48
110V input
Output
Voltage
50W 75W 150W 300W
Output
Current
Model (F)
Output
Current
Model (F) Model (S)
Output
Current
Model (F) Model (S)
Output
Current
Model (F)
2V ― ― 15A PH75F110-2 ―30A PH150F110-2 ―60A PH300F110-2
3V ― ― 15A PH75F110-3 ―30A PH150F110-3 ―60A PH300F110-3
3.3V ―――― ――― ―――
5V 10A PH50S110-5 15A PH75F110-5 PH75S110-5 30A PH150F110-5 PH150S110-5 60A PH300S110-5
12V 4.2A PH50S110-12 6.3A PH75F110-12 PH75S110-12 12.5A PH150F110-12 PH150S110-12 25A PH300S110-12
15V 3.4A PH50S110-15 5A PH75F110-15 PH75S110-15 10A PH150F110-15 PH150S110-15 20A PH300S110-15
24V 2.1A PH50S110-24 3.2A PH75F110-24 PH75S110-24 6.3A PH150F110-24 PH150S110-24 12.6A PH300S110-24
28V 1.8A PH50S110-28 2.7A PH75F110-28 PH75S110-28 5.4A PH150F110-28 PH150S110-28 10.8A PH300S110-28
280V input (1)
Output
Voltage
50W 75W 100W 150W
Output
Current
Model (S)
Output
Current
Model (F) Model (S)
Output
Current
Model (S)
Output
Current
Model (F) Model (S)
2V ― ― 15A PH75F280-2 ― ― ― 30A PH150F280-2 ―
3V ― ― 15A PH75F280-3 ― ― ― 30A PH150F280-3 ―
3.3V 10A PH50S280-3.3 15A ―PH75S280-3.3 20A PH100S280-3.3 30A ―PH150S280-3.3
5V 10A PH50S280-5 15A PH75F280-5 PH75S280-5 20A PH100S280-5 30A PH150F280-5 PH150S280-5
12V 4.2A PH50S280-12 6.3A PH75F280-12 PH75S280-12 8.4A PH100S280-12 12.5A PH150F280-12 PH150S280-12
15V 3.4A PH50S280-15 5A PH75F280-15 PH75S280-15 6.7A PH100S280-15 10A PH150F280-15 PH150S280-15
24V 2.1A PH50S280-24 3.2A PH75F280-24 PH75S280-24 4.2A PH100S280-24 6.3A PH150F280-24 PH150S280-24
28V 1.8A PH50S280-28 2.7A PH75F280-28 PH75S280-28 3.6A PH100S280-28 5.4A PH150F280-28 PH150S280-28
48V ― ― ― ― ― ― ― ― ― ―
280V input (2)
Output
Voltage
300W 600W
Output
Current
Model (F)
Output
Current
Model (S)
Output
Current
Model (S)
2V 60A PH300F280-2 ― ― ― ―
3V 60A PH300F280-3 ― ― ― ―
3.3V ― ― 50A PH300S280-3.3 100A PH600S280-3.3
5V 60A PH300F280-5 50A PH300S280-5 100A PH600S280-5
12V 25A PH300F280-12 25A PH300S280-12 50A PH600S280-12
15V 20A PH300F280-15 20A PH300S280-15 40A PH600S280-15
24V 12.6A PH300F280-24 12.5A PH300S280-24 25A PH600S280-24
28V 10.8A PH300F280-28 10.8A PH300S280-28 21.5A PH600S280-28
48V ― ― 6.3A PH300S280-280 12.5A PH600S280-48

PH
PH
B-301
・All specifications are subject to change without notice.
PH50S24 PH50S24 Specifications
PH50S24
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)
(*1) At 24VDC and maximum output current.
(*2) 18 - 36 VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
ITEMS/UNITSMODEL
PH50S24-3.3 PH50S24-5 PH50S24-12 PH50S24-15 PH50S24-24 PH50S24-28
Input Voltage Range V DC18 - 36 Efficiency (typ) (*1) ％72 80 81 82 83
Current (typ) (*1) A 1.91 2.6 2.59 2.53
Output
Nominal Voltage
VDC 3.3 5 12 15 24 28
Maximum Current A 10 4.2 3.4 2.1 1.8
Maximum Power W 33 50 50.4 51 50.4
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation(*2) mV 20 48 60 96 112
Maximum Load Regulation(*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*8) +10%, -10% (At 24VDC input)
Function
Over Current Protection (*4) 105 - 150%
Over Voltage Protection (*5) 165 - 240% 125 - 145%
Remote Sensing ―――――
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation ―――――
Series Operation (*8) Possible
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20℃
Storage Temperature ℃-40 to + 85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz amplitude (sweep for 1min)
0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC (20mA) for 1min,
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 100
Size (W x H x D) mm 41 x 12.7 x 86 (Refer to outline drawing)
Derating Curve
0
20
40
60
80
100
−20 0 20 40 60 80 100
85
型名 PH50S24
BaseplateTemperature（℃）
Load（%）

PH
B-302
・All specifications are subject to change without notice.
PH300F24
PH100F24
ITEMS/UNITSMODEL
PH100F24-2 PH100F24-3 PH100F24-5 PH100F24-12 PH100F24-15 PH100F24-24 PH100F24-28
Input Voltage Range V DC18 - 36 Efficiency (typ) (*1) ％66 70 80 81 82 83
Current (typ) (*1) A 2.53 3.57 5.21 5.19 5.11 5.06
Output
Nominal Voltage
VDC 2 3 5 12 15 24 28
Maximum Current A 20 8.4 6.7 4.2 3.6
Maximum Power W 40 60 100 100.8 100.5 100.8
Voltage Setting Accuracy (*1) ％ ±1%
Maximum Line Regulation(*2) mV 20 48 60 96 112
Maximum Load Regulation(*3) mV 40 96 120 192 224
Temperature Coefficient 0.02% / ℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*10) ±20% +20%, -60%
Function
Over Current Protection (*4) 105% - 140%
Over Voltage Protection (*5) 165% - 240% 125% - 145%
Remote Sensing (*8) Possible
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation (*8) Possible
Series Operation (*8) Possible
I.O.G. Signal (*8) Possible (Open collector output)
Environment
Operating Temperature (*6) ℃- 20 to + 85 (Baseplate) ambient temperature MIN = - 20
Storage Temperature ℃- 40 to + 85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz (sweep for 1min)
Amplitude 0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2kVAC, Input-Output : 2kVAC (20mA) for 1min
Output-Baseplate : 500VDC (100mA) for 1min
Isolation Resistance More than 100Mohm at 25℃and 70%RH Output-Baseplate...500VDC
Standards Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 180
Size (W x H x D) mm 83 x 12.7 x 86 (Refer to outline drawing)
PH100F24 Specifications
(*1) At 24VDC and maximum output current.
(*2) 18 - 36VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basical connection and instruction manual.)
(*10) At 24VDC input.(Refer to instruction manual.)
0
20
40
60
80
100
−20 0 20 40 60 80
85
100
型名 PH100F24
BaseplateTemperature（℃）
Load（%）
Derating Curve

PH
PH
B-303
・All specifications are subject to change without notice.
PH300F24 PH300F24 Specifications
PH300F24
0%
20%
40%
60%
80%
100%
−20 0 20 40 60 85 100
型名 PH300F24
BaseplateTemperature（℃）
Load（%）
(*1) At 24VDC and maximum output current.
(*2)18 - 36VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)
(*10) At 24VDC Input. (Refer to instruction manual.)
ITEMS/UNITSMODEL PH300F24-12 PH300F24-28
Input Voltage Range V DC18 - 36 Efficiency (typ) (*1) ％83 84
Current (typ) (*1) A 12 15
Output
Nominal Voltage
VDC 12 28
Maximum Current A 20 10.8
Maximum Power W 240 302.4
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation(*2) mV 48 112
Maximum Load Regulation(*3) mV 96 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 150 280
Voltage Adjustable Range(*10) +20%, -60%
Function
Over Current Protection (*4) 105% - 140%
Over Voltage Protection (*5) 125% - 145%
Remote Sensing (*8) Possible
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation (*8) Possible
Series Operation (*8) Possible
I.O.G. Signal (*8) Possible (Open collector output)
AUX-BIAS Power Supply 7 - 10V, 10mA max.
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20
Storage Temperature ℃-40 to +85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz (sweep for 1min)
Amplitude 0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2kVAC, Input-Output : 2kVAC(20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 250
Size (W x H x D) mm 146 x 12.7 x 86 (Refer to outline drawing)
Derating Curve

PH
PH
B-304
・All specifications are subject to change without notice.
PH50S48 Specifications
PH50S48
0
20
40
60
80
100
−20 0 20 40 60 85 100
型名 PH50S48
BaseplateTemperature（℃）
Load（%）
Derating Curve
ITEMS/UNITS MODEL
PH50S48-3.3 PH50S48-5 PH50S48-12 PH50S48-15 PH50S48-24 PH50S48-28
Input Voltage Range V DC36 - 76 Efficiency (typ) (*1) ％72 80 82 83 84
Current (typ) (*1) A 0.95 1.30 1.28 1.25
Output
Nominal Voltage
VDC 3.3 5 12 15 24 28
Maximum Current A 10 4.2 3.4 2.1 1.8
Maximum Power W 33 50 50.4 51 50.4
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation (*2) mV 20 48 60 96 112
Maximum Load Regulation (*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*8) +10%, -10% (At 48VDC Input)
Function
Over Current Protection (*4) 105 - 150%
Over Voltage Protection (*5) 165 - 240% 125 - 145%
Remote Sensing ―――――
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation ―――――
Series Operation (*8) Possible
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20
Storage Temperature ℃-40 to + 85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration 0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC (20mA) for 1min,
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards
Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 100
Size (W x H x D) mm 41 x 12.7 x 86 (Refer to outline drawing)
(*1) At 48VDC and maximum output current.
(*2) 36 - 76 VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)

PH
PH
B-305
・All specifications are subject to change without notice.
PH75S48 Specifications
PH75S48
0
20
40
60
80
100
−20 0 20 40 60 85 100
型名 PH75S48
BaseplateTemperature（℃）
Load（%）
Derating Curve
ITEMS/UNITS MODEL
PH75S48-3.3 PH75S48-5 PH75S48-12 PH75S48-15 PH75S48-24 PH75S48-28
Input Voltage Range V DC36 - 76 Efficiency (typ) (*1) ％72 81 83 84 85
Current (typ) (*1) A 1.43 1.93 1.9 1.86 1.88 1.85
Output
Nominal Voltage
VDC 3.3 5 12 15 24 28
Maximum Current A 15 6.3 5 3.2 2.7
Maximum Power W 49.5 75 75.6 75 76.8 75.6
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation (*2) mV 20 48 60 96 112
Maximum Load Regulation (*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*8) +10%, -10% (At 48VDC Input)
Function
Over Current Protection (*4) 105 - 150%
Over Voltage Protection (*5) 165 - 240% 125 - 145%
Remote Sensing ―――――
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation ―――――
Series Operation (*8) Possible
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20
Storage Temperature ℃-40 to + 85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz amplitude (sweep for 1min)
0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC (20mA) for 1min,
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards
Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 100
Size (W x H x D) mm 41 x 12.7 x 86 (Refer to outline drawing)
(*1) At 48VDC and maximum output current.
(*2) 36 - 76 VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)

PH
PH
B-306
・All specifications are subject to change without notice.
PH75F48
PH75F48
0
20
40
60
80
100
−20 0 20 40 60 100
85
型名 PH75F48
BaseplateTemperature（℃）
Load（%）
Derating Curve
(*1) At 48VDC and maximum output current.
(*2) 36 - 76VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
PH75F48 Specifications
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)
(*10) At 48VDC Input. (Refer to instruction manual.)
ITEMS/UNITSMODEL
PH75F48-2 PH75F48-3 PH75F48-5 PH75F48-12 PH75F48-15 PH75F48-24 PH75F48-28
Input Voltage Range V DC36 - 76 Efficiency (typ) (*1) ％66 70 81 83 84 85
Current (typ) (*1) A 0.95 1.34 1.93 1.90 1.86 1.88 1.85
Output
Nominal Voltage
VDC 2 3 5 12 15 24 28
Maximum Current A 15 6.3 5 3.2 2.7
Maximum Power W 30 45 75 75.6 75 76.8 75.6
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation(*2) mV 20 48 60 96 112
Maximum Load Regulation(*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*10) ±20% +20%, -60%
Function
Over Current Protection (*4) 105% - 140%
Over Voltage Protection (*5) 165% - 240% 125% - 145%
Remote Sensing (*8) Possible
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation (*8) Possible
Series Operation (*8) Possible
I.O.G. Signal (*8) Possible (Open collector output)
Environment
Operating Temperature (*6) ℃-20 to +85(Baseplate) Ambient temperature min=-20
Storage Temperature ℃-40 to +100
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz amplitude (sweep for 1min)
0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC(20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950
Mechanical
Weight (typ) g 150
Size (W x H x D) mm 62 x 12.7 x 86 (Refer to outline drawing)

PH
PH
B-307
・All specifications are subject to change without notice.
PH100S48 PH100S48 Specifications
PH100S48
0
20
40
60
80
100
−20 0 20 40 60 85 100
型名 PH100S48
BaseplateTemperature（℃）
Load（%）
Derating Curve
ITEMS/UNITS MODEL
PH100S48-3.3 PH100S48-5 PH100S48-12 PH100S48-15 PH100S48-24 PH100S48-28
Input Voltage Range V DC36 - 76 Efficiency (typ) (*1) ％74 81 83 84 85
Current (typ) (*1) A 1.86 2.57 2.53 2.49 2.47
Output
Nominal Voltage
VDC 3.3 5 12 15 24 28
Maximum Current A 20 8.4 6.7 4.2 3.6
Maximum Power W 66 100 100.8 100.5 100.8
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation(*2) mV 20 48 60 96 112
Maximum Load Regulation(*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*8) +10%, -10% (At 48VDC Input)
Function
Over Current Protection (*4) 105 - 150%
Over Voltage Protection (*5) 165 - 240% 125 - 145%
Remote Sensing Possible
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation ―――――
Series Operation (*8) Possible
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20
Storage Temperature ℃-40 to + 85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz amplitude (sweep for 1min)
0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC(20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 150
Size (W x H x D) mm 62 x 12.7 x 86 (Refer to outline drawing)
(*1) At 48VDC and maximum output current.
(*2) 36 - 76 VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)

PH
PH
B-308
・All specifications are subject to change without notice.
PH150S48 PH150S48 Specifications
PH150S48
0
20
40
60
80
100
−20 0 20 40 60 85 100
型名 PH150S48
BaseplateTemperature（℃）
Load（%）
Derating Curve
ITEMS/UNITS MODEL
PH150S48-3.3 PH150S48-5 PH150S48-12 PH150S48-15 PH150S48-24 PH150S48-28
Input Voltage Range V D36 - 76 Efficiency (typ) (*1) ％72 82 85 88
Current (typ) (*1) A 2.75 3.81 3.68 3.58
Output
Nominal Voltage
VDC 3.3 5 12 15 24 28
Maximum Current A 30 12.5 10 6.3 5.4
Maximum Power W 99 150 151.2
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation(*2) mV 20 48 60 96 112
Maximum Load Regulation(*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*8) +10%, -10% (At 48VDC Input)
Function
Over Current Protection (*4) 105 - 150%
Over Voltage Protection (*5) 165 - 240% 125 - 145%
Remote Sensing Possible
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation ―――――
Series Operation (*8) Possible
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20
Storage Temperature ℃-40 to + 85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz amplitude (sweep for 1min)
0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC (20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 150
Size (W x H x D) mm 72 x 12.7 x 86 (Refer to outline drawing)
(*1) At 48VDC and maximum output current.
(*2) 36 - 76 VDC, constant Load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and Instruction manual.)

PH
PH
B-309
・All specifications are subject to change without notice.
PH150F48 PH150F48 Specifications
PH150F48
0
20
40
60
80
100
−20 0 20 40 60 85 100
BaseplateTemperature（℃）
Load（%）
型名 PH150F48
Derating Curve
ITEMS/UNITS MODEL
PH150F48-2 PH150F48-3 PH150F48-5 PH150F48-12 PH150F48-15 PH150F48-24 PH150F48-28
Input Voltage Range V DC36 - 76 Efficiency (typ) (*1) ％68 73 82 86 87 89 90
Current (typ) (*1) A 1.84 2.57 3.81 3.55 3.59 3.54 3.5
Output
Nominal Voltage
VDC 2 3 5 12 15 24 28
Maximum Current A 30 12.5 10 6.3 5.4
Maximum Power W 60 90 150 151.2
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation(*2) mV 20 48 60 96 112
Maximum Load Regulation(*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*10) ±20% +20%, -60%
Function
Over Current Protection (*4) 105% - 140%
Over Voltage Protection (*5) 165% - 240% 125% - 145%
Remote Sensing (*8) Possible
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation (*8) Possible
Series Operation (*8) Possible
I.O.G. Signal (*8) Possible (Open collector output)
Environment
Operating Temperature (*6) ℃- 20 to 85 (Baseplate) Ambient temperature MIN = -20
Storage Temperature ℃-40 to + 85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz (sweep for 1min)
Amplitude 0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC(20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 180
Size (W x H x D) mm 83 x 12.7 x 86 (Refer to outline drawing)
(*1) At 48VDC and maximum output current.
(*2) 36 - 76 VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)

PH
PH
B-310
・All specifications are subject to change without notice.
PH300S48 Specifications
PH300S48
0
20
40
60
80
100
−20 0 20 40 60 80 90 100
BaseplateTemperature（℃）
Load（%）
3.3,5V
12,15,24,28,48V
83
型名
PH300S48
Derating Curve
ITEMS/UNITS MODEL
PH300S48-3.3 PH300S48-5 PH300S48-12 PH300S48-15 PH300S48-24 PH300S48-28 PH300S48-48
Input Voltage Range V DC36 - 76 Efficiency (typ) (*1) ％80 84 88
Current (typ) (*1) A 4.30 6.20 7.10 7.16
Output
Nominal Voltage V 3.3 5 12 15 24 28 48
Maximum Current A 50 25 20 12.5 10.8 6.3
Maximum Power W 165 250 300 302.4
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation(*2) mV 20 48 60 96 112 192
Maximum Load Regulation(*3) mV 40 96 120 192 224 384
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (0~＋100℃)(*9) mVp-p 100 150 240 280 480
Maximum Ripple & Noise (－20~0℃)(*9) mVp-p 150 225 360 420 720
Voltage Adjustable Range(*10) ％+20,-10 ±10 +20,-10
Function
Over Current Protection (*4) 105 - 150％
Over Voltage Protection (*5) 140 - 170％125 - 145％
Remote Sensing (*8) Possible
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation (*11) Applicable with CS signal
Series Operation (*8) Possible
I.O.G. Signal (*8) Built-in (Open collector output)
Environment
Operating Temperature (*6) ℃-20 to +100(Baseplate), Ambient temperature min -20
-20 to +100 : 100% -20 to +90 : 100% , +100 : 83%
Storage Temperature ℃-40 to + 100
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz (sweep for 1min)
Amplitude 0.825mm constant (maximum 49.0m/s²) X, Y, Z 1 h each
Shock 196.1m/s²
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 1.5kVAC, Input-Output : 1.5kVAC(20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 200
Size (W x H x D) mm 83 x 12.7 x 86 (Refer to outline drawing)
(*1) At 48VDC and maximum output current.
(Baseplate temprature = +25℃)
(*2) 36 - 76VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset with CNT signal.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)
(*10) At 48VDC Input. (Refer to instruction manual.)
(*11) External circuit is needed for operation.
(Refer to instruction manual.)

PH
PH
B-311
・All specifications are subject to change without notice.
PH300F48 PH300F48 Specifications
PH300F48
0
20
40
60
80
100
−20 0 20 40 60 80 100
BaseplateTemperature（℃）
Load（%）
85
型名 PH300F48
Derating Curve
ITEMS/UNITS MODEL
PH300F48-2 PH300F48-3 PH300F48-5 PH300F48-12 PH300F48-15 PH300F48-24 PH300F48-28
Input Voltage Range V DC36 - 76 Efficiency (typ) (*1) ％68 73 82 85 86 89 90
Current (typ) (*1) A 3.68 5.14 7.62 7.35 7.26 7.16 7
Output
Nominal Voltage
VDC 2 3 5 12 15 24 28
Maximum Current A 60 25 20 12.6 10.8
Maximum Power W 120 180 300 302.4
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation(*2) mV 20 48 60 96 112
Maximum Load Regulation(*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*10) ±20% +20%, -60%
Function
Over Current Protection (*4) 105% - 140%
Over Voltage Protection (*5) 165% - 240% 125% - 145%
Remote Sensing (*8) Possible
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation (*8) Possible
Series Operation (*8) Possible
I.O.G. Signal (*8) Possible (Open collector output)
Environment
Operating Temperature (*6) ℃-20 to 85（Baseplate) Ambient temperature MIN=20℃
Storage Temperature ℃-40 to 85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz (sweep for 1min)
Amplitude 0.825mm constant (maximum 49.0m/s²) X, Y, Z 1 h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC(20mA) for 1min
Output-Baseplate : 500VDC(100mA) for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 250
Size (W x H x D) mm 146 x 12.7 x 86 (Refer to outline drawing)
(*1) At 48VDC and maximum output current.
(*2) 36 - 76VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External capacitor is required.
(Refer to instruction manual.)
(*10) At 48VDC input. (Refer to instruction manual.)

PH
PH
B-312
・All specifications are subject to change without notice.
PH50S110 PH50S110 Specifications
PH50S110
ITEMS/UNITS MODEL PH50S110-5
PH50S110-12 PH50S110-15 PH50S110-24 PH50S110-28
Input Voltage Range V DC82 - 185 Efficiency (typ) (*1) ％80 82 83 84
Current (typ) (*1) A 0.57 0.56 0.55
Output
Nominal Voltage
VDC 5 12 15 24 28
Maximum Current A 10 4.2 3.4 2.1 1.8
Maximum Power W 50 50.4 51 50.4
Voltage Setting Accuracy (*1) ％ ±1%
Maximum Line Regulation(*2) mV 20 48 60 96 112
Maximum Load Regulation(*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*8) +10%, -10% (At 110VDC Input)
Function
Over Current Protection (*4) 105% - 150%
Over Voltage Protection (*5) 125% - 145%
Remote Sensing ―――――
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation ―――――
Series Operation (*8) Possible
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20℃
Storage Temperature ℃-40 to +85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz (sweep for 1min)
Amplitude 0.825mm constant (maximum 49.0m/s²) X, Y, Z 1 h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC(20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate…500VDC
Standards Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 100
Size (W x H x D) mm 41 x 12.7 x 86 (Refer to outline drawing)
(*1) At 110VDC and maximum output current.
(*2) 88 - 185VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)
0
20
40
60
80
100
−20 0 20 40 60 80
85
100
BaseplateTemperature（℃）
Load（％）
型名 PH50S110
Derating Curve

PH
PH
B-313
・All specifications are subject to change without notice.
PH75S110 PH75S110 Specifications
PH75S110
ITEMS/UNITS MODEL PH75S110-5
PH75S110-12 PH75S110-15 PH75S110-24 PH75S110-28
Input Voltage Range V DC82 - 185 Efficiency (typ) (*1) ％81 83 84 85
Current (typ) (*1) A 0.84 0.83 0.81 0.82 0.81
Output
Nominal Voltage
VDC 5 12 15 24 28
Maximum Current A 15 6.3 5 3.2 2.7
Maximum Power W 75 75.6 75 76.8 75.6
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation(*2) mV 20 48 60 96 112
Maximum Load Regulation(*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*8) +10%, -10% (At 110VDC Input)
Function
Over Current Protection (*4) 105% - 150%
Over Voltage Protection (*5) 125% - 145%
Remote Sensing ―――――
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation ―――――
Series Operation (*8) Possible
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20
Storage Temperature ℃-40 to +85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz (sweep for 1min)
Amplitude 0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC(20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards
Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 100
Size (W x H x D) mm 41 x 12.7 x 86 (Refer to outline drawing)
(*1) At 110VDC and maximum output current.
(*2) 88 - 185VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)
0
20
40
60
80
100
−20 0 20 40 60 85 100
BaseplateTemperature（℃）
Load（％）
型名 PH75S110
Derating Curve

PH
PH
B-314
・All specifications are subject to change without notice.
PH75F110 PH75F110 Specifications
PH75F110
(*1) At 110VDC and maximum output current.
(*2) 88 - 185VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)
(*10) At 110VDC Input. (Refer to instruction manual.)
ITEMS/UNITS MODEL
PH75F110-2 PH75F110-3 PH75F110-5 PH75F110-12 PH75F110-15 PH75F110-24 PH75F110-28
Input Voltage Range V DC82 - 185 Efficiency (typ) (*1) ％66 70 81 83 84 85
Current (typ) (*1) A 0.41 0.58 0.84 0.83 0.81 0.82 0.81
Output
Nominal Voltage
VDC 2 3 5 12 15 24 28
Maximum Current A 15 6.3 5 3.2 2.7
Maximum Power W 30 45 75 75.6 75 76.8 75.6
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation (*2) mV 20 48 60 96 112
Maximum Load Regulation (*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*10) ±20% +20%, -60%
Function
Over Current Protection (*4) 105% - 140%
Over Voltage Protection (*5) 165% - 240% 125% - 145%
Remote Sensing (*8) Possible
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation (*8) Possible
Series Operation (*8) Possible
I.O.G. Signal (*8) Possible (Open collector output)
AUX-BIAS Power Supply 7-10VDC Maximum load 10mA
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20
Storage Temperature ℃-40 to +85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz (sweep for 1min)
Amplitude 0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC(20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards
Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 150
Size (W x H x D) mm 62 x 12.7 x 86 (Refer to outline drawing)
0
20
40
60
80
100
−20 0 20 40 60 100
BaseplateTemperature(℃)
Load(%)
85
型名 PH75F110
Derating Curve

PH
PH
B-315
・All specifications are subject to change without notice.
PH150S110
ITEMS/UNITS MODEL
PH150S110-5 PH150S110-12 PH150S110-15 PH150S110-24 PH150S110-28
Input Voltage Range (*6) V DC82 - 185 Efficiency (typ) (*1) ％82 85 88
Current (typ) (*1) A 1.66 1.60 1.56
Output
Nominal Voltage
VDC 5 12 15 24 28
Maximum Current A 30 12.5 10 6.3 5.4
Maximum Power W 150 151.2
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation (*2) mV 20 48 60 96 112
Maximum Load Regulation (*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*8) +10%, -10% (At 110VDC Input)
Function
Over Current Protection (*4) 105% - 150%
Over Voltage Protection (*5) 125% - 145%
Remote Sensing Possible
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation ―――――
Series Operation (*8) Possible
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20
Storage Temperature ℃-40 to +85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz (sweep for 1min)
Amplitude 0.825mm constant (maximum 49.0m/s²) X, Y, Z 1 h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC(20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards
Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 150
Size (W x H x D) mm 72 x 12.7 x 86 (Refer to outline drawing)
(*1) At 110VDC and maximum output current.
(*2) 88 - 185VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
PH150S110 Specifications
PH150S110
0
20
40
60
80
100
120
InputVoltage(V)
Load(%)
8882 100
0
20
40
60
80
100
120
−20 0 20 40 60 85 100
BaseplateTemperature(℃)
Load(%)
型名 PH150S110
Derating Curve
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)

PH
PH
B-316
・All specifications are subject to change without notice.
PH150F110 Specifications
PH150F110
PH150F110
ITEMS/UNITS MODEL
PH150F110-2 PH150F110-3 PH150F110-5 PH150F110-12 PH150F110-15 PH150F110-24 PH150F110-28
Input Voltage Range (*6) V DC82 - 185 Efficiency (typ) (*1) ％68 73 83 86 87 89 90
Current (typ) (*1) A 0.80 1.12 1.64 1.59 1.57 1.54 1.53
Output
Nominal Voltage
VDC 2 3 5 12 15 24 28
Maximum Current A 30 12.5 10 6.3 5.4
Maximum Power W 60 90 150 151.2
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation (*2) mV 20 48 60 96 112
Maximum Load Regulation (*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*10) ±20% +20%, -60%
Function
Over Current Protection (*4) 105% - 140%
Over Voltage Protection (*5) 165% - 240% 125% - 145%
Remote Sensing (*8) Possible
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation (*8) Possible
Series Operation (*8) Possible
I.O.G. Signal (*8) Possible (Open collector output)
AUX-BIAS Power Supply 7-10VDC Maximum load 10mA
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20
Storage Temperature ℃-40 to +85
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz (sweep for 1min)
Amplitude 0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC(20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards
Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 180
Size (W x H x D) mm 83 x 12.7 x 86 (Refer to outline drawing)
(*1) At 110VDC and maximum output current.
(*2) 88 - 185VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)
(*10) At 110VDC Input.(Refer to instruction manual.)
0
20
40
60
80
100
InputVoltage（V）
Load（%）
8882 100
0
20
40
60
80
100
−20 0 20 40 60 80 100
BaseplateTemperature（℃）
Load（%）
型名 PH150F110
Derating Curve

PH
PH
B-317
・All specifications are subject to change without notice.
PH300F110
ITEMS/UNITS MODEL
PH300F110-2 PH300F110-3 PH300F110-5 PH300F110-12 PH300F110-15 PH300F110-24 PH300F110-28
Input Voltage Range (*6) V DC82 - 185 Efficiency (typ) (*1) ％68 73 83 86 87 89 90
Current (typ) (*1) A 1.60 2.24 3.29 3.17 3.13 3.09 3.05
Output
Nominal Voltage
VDC 2 3 5 12 15 24 28
Maximum Current A 60 25 20 12.6 10.8
Maximum Power W 120 180 300 302.4
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation (*2) mV 20 48 60 96 112
Maximum Load Regulation (*3) mV 40 96 120 192 224
Temperature Coefficient (%) 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*10) ±20% +20%, -60%
Function
Over Current Protection (*4) 105% - 140%
Over Voltage Protection (*5) 165% - 240% 125% - 145%
Remote Sensing (*8) Possible
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation (*8) Possible
Series Operation (*8) Possible
I.O.G. Signal (*8) Possible (Open collector output)
AUX-BIAS Power Supply 7-10VDC Maximum load 10mA
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20
Storage Temperature ℃-40 to +100
Operating Humidity
％RH 30 - 95 (No dewdrop)
Storage Humidity
％RH 10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz (sweep for 1min)
Amplitude 0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC, Input-Output : 3kVAC(20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards
Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 250
Size (W x H x D) mm 146 x 12.7 x 86 (Refer to outline drawing)
(*1) At 110VDC and maximum output current.
(*2) 82 - 185VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
PH300F110 Specifications
PH300F110
0
20
40
60
80
100
InputVoltage（V）
Load（％）
8882 85 100 0
20
40
60
80
100
−20 0 20 40 60 80 100
BaseplateTemperature（℃）
Load（％）
型名 PH300F110
Derating Curve
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)
(*10) At 110VDC input.(Refer to instruction manual.)

PH
PH
B-318
・All specifications are subject to change without notice.
PH50S280 Specifications
PH50S280
0
20
40
60
80
100
−20 0 20 40 60
85
80 100
BaseplateTemperature（℃）
Load（％）
型名 PH50S280
Derating Curve
(*1) At 280VDC and maximum output current.
(*2) 200 - 400VDC, constant load.
(*3) No load - full load, constant input voltage.
(*4) Constant current limiting with automatic recovery.
(*5) Inverter shutdown method, manual reset.
(*6) Ratings - Refer to derating curve below.
- Load(%) is percent of maximum output current.
(*7) Heatsink has to be chosen according to instruction manual.
(*8) Refer to instruction manual.
(*9) External components are needed for operation.
(Refer to basic connection and instruction manual.)
ITEMS/UNITS
MODEL
PH50S280-3.3 PH50S280-5 PH50S280-12 PH50S280-15 PH50S280-24 PH50S280-28
Input Voltage Range V DC200 - 400 Efficiency (typ) (*1) ％72 80 82 83 84
Current (typ) (*1) A 0.16 0.22 0.21
Output
Nominal Voltage
VDC 3.3 5 12 15 24 28
Maximum Current A 10 4.2 3.4 2.1 1.8
Maximum Power W 33 50 50.4 51 50.4
Voltage Setting Accuracy (*1) ％ ±1
Maximum Line Regulation(*2) mV 20 48 60 96 112
Maximum Load Regulation (*3) mV 40 96 120 192 224
Temperature Coefficient 0.02%/℃
Maximum Ripple & Noise (*9)
mVp-p 100 150 240 280
Voltage Adjustable Range(*8) +10%, -10% (At 280VDC Input)
Function
Over Current Protection (*4) 105 - 150%
Over Voltage Protection (*5) 165 - 240% 125 - 145%
Remote Sensing (*8) ―――――
Remote ON/OFF Control (*8) Possible (SHORT: ON OPEN: OFF)
Parallel Operation (*8) ―――――
Series Operation (*8) Possible
Environment
Operating Temperature (*6) ℃-20 to +85 (Baseplate) Ambient temperature min=-20
Storage Temperature ℃-40 to + 85
Operating Humidity
％RH 30 ~ 95 (No dewdrop)
Storage Humidity
％RH 10 ~ 95 (No dewdrop)
Vibration At no operating, 10-55Hz amplitude (sweep for 1min)
0.825mm constant (maximum 49.0m/s²) X, Y, Z 1h each
Shock 196.1m/s² (In package)
Cooling (*7) Conduction cooled
Isolation
Withstand Voltage Input-Baseplate : 2.5kVAC. Input-Output : 3kVAC(20mA) for 1min
Output-Baseplate : 500VDC for 1min
Isolation Resistance More than 100MΩat 25℃and 70%RH Output-Baseplate...500VDC
Standards Safety Standards Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1
Mechanical
Weight (typ) g 100
Size (W x H x D) mm 41 x 12.7 x 86 (Refer to outline drawing)
