TDK-Lambda HWS-L/BAT Series User manual

CA771-04-11/BAT-D
- 1 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
HWS-L/BAT Series
Instruction Manual
BEFORE USING THE POWER SUPPLY UNIT
Be sure to read this instruction manual thoroughly before using this product. Pay attention to all cautions and warnings before
using this product. Incorrect usage could lead to an electrical shock, damage to the unit or a fire hazard.
DANGER
Never use this product in locations where flammable gas or ignitable substances are present.
INSTALLATION WARNING
When installing, ensure that work is done in accordance with the instruction manual. When installation is improper, there is risk of
electric shock and fire.
Installation shall be done by Service personnel with necessary and appropriate technical training and experience. There is a risk of
electric shock and fire.
Do not cover the product with cloth or paper etc. Do not place anything flammable around. This might cause damage, electric sh
ock
or fire.
WARNING on USE
Do not touch this product or its internal components while circuit in operation, or shortly after shutdown. You may receive a burn.
While this product is operating, keep your hands and face away from it as you may be injured by an unexpected situation.
There are cases where high voltage charge remains inside the product immediately after the input is cut
off. Therefore, do not touch
even if they are not in operation as you might get injured due to high voltage and high temperature.
You might also get electric shock or burn.
Do not make unauthorized changes to this product nor remove the cover as you might get an electric shock or might damage the
product. We will not be held responsible after the product has been modified, changed or dis-assembled.
Do not use this product under unusual condition such as emission of smoke or abnormal smell and sound etc. Please stop using it
immediately and shut off the product.
It might lead to fire and electric shock. In such cases, please contact us. Do not attempt repair by yourself, as it is dangerous for the
user.
Do not operate and store these products in environments
where condensation occurs due to moisture and humidity. It might lead fire
and electric shock.
Do not drop or apply shock to this product. It might cause failure. Do not operate these products mechanical stress is applied.
When necessary, this product is to be repaired only by us or our authorized agents. It is important that this product cannot be used
in hazardous environments (facilities such as nuclear power control system or life support equipment) without our written consent.
The Output and control terminals of HWS600L-36/BAT and HWS1000L-36/BAT are SELV.
The Output and control terminals of HWS600L-60/BAT and HWS1000L-60/BAT are hazardous voltage.
These terminals must not be user and service person accessible.
HWS600L-*/BAT andHWS1000L-*/BAT have OCP ADJ trimmer which is located in primary circuit.
CAUTION on MOUNTING
Confirm connections to input/output terminals are correct as indicated in the instruction manual before switching on.
Input voltage, Output current, Output power, ambient temperature and ambient humidity should be kept within specifications,
otherwise the product will be damaged.
Input line, please use the wires as short and thick as possible.
Do not use this product in special environment with strong electromagnetic field, corrosive gas or conductive substances and direct
sunlight, or places where product is exposed to water or rain.
Mount this product properly in accordance with the instruction manual, mounting direction and shall be properly be ventilated.
Please shut down the input when connecting input and output of the product.
When installing in environment where conductive foreign, dust and liquid may be present, please consider penetration of above
foreign material in the power supply by installing filter, to prevent trouble or malfunction.

- 2 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
CAUTION on USE
Product individual notes are shown in the instruction manual. If there is any difference with common notes individual notes shall
have priority.
Before using this product, be sure to read the catalog and instruction manual. There is risk of electric shock or damage to the
product or fire due to improper use.
Input voltage, Output current, Output power, ambient temperature and ambient humidity should be kept within specifications,
otherwise the product will be damaged, or cause electric shock or fire.
If the built-in fuse is blown, do not use the product even after replacing the fuse, as there is risk of abnormality inside. Be sure to
request repair to our company.
For products without built-in protection circuit (element, fuse, etc.), insert fuse at the input to prevent smoke, fire during abnormal
operation. As for products with built-in protection circuit, depending on usage conditions, built-in protection circuit might not
work. It is recommended to provide separate proper protection circuit.
For externally mounted fuse do not use other fuses aside from our specified and recommended fuse.
This product was made for general purpose electronic equipment use and is not designed for applications requiring high safety
(such as extremely high reliability and safety requirements). Even though high reliability and safety are not required, this product
should not be used directly for applications that have serious risk for life and physical safety. Take sufficient consideration in
fail-safe design (such as providing protective circuit or protective device inside the system, providing redundant circuit to ensure
no instability when single device failure occurs).
When used in environments with strong electromagnetic field, there is possibility of product damage due to malfunction.
When used in environment with corrosive gas (hydrogen sulfide, sulfur dioxide, etc.), there is possibility that they might penetrate
the product and lead to failure.
When used in environments where there is conductive foreign matter or dust, there is possibility of product failure or malfunction.
Provide countermeasure for prevention of lightning surge voltage as there is risk of damage due to abnormal voltage.
Connect together the frame ground terminal of the product and the ground terminal of the equipment
for safety and noise reduction.
If these ground is not connected together, there is risk of electric shock.
Parts with lifetime specifications (built-in fan electrolytic capacitor) are required to be replaced periodically. Set the
overhaul period depending on the environment of usage and perform maintenance. Also, note that there are cases when EOL
products cannot be overhauled.
Take care not to apply external abnormal voltage to the output. Especially, applying reverse voltage or overvoltage more than the
rated voltage to the output might cause failure, electric shock or fire.
This product is designed under condition Material group IIIb, Pollution Degree (PD): PD2, Over Voltage category
(OVC): OVC and Class of equipment: Class I. This product is designed to be accessible only to service technicians as
part of indoor use device.
This product is primarily designed and manufactured to use and enclose in other equipment.
This product has a built-in fan for air-cooling. Do not block the air intake and exhaust as this might lead to fire.
The output of this product is considered to be a hazardous energy level (The voltage is 2V or more and the power is 240VA or
more). It must not be made accessible to users. Protection must be provided for Service Engineers against indirect contact with the
output terminals and/or to prevent tools being dropped across them. While working on this product, the AC input power must be
switched off and the input and output voltage should be zero.
General installation instructions
These products are optional for installation in Class I end equipment, and must be reliably earthed and professionally installed.
These products are IPX0, and therefore chemicals/solvents, cleaning agents and other liquids must not be used.
The first protective earth connection in the final installation must be marked with the protective earth symbol.

- 3 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
Special instructions for IEC/EN/UL 60601-1 (HWS1000L/BAT only)
Connect only apparatus complying with IEC/EN/UL60601-1 to the signal ports.
Except for permanently installed equipment as defined in Clause 57.6 of IEC/EN/UL60601-
1 the overall equipment in which these
products are installed must have double pole fusing on the input mains supply. The products themselves have single pole fusing in
the live line.
When the PSU is installed within medical equipment an all pole mains input disconnect device must be fitted.
These products have not been assessed to IEC/EN60601-1-2 (EMC) but EMC test data is available from TDK-Lambda.
These products are 2MOPP between input and outputs and 1MOPP between input and .
Note
Take note that traces of sheet metal processing be left in our power supplies.
When disposing product, follow disposal laws of each municipality.
Published EMI (CE, RE) or immunity is the result when measured in our standard measurement conditions and might not satisfy
specification when mounted and wired inside end-user equipment. Use the product after sufficiently evaluating at actual end-user
equipment.
When exporting our products, apply for necessary permissions as required by rules and regulations of Foreign Exchange and
Foreign Trade Control Act.
Catalogue, contents of the instruction manual may be changed without a prior notice. Refer to latest catalogue or instruction
manual.
Reproduction or reprinting the instruction manual or its portion is forbidden without our permission.
CE Marking
CE Marking, when applied to a product covered by this handbook, indicates compliance with the low voltage
directive.
LONG-TERM STORAGE METHOD AND LONG-TERM STORAGE PERIOD
Please keep the product in carton box.
Please do not apply excessive vibration, shock or mechanical stress applied directly to the product.
Please keep away from direct sunlight.
For long-term storage temperature and humidity, the following conditions shall be used as a guideline :
Temperature range
Humidity range : 40% 60%RH
Please keep away from the places where temperature and humidity can change drastically.
It can cause condensation on the product or deterioration.
For long-term storage period, we recommend to use within 2 years after receiving the product.
There is tendency that the leakage current of an
aluminium electrolytic capacitor may increase when stored without using for a long
time.
This phenomenon can be improved by applying voltage to the aluminum electrolytic capacitor to reduce the increased leakage
current through the self-recovery effect of the electrolyte.
For reference, before using products that have been stored for a very long
time, please warm-up first for 30 minutes or more without taking load.
< Criterion of warm up voltage condition >
(1)Implementation period : 1 year or above after the delivery
(2)Electrical continuity condition
Input voltage : Rating
Load : 0A
Ambient temperature : Normal temperature
Time : 30 minutes or more

- 4 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
1. Model name identification method
HWS 600L 60 /BAT

Suffix name OCP Adjustable
Rated Output Voltage 36 36V 60:60V
Output Power type 600 600W 1000:1000W
Series name
2. Terminal Explanation
Please pay extra attention to the wiring. Incorrect connection will damage the power supply.
2-1. Panel Explanation
Front Panel of HWS600L /BAT Top Panel of HWS600L /BAT
Front Panel of HWS1000L /BAT Right side Panel of HWS1000L /BAT













V.ADJ: Output voltage adjustment trimmer.
(The output voltage rises when a trimmer is turned clockwise.)
ON: Output (Power on) indication LED
(The indicator turns on when the power supply output is in normal operating condition.)
CN1
CN2
CN3
CN1
CN2
CN3
CN1
CN2
CN3

- 5 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
CN1, CN2, CN3: Remote sensing, ON/OFF control signal, current balance signal, power fail alarm signal, auxiliary
output, output voltage external control signal. (Refer to 2-2.)
: Protective earth (Frame ground), M4 screw. (HWS1000L/BAT: M4 screw x 2)
AC input terminal L: Live line (Fuse in line), M4 screw.
AC input terminal N: Neutral line, M4 screw.
+: + Output terminal
(HWS600L/BAT: M5 screw x 2 / HWS1000L/BAT: 9 hole, M4 tapped hole x 2)
-: - Output terminal
(HWS600L/BAT: M5 screw x 2 / HWS1000L/BAT: 9 hole, M4 tapped hole x 2)
OCP. ADJ: Over current protection adjustment trimmer.(primary component) See 6-4 and 6-17.
2-2. CN1, CN2, CN3 Connector pin Configuration and Function
CN1 and CN2 are same pin configuration and function.
They are connected to each other in this power supply unit.
When the pin of CN1 side is shorted, the same function pins of CN2 side are also shorted.
Please note that the function cannot be separately set with CN1 and CN2.
No. Configura
tion Function
1 Vm +OUTPUT VOLTAGE MONITOR
2 S +SENSING
3 Vm -OUTPUT VOLTAGE MONITOR
4 S  SENSING
5 NC NO CONNECTION
6 PC CURRENT BALANCE
7 PV ADJUSTMENT OF OUTPUT VOLTAGE
8 COM GROUND FOR PC AND PV SIGNAL 
9 CNT2 REMOTE ON/OFF (2)
10 TOG GROUND FOR CNT2
CN3 No. Configura
tion
Function
1 COM GROUND FOR PC AND PV SIGNAL
2 COM GROUND FOR PC AND PV SIGNAL
3 AUX AUXILIARY OUTPUT (12V 0.1A)
4 CNT1 REMOTE ON/OFF (1)
5 G2 GROUND FOR AUX AND CNT1
6 G2 GROUND FOR AUX AND CNT1
7 ALM ALARM
8 G1 ALARM GROUND
CN1
CN2
4
10
8
6
2
7
9
5
3
1
1
3
5
7
4
2
6
8
4
10
8
6
2
7
9
5
3
1
CN1, CN2

- 6 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
CN1, CN2, CN3 Connector & Housing & Terminal Pin
PART DESCRIPTION PART NAME MANUFACT
PIN HEADER S10B-PHDSS (CN1, CN2)
S8B-PHDSS (CN3) JST
SOCKET HOUSING PHDR-10VS (CN1, CN2)
PHDR-8VS (CN3) JST
TERMINAL PINS SPHD-002T-P0.5 (AWG28~24)
SPHD-001T-P0.5 (AWG26~22) JST
HAND CRIMPING TOOL YRS-620 (SPHD-002T-P0.5)
YC-610R (SPHD-001T-P0.5) JST

- 7 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
3. Block Diagram
HWS600L /BAT
HWS1000L /BAT
Circuit topology, Switching frequency
Switching Circuit
HWS600L/BAT : Forward 300kHz
HWS1000L/BAT : Cascade forward 200kHz
PFHC Circuit : Active filter
HWS600L/BAT : 100kHz
HWS1000L/BAT : 130kHz
Fuse rating
HWS600L/BAT : 15A
HWS1000L/BAT : 20A
L
N
OCP
Circuit
OVP
Circuit
Photo-coupler
Photo-
coupler
Input
85 265VAC
FG
Output
CNT2
TOG
COM
PC
Current
Sensing
Photo-coupler
ALM
G1
Remote
ON/OFF
Control
+Vm
+V
-V
-Vm
Photo-
coupler
Photo-
coupler
+S
PV
-S
Output
Sensing
Fan
Alarm
AUX
CNT1
G2
AUX
Photo-
coupler
Current
Sharing
Circuit
OVP
Sensing
Stand by
Supply

- 8 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
4. Sequence time chart
HWS600L /BAT
HWS1000L /BAT
(*1)OVP point
36V : 125 145%
60V : 115 135%
Input Voltage
Output Voltage
Remote ON/OFF
Control
0V
Vout
H(CNT)
0V
L(TOG)
Alarm
H(ALM)
L(G1)
OVP point (*1)

- 9 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
5.Terminal Connection Method
Please pay extra attention to the wiring. Incorrect connection will damage the power supply.
When connecting input, output wiring and CN1, CN2, CN3, input AC-Line should be off.
Input wiring and output wring shall be separated to improve noise sensibility.
The protective earth (PE) must be connected to the terminal or chassis.
Remote sensing lines shall be twisted or used shielded wires.
Remote ON/OFF control lines shall be twisted or used shielded wires. Separate from load line.
Output current of each terminal screw shall be 60A or less for HWS600L/BAT.
Basic connection (Local sensing)
- -
HWS600L HWS1000L
Remote sensing required
- -
wires

HWS600L HWS1000L









B
CN1or CN2
A
B
Twisted or Shielded wire
CN1 or CN2
B
A
Twisted or Shielded wire
CN1 or CN2
CN1 or CN2
HWS600L/BAT HWS1000L/BAT
HWS600L/BAT HWS1000L/BAT

- 10 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
ALM signal output required
Open collector method shown below shall be used.
al.
HWS600L HWS1000L
6. Functions and Precautions
6-1. Input Voltage Range
Input voltage range is single phase 85 ~ 265VAC (47 ~ 63Hz) or 120 ~ 350VDC. Input voltage, which is out of
specification, may cause unit damage. Rated input voltage for safety standard application is 100VAC-240VAC (50/60Hz).
6-2. Output Voltage Range
Output voltage is set to the rated value at shipment. V.ADJ trimmer on the front panel side can be used to adjust the
output voltage within the range specified (refer to specifications for adjustable range).
To turn the trimmer clockwise, the output voltage will be increased. Take note when the output voltage is increased
excessively, over voltage protection (OVP) function may trigger and output voltage will be shut down.
6-3. Over Voltage Protection (OVP)
The OVP function (Inverter shutdown method, manual reset type) is provided. OVP function operates within specified
range (refer to specification) of the rated output voltage value and the output will be shut down when OVP function
triggers (refer to specifications for OVP range of each models). To reset OVP, remove the input of power supply for a
few minutes, and then re-input. Or, use CNT to reset (remote ON/OFF: OFF to ON). OVP value is fixed and not to be
adjusted externally. Never apply more than rated output voltage to output terminal, which may leads to damage. In the
case of inductive load, use decoupling diode at output line.
6-4. Over Current Protection (OCP)
OCP function is provided. OCP characteristic is constant current limiting, automatic recovery. OCP default value is
set at 85 ~ 95% of output current at shipment.
OCP function operates when the output current exceeds OCP setting value (default: 85 ~ 95% of maximum DC
output current specification).
The output will be automatically recovered when the overload condition is removed. OCP.ADJ trimmer on top panel
of HWS600L-*/BAT or right side panel of HWS1000L-*/BAT can be used to adjust the OCP operation current within
the range specified (refer to specifications for adjustable range).
By turning the trimmer clockwise, the OCP operating current will be increased.
Never operate the unit under overload or shorted conditions continuously beyond the 100% output current rating as
this may lead to damage.
Constant Current Setting accuracy is +/- 10%. In case of Output Voltage less than 50% during OCP operating, setting
accuracy might be over +10%. Avoid to operate at Constant Current condition that output voltage is less than 50% of
rated output voltage .
OCP ADJ trimmer is located in primary circuit. OCP ADJ trimmer should be adjusted by skilled person once this
product to be installed into the equipment. See 6-17.
CN3
ALM
Signal
Output
Signal
Ground
CN3
ALM
Signal
Output
Signal
Ground
HWS600L/BAT HWS1000L/BAT

- 11 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
6-5. Over Temperature Protection (OTP)
The OTP function (manual reset type) is provided. When ambient or internal temperature rises abnormally, OTP
function operates and output will be shut down. After shut down, remove the input and cool it down to reset OTP. then re-
input.
6-6. Power Failure Detection Circuit (ALM)
Power failure detection circuit is provided. ALM (Alarm
when converter stops and Fan Stop. Please take note in parallel or N+1 operation at light load condition, maybe only one
of the power supply operates and other power supply stops. When the built-in FAN motor of this power supply unit stops,
ALM igh too. If the output voltage is decreased to less than 20% of rated voltage, or decreased
rapidly through an external adjustment mechanism when load is light, the The ALM signal
is isolated from input and output by a photo-mosfet. It uses the open collector method shown as below.
ALM Signal circuit
6-7. Remote Sensing (+S, -S terminal)
This function compensates voltage drop of
- - -
side line) shall be less than 0.3V. In case that sensing lines are too long, it is necessary to put an electrolytic capacitor in
following places.
1) Across the load terminal,
2)
3) B terminal.
When the function of remote sensing is not in used, connect +S terminal to +Vm terminal, and S terminal to Vm
terminal by the attachment connector.
If remote sensing terminals are opened, the stability and the accuracy of the output deteriorated. Therefore, terminal +S,
-S must be connected.
6-8. Remote ON/OFF Control
Remote ON/OFF control is provided.
Using this function, output on/off is allowed to control without input voltage on/off. 
1. The maximum input voltage to CNT2 terminal is 12V, and the maximum allowable reverse voltage is -
1V; Current flow into CNT2 is 5mA typical and 12mA maximum.
2. A switch and relay or a transistor can be used as ON/OFF switch.
3. Remote ON/OFF control circuit is isolated from the input and output by a photo-coupler and can be
controlled regardless of the output potential (+ or -). Connect TOG terminal to ground of control signal.
ALM
(Drain)
G1
(Source)
Vmax=50V
Imax=10mA

- 12 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
Specifications of remote ON/OFF
CNT2-TOG current or voltage condition:
Connection method (a) (b) (c)
SW Logic
Output on SW open
(0.1mA max)
SW open
(0.1mA max)
SW close
(0.5V max)
Output off SW close
(3mA min)
SW close
(3mA min)
SW open
(0.1mA max)
pin CNT2, TOG CNT1, CNT2, TOG, G2 CNT1, CNT2, TOG, G2
( a ) ( b ) ( c )
6-9. Output Ripple & Noise
Measurement circuit as below measures the standard specification for maximum ripple value. When load lines are longer,
ripple becomes larger. In this case, electrolytic capacitor, film capacitor, etc. might be necessary to use across the load
terminal. The output ripple cannot be measured accurately if the probe ground lead of oscilloscope is too long.
6-10. Battery Charger Applications
By using the OCP function, HWS600L-*/BAT and HWS1000L-*/BAT can be used in battery charger applications.
When connecting with these devices, put Oring-diode on the output line as shown in fig. below.
In case of any failure on the power supply side, please take safety measures to prevent large reverse current flow from
the battery to the power supply unit.
Heat will be generated by power losses due to diode forward voltage Vf and output current Io
(Pd = Vf × Io). Therefore, the diodes must be cooled.
In addition, please use power supply within the rated output voltage and output power specification.
Constant Current Setting accuracy is +/- 10%.
In case of Output Voltage less than 50% during OCP operating, Setting accuracy might be over +10%.
Avoid to operate at Constant Current condition that output voltage is less than 50% voltage .
Please contact your nearest sales office for application using high capacitive devices at OCP area less than half of
rated output voltage.
Output Power (W)=(Vo+Vf) Io
Power
Supply +Vm
+S
Vf Io
- Vm
- S
Vo+Vf
Vo
Battery, Capacitor and etc.
Power
Supply
+
-
Coaxial Cable
Load
0.1
Oscilloscope
20MHz
150mm
47
1.5m
(For example V1:5V , R1:620 )

- 13 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
6-11. Series Operation
For series operation, either method (A) or (B) is possible.
In series operation, the actual voltage between output and must be less than withstand voltage
(500VAC).
In addition, take note that using the product with total output voltage 60V or more does not comply with SELV
in safety standard. In series operation, the rising waveform may have steps.
When connecting with a battery, connect an ORing-diode to the output side of the product.
Method (A) Method (B)
6-12. Parallel Operation
Current balancing function is provided. Both operations mode (A) and (B) are possible.
(A) To Increase the Output Current
Connect PC-to-PC terminal and COM-to-COM terminal, the current balancing function activates and output current of
each power supply is equivalently supplied to load. Wires to PC terminals, COM terminals shall be as short as possible
and same length and twisted.
1. Adjust the output voltage of each power supply to be same value within 1% or 100mV whichever is smaller.
2. Use same length and type of wires for all load lines.
3. Please make sure that the sum of output current values does not exceed a value obtained from the right side of
following equation.
Maximum of total output current in parallel operation Rated current per unit Number of units 0.9
4. Parallel operation is possible up to 5 units.
(B) To Use as a Backup Power Supply
1. Adjust the output voltage (Vo) of each power supply to be same value within 1% or 100mV whichever is smaller.
2. Set power supply output voltage higher to compensate the forward voltage drop of diode.
3. Use within the specifications for output voltage and output current.
4. When one of power supplies fails, the remaining non-failure power supplies continue to maintain the output. If one
of the power supplies stop operating, the output voltage may change about 5%( 36V, 60V) in its transient response.
( A ) ( B )
Power
Supply
Load
PC
COM
PC
COM
+ Vm
-Vm
-S
+S
+ Vm
-Vm
-S
+S
(W) =(Vo+Vf)
Io
Output Power
Vo
Io
Power
Supply
Load
PC COM
PC COM
+ Vm
-Vm
-S
+S
+ Vm
-Vm
-S
+S
V
V
Load
+
Vm
-
Vm
Power
Supply
-
S
+
S
+
Vm
-
Vm
Power
Supply
-
S
+S
+
Vm
-
Vm
Power
Supply
-
S
+S
+
Vm
-
Vm
Power
Supply
-
S
+S
Load
Load

- 14 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
6-13. Isolation Test
Isolation resistance between output and (chassis) shall be more than 50M at 500VDC and between output and AUX,
CNT, ALM shall be more than 50M at 100VDC. For safety operation, voltage setting of DC isolation tester must be
done before the test. Ensure that it is fully discharged after the test.
Output ~ FG (chassis) : 500VDC 50 or more Output ~ CNT ꞏ AUX ꞏ ALM : 100VDC 50
6-14. Withstand Voltage
HWS600L/BAT is designed to withstand 3.0kVAC, HWS1000L/BAT is designed to withstand 4.0kVAC between input
and output, This series is designed to withstand 2.0kVAC between input and (chassis), 500VAC between output and
(chassis), and 100VAC between output and CNT, AUX, ALM terminal each for 1 minute. When testing withstand
voltage, set current limit of withstand voltage test equipment at 20mA.
(Output- (chassis) and Output-Control: 100mA).
The applied voltage must be gradually increased from zero to testing value and then gradually decreased for shut down.
When timer is used, the power supply may be damaged by high impulse voltage at timer switch on and off. Connect input
and output as follows.
Input ~ Output (dotted line): 3.0kVAC 1min. (20mA), (HWS1000L/BAT: 4.0kVAC 1min 20mA)
Input ~ (chassis) (solid line): 2.0kVAC 1min. (20mA)
 
Output ~ (chassis): 500VAC 1min. (100mA), Output ~ CNTꞏ AUX ꞏ ALM: 100VAC 1min. (100mA)
HWS600L-60/BAT and
HWS1000L-60/BAT: 651VAC 1min 130mA)
AC(L)
AC(N)
+S
Isolation
Tester
+
Vm
+
-
-
Vm
-
S
PC
COM
PV
CNT
1
CNT2
TOG
ALM
AUX
G2
G1
AC(L)
AC(N)
+S
Isolation
Tester
+
Vm
+
-
-
Vm
-
S
PC
COM
PV
CNT
1
CNT2
TOG
ALM
AUX
G2
G1
AC(L)
AC(N)
Withstand
Voltage
Tester
+S
+
Vm
+
-
-
Vm
-
S
PC
COM
PV
CNT
1
C
NT2
TOG
ALM
AUX
G2
G1
AC(L)
AC(N)
Withstand
Voltage
Tester
+S
+
Vm
+
-
-
Vm
-
S
PC
COM
PV
CNT
1
CNT2
TOG
ALM
AUX
G2
G1

- 15 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
6-15. Output Voltage External Control (PV)
Output voltage external control function is available. Output voltage can be varied by applying an external voltage
(1 6V) acteristics
Note 1. Regarding output voltage adjustment below 20%, please consult our sales.
Note 2. For 60V output model, limit output voltage variation range at 20% ~ 110%. At PV voltage variation 1V ~ 5.5V
Note 3. When the output voltage setting is over the nominal output Voltage, Current limit setting should be set within
the Max .Current Limit Setting.
6-16. Auxiliary Supply
Auxiliary supply is provided to ease customer application. Supply power is 12Vtyp (11 to 13V). 0.1A max.
And Ground terminal of AUX. is G2 terminal.
Aux voltage is functionally isolated from all other signal terminals and output terminals, and it is always available as
long as input power in the specified voltage range is present.
6-17. Method of OCP Adjustment
The method of adjusting the OCP below the rated value by using OCP ADJ. Trimmer is described below.
(Note) Please do not adjust the OCP operating point more than the rated Maximum current value.
OCP ADJ trimmer is located in primary circuit. OCP ADJ trimmer should be adjusted by skilled person once
this product to be installed into the equipment.
Ordinary user must not do the OCP adjustment.
1) Turn on the power supply without connecting the electric loads to output terminals and check that output voltage
value is normal (within specification) by using DC Voltmeter.
2) Turn off the power supply, and make sure that output voltage drops down to 0V. Then connect the DC Volt meter,
DC Ammeter and Electric load to Output terminals of power supply unit as shown in figure below.
3) Check that the connection is correct. Then turn on the power supply and check that output voltage is normal (within
specification) by DC voltmeter and DC ammeter.
4) Set electronic load current to desired OCP operating point (between 55% and 95% of maximum rated current).
5) Turn OCP ADJ. trimmer counter clockwise slowly until the output voltage of power supply starts to drop.
6) Verify that the output current is limited at OCP setting by checking that output voltage drops when output current is
increased
Connection Output Voltage Linearity
5.5V
6V
5V
Nominal
0
20%
1V
110%
120%
PV voltage (Nominal Input Voltage)
Output Voltage Derating
86
%
95%
79%
Nominal
0
20%
110
%
120%
Load Current
Max.
Current
Limit
Setting
D
ecrease OCP point
OCP,
ADJ

- 16 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
7. Mounting Directions
7-1. Mounting Directions.
Recommended standard mounting method is (A). Method (B), (C) is also possible.
Refer to the derating below.
HWS600L/BAT
(A) Mounting A (B) Mounting B (C) Mounting C
(D) Not Possible (E) Not Possible (F) Not Possible
HWS1000L/BAT
(A) Mounting A (B) Mounting B (C) Mounting C
(D) Not Possible (E) Not Possible (F) Not Possible

- 17 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
7-2. Output Derating
7-3. Mounting Method
(1) Forced air-cooling type power supply.
This power supply has ventilating holes on the front and back side panels. Keep these two areas freely as much as
possible.
(2) The maximum allowable penetration for screw is 6mm.
Incomplete thread of mounting screw should not be penetrated.
(3) Recommended torque for mounting screw:
M4 screw: 1.27 N ꞏ m (13.0kgf ꞏ cm)
Please take caution not to place any conductive foreign objects at the air intake of the cooling fan to prevent
penetration into the power supply.
(4) Power Supply unit installation should be done by skilled person, not by ordinary user.
8. Wiring Method
(1) The output load line and input line shall be separated to improve noise sensitivity.
(2) The sensing lines shall be twisted and separated from the output lines for remote sensing.
(3) Use all lines as thick and short as possible to make lower impedance, clamping core at both input and output wires
benefit EMI performance.
(4) Attaching a capacitor to the load terminals can eliminate noise.
(5) For safety and EMI considerations, connect terminal to the mounting set ground terminal, power supply and load
mounting on aluminum plate is recommended for EMI setting.
(6) Recommended torque for the terminal:
HWS600L/BAT Input terminal (M4 screw) : 1.27 N m (13.0kgf cm)
Output terminal (M5 screw) : 2.5 N m (25.5kgf cm)
HWS1000L/BAT Input terminal (M4 screw) : 1.27 N m (13.0kgf cm)
Output terminal (M8 bolt & nut) : 10.8 N m (110kgf cm)
(M4 screw) : 1.27 N m (13.0kgf cm)
Ta( )
Load (%)
Mounting A, B, C
-20 ~ +50 100
+74 50
70
40 20 0 -10
Ambient Temperature ( )
40
80
60
0
20
100

- 18 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
[ The PHD connector manufacture method ]
This product is using SPHD-001T-P0.5 or SPHD-002T-0.5 connector made from JAPAN SOLDERLESS TERMINAL
MFG CO LTD.
Regarding to manufacture of a connector, it becomes the regulation as following.
a). Appricable Wire and Crimping tool
Wire size is AWG#26 ~ AWG#22 and insulation outer dia is 1.0 ~ 1.5 mm.
Appreciable wire per barrel size is UL1007 (standard wire ) and its equivalent standard wire can be used.
Regarding the AWG#22, use UL1061 or its equivalent standard wire,because wire insulation outer diameter
of UL1061 is small
Crimping tool is as below.
Crimping tool Crimping applicator Dies
AP-K2 or AP-KS MKS-LS-10 or MKS-L-10 SPHD-001-05/SPHD-002-05
b). Crimping Operation
The reference value of wire strip is 2.3mm. As wire strip length differs depending on type of wire
and crimping method ,decide the best wire strip length considering processing condition.
When wire is stripped, do not damage or cut off wire conductores.
Table of crimp height
SPHD-001T-P0.5
Wire Insulation O.D (mm) Crimp height (mm)
Type Size Conductor part Insulation part
UL1007 AWG #26 1.3 0.60 ~ 0.70 1.7
UL1007
AWG #24
1.5
0.65 ~ 0.75
1.8
UL1061
AWG #22
1.4
0.70 ~ 0.80
1.8
SPHD-002T-P0.5
Wire
Insulation O.D (mm)
Crimp height (mm)
Type
Size
Conductor part
Insulation part
UL1007
AWG #28
1.2
0.55 ~ 0.60
1.
6
UL1007
AWG #26
1.3
0.60 ~ 0.65
1.7
UL1007
AWG #24
1.5
0.62 ~ 0.67
1.8
Note 1. Crimp height at wire barrel should be set to pre-determined dimensions.
Note 2. Adjust crimp height at wire insulation barrel to the extent that wire insulation is slightly pressed,
and set it so that crimping is not excessivery.
Note 3. Crimping condition at wire insulation barrel is as below Fig.1.
Note 4. For AWG#28,#26,#24, use UL1007 type. For AWG#22, use UL1061 type.
Fig.1 Fig.2: Examples of defective crimping
Check of crimping appearance visually for correct crimping as referring to above Fig.2
Check the tensile strength at crimped part when operation finishes.

- 19 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
Table of tensile strength at crimped part.
SPHD-001T-P0.5
Wire size Requirement N min. Actual value N
UL1007 AWG#26 20 39.2 ~ 45.1
UL1007 AWG#24 30 68.6 ~ 74.5
UL1007 AWG#22 40 92.1 ~ 96.0
SPHD-002T-P0.5
Wire size Requirement N min. Actual value N
UL1007 AWG#28 15 27.0 ~ 34.3
UL1007 AWG#26 20 44.1 ~ 48.0
UL1007 AWG#24 30 66.6 ~ 71.5
c). Inserting contact into housing
Inserting crimped contact into housing
(1) Do not apply any pulling force to crimped part, and insert contact parallel to housing.
(2) Insert contact into housing without stopping to innermost.
(3) Check secure locking per each insertion by pulling wire softly in order to check that contact does not come off
housing. Besides, check whether there is the backlash in the direction of insertion axis.
Defect example of slation insertion
d). Mating and Unmating Connector
(1) Inserting connector
Hold receptacle housing securely and insert into header straight against to header post until click sounds.
(2) Unmating connector
Hold all wires securely and fix receptacle housing by fingers so as to pry, and then, withdraw it on the mating axis.
e). Routing of Wire
Routing wire so as not to apply external force to connector except force to such an extent that wire slightly buckles,
considering an enough length to route and fixing of wire.
9. External Fuse Rating
Refer to the following fuse rating when selecting the external fuses that are to be used on input line. Surge current flows
when line turns on. Please do not use fast-blow fuse but use slow-blow or time-lag type fuse. Fuse rating is specified by
in-rush current value at line turn-on. Do not select the fuse according to input current (RMS.) values under the actual load
condition.
HWS600L/BAT: 15A
HWS1000L/BAT: 20A

- 20 -
TDK-Lambda
HWS-L/BAT Series
INSTRUCTION MANUAL
10. The life expectancy
The life of the power supply depends on the life of the built-in aluminum electrolytic capacitor being used
and mounted fan. Each life is described in reliability data.
The life of the aluminum electrolytic capacitor varies depending on the method of mounting the power supply,
the load current, and the ambient temperature. Please refer to
Please do not use the product which passed over the life expectancy. There is a risk of unexpected output
shutdown and specifications may not be satisfied.
Please contact us for maintenance or exchange the product which passed over the life expectancy.
11. Fan life expectancy
The Fan-life has limitation. Therefore, periodic maintenance by exchanging the life-expired fan is required for the power
supply. The following figure shows the life of fan.
Fan acoustic noise:
HWS600L/BAT, HWS1000L/BAT: build in fan speed control circuit.
HWS600L/BAT: 45dB[A] at room temperature, 50dB[A] at high ambient temperature.
HWS1000L/BAT: 53dB[A] at room temperature, 55dB[A] at high ambient temperature.
12
Before concluding that the unit is at fault, make the following checks.
(1) Check if the rated input voltage is connected.
(2) Check if the wiring of input and output is correct.
(3) Checks if the I/O terminal connection is properly tighten by regulated torque.
(4) Check if the wire thickness is enough.
(5) Check if the output voltage control (V.adj) is properly adjusted. OVP might be trigged and output is shut down.
(6) If use function of the Remote ON/OFF control, check if the Remote ON/OFF control is properly used.
(7) Check if the built-in FAN is not stopped. Is FAN stopped by something irregulars or etc?
might be activated.
(8) Power supply has ventilating holes on the front and back panels. Check if there is any irregulars or dust, etc.
(9) Is the chassis of power supply hot abnormally? The output is shut down by OTP operation.
Please re-input after the unit to cool down sufficiently.
(10) Check if the output current and output wattage does not over specification.
(11) Audible noise can be heard when input voltage waveform is not sinusoidal.
(12) Audible noise can be heard during dynamic load operation.
13 Warranty Period
This product is warranted for a period of 5 yeas from the date of shipment.
For damages occurring at normal operation within this warranty period, repair is free of charge.
1
10
0 50 100
Ambient temperature (
)
